Toshiba BCN002Z User manual

E6581402c
TOSVERT VF-FS1 series
BACnet®option unit
Instruction Manual
NOTICE
1. Make sure that this instruction manual is delivered to the end user of BACnet
®
option
unit.
2. Read this manual before installing or operating the BACnet
®
option unit. Keep it in a
safe place for reference.
3. All information contained in this manual are subject to change without notice. Please
confirm the latest information on our web site ³www.inverter.co.jp´.

E6581402c
-1-
Safety precautions
On the inverter and in its instruction manual, important information is contained for preventing
injuries to users, damages to assets, and for proper use of the device.
Read the instruction manual attached to the inverter along with this instruction manual to
completely understand the safety precautions, the symbols and indications shown below. Please
adhere to the contents of these manuals at all times.
Explanation of markings
Marking Meaning of marking
Danger Indicates that errors in operation may lead to death or serious injury.
Warning
Indicates that errors in operation may lead to injury (*1) to people or that these errors may
cause damage to physical property. (*2)
(*1) Such things as injury, burns or shock that will not require hospitalization or long periods of
outpatient treatment.
(*2) Physical property damage refers to wide-ranging damage to assets and materials.
Meanings of symbols
Marking Meaning of marking
Indicates prohibition (Do not do it).
What is prohibited will be described in or near the symbol in either text or picture form.
Indicates something mandatory (must be done).
What is mandatory will be described in or near the symbol in either text or picture
form.
Indicates danger.
What is dangerous will be described in or near the symbol in either text or picture
form.
Indicates warning.
What the warning should be applied to will be described in or near the symbol in either
text or picture form.

E6581402c
-2-
Limitation of use
Safety precaution
Never use this unit with any device other than TOSVERT VF-FS1 series inverters. Doing so may cause
an accident.
Handling in general
Danger
Never
Disassemble
Never disassemble, modify or repair the product.
Disassembling the product may cause electric shocks, fire or injuries.
For repairs, call your sales/repair agency.
Prohibited
Do not open the front cover on the inverter while the inverter power is on.
It may lead to electric shocks.
Do not remove this option from VF-FS1 while the power is on.
It may lead to electric shocks.
Do not put or insert foreign objects such as waste cable, bars or wires into the product.
It may lead to electric shocks or fire.
Do not splash water over the product, and do not wipe the body with a wet cloth.
It may lead to electric shocks or fire.
Mandatory
Turn off the power immediately in case of any abnormalities such as smoke, smell or
abnormal noise.
Neglect of these conditions may lead to fire.
For repairs, call your sales/repair agency.
Do not touch the sharp portions (such as leads of parts on the board, the corner of board,
or etc.) on this option.
It may lead to injuries.
Warning
Mandatory
This option is an electrostatic discharge sensitive device. Handle it, where the
environment is protected against electrostatic electricity.
Otherwise, permanent damage to device will result.
Transportation and installation
Danger
Prohibited
Do not apply a dropping shock or other physical shocks.
Otherwise, damage or malfunction will result.
Do not install or operate the inverter if it is damaged or any part of it is missing.
Operating a defective inverter may lead to electric shocks or fire.
For repairs, call your sales/repair agency.
Do not put any flammable material near the product.
It may catch fire due to the product sparking in the case of a malfunction.
Mandatory
Use this product under the environmental conditions prescribed in the instruction manual.
Usage it under any other conditions may result in malfunction.
An emergency stop device must be installed that fits with system specifications
(e.g. shut off input power then engage mechanical brake).
Operation cannot be stopped immediately by the inverter or this unit alone, thus risking an
accident or injuries.
Install this option into VF-FS1 and secure it by tightening the terminal board fixing
screws to the specified torque. Otherwise, it may cause the product falling, the damage,
or malfunctions.
When installing this option, do not touch its sharp portions such as leads of parts on the
board, the corner of board or etc.
It may lead to injuries.

