Toro 44908 User manual

FormNo.3375-919RevA
ArmrestKit
GreensPro™1200GreensRoller
ModelNo.44908
InstallationInstructions
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Leftarmrestbracket1
Rightarmrestbracket1
Armrestpad2
Bolt(M10x45mm)2
Locknut2
Spacer4
Assemblethearmrest.
Bolt(M6x25mm)6
Clipnut6Installthearmrest.
AssemblingtheArmrest
1.Alignaspaceroneachsideoftherightarmrestbracket
(Figure1).
2.Alignthespacersandtherightarmrestbracketwiththe
holesinthearmrestpad(Figure1).
3.Alignabolt(M10x45mm)withtheholesinthearmrest
pad,spacers,andthearmrestbracket(Figure1).
4.Threadanutontothebolt(M10x45mm)(Figure1).
5.Tightenthenutontotheboltuntilthenutandbolt
headareushwiththearmrestpad.
Note:Donotovertightenthenutandbolt.
6.Repeatsteps1through5toassembletheleftarmrest.
G019824
1
1
6
4
3
8
9
7
10
1 2
5
9
Figure1
1.Armrestpad6.Clipnut
2.Rightarmrestbracket7.Nut
3.Leftarmrestbracket8.Bolt(M10x45mm)
4.Bolt(M6x25mm)9.Spacer
5.Seatpanange10.Armrestbracket(left
shown)
©2012—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved*3375-919*A

InstallingtheArmrest
1.Inserttheclipnutsovereachholeoftheseatpan
ange(Figure1).
2.Alignthecompletedrightarmrestwiththeholesfound
ontherightsideoftheseatpanange(Figure1).
3.Insertabolt(M6x25mm)intoeachholeofthe
armrestandclipnuts(Figure1).
4.Tightenthebolts.
5.Repeatsteps1through4toinstalltheleftarmrest.
