Toshiba TC Series User manual

1
TOSHIBA MACHINE CO., LTD.
TC Series
(TCmini/TC200)
Driver
1 System Configuration.......................................................................................................3
2 Selection of External Device............................................................................................7
3 Example of Communication Setting.................................................................................8
4 Setup Items....................................................................................................................31
5 Cable Diagram...............................................................................................................36
6 Supported Devices.........................................................................................................72
7 Device Code and Address Code....................................................................................79
8 Error Messages..............................................................................................................84

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 2
Introduction
This manual describes how to connect the Display and the External Device (target PLC).
In this manual, the connection procedure will be described by following the below sections:
1System Configuration
This section shows the types of External
Devices which can be connected and SIO
type.
)"1 System Configuration" (page 3)
2Selection of External Device
Select a model (series) of the External
Device to be connected and connection
method.
)"2 Selection of External Device" (page 7)
3Example of Communication Settings
This section shows setting examples for
communicating between the Display and
the External Device.
)"3 Example of Communication Setting"
(page 8)
4Setup Items
This section describes communication
setup items on the Display.
Set communication settings of the Display
with GP-Pro Ex or in offline mode.
)"4 Setup Items" (page 31)
5Cable Diagram
This section shows cables and adapters
for connecting the Display and the
External Device.
)"5 Cable Diagram" (page 36)
Operation

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 3
1 System Configuration
The following table lists system configurations for connecting TOSHIBA MACHINE CO., LTD. External
Devices and the Display.
Series CPU Link I/F SIO Type Setting Example Cable Diagram
TC200 TCCUH
TCCMW
RS-232C
"Setting Example
1" (page 8)
"Cable Diagram 1"
(page 36)
TCCMO "Setting Example
2" (page 11)
RS-232C connector on CPU
Module*1
*1 To connect the Display directly to the External Device, in GP-Pro EX open the [Individual Device Settings]
dialog box and set PC No. to 64.
"Setting Example
3" (page 13)
TC200S TCCUHS
TCCUSS
TCCMWA
RS-232C
"Setting Example
4" (page 15)
"Cable Diagram 1"
(page 36)
TCCMOA "Setting Example
5" (page 18)
RS-232C connector on CPU
Module*1 "Setting Example
6" (page 20)
TCmini
TC3-01
Port on CPU Module RS-232C "Setting Example
7" (page 22) "Cable Diagram 2" (page 38)
CN17A port on CPU Module RS-422/485
(2 wire) "Setting Example 8" (page 24) "Cable Diagram 3" (page 40)
CN17B port on CPU Module
TC3-02 Port on CPU Module RS-232C "Setting Example
7" (page 22) "Cable Diagram 2" (page 38)
TC5-02
Port on CPU Module RS-232C "Setting Example
7" (page 22) "Cable Diagram 2" (page 38)
CN24A port on CPU Module RS-422/485
(2 wire) "Setting Example 9" (page 27) "Cable Diagram 4" (page 48)
CN24B port on CPU Module
TC6-00 Port on CPU Module RS-232C "Setting Example
7" (page 22) "Cable Diagram 2" (page 38)
TC8-00
Port on CPU Module RS-232C "Setting Example
7" (page 22) "Cable Diagram 2" (page 38)
CN11 port on CPU Module RS-422/485
(2 wire) "Setting Example 8" (page 24) "Cable Diagram 5" (page 56)
TC9-00 CN11 port on CPU Module RS-422/485
(2 wire) "Setting Example 10" (page 29) "Cable Diagram 6" (page 64)
• For TCmini series to run RS-422/485 (2 wire) communications, one of the following CPU
versions or later is necessary.
TC3-01 (Version: TCmini LT3CU01D1)
TC5-02 (Version: TCmini LT5CU02C0)
TC8-00 (Version: TCmini LT8CU00A0)
TC9-00 (Version: TCmini LT9CU00A0)

