FormNo.3428-921RevA
PremiumSeatKit
Groundsmaster®3500-D/3505-DandReelmaster®3100-D
ModelNo.30629
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
UseofthisproductmaycauseexposuretochemicalsknowntotheStateofCalifornia
tocausecancer,birthdefects,orotherreproductiveharm.
Installation
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Shutofftheengineandremovethekey.
2
RemovingtheExistingSeat
NoPartsRequired
Procedure
1.Removethe4boltsandwashersthatsecurethe
seat-supportstrapstothefueltank(Figure1).
Note:Retaintheboltsandwashersforinstalling
thenewseat.
2.Disconnecttheelectricalharnessfromtheseat
switchonthebottomoftheseat.
3.Removeanddiscardtheboltsandwashersthat
securetheseatbelttotheexistingseat(Figure
1).
Note:Retaintheseatbeltforinstallingthenew
seat.
4.Removeanddiscardthe4locknutsthatsecure
theseattotheseat-supportstraps(Figure1).
Note:Youmaydiscardtheseatstraps.
g220545
Figure1
1.Seat3.Supportstrap
2.Seatbelt
©2019—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3428-921*A

3
InstallingtheSeat
Partsneededforthisprocedure:
1Seat
2Supportstrap(4-hole)
2Supportstrap(3-hole)
2Screw
4Flangenut
2Flatwasher(1/2inch)
2Flatwasher(9/16inch)
4Spacer
Procedure
1.Mounttheseatbelttotheseatwith2bolts,2
atwashers(1/2inch),and2atwashers(9/16
inch);refertoFigure2.
Note:Mounttheseatbeltretractortotheleft
sideoftheseat.
2.Torquetheboltsto49to61ft-lb(66to83N∙m).
3.Mountthenewseattotheseatsupportstraps
withthe4angelocknutsand4spacers(Figure
2).
Important:ForReelmaster3100-D
machines:Usethestrapswith3-holepattern
inthecenter.
Important:ForGreensmaster3500-D/3505-D
machines:Usethestrapswith4-holepattern
inthecenter.
Note:Usetheinner-frontsetofholesinthe
seatsupportstraps.
4.Torquethenutsto15to19ft-lb(20to26N∙m).
5.Connecttheelectricalharnesstotheseatswitch
onthebottomoftheseat.
6.Mounttheseat-supportstrapstothefueltank
withthepreviouslyremovedboltsandwashers
(Figure2).
7.Torquetheboltsto27to33ft-lb(37to45N∙m).
g220508
Figure2
Greensmaster3500-Dmachineshown
1.Seat3.Supportstrap
2.Seatbeltretractor4.Spacer
