FormNo.3403-325RevA
Height-of-CutBlocks
GrandStand®Mower
ModelNo.133-1439
InstallationInstructions
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
Installation
PreparingtheMachine
1.Parkthemachineonalevelsurface,disengagethePTO,
movethemotion-controlleverstotheNEUTRAL-LOCK
position,andsettheparkingbrake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Movetheheight-of-cutlevertotheTRANSPORT
position.
4.Movetheheight-of-cutpintothe7cm(2-3/4inch)or
lowerposition
CorrectingtheHeightofCut
1.Placetheheight-of-cutblocksbelowthemowerdeck
sothatthedeckshellrestsontheblockswhenyou
lowerthedeck(Figure1).
Note:Ensurethattheblocksarenotdirectlybelow
thebafesonthefrontofthedeckortheblades.
Figure1
1.Height-of-cutblock(belowthedeck)
2.Lowerthedeckontotheblocks.
3.Verifythatonlythedeckshellisrestingontheblocks.
Note:Ensurethattheweightofthedeckrestsonthe
blocksandthereisnotensiononthelinkages.
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3403-325*A

4.Lightlypullbacktheheight-of-cutleverwith1nger
andnotethepositionoftheleverrelativetothetangent
oftheholeforthe7.6cm(3inch)heightofcut(Figure
2).
Figure2
1.Tangentfor7.6cm(3inch)heightofcut
5.Loosenthe2jamnutsontheheight-of-cutlinkage
(Figure3).
Figure3
1.Jamnut2.Height-of-cutlinkage
6.Adjustthelinkageuntiltheleveristangenttothe7.6
cm(3inch)holewhenyoupullbacktheleverwith1
nger(Figure2).
7.Tightenthe2jamnuts.
8.Loosenthejamnutsandsideboltsintheyokesforthe
deckchainsandlinkages(Figure4).
Figure4
1.Topbolt4.Sidenut
2.Jamnut5.Chains
3.Yoke6.Linkages
9.Rotatethetopboltoftheyokesclockwiseuntilthereis
noslackinthechainsandlinkages(Figure4).
Note:Donotoveradjustthebolts.Overadjustingmay
preventyoufromraisingthedecktotheTRANSPORT
position.
10.Tightenthejamnutsandsidebolts(Figure4).
11.VerifythatyoucanraisethedecktotheTRANSPORT
position.
12.Removetheblocks.
