Thermo Scientific
HIGHPlate™
Instruction Manual
50119962-e • 05 / 2020
Visit us online to register your warranty:
thermofisher.com/labwarranty

WEEE Conformity
This product is subject to the regulations of the EU Waste Electrical & Electronic
Equipment (WEEE) Directive 2012/19/EU. It is marked by the following symbol:

Centre of Emergency Preparedness and Response
Health Protection Agency
Parton Down
Salisbury
Wiltshire SP4 OJG
United Kingdom
Certificate of Containment Testing
Containment Testing of Thermo
Scientific rotor 75003606
Report No. 59-08 H
Report prepared for: Thermo Fisher
Issue Date: 15
th
January 2009
Test Summary
A Thermo Scientific 75003606 contained rotor (Max speed 6,300
rpm) was supplied by Thermo Fisher and containment tested at 6,300
rpm using the method described in Annex AA of EN 61010-2-020.
The rotor was shown to contain a spill when tested in triplicate.
Report Written By

Thermo Scientific HIGHPlate™i
T
Preface .......................................................................................................................................iii
Scope of Supply ........................................................................................................................iii
Precautions ...............................................................................................................................iii
Chapter1RotorSpecifications ..............................................................................................................1-1
Technical Data ........................................................................................................1-2
230 V,50 / 60 Hz ventilated ................................................................................1-2
230 V,50 / 60 Hz refrigerated ..............................................................................1-2
120 V,60 Hz ventilated .......................................................................................1-3
120 V,60 Hz refrigerated .....................................................................................1-3
230 V,50 / 60 Hz ventilated ................................................................................1-4
230 V,50 / 60 Hz refrigerated ..............................................................................1-4
120 V,60 Hz ventilated .......................................................................................1-5
120 V,60 Hz refrigerated .....................................................................................1-5
100 V, 50 / 60 Hz ventilated ................................................................................1-6
100 V,50 / 60 Hz refrigerated ..............................................................................1-6
230 V,50 / 60 Hz ventilated ................................................................................1-7
230 V,50 / 60 Hz refrigerated ..............................................................................1-7
Chapter2 Accessories .............................................................................................................................2-1
Rotor Loading ..........................................................................................................2-2
Chapter3 AutoLock™.............................................................................................................................3-1
Rotor Installation .....................................................................................................3-2
Removing the Rotor .................................................................................................3-3
Chapter4RotorLoading ..........................................................................................................................4-1
Before a Run ............................................................................................................4-2
Proper Loading .........................................................................................................4-2
Improper Loading ....................................................................................................4-2
Maximum Loading ...................................................................................................4-3
Cycle Counter ..........................................................................................................4-3
Chapter5Aerosol-tight Applications ...................................................................................................5-1
Basic Principles .........................................................................................................5-2
Placing O-ring ..........................................................................................................5-2
Fill Level ...................................................................................................................5-2
Checking the Aerosol-Tightness ...............................................................................5-2
Table of Contents

Contents
Chapter6 Maintenance and Care ......................................................................................................... 6-1
Cleaning intervals .................................................................................................... 6-2
Cleaning .................................................................................................................. 6-2
Disinfection ............................................................................................................. 6-3
Decontamination ..................................................................................................... 6-4
Autoclaving .............................................................................................................. 6-5
Service of Thermo Fisher Scientific .......................................................................... 6-5
RCF-values ................................................................................................................A-1
Chemical Compatibility Chart ..............................................................................B-1
iiHIGHPlate™Thermo Scientific

