FormNo.3444-587RevA
FinishGrader
SandPro®/IneldPro®3040and5040TractionUnit
ModelNo.08754—SerialNo.400000000andUp
Operator'sManual
Introduction
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.Toro.comformoreinformation,including
safetytips,trainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
g003797
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3444-587*

Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal106-5517
106-5517
1.Warning—donottouchthehotsurface.
2

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Finishgrader1Mountthenishgrader.
Nopartsrequired–Adjustthelinkassembly.
Nopartsrequired–Finishthesetup.
MountingtheFinishGrader
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1.Removeanyattachmentfromtherearofthe
machine.
2.Backthetractionunitintopositioninfrontof
theattachmentadapter.Lowerthetractionunit
adapter.
Note:Ensurethatthelockingleverispivotedto
theleft(unlockedposition)asviewedfromthe
rearofthemachine(Figure3).
g003650
Figure3
1.Lockinglever(unlocked
position)
2.Attachmentadapter
3.Raisethetractionunitadapterintothe
attachmentadapter.
4.Pivotthelockinglevertotheright(locked
position)asviewedfromtherearofthemachine
sothatitisstandingstraightuptolockthe
adapterstogether.
AdjustingtheLink
Assembly
1.Withtheattachmentmountedandsecuredon
thetractionunit,raisetheattachment.
2.Measurethegapbetweenthetopwasher
andthespacerinthelinkassemblyonthe
attachmentadapterasshowninFigure4.
Important:Thegapbetweenthewasherand
theshouldershouldbe0.060to0.080inch
(1.5to2.0mm).
g347343
Figure4
1.Adjustmentnut
2.Jamnut
3.0.060to0.080inch(1.5to2.0mm)clearance
3

FinishingtheSetup
Beforeoperatingthenishgrader,reviewthefollowing
materialsandsavetheminanappropriateplace:
•PartsCatalog
•InstallationInstructions
Operation
OperatingtheFinishGrader
•Raiseorlowerthenishgradertocontrolthe
gradingorscarifyingdepth.
•Whengrading,rotatethescariertotheupper
positionandsecureeachendwithaclevispinand
hairpin(Figure5).
g348148
Figure5
1.Scarier4.Hairpin
2.Clevispin5.Scarifyingposition(lower)
3.Gradingposition(upper)
•Whenscarifying,rotatethescariertothelower
positionandsecureeachendwithaclevispinand
hairpin(Figure5).
•Thescarieraggressivenesscanbechanged
byadjustedthelengthofthesprings(Figure8).
Lengtheningthespringswillmakethescarier
lessaggressive.Shorteningthespringswillmake
thescariermoreaggressive
•Fornalgrading/leveling,anAdjustableOriceKit
(PartNo.112-1433)canbeobtainedtoregulate
theraise/lowerspeeds.
4

InspectingandCleaning
theFinishGrader
Whenthegradingoperationiscompleted,cleanthe
machinethoroughly.Sincethismachineisused
primarilyinextremelyabrasiveconditions,thematerial
shouldbeushedoffaftereachuse.Ifthemachineis
cleanedfrequently,itcanbecleanedwithastreamof
waterfromahosewiththenozzleremoved.
Important:Donotusepressurizedwatertoclean
themachine;ahighpressurestreamcoulddrive
sandorothermaterialintowearareaswhereit
couldactasagrindingcompound.
Note:Iftheattachmentadapterbecomesstuckto
thetractionunitadapter,insertaprybar/screwdriver
intothepryslottodisengagetheparts.
g003783
Figure6
1.Pryslot
5

Maintenance
GreasingtheAttachment
Adapter
Ifthelockingleverontheattachmentadapterdoes
notpivotfreelyandeasily,applyalightcoatofgrease
totheareashowninFigure7.
g003731
Figure7
AdjustingtheActuating
RodSprings
Thespringsandactuatingrodsareadjustedatthe
factory.However,ifnewpartsareinstalledorthe
springsareremovedforanyreason,thespringlength
shouldbeadjustedto5.24inches(133mm)asshown
inFigure8.
g003653
Figure8
LevelingtheFinishGrader
Blade
Tolevelthebladeinrelationtothetractionunit,
placetheunitonalevelsurface(suchasaconcrete
driveway),andslightlyvarythereartirepressureas
required.
ReversingtheScraper
Blade
Thescraperblade(Figure9)canbereversedfora
secondwearsurfaceaftertheoriginaledgehasworn
beyondtheloweredgeofthenishgraderboxthatit
isattachedto.
g003654
Figure9
6

OptionalEquipment
DragkitPartNo.140-0274
WeightKit(Requiredwhen
using140-0274)
PartNo.100-6442
CarbideTinePack(15tines
included)
PartNo.119-2152
WeederTine(15tinesrequired
permachine)
PartNo.110-0260-0P
WeederBlade(5blades
requiredpermachine)
PartNo.132-4427-0P
7