E6581402c
-3-
Wiring
Warning
Mandatory
Electrical construction work must be done by a qualified expert.
Connection of input power by someone who does not have expert knowledge may result
in electric shocks or fire.
Turn off input power before wiring.
Wait at least 10 minutes and make sure that the charge lamp (on the inverter unit) is no
longer lit. Otherwise, it may lead to electric shocks.
Tighten the screws on the terminal blocks to the specified torque when connecting cables
to terminal blocks.
Otherwise, it may lead to fire.
Operations
Danger
Prohibited
Do not pull on the cable and connector.
It may cause damage or malfunctions.
Mandatory
Use this option under the environment specified in the instruction manual.
Usage under the environment other than them may cause damages or malfunctions or
an accident.
Use an additional safety device with your inverter or system to prevent a serious
accident due to the unit malfunctions.
Usage without an additional safety device may cause an accident.
Warning
Mandatory
Set up ³Communication error trip function (see below)´to stop the inverter when the
option unit is deactivated by an unusual event such as an operating error, power outage,
failure, etc.
- Communication error trip time (Between the inverter and option board) (f803)
- Network timeout (f892)
(See the VF-FS1 BACnet®Communication Function Manual for details)
Deactivated option unit may cause an accident, if the ³Communication error trip
function´is not properly set up.
Make sure that the operation signals are STOP before resetting inverter¶s fault. The
motor may suddenly start and that may result in injuries.
Disposal
Warning
Mandatory
If you dispose off this unit, have it done by a specialist in industrial waste disposal*.
Improper disposal may result in explosion of capacitors or produce noxious gases,
resulting in injuries.
(*) Persons who specialize in the processing of waste and known as ³Industrial Waste
Product Collectors and Transporters´or ³Industrial Waste Disposal Persons.´If the
collection, transport and disposal of industrial waste is done by someone who is not
licensed for that job, it is a punishable violation of the law (Laws in regard to cleaning and
processing of waste materials).
Notes on operation
Notes
Avoidinstalling in a place where ambient temperature or/and humidity change sharply.
Keep the transmission cable separate from the power cable of the inverter to prevent the
inverter from malfunctioning due to electromagnetic noise.
Ground of SCR terminal on this option at the grounding terminal separated from those of
inverters and motors. It may cause malfunction due to noise.

E6581402c
-4-
Preface
Thank you for purchasing the ³BACnet®option (BCN002Z)´for TOSVERT VF-FS1 inverter. By
Installing this board into the VF-FS1, data communication can be made with a host computer or
other device via
BACnet network.
Before using this unit, carefully read this instruction manual in order to completely and correctly
utilize excellent performance of this unit. Besides this instruction manual, the ³VF-FS1
BACnet®
Communication Function Manual´which includes the contents to install into BACnet® network is
prepared. If it is required, please contact with our branch offices, sales offices or web site
³www.inverter.co.jp´.
(³VF-FS1
BACnet
®Communication Function Manual´: E6581404)
After reading this instruction manual, please keep it handy for future reference.
*
BACnet is a registered trademark of ASHRAE.
- Part numbering
BCN 002 Z ±0
Revision number
Cable length ( ³Z´means ³without cable´)
Model number of BACnet option
Symbol of BACnet option
- Accessory check list
BACnet communication option is shipped together with the following accessories. On opening the
packing case, check to see if the following accessories are contained or not.
(1) BACnet option board (BCN002Z)
Board (BCN002Z) ............................................1 pcs
Connector: MSTB2.5/4-ST-5.08
Manufactured by PHOENIX CONTACT
(2) Instruction manual
English (E6581402).......................................1 copy (This book)
(3) Cabling label & Name plate ............................1 sheet
(1 cabling label and 2 name plates)
(4) Insulating sheet ...............................................1 sheet
Instruction
Manual

E6581402c
-5-
Table of Contents
1. Overview 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 6
2. Names and functions 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 6
2.1. Outline㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 6
2.2. Use of RS485 communication port㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 6
2.3. LED indicator 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯7
3. Installation and Setup 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 8
3.1. Installation method 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 8
3.2. Description of terminals 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 9
3.3. Network cable connection 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 10
3.4. Network configuration㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 10
3.5. Wiring of a control terminal 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 11
4. Parameters 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 12
4.1. Communication parameters 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 12
5. Specifications 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 13
6. Warranty 㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯㨯 14

E6581402c
-6-
1. Overview
The BACnet (BCN002Z) interface allows the VF-FS1 inverter to be connected into a BACnet network.
BACnet MS/TP supports a maximum of 32 nodes for one segment.
2. Names and functions
The drawing below shows names and functions of main parts.
2.1. Outline
2.2. Use of RS485 communication port
Serial communication (2-wire RS485) option can be used. However, while it is connected, the
internal communication line is switched to RS485 then the communication via BACnet network is
disabled. In this case, communication error trip time (f803) is also active. Use RS485 serial
communication option specified by Toshiba.
Detachable terminal
Network
communication
Communication
condition monitor LED
Input terminal
SINK/SOURCE
VIB/PTC select SW
Optional RS485 communication port
RS485 communication option can be
used. However it makes BACnet
Communication be disabled.
BAGNDSCR
Connector
Termination
resistor SW
Terminal board fixing
screw hole
(M3 screw)