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 4
Connection Configuration
• 1:1 Connection
• 1:n Connection (Case of using TC200 Series / TC200S Series’ External Device)
• In this case, Display can communicate with the port on CPU module or PC link Module.
Display External Device
Display
External Device External Device External Device
When using Link module,
a Display can access up to 16 unit.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 5
IPC COM Port
When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please
refer to the IPC manual for details.
Usable port
DIP Switch setting: RS-232C
Series Usable Port
RS-232C RS-422/485(4 wire) RS-422/485(2 wire)
PS-2000B COM1*1 , COM2,
COM3*1, COM4
*1 The RI/5V can be switched. Use the IPC’s switch to change if necessary.
--
PS-3450A, PS-3451A,
PS3000-BA, PS3001-BD COM1, COM2*1*2 COM2*1*2 COM2*1*2
PS-3650A (T41 model),
PS-3651A (T41 model) COM1*1 --
PS-3650A (T42 model),
PS-3651A (T42 model) COM1*1*2, COM2 COM1*1*2 COM1*1*2
PS-3700A (Pentium®4-M)
PS-3710A COM1*1, COM2*1, COM3*2 , COM4
*2 Set up the SIO type with the DIP Switch. Please set up as follows according to SIO type to be used.
COM3*2 COM3*2
PS-3711A COM1*1, COM2*2 COM2*2 COM2*2
PS4000*3
*3 When making communication between an External Device and COM port on the Expansion slot,
only RS-232C is supported. However, ER (DTR/CTS) control cannot be executed because of the
specification of COM port.
For connection with External Device, use user-created cables and disable Pin Nos. 1, 4, 6 and 9.
Please refer to the IPC manual for details of pin layout.
COM1, COM2 - -
PL3000 COM1*1*2, COM2*1,
COM3, COM4 COM1*1*2 COM1*1*2
DIP Switch Setting Description
1OFF
*1
*1 When using PS-3450A, PS-3451A, PS3000-BA and PS3001-BD, turn ON the set value.
Reserved (always OFF)
2OFF
SIO type: RS-232C
3OFF
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Not available
8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Not available
9OFF
RS (RTS) Auto control mode: Disabled
10 OFF

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 6
DIP Switch setting: RS-422/485 (4 wire)
DIP Switch setting: RS-422/485 (2 wire)
DIP Switch Setting Description
1 OFF Reserved (always OFF)
2ON
SIO type: RS-422/485
3ON
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Not available
8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Not available
9OFF
RS (RTS) Auto control mode: Disabled
10 OFF
DIP Switch Setting Description
1 OFF Reserved (always OFF)
2ON
SIO type: RS-422/485
3ON
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 ON Short-circuit of SDA (TXA) and RDA (RXA): Available
8 ON Short-circuit of SDB (TXB) and RDB (RXB): Available
9ON
RS (RTS) Auto control mode: Enabled
10 ON

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 7
2 Selection of External Device
Select the External Device to be connected to the Display.
Setup Items Setup Description
Number of Devices/
PLCs Enter an integer from 1 to 4 to define the number of Devices/PLCs to connect to the display.
Manufacturer Select the manufacturer of the External Device to connect. Select "TOSHIBA MACHINE
Co., Ltd.".
Series
Select the External Device model (series) and the connection method. Select "TC Series
(TCmini/TC200)".
In System configuration, make sure the External Device you are connecting is supported by
"TC Series (TCmini/TC200)" in system configuration.
)"1 System Configuration" (page 3)
Port Select the Display port to be connected to the External Device.
Use System Area
Check this option to synchronize the system data area of the Display and the device
(memory) of the External Device. When synchronized, you can use the External Device’s
ladder program to switch the display or display the window on the Display.
Cf. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)"
This feature can also be set in GP-Pro EX or in the Display's offline mode.
Cf. GP-Pro EX Reference Manual "System Settings [Display Unit] - [System
Area] Settings Guide"
Cf. Maintenance/Troubleshooting Guide "Main Unit - System Area Settings"

