Spectrum Industries Flex Active 37239 User manual

Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 5 days of receipt. To report information regarding
missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
(Shown with casters, Cove
module and modesty panel)
60”W x 30”D
48”W x 30”D
72”W x 30”D
60”W x 24”D
48”W x 24”D
72”W x 24”D
(Shown with glides)
Owner’s Manual
0190534 Page 1 of 9
Flex Active Table™
37239

Worksurfaces
Modesty Panels (Optional)
Legs
Panel only:
0190447 - 48”W
0190448 - 60”W
0190449 - 72”W
with insert panel:
0190450 - 48”W
0190451 - 60”W
0190452 - 72”W
(1) Modesty panel
(11) 026073
#8 x 3/4” PHSM
(1) 0133632
Right Corner
0190534 Page 2 of 9
• Read this owner’s manual before assembly or operation.
• Do not allow children to move the table.
• For indoor use only. Do not install or store the table where it will be
exposed to moisture.
• Do not block the ventilation openings.
• Do not allow anyone to sit, stand, or climb on the table.
• Use a damp, soft-cloth, or sponge, with mild soap or detergent solution
to clean dirty surfaces. Do not use harsh solvents or abrasives.
• This table is intended for institutional use. It does not have any user-
serviceable parts or user-maintenance requirements. If servicing is
necessary, please contact Spectrum Industries for assistance.
General Electrical Safety:
• Keep power switches in the OFF position before plugging or
unplugging from the wall outlet.
• Be sure total device / equipment load does not exceed 12-amps.
• Do not plug power cords into an extension cord.
• Inspect power cords for damage before each use. Do not use cords
that are damaged.
• Unplug power cord from electrical outlet by gripping the cord-do not
unplug by pulling only on the cord.
• Do not step on, drive over, drag, or place objects on power cords.
• For added safety, plug into a grounded outlet controlled by a GFI
(Ground Fault Interrupter) circuit breaker.
• Damaged electrical components can create signi cant hazards to
users and is not covered by the warranty. Repairs should always be
performed by a quali ed electrician.
• Electrical devices are not toys. Children are often unaware of the
hazards associated with electrical devices. This table must always
be used by adults or with adult supervision.
Warning - Relocating audio and/or video equipment to furniture not speci cally
designed to support audio and/or video equipment may result in death or
serious injury due to the furnishing collapsing or over turning onto a child.
Warning - Death or serious injury may occur when children climb
on audio and/or video equipment furniture. A remote control or toys
placed on the furnishing may encourage a child to climb on the
furnishing and as a result the furnishing may tip over on to the child.
Important Safety and Care Instructions
Components
Parts bag - Glides
(1) Worksurface
(2) T-Leg assembly
(4) 037779
5/16-18 Glide
(28) 0190419
#14 x 1” PHSM
Parts bag - Casters
(2) 051070
Half clip
(2) 026073
#8 x 3/4” PHSM
(4) 0105662
5/16-18
60mm Caster
(28) 0190419
#14 x 1” PHSM
(2) 051070
Half clip
(2) 026073
#8 x 3/4” PHSM
Plain:
0190433 - 48”W X 24”D
0190434 - 48”W X 30”D
0190435 - 60”W X 24”D
0190436 - 60”W X 30”D
0190437 - 72”W X 24”D
0190438 - 72”W X 30”D
with Cove cutout:
0190439 - 48”W X 24”D
0190440 - 48”W X 30”D
0190441 - 60”W X 24”D
0190442 - 60”W X 30”D
0190443 - 72”W X 24”D
0190444 - 72”W X 30”D
Glide-length:
0190446
Caster-length:
0190445
Note: Depending on conguration ordered, not all components below may be included.
(3) 0134099
Mounting bracket
(1) 0133629
Left Corner

0190534 Page 3 of 9
Assembly / Setup
1. Attach worksurface brace
1. Place the worksurface face down (laminate side-down) onto a at,
non-abrasive surface like another table. Figure 1.
2. Attach the worksurface brace with #14 x 1” PHSM screws.
Phillips
screwdriver
Tools Required
Cordless drill
with Phillips driver
(best)
or
2. Install glides or casters
1. Thread the (4) glides or casters into the legs. Figure 2.
Figure 2
Figure 3.1Figure 3.2
Optional backpack
hanger
Leg
(8) #14 x 1” PHSM
(8) #14 x 1” PHSM
Leg
Worksurface
3. Attach legs to worksurface
1. Attach each leg as shown with (8) #14 x 1” PHSM screws. Figure 3.1.
2. If you have the optional backpack hangers, use (2) screws to attach
each. Figure 3.2.
Figure 1
Caster
Glide
Worksurface brace
#14 x 1” PHSM screws
Worksurface

