LEDWorkLightKit
Workman®MDorHDSeriesUtilityVehicle
ModelNo.133-0554
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotential
danger.Replaceanydecalthatisdamagedorlost.
107-8008
1.Worklight—rear2.Worklights—front
107-8011
1.Work-lightfuse—15A
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3404-236*A

Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
Wireharness1
2Cabletie8Routethewireharness.
LEDworklight3
Lightchannel2
Work-lightbracket1
Springwasher6
Hex-headbolt(5/16x3/4inch)4
Locknut(5/16inch)4
Light-channel-mountbracket4
Hex-headbolt(1/4x2-3/4inches)4
Flatwasher(1/4inch)4
3
Flangenut(1/4inch)4
InstalltheLEDworklights.
Rockerswitch1
4Work-lightdecal1Installtherockerswitch.
Fuse(15A)1
5Fusedecal1
Connectthewireharnesstothe
ground-blockterminalandinstallthe
fuse.
6Nopartsrequired–Connectthebattery.
7Nopartsrequired–TesttheLEDworklights.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface,settheparking
brake,shutofftheengine,andremovethekey.
2.Disconnectthenegativebatterycable;refertoyour
Operator’sManual.
3.Openthehood.
2
RoutingtheWireHarness
Partsneededforthisprocedure:
1Wireharness
8Cabletie
2

ForMDUtilityVehicles
RoutethewireharnessasshowninFigure1andsecurethewireharnesstothemachinewithcabletiesasnecessary.
Figure1
3

ForHDUtilityVehicles
RoutethewireharnessasshowninFigure2andsecurethewireharnesstothemachinewithcabletiesasnecessary.
Figure2
4

3
InstallingtheLEDWorkLights
Partsneededforthisprocedure:
3LEDworklight
2Lightchannel
1Work-lightbracket
6Springwasher
4Hex-headbolt(5/16x3/4inch)
4Locknut(5/16inch)
4Light-channel-mountbracket
4Hex-headbolt(1/4x2-3/4inches)
4Flatwasher(1/4inch)
4Flangenut(1/4inch)
Procedure
1.Installthework-lightbrackettothe2lightchannels
withthe4hex-headbolts(5/16x3/4inch)and4
locknuts(5/16inch)asshowninFigure3.
Figure3
1.Lightchannel3.Work-lightbracket
2.Locknut(5/16inch)4.Hex-headbolt(5/16x3/4
inch)
2.Securethe2lightchannelstotheROPSwiththe4
light-channel-mountbrackets,4hex-headbolts(1/4x
2-3/4inches),4atwashers(1/4inch),and4ange
nuts(1/4inch)asshowninFigure4.
Figure4
1.Flangenut(1/4inch)3.Flatwasher(1/4inch)
2.Light-channel-mount
bracket
4.Hex-headbolt(1/4x2-3/4
inches)
3.Installthe3LEDworklightstothework-lightbracket
withthe3angenuts(alreadyinstalledontheLED
worklights)andthe6springwashers(Figure5).
Note:Ensurethateachspringwasherispositioned
sothattheconvexsidefacestheangenutasshown
inFigure5.
Figure5
1.LEDworklight3.Flangenut
2.Springwasher4.Notetheorientationofthe
springwashers.
4.Connectthe3wire-harnessconnectorstothe3
openingsinthe3LEDworklights(Figure6).
5

Figure6
1.OpeningintheLEDwork
light
2.Wire-harnessconnector
4
InstallingtheRockerSwitch
Partsneededforthisprocedure:
1Rockerswitch
1Work-lightdecal
Procedure
1.Removetheplasticplugfromtheleftsideofthedash
(Figure7).
Figure7
1.Plasticplug
2.Inserttherockerswitchintotheopeningandapplythe
work-lightdecaltotheleftoftherockerswitch(Figure
8).
Figure8
1.Work-lightdecal2.Rockerswitch
3.Connectthefemaleconnectorattachedtothewire
harnesstotherocker-switchblades(Figure9).
Figure9
1.Rocker-switchblades2.Femaleconnector
6

5
ConnectingtheWireHarness
totheGround-BlockTerminal
andInstallingtheFuse
Partsneededforthisprocedure:
1Fuse(15A)
1Fusedecal
Procedure
1.Insertthefuse(15A)intothefuseblockandapply
thefusedecalbeneaththefuseblock(Figure10or
Figure11).
Figure10
MDModelShown
1.Fusedecal3.Fuseblock
2.Fuse(15A)
Figure11
HDModelShown
1.Fuseblock3.Fuse(15A)
2.Fusedecal
2.Connectthewire-harness-terminalringtothe
ground-blockterminal(Figure12orFigure13).
Figure12
MDModelShown
1.Ground-blockterminal2.Wire-harness-terminalring
Figure13
HDModelShown
1.Wire-harness-terminalring2.Ground-blockterminal
7

6
ConnectingtheBattery
NoPartsRequired
Procedure
Connectthenegativebatterycable;refertoyourOperator’s
Manual.
7
TestingtheLEDWorkLights
NoPartsRequired
Procedure
PushtherockerswitchuptoturnthefrontLEDworklights
totheONposition.
PushtherockerswitchdowntoturntherearLEDwork
lightstotheONposition.
Pushtherockerswitchtothemiddlepositiontoturnthe
LEDworklightstotheOFFposition.
