FormNo.3408-523RevA
SideMirrorKit
Workman®MD/MDX/MDEUtilityVehicle
ModelNo.119-9546
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
UseInstallingtheSideMirrorKit(forMachineswithoutaCanopy)(page2)wheninstallingthekitonmachineswithouta
canopy.UseInstallingtheSideMirrorKit(forMachineswithaCanopy)(page3)formachineswithacanopy.Youmay
discardunusedcomponents.
Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Nopartsrequired–Preparethemachine.
Uppermirrorbracket1
Lowermirrorbracket1
Mirror-mountingbracket1
Bolt(5/16x3/4inch)2
Flangenut(5/16inch)2
Mirror1
Screw(1/4x1inch)4
Nutinsert4
Installthesidemirrorkit(withoutcanopy).
Mirror-mountingbracket1
Bolt(5/16x1-1/2inches)2
Flangenut(5/16inch)2
Installthesidemirrorkit(withcanopy).
PreparingtheMachine
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Shutofftheengineandremovethekeyfromthekeyswitch.
g038447
Figure1
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3408-523*A

InstallingtheSideMirror
Kit(forMachineswithouta
Canopy)
1.Measure29mm(1-1/8inches)outfromtheedgeof
thedashonboththedriver'sandpassenger'sside(if
installingamirroronthepassenger'sside)anddrawa
parallellinetotheedge(Figure2).
1
G014829
1
g014829
Figure2
1.29mm(1-1/8inches)
2.Assemblethemirror-mountingbrackettothelower
anduppermirrorbracketswith2bolts(5/16x3/4
inch)andangenuts(5/16inch)asshowninFigure3.
G014830
3 4 5 21
g014830
Figure3
1.Uppermirrorbracket4.Mirror-mountingbracket
2.Flangenut(5/16inch)5.Bolt(5/16x3/4inch)
3.Lowermirrorbracket
3.Positiontheuppermirrorbracketalongtheparallel
linedrawnonthedash(Figure4).
Note:Ensurethatthelowermirror-mountingbracket
iscontactingthesideofthemachine.
G014831
g014831
Figure4
4.Usingtheuppermirrorbracketasatemplate,locate,
mark,anddrill2holes(1/2inch)inthedash.
5.Installanutinsertintoeachofthedrilledholes(Figure
5).
G014832
3
2
1
g014832
Figure5
1.Uppermirrorbracket3.Nutinsert
2.Screw
6.Securetheuppermirrorbrackettothenutinsertswith
2screws(1/4x1inch)asshowninFigure5.
7.Usingthelowermirrorbracketasatemplate,locate,
mark,anddrill2holes(1/2inch)inthesideofthe
machine(Figure6).
G014833
g014833
Figure6
8.Removethescrewssecuringtheuppermirror-mounting
brackettothedash,andremovethemounts.
Note:Retainthehardware.
2

9.Installanutinsertintoeachofthedrilledholes(Figure
7).
G014834 3
2
2
1
g014834
Figure7
1.Uppermirrorbracket3.Nutinsert
2.Screw
10.Securetheupperandlowermirrormountstothenut
insertswith4screws(1/4x1inch)asshowninFigure
7.
11.Securethemirrortothemirror-mountingbracketwith
thescrewandwasher(Figure8).
G014835
3
21
g014835
Figure8
1.Mirror3.Screw
2.Washer
12.Adjustthemirror(s)tothedesiredposition.
InstallingtheSideMirrorKit
(forMachineswithaCanopy)
1.Locatethewindshield-mountingholesinthefront
canopy-supporttubes(Figure9).
Note:Theleftcanopyfront-supporttubeisshown
inFigure9.
G014837
2
1
g014837
Figure9
1.Windshield-mountinghole2.Mirror-mountingbracket
2.Verticallycenterthemirror-mountingbrackettothe
windshield-mountinghole,andusethebrackettomark
thelocationoftheholes(Figure9).
3.Atthemarkedlocation,drill2holes(5/16inch)
throughbothwallsofthetube(Figure9).
3

4.Securethemirrormountingbrackettothetubewith
2bolts(5/16x1-1/2inches)andangenuts(5/16
inch)asshowninFigure10.
G014838
1
2
3
g014838
Figure10
1.Mirror-mountingbracket3.Flangenut(5/16inch)
2.Bolt(5/16x1-1/2inches)
5.Securethemirrortothemirror-mountingbracketwith
thescrewandwasher(Figure11).
g011855
Figure11
1.Mirror3.Screw
2.Washer
6.Adjustthemirror(s)tothedesiredposition.