0190534 Page 4 of 9
4. Install modesty panel - Optional
1. Orient the modesty panel and corners as shown and lock together.
Figure 4.1.
Figure 4.3
Figure 4.1 Figure 4.2
2. Place a mounting bracket inside each panel opening.
Figure 4.2.
Modesty Panel
Left Corner
Right Corner
Mounting
bracket
3. Align the modesty panel, bracket, and worksurface mounting holes.
Figure 4.3.
Figure 4.4
4. Attach to worksurface with (11) #8 x 3/4” PHSM
screws. Figure 4.4.
#8 x 3/4” PHSM
Assembled Modesty Panel
Worksurface
2
1
2
1

0190534 Page 5 of 9
5. Flip table upright
1. Carefully ip the table upright-this will take 2 people. Figure 5.
Figure 5
CAUTION
Do not allow the table legs to contact the oor
until the table is completely rotated. Side-
loading of the legs could cause damage.
Ganging latch installation - 37238 - Optional
1. Place two tables next to each other.
2. Open the latch and attach to table #1 with (2) #8 x 3/4” PHSM screws.
Figure 6.1.
3. Attach keeper #1 to table #1 with (2) #8 x 3/4” PHSM screws.
4. Attach keeper #2 to table #2 with (2) #8 x 3/4” PHSM screws.
5. Tighten screws securely.
6. Close and lock latch to secure tables together. Figure 6.2.
(6) 026073
#8 x 3/4” PHSM
(1) 0190420
Ganging latch
+ Keeper #2
(1) 0190421
Keeper #1
Figure 6.2Figure 6.1
Table #1 Table #2
Keeper #2
Latch
#8 x 3/4” PHSM
(6 required)
Keeper #1

“Easy Power Connection” installation - Optional
0190534 Page 6 of 9
2. Replace locking tabs and secure with thumbscrews. Figure 7.2.1. Remove locking tabs from the Cove module and place
into the worksurface cutout. Figure 7.1.
3. Plug the left and right power cables into the Cove module. Figure 7.3.
Female plug
Thumbscrews
Worksurface
Worksurface cutout
“Easy Power” Cove Module
Cord Clip
Flexible metal conduit
Right power cable
Left power cable
Cove Module
Cove Module
Male plug to
next desk
Female plug
Female plug
4. Install each cord clip with (1) #8 x 3/4” PHSM screw to secure the
exible metal conduit under the worksurface. Figure 7.4.
5. On tables near wall or oor outlets, the starter can be routed through
the leg openings and down to the oor.
Figure 7.2Figure 7.1
Figure 7.4
Figure 7.3
Note: One 99050 starter cable is required per row.
Note: Worksurface cutout is provided when congured.
(1) #8 x 3/4” PHSM

0190534 Page 7 of 9
Cove™Power Module installation - Optional
1. Remove locking tabs from the Cove module.
2. Insert the power cord through worksurface cutout and place the Cove
module into the cutout. Figure 8.1.
2
5.25
Figure 8.1
Note: Worksurface cutout is provided when congured.
Cove module
Power cord routed through
leg to oor or wall outlet.
Figure 8.4
4. Install each cord clip with (1) #8 x 3/4” PHSM screw and predrilled pilot
hole to secure the power cord under the worksurface. Figure 8.3.
3. Replace locking tabs and secure with thumbscrews. Figure 8.2.
Figure 8.2
5. On tables near wall or oor outlets, the power cord can be routed
through the leg openings and down to the oor. Figure 8.4.
Figure 8.3
Worksurface
cutout
Cove Module
Cord Clip
(1) #8 x 3/4” PHSM
Power Cord
Power cord Thumbscrews
Worksurface
Cove Module