Thermo Scientific HIGHPlate™iii
P
Preface
Before starting to use the rotor, read through this Operating Instructions carefully and follow the
instructions.
The information contained in theOperating Instructions is the property of Thermo Fisher Scientific;
it is forbidden to copy or pass on this information without explicit approval.
Failure to follow the instructions and safety information in this instruction manual will result in the
expiration of the seller’swarranty.
Scope of Supply
If any parts are missing, please contact the nearest Thermo Fisher Scientific representative.
Precautions
In order to ensure safe operation of the HIGHPlate™, the following general safety regulations must be
followed:
•Do not remove the magnet at the rotor bottom.
•Do not use rotors which show any signs of corrosion and / or cracks.
•Use only with rotors which have been loaded properly.
•Never overload the rotor.
Article NumberQuantity Check
75003606 HIGHPlate™1
76003500 Rubber seal grease 1
75003786 Bolt grease 1
50119962 Instruction Manual 1

Preface
iv HIGHPlate™Thermo Scientific
•Use only accessories which have been approved by Thermo Fisher Scientific. Exceptions to this
rule are commercially available glass or plastic centrifuge tubes, provided they have been approved
for the speed or the RCF value of the rotor.
•Please observe the safety instructions.
Please pay particular attention to the following aspects:
•Rotor installation: Check that the rotor is locked properly into place before operating the
centrifuge.
•Always balance the samples.
Maximum sample density at maximum speed: 1.2 g
cm3
-----------
This symbol refers to general hazards.
CAUTION means that material damage could occur.
WARNING means that injuries or material damage or contamination could occur.
This symbol refers to biological hazards.
Observe the information contained in the instruction manual to keep yourself and your
environment safe.

Thermo Scientific HIGHPlate™1-1
1
RotorSpecifications
Contents
•“Technical Data” on page 1-2

1-2 HIGHPlate™Thermo Scientific
1RotorSpecifications
Technical Data
Technical Data
Table 1-1. 230 V,50 / 60 Hz ventilated
Centrifuge Multifuge X3Multifuge X3F
Catalog # 75004500 75004530
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 60 / 65 60 / 65
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
120 minutes
11
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
Table1-2. 230 V,50 / 60 Hz refrigerated
Centrifuge Multifuge X3RMultifuge X3FR
Catalog # 75004515 75004536
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 60 / 65 60 / 65
Aerosol-tight *yes yes
Permissible temperature range
autoclavable (cycle number) °C
121 121
*Tested by HPA, Porton-down, UK

1 RotorSpecifications
Technical Data
Thermo Scientific HIGHPlate™1-3
Table 1-3. 120 V,60 Hz ventilated
Centrifuge Multifuge X3Multifuge X3F
Catalog # 75004501 75004531
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 90 / 65 90 / 65
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
120 minutes
55
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK
Table1-4.120 V,60 Hz refrigerated
Centrifuge Multifuge X3RMultifuge X3FR
Catalog # 75004516 75004537
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 90 / 65 90 / 65
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK

1RotorSpecifications
Technical Data
1-4 HIGHPlate™Thermo Scientific
Table1-5. 230 V,50 / 60 Hz ventilated
Centrifuge Sorvall Legend XT Sorvall Legend XF
Catalog # 75004505 75004532
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 60 / 65 60 / 65
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
120 minutes
11
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK
Table1-6. 230 V,50 / 60 Hz refrigerated
Centrifuge Sorvall Legend XTR Sorvall Legend XFR
Catalog # 75004520 75004538
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 60 / 65 60 / 65
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK

1 RotorSpecifications
Technical Data
Thermo Scientific HIGHPlate™1-5
Table 1-7. 120 V,60 Hz ventilated
Centrifuge Sorvall Legend XT Sorvall Legend XF
Catalog # 75004506 75004533
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 90 / 65 90 / 65
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
120 minutes
55
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK
Table1-8.120 V,60 Hz refrigerated
Centrifuge Sorvall Legend XTR Sorvall Legend XFR
Catalog # 75004521 75004539
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 90 / 65 90 / 65
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK

