Toshiba DA364/DA374 User manual

UM-TS03***-E017
PROGRAMMABLE CONTROLLER
PROSEC T3
ANALOG OUTPUT MODULE
DA364/DA374
USER’S MANUAL
Toshiba Corporation
Contents

Contents
3
Contents 1. Overview of the DA364/DA374......................................5
1.1 Overview..........................................................................5
1.2 Names and functions .......................................................6
1.3 Internal block diagram......................................................9
2. Settings.........................................................................10
2.1 Settings for output signal ranges ...................................10
3. Installing and Wiring....................................................12
3.1 Installing the module .....................................................12
3.2 Wiring.............................................................................13
3.2.1 Terminal arrangement ...............................................13
3.2.2 How to wire................................................................14
3.3 Application precautions..................................................15
3.3.1 Installing environment................................................15
3.3.2 Wiring precautions.....................................................16
4. Register Configuration ...............................................17
4.1 l/O registers and buffer memory ....................................17
4.2 Data format ....................................................................20
4.2.1 Analog output data ....................................................20
4.2.2 Status.........................................................................22
4.2.3 Offset calibration data ...............................................23
4.2.4 Gain calibration data .................................................23
Appendix ..............................................................................24
A. Specification...................................................................24
B. Operation flow................................................................25
C. How to calibrate .............................................................26
D. Details of the READ instruction......................................28
E. Details of the WRITE instruction ....................................30
