X-CREATE BRIDGE SPACE
Assembly Guide
PART # 5616501-B

NOTE:
X-CREATE Wall Space Systems can be customized in countless ways. This
manual provides instructions for assembling base units, module options and
attachment options. If you worked with Torque X-Team Design during the
purchasing process, please request a Bill of Material Drawing to reference your
exact set-up. For assistance, contact [email protected] or call
[phone]; Toll free in USA [phone].
NOTE:
When assembling any X-CREATE System that is longer than one module wide,
the hardware will shared between two side by side modules and pull-up bars.
It is recommended to keep all bolt connections loose until the base system and
all of the module stations have been assembled. Securely tighten all frame
connections at this time, and then proceed to the attachment options.
Attachment options can be securely tightened as they are assembled.
TOOLS FOR ASSEMBLY:
3/8" ALLEN WRENCH •
5/16" ALLEN WRENCH •
3/16" ALLEN WRENCH •
3/4" WRENCH OR SOCKET •
9/16" WRENCH OR SOCKET •
1/2" WRENCH OR SOCKET •
RUBBER MALLET •
TABLE OF CONTENTS
BRIDGE ASSEMBLY: PAGES 4-9 1.
MODULE ASSEMBLY 2.
8' UPRIGHT EXTENSION MODULE: PAGE 12 •
STORAGE MODULE: PAGES 14-17 •
STALL BAR MODULE: PAGE 19 •
BALL & HANGING STORAGE MODULE: PAGES 21-24 •
BALL TARGET WALL MODULE: PAGE 26 •
BALL TARGET WALL REVERSE SIDE: PAGES 27-28 •
8' OLYMPIC LIFTING STATION MODULE: PAGES 30-33 •
ATTACHMENT ASSEMBLY 3.
BALL & HANGING STORAGE EXTENSION: PAGE 36 •
BATTLE ROPE ANCHOR: PAGE 37 •
HANGING STORAGE HOOK: PAGE 38 •
DOUBLE PLAY: PAGE 39 •
HORIZONTAL MOUNT GROUND ROTATIONAL TRAINER: PAGE 40 •
3-DIMENSIONAL SWIVEL ON UPRIGHT: PAGES 41-42 •
BALL TARGET: PAGES 43-45 •
RESISTANCE BAND ANCHOR: PAGE 46 •
VERTICAL DUMBBELL STORAGE - 4 PAIR: PAGE 47 •
ENDLESS ROPE DRUM (VERTICAL MOUNT): PAGES 48-49 •
ENDLESS ROPE DRUM (HORIZONTAL MOUNT): PAGES 50-51 •
3 DIMESIONAL SWIVEL W/ MOUNT: PAGE 52 •
ROCK CLIMBING KIT: PAGE 53 •
ATTACHMENT ANCHOR: PAGE 54 •
DIP ATTACHEMNT: PAGE 55 •
PLYO STEP: PAGE 56 •
ANCHORING: PAGE 57 4.
URETHANE BOOT: PAGE 58 5.
WARNING!
ALL X-CREATE ARE REQUIRED TO BE ANCHORED TO THE
FLOOR TO PREVENT ROCKING OR TIPPING DURING USE.
2

XCREATE-8U (4)
XCREATE-6MBX (2)
XCREATE-4MBX (2)
XCREATE-6FB (2)
XCREATE-4FB (2)
XCREATE-MBXE (4)
XCREATE-4SX (2)
XRACK-4MB (12)
3
BRIDGE ASSEMBLY

XCREATE-8U
NOTE:
URETHANE BOOTS
WILL BE ASSEMBLED
IN THE LAST STEP
NOTE:
TEMPORARILY REMOVE
PRE-INSTALLED BOLTS,
WASHERS AND NUTS
NOTE:
REMOVE END CAP
AND DISCARD
NOTE:
REMOVE SPACERS
(2) AND DISCARD
4
BRIDGE ASSEMBLY
NOTE:
Repeat this step for three more uprights.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U
XCREATE-MBXE
NOTE:
USE BOLTS, WASHERS AND
NUTS FROM PREVIOUS STEP
1/2 X 6" BOLT
1/2" FLAT WASHER
BRIDGE ASSEMBLY
5
NOTE:
LOOSELY assemble bolt connections in this step.
Repeat this step for three more uprights.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
1/2 X 1-1/2" BOLT (12)
1/2" FLAT WASHER (24)
1/2" LOCK NUT (12)
XCREATE-8U (2)
XCREATE-MBXE (2)
XCREATE-6MBX
XCREATE-4MBX
NOTE:
For ease of assembly, assemble this step on the floor.
LOOSELY assemble bolt connections in this step.
Repeat this step for the opposite side.
6
BRIDGE ASSEMBLY