1RotorSpecifications
Technical Data
1-6 HIGHPlate™Thermo Scientific
Table 1-9. 100 V,50 / 60 Hz ventilated
Centrifuge Sorvall Legend XT Sorvall Legend XF
Catalog # 75004507 75004534
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 90 / 65 90 / 65
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
120 minutes
55
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK
Table 1-10. 100 V,50 / 60 Hz refrigerated
Centrifuge Sorvall Legend XTR Sorvall Legend XFR
Catalog # 75004522 75004540
Weight empty [kg] 8 8
Max. cycle number 50000 50000
Maximum permissible load [g] 2 x 500 2 x 500
Maximum speed nmax [rpm] 6300 6300
Maximum RCF value at nmax 6168 6168
Max. / min. radius [cm] 13.9 / 5.8 13.9 / 5.8
Accel. / braking time [s] 90 / 65 90 / 65
Aerosol-tight*yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121
*Tested by HPA, Porton-down, UK

1RotorSpecifications
Technical Data
Thermo Scientific HIGHPlate™1-7
Table 1-11. 230 V,50 / 60 Hz ventilated
Centrifuge SL 40F
Catalog # 75004542
Weight empty [kg] 8
Max. cycle number 50000
Maximum permissible load [g] 2 x 500
Maximum speed nmax [rpm] 6300
Maximum RCF value at nmax 6168
Max. / min. radius [cm] 13.9 / 5.8
Accel. / braking time [s] 60 / 65
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running time
120 minutes
1
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes
Permissible temperature range autoclavable
(cycle number) °C
121
Table 1-12. 230 V,50 / 60 Hz refrigerated
Centrifuge SL 40FR
Catalog # 75004543
Weight empty [kg] 8
Max. cycle number 50000
Maximum permissible load [g] 2 x 500
Maximum speed nmax [rpm] 6300
Maximum RCF value at nmax 6168
Max. / min. radius [cm] 13.9 / 5.8
Accel. / braking time [s] 60 / 65
Aerosol-tight *yes
Permissible temperature range
autoclavable (cycle number) °C
121
*Tested by HPA, Porton-down, UK

Thermo Scientific HIGHPlate™2-1
2
Accessories
Content
•“Rotor Loading” on page 2-2

2Accessories
Rotor Loading
2-2 HIGHPlate™Thermo Scientific
RotorLoading
Handling Micro Plate Carriers
1. Always remove the microplates from the microplate carriers for loading.
2. Make sureyou use a rubber bottom placed in the cut outs of the micro plate carrier.
Deepwell plates may be used without the rubber bottom.
3. Make sure the load is balanced.
4. Place the loaded micro plate carriers in therotor.
CAUTION The HIGHPlate™ must always be used with the lid.

Thermo Scientific HIGHPlate™3-1
3
AutoLock™
Contents
•“Rotor Installation” on page 3-2
•“Removing the Rotor” on page 3-3

3AutoLock™
Rotor Installation
3-2 HIGHPlate™Thermo Scientific
RotorInstallation
This rotor is equipped with an AutoLock™-system.
This system is used to automatically lock the rotor to the centrifuge spindle. The rotor does not have
to be bolted onto the centrifuge spindle.
Proceed as follows:
1. Open the lid of the centrifuge and if necessary,remove any dust, foreign objects orresidue from
the chamber.
AutoLock™and O-ring must be clean and undamaged.
Figure 3-1. AutoLock™
2. Hold the rotor over the centrifuge spindle and let it slide slowly down the centrifuge spindle.
The rotor clicks automatically into place.
3. Check if the rotor is properly installed by lifting slightly on the handle. If the rotor can be pulled
up, then it must be reclamped to the centrifuge spindle.
CAUTION Unapproved or incorrectly combined accessories can cause serious damage to
the centrifuge.
CAUTION Do not force the rotor onto the centrifuge spindle.
If the rotor is very light, then it may be necessary to press it onto the centrifuge spindle
with a small amount of pressure.
WARNING If the rotor cannot be properly locked in place after several attempts, then the
AutoLock™is defective and you are not permitted to operate the rotor.
Check for any damage tothe rotor, damaged rotors must not be used.
Keep the hub area clear of objects.
AutoLock™
O-ring