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 8
3 Example of Communication Setting
Examples of communication settings of the Display and the External Device, recommended by Pro-face, are
shown.
3.1 Setting Example 1
Settings of GP-Pro EX
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Device Setting
To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]
window, select the external device and click [Settings] .
To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add
Device] to add another External Device.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 9
Settings of External Device
Set PC No. of the External Device using DIP Switches and the rotary switch of External Device.
Please refer to the manual of the External Device for more details.
After setting, reboot the External Device to enable the setting.
Setup Items
•DIPSwitch
• Rotary switch
DIP Switch Settings*1
*1 For SW3 to SW6, if two or more than two switches are turned on, there will be a set error.
SW3 must be turned ON when connect to Display.
Setup Description
SW1 OFF Set PC No. by combining with the rotary switch.
SW2 OFF
SW3 ON Link Master
SW4 OFF Link Slave
SW5 OFF Remote Master
SW6 OFF Remote Slave
Settings Setup Description
0PCNo.
• Set PC No. using DIP Switches 1 and 2 and the rotary switch. Combination of possible
settings is as follows.
DIP Switch PC No. that can be set
with the rotary switch
SW1 SW2
OFF OFF 0 - 15
OFF ON 16 - 31
ON OFF 32 - 47
ON ON 48 - 63

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 10
Caution
In the case of a 1:n connection, the terminating resistance switch and shield grounding switch need to be set.
• Setting of the terminating resistance switch (ON/OFF) (LINE T)
Always turn on the terminating resistance on both end stations of the communication circuit. Always turn off
the terminating resistance of the way station.
• Setting of the shield grounding switch (grounding/isolating) (LINE G) of communication cable
Turn on the shield grounding switch (grounding) on the shield side of the communication cable.
• Turning off the terminating resistance on both end stations or turning on the
terminating resistance of the way station disables normal communication.
If there is 4V or more grounding electric potential difference between the other control
panel and this module control panel, take the following steps.
• Turn off the shield grounding switch (isolating).
• If the total extension of communication cable exceeds 100m, turn on one or more
switch(es) (grounding) every 100m. Select a place with 4V or lower grounding electric
potential difference for grounding.
• If the total extension of the communication cable is 100m or less, turn on a switch
(grounding) in the intermediate position.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 11
3.2 Setting Example 2
Settings of GP-Pro EX
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Device Setting
To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]
window, select the external device and click [Settings] .
To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add
Device] to add another External Device.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 12
Settings of External Device
Set PC No. of the External Device using DIP Switches and the rotary switch of External Device.
Please refer to the manual of the External Device for more details.
After setting, reboot the External Device to enable the setting.
Setup Items
•DIPSwitch
• Rotary switch
DIP Switch Settings*1
*1 For SW3 to SW6, if two or more than two switches are turned on, there will be a set error.
SW3 must be turned ON when connect to Display.
Setup Description
SW1 OFF Set PC No. by combining with the rotary switch.
SW2 OFF
SW3 ON Link Master
SW4 OFF Link Slave
SW5 OFF Remote Master
SW6 OFF Remote Slave
Settings Setup Description
0PCNo.
• Set PC No. using DIP Switches 1 and 2 and the rotary switch.
Combination of possible settings is as follows.
DIP Switch PC No. that can be set
with the rotary switch
SW1 SW2
OFF OFF 0 - 15
OFF ON 16 - 31
ON OFF 32 - 47
ON ON 48 - 63

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 13
3.3 Setting Example 3
Settings of GP-Pro EX
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Device Setting
To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]
window, select the external device and click [Settings] .
To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add
Device] to add another External Device.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 14
Settings of External Device
Communication setting of External Device by ladder software (TCPRGOS-W (J)).
Please refer to the manual of the External Device for more details.
Procedure
1Start the ladder software of the computer.
2Select [Register editor] in the [Tool] menu.
[Register data [online]] window is displayed.
3Click [A].
4Double click the special auxiliary relay (A00F) to set communication speed.
Communication speed A00F
9600bps OFF
• The other setting of communication speed is as follows.
Communication speed A00F
19200bps ON