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-6MBX
XCREATE-4MBX
XCREATE-6FB
XCREATE-4FB
XCREATE-MBXE (2)
1/2 X2" BOLT (6)
1/2" FLAT WASHER (12)
1/2" LOCK NUT (6)
7
BRIDGE ASSEMBLY
NOTE:
For ease of assembly, assemble this step on the floor.
LOOSELY assemble bolt connections in this step.
Repeat this step for the opposite side.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (4)
XCREATE-4SX (2)
1/2 X 4-3/4" BOLT (8)
PRE-INSTALLED
1/2" FLAT WASHER (16)
PRE-INSTALLED
1/2" LOCK NUT (8)
PRE-INSTALLED
8
BRIDGE ASSEMBLY
NOTE:
CAREFULLY stand each side up. Space sides
approximately 4' apart.
LOOSELY assemble bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-6MBX (2)
XCREATE-4MBX (2)
XCREATE-MBXE (4)
XRACK-4MB (12)
NOTE:
REPEAT THIS STEP FOR
AS MANY MONKEY BARS
TO BE ASSEMBLED
1/2 X 4-1/2" BOLT (4)
1/2" FENDER WASHER (8)
1/2" LOCK NUT (4)
9
BRIDGE ASSEMBLY
NOTE:
After this step has been completed, SECURELY
tighten all bolt connections made to this point.

8' UPRIGHT EXTENSION MODULE
STORAGE MODULE
STALL BAR MODULE
BALL & HANGING
STORAGE MODULE
8' OLYMPIC LIFTING
STATION MODULE
BALL TARGET WALL MODULE
BALL TARGET WALL
FOR REVERSE SIDE
MODULE ASSEMBLY
10

XCREATE-8U
XCREATE-4SX
11
8' UPRIGHT EXTENSION MODULE

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U
NOTE:
REMOVE END CAP PRIOR TO ASSEMBLY.
RE-ATTACH END CAP AFTER ASSEMBLY.
XCREATE-4SX
1/2 X 4-3/4" BOLT (4)
PRE-INSTALLED
1/2" FLAT WASHER (8)
PRE-INSTALLED
1/2" LOCK NUT (4)
PRE-INSTALLED
NOTE:
MAKE SURE TO USE PRE-
INSTALLED SPACER (2)
12
8' UPRIGHT EXTENSION MODULE
NOTE:
LOOSELY assemble all bolt connections in this step.
Repeat this step for as many modules there are to assemble.

XCREATE-4BS
XCREATE-4AT (4)
STORAGE MODULE
13

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (2)
XCREATE-4AT (4)
1/2 X 4-1/4"
BOLT (16)
1/2 FLAT WASHERS (32)
1/2 LOCK NUT (16)
14
STORAGE MODULE
NOTE:
LOOSELY assemble all bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (2)
END BRACKET (2)
1/2" FLAT WASHER (8)
1/2 X 4-1/4" BOLT (4)
1/2" LOCK
NUT (4)
NOTE:
LOOSELY assemble bolt connections in this step.
STORAGE MODULE
15

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
RAIL (2)
END BRACKET (2)
3/8 X 1-1/4" BOLT (4)
3/8" FLAT WASHER (4)
NOTE:
RAILS ARE ASSEMBLED
FOR STABILITY BALL WIDTH.
RAILS CAN BE BOLTED TO
NARROWER HOLES FOR
SMALLER ACCESSORIES.
16
STORAGE MODULE
NOTE:
If more modules will be assembled, do not tighten bolts at this time.

ACCESSORY LABEL
XCREATE-4AT (4)
3/8"
1-3/4"
ATTACH DESIRED
LABEL TO EACH
ACCESSORY TRAY
NOTE:
If you are a professional contractor installing this system for a facility,
leave these labels and instructions with a manager or inquire what
label to attach to each accessory tray.
17
STORAGE MODULE

18
STALL BAR MODULE

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-4SB (2)
XCREATE-8U (2)
1/2 X 4-1/4" BOLT (20)
1/2" FLAT WASHER (40)
1/2" LOCK NUT (20)
NOTE:
If more modules will be assembled, do not tighten bolts at this time.
STALL BAR MODULE
19

20
BALL & HANGING STORAGE MODULE