0190534 Page 8 of 9
Backpack Hanger - 37237
• Includes two brackets
• Available in all metal colors
• 12 ga steel
• Each hanger bracket installs
with (2) included screws
• Each Active Table supports up
to two brackets
Ganging Latch - 37238
• Low prole and made of exible rubber
• (1) Latch required per seam
• Fasteners included
Modesty Panel
37234 - (for 48"W table)
37235 - (for 60”W table)
37236 - (for 72"W table)
• 16 ga steel
• 9”H panel attaches to worksurface
• Available with or without laminate insert
• Fasteners included
Accessories (Available separately after initial congured purchased)
99047 - 48”W Table
99048 - 60”W Table
99049 - 72”W Table
99050 - Starter Kit (One required per row)
• Each table accommodates one
power connection kit
• Two AC power receptacles
• Two USB charge ports
(not data-compatible)
• Requires 5.25”W x 2”D
worksurface cutout
• Flexible metal conduit is secured
to worksurface underside
• Cove is ETL listed
• Thumbscrew clamps
• Cove available in Black or Silver
• Starter connects to standard
3-prong wall outlet
Cove™Power Module with Easy Power Connection Kit Cove™Power Module - 99044
• Two AC power receptacles
• Two USB charge ports
(not data-compatible)
• Thumbscrew clamps
• Requires worksurface cutout
• 9’ AC power cord
• ETL listed
• Available in Black or Silver
See spectrumfurniture.com for the latest
accessories and detailed warranty information.

0190534 Page 9 of 9
WE WILL MAKE IT RIGHT FOR YOU!
Spectrum is committed to provide complete customer satisfaction. Each of our products is manufactured from the best materials available and each
product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations).
We expressly warrant that Spectrum products will be of good quality and workmanship and free from defect for the period set out in the warranty table below
from the date of delivery. This warranty shall not apply to defects or damage resulting from misuse, abuse, neglect, improper care, modifi cation or repair not
authorized by Spectrum, or any other cause outside the control of Spectrum. Spectrum will, at its sole option, either repair or replace the defective product.
This warranty is exclusive; no other warranty, written or oral, is expressed or implied. This warranty is given by Spectrum to Buyer and to no other per-
son or legal entity. No Spectrum dealer, distributor, agent or employee is authorized to make any modifi cation or addition to this warranty.
NOTWITHSTANDING ANYTHING TO THE CONTRARY, SPECTRUM WILL NOT UNDER ANY CIRCUMSTANCES BE LIABLE FOR INDIRECT OR LIQUI-
DATED DAMAGES, INCLUDING CONSEQUENTIAL, INCIDENTAL AND SPECIAL DAMAGES. IN NO EVENT SHALL SPECTRUM’S LIABILITY, WHETHER
UNDER CONTRACT OR WARRANTY, IN TORT OR OTHERWISE, EXCEED THE PURCHASE PRICE RECEIVED BY SPECTRUM FOR THE PRODUCT AT
ISSUE AND “RECALL ACTION” EXPENSES. SPECTRUM SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES, WHETHER ARIS-
ING OUT OF BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING NEGLIGENCE AND STRICT LIABILITY) OR OTHER THEORIES OF LAW, WITH
RESPECT TO PRODUCTS SOLD OR SERVICES RENDERED BY SPECTRUM, OR ANY UNDERTAKINGS, ACTS OR OMISSIONS RELATING THERETO.
Our Customer Service Department is ready to provide immediate attention to any questions, comments or concerns. They are available to answer your calls
Monday through Friday from 7 am to 5 pm CST. In addition your product comments or concerns are welcome via e-mail at: [email protected].
Item Warranty Period
effective 1/1/2015
Adjustable Crank / Electric Desk Legs • 1 Year
Flat Panel Desk Gas Cylinders
Chairs
• Adjustable Height Chair Parts – including frames, gas
cylinders, wood and plastic parts, control handles, casters
• Adjustable Height Chair Upholstery
• In-Stock Upholstery
• Graded-In Fabrics and Customer Owned Material
• 7 Years
• 2 Years
• 2 Years
• No Warranty
Height Adjustable Columns and Lifts • 1 Year
General Use Casters
Electrical (including timers and LINAK actuators) • 2 Years
Keyboard / Mouse Trays • 1 Year
Flat Panel Monitor Arms
• Flat Panel Monitor Arm – General Parts
• Flat Panel Monitor Arm – Gas Cylinders
• 5 Years
• 2 Years
Desks and Lecterns
• Computer Desk Chassis
• Cart Chassis
• Lectern Chassis
• 10 Years
Warranty Table
Warranty
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2017 Spectrum Industries Inc., All rights reserved.
DESIGNED AND ASSEMBLED IN
CHIPPEWA FALLS
WISCONSIN.USA