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 15
3.4 Setting Example 4
Settings of GP-Pro EX
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Device Setting
To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]
window, select the external device and click [Settings] .
To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add
Device] to add another External Device.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 16
Settings of External Device
Set PC No. of the External Device using DIP Switches and the rotary switch of External Device.
Please refer to the manual of the External Device for more details.
After setting, reboot the External Device to enable the setting.
Setup Items
•DIPSwitch
• Rotary switch
DIP Switch Settings*1
*1 For SW3 to SW6, if two or more than two switches are turned on, there will be a set error.
SW3 must be turned ON when connect to Display.
Setup Description
SW1 OFF Set PC No. by combining with the rotary switch.
SW2 OFF
SW3 ON Link Master
SW4 OFF Link Slave
SW5 OFF Remote Master
SW6 OFF Remote Slave
Settings Setup Description
0PCNo.
• Set PC No. using DIP Switches 1 and 2 and the rotary switch.
Combination of possible settings is as follows.
DIP Switch PC No. that can be set
with the rotary switch
SW1 SW2
OFF OFF 0 - 15
OFF ON 16 - 31
ON OFF 32 - 47
ON ON 48 - 63

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 17
Caution
In the case of a 1:n connection, the terminating resistance switch and shield grounding switch need to be set.
• Setting of the terminating resistance switch (ON/OFF) (LINE T)
Always turn on the terminating resistance on both end stations of the communication circuit. Always turn off
the terminating resistance of the way station.
• Setting of the shield grounding switch (grounding/isolating) (LINE G) of communication cable
Turn on the shield grounding switch (grounding) on the shield side of the communication cable.
• Turning off the terminating resistance on both end stations or turning on the
terminating resistance of the way station disables normal communication.
If there is 4V or more grounding electric potential difference between the other control
panel and this module control panel, take the following steps.
• Turn off the shield grounding switch (isolating).
• If the total extension of communication cable exceeds 100m, turn on one or more
switch(es) (grounding) every 100m. Select a place with 4V or lower grounding electric
potential difference for grounding.
• If the total extension of the communication cable is 100m or less, turn on a switch
(grounding) in the intermediate position.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 18
3.5 Setting Example 5
Settings of GP-Pro EX
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Device Setting
To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]
window, select the external device and click [Settings] .
To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add
Device] to add another External Device.

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 19
Settings of External Device
Set PC No. of the External Device using DIP Switches and the rotary switch of External Device.
Please refer to the manual of the External Device for more details.
After setting, reboot the External Device to enable the setting.
Setup Items
•DIPSwitch
• Rotary switch
DIP Switch Settings*1
*1 For SW3 to SW6, if two or more than two switches are turned on, there will be a set error.
SW3 must be turned ON when connect to Display.
Setup Description
SW1 OFF Set PC No. by combining with the rotary switch.
SW2 OFF
SW3 ON Link Master
SW4 OFF Link Slave
SW5 OFF Remote Master
SW6 OFF Remote Slave
Settings Setup Description
0PCNo.
• Set PC No. using DIP Switches 1 and 2 and the rotary switch.
Combination of possible settings is as follows.
DIP Switch PC No. that can be set
with the rotary switch
SW1 SW2
OFF OFF 0 - 15
OFF ON 16 - 31
ON OFF 32 - 47
ON ON 48 - 63

TC Series (TCmini/TC200) Driver
GP-Pro EX Device/PLC Connection Manual 20
3.6 Setting Example 6
Settings of GP-Pro EX
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Device Setting
To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]
window, select the external device and click [Settings] .
To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add
Device] to add another External Device.
• Set Stop Bit to 1 bit.