E6581402c
-7-
2.3. LED indicator
The option has two LEDs. Those functions are below table.
State LEDs Comment
AGreen LED : OFF
RedLED :Flashing5timesin1second BACnet board failure
B
Green LED : OFF
Red LED :
Flashing 3 times in 2 seconds, Off for 1
second
Communication loss detected. Confirm the
network condition and connection of the cable.
CGreen LED : ON
Red LED : OFF 0.5s, ON 0.5s
Invalid configuration detected (ADR > max
master), or an option is connected to RJ45.
D
Green LED :
Flashing 3 times in 2 seconds, Off for 1
second
Red LED : OFF
Waiting for Auto baud rate detection
EGreen LED : Flashing Intermittent Green
Red LED : --- Valid message received for this node
FGreen LED : ---
Red LED : Flashing Intermittent Red Invalid message received (any node)
COM
Green
ERR
Red
1s
OFF
2s
OFF
1s 1s
ON
ABC EF
2s
OFF
1s
D

E6581402c
-8-
3. Installation and Setup
3.1. Installation method
Install the BACnet communication option to VF-FS1 as follows.
(1) Turn off the input power of VF-FS1 and wait for at least 10 minutes and then check that the
CHARGE lamp on VF-FS1 is no longer lit.
(2) Open the VF-FS1 front cover, remove the terminal board fixing screw and take off the VF-FS1
standard terminal board.
(Be careful not to lose the terminal board fixing screw when removed since it may be used again.)
(3) Perform wiring an inverter before installing BACnet communication option.
(4) Please attach the insulating sheet in VF-FS1.
(Fix to the terminal board fixing screw hole and PWB catch pin.)
(5) Install the BACnet communication option over the insulating sheet and secure it with the board
fixing screw (tightening torque of M3 tapping screw: 0.7 to 0.8Nm).
(6) Set up the SW of the board with the input terminal for sink or source.
(7) Stick the cabling label for BACnet communication option on the standard cabling label stuck on
the reverse side of the VF-FS1 front cover. And stick the BACnet communication option
nameplate near the standard nameplate. (Be careful not to cover slits on the VF-FS1 enclosure.
N.B.: To install or remove the terminal board, make it slide in or out in parallel with board.
VF-FS1 name plate
BACnet communication option
(
BCN002Z
)
VF-FS1 Standard terminal board
VF-FS1 unit
Stick the BCN002Z nameplate
like bellow figure.
BCN002Z
Insulating seat
(attached)
Board catching pin
Board fixing screw hole
BCN002Z
Terminal board fixing screw
(M3 screw tightening torque: 0.7 to 0.8Nm)
Cabling label position
Example

E6581402c
-9-
3.2. Description of terminals
<Control terminals specification>
Terminal
symbol Function Electrical specifications Internal circuits
B Communication signal (+)
A Communication signal (-)
GND Signal common
SCR
BACnet communication
signal
EIA-485 Shield terminal.
Connect to network ground.
B
A
GND
SCR
47k
47k
4.7k
4.7k
120
SW4
TERM
F
R
Multifunctional programmable
contact input.
SINK/SOURCE can be
selected with SW.
No voltage contact input
24VDC,5mAorless
N.B. Use contact parts for low
current. F, R
CC
P24
4.7k
P24
PTC
SOURCESINK
820
VIB
Multifunction programmable
analog input.
with internal pull-up resistor
for PTC
0to10V
DC input
Using this terminal as PTC
input, set SW2 to PTC side
and set the parameters
(f645 and f646)to
proper value.
VIB
15k
VIB
P10
PT
C
15k
3.3k
CC Control circuit¶s equipotential
terminal
P24 24 V
DC power supply output 24VDC-50mA P24
P24
PTC
FLA
FLB
FLC
Multifunctional programmable
relay contact outputs
1c contact
30V
DC-0.5A
250VAC-1A (cosI=1㧕
250VAC-0.5A (cosI=0.4)
FL
A
FLB
FLC
Ry
Danger
Prohibited
Do not change switches settings while the power is on.
It may lead to electric shocks or damage.
Mandatory
Turn off the motor operation signals before setting the parameter and the switch
(SW), when changing the VIB function. Otherwise, the motor may suddenly start
and that may result in injuries.
