Touch Dynamic Breeze User manual

Revision v1.4 January 2011
Breeze
All-in-one
Hardware System
User Manual

- i -
Copyright 2011
All Rights Reserved
Manual Version 1.4
Part Number:
The information contained in this document is subject to change without notice.
We make no warranty of any kind with regard to this material, including, but not
limited to, the implied warranties of merchantability and fitness for a particular
purpose. We shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use
of this material.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced or translated to another language without the prior written consent
of the manufacturer.
TRADEMARK
Intel®, Pentium® and MMX are registered trademarks of Intel® Corporation.
Microsoft® and Windows® are registered trademarks of Microsoft Corporation.
Other trademarks mentioned herein are the property of their respective owners.

- ii -
Safety
IMPORTANT SAFETY INSTRUCTIONS
1. To disconnect the machine from the electrical power supply, turn off the
power switch and remove the power cord plug from the wall socket. The
wall socket must be easily accessible and in close proximity to the
machine.
2. Read these instructions carefully. Save these instructions for future
reference.
3. Follow all warnings and instructions marked on the product.
4. Do not use this product near water.
5. Do not place this product on an unstable cart, stand, or table. The product
may fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for
ventilation to ensure reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should never be placed near or
over a radiator or heat register or in a built-in installation unless proper
ventilation is provided.
7. This product should be operated from the type of power indicated on the
marking label. If you are not sure of the type of power available, consult
your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product
where persons will walk on the cord.
9. Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the product.
CE MARK
This device complies with the requirements of the EEC directive
2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC
“Low Voltage Directive”.
FCC
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference
that may cause undesired operation.

- iii -
CAUTION ON LITHIUM BATTERIES
There is a danger of explosion if the battery is replaced incorrectly. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.
Battery Caution
Risk of explosion if battery is replaced by an incorrectly type.
Dispose of used battery according to the local disposal instructions.
Safety Caution
Note: To comply with IEC60950-1 Clause 2.5 (limited power sources, L.P.S)
related legislation, peripherals shall be 4.7.3.2 "Materials for fire enclosure"
compliant.
4.7.3.2 Materials for fire enclosures
ForMOVABLEEQUIPMENT having a total mass not exceeding
18kg.the material of a FIRE ENCLOSURE, in the thinnest significant
wall thickness used, shall be of V-1 CLASS MATERIAL or shall pass
the test of Clause A.2.
For MOVABLE EQUIPMENT having a total mass exceeding 18kg
and for all STATIONARY EQUIPMENT, the material of a FIRE
ENCLOSURE, in the thinnest significant wall thickness used, shall
be of 5VB CLASS MATERIAL or shall pass the test of Clause A.1
LEGISLATION AND WEEE SYMBOL
2002/96/EC Waste Electrical and Electronic Equipment Directive on the
treatment, collection, recycling and disposal of electric and electronic devices
and their components.

- iv -
The crossed dustbin symbol on the device means that it should not be disposed
of with other household wastes at the end of its working life. Instead, the device
should be taken to the waste collection centers for activation of the treatment,
collection, recycling and disposal procedure.
To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can
take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
This product should not be mixed with other commercial wastes for disposal.

- v -
Revision History
Changes to the original user manual are listed below:
Version Date Description
1.0 2008 July Initial release
1.1 2009 February
B78 M/B Upgraded from v2.1 to 2.2
B98 V1.0 M/B information added
Second display installation added
2nd FAN of B98 MB added
Drivers list and installation upgraded
Jumper setting upgraded
VGA version upgraded
Specification upgraded
2-in-1 MSR + iButton / Fingerprint
module installation added
1.2 2009 November
17” TFT LCD added
Drivers installation removed
BIOS setup removed
B68 motherboard version added
1.3 2010 June
C48 motherboard version added
New system stand phased in
B68, B78 Jumper updated
1.4 2011 January
C48 motherboard updated to V2.1
B78 motherboard updated to V2.4
B98 motherboard updated to V1.1
8.4” 2nd display phased in
SSD module added
OSD functions for 2nd display added

- vi -
Table of Contents
1 Item Checklist ...........................................1
1-1 Standard Item ...............................................................................1
1-2 Optional Item ................................................................................2
2 System View .............................................3
2-1 Front View.....................................................................................3
2-2 Rear View with stand....................................................................4
2-3 Rear View without stand...............................................................4
2-4 Side View...................................................................................... 5
2-5 Bottom View..................................................................................5
2-6 I/O View ........................................................................................6
3 System Dimensions .................................7
3-1 15” System Dimensions................................................................7
3-2 17” System Dimensions................................................................7
4 Peripheral Installation..............................8
4-1 VFD Installation ............................................................................8
4-2 Second Display Installation ..........................................................9
4-3 Power Cord Installation ..............................................................14
4-4 MSR / 2-in-1 MSR Installation ....................................................15
4-5 Cash Drawer Installation for B78 Motherboard ..........................16
4-6 Cash Drawer Installation for B98/B68/C48 Motherboard ...........18
4-7 VESA Wall-Mount Kit Installation ...............................................20
4-8 Stand Assembly & Disassembly.................................................21
5 System Assembly & Disassembly........23
5-1 HDD Replacement......................................................................23
5-2 Compact Flash Card Replacement ............................................23
5-3 SSD Card Replacement .............................................................24
5-4 Power Adapter Replacement...................................................... 24
6 Specification ...........................................25
6-1 B78 Motherboard........................................................................25
6-2 B98 / B68 / C48 Motherboard.....................................................27
7 Jumper Settings .....................................29
7-1 B78 Motherboard........................................................................29
7-2 B98 Motherboard........................................................................36
7-3 B68 Motherboard........................................................................42
7-4 C48 Motherboard........................................................................48
7-5 C48 Jumper & BIOS/Utility Settings ...........................................51
Appendix A: Drivers Installation..............58
Appendix B: OSD Functions for 2nd Display 59
Appendix C: VFD Customer Display .......62

- 1 -
1 Item Checklist
Take the system unit out of the carton. Remove the unit from the carton by
holding it by the foam inserts. The following contents should be found in the
carton:
1-1 Standard Item
a. b.
c. d.
e.
a. System
b. Driver CD
c. RJ45-DB9 cable (x2)
d. Power Cord
e. Power adapter

- 2 -
1-2 Optional Item
The touch terminal device provides various peripheral options for your selection.
Please refer to your local sales representative or distributor for further
information.
a. b. c
d e f
g h
a. MSR Module
b. MSR + iButton Module
c. MSR + Fingerprint Module
d. VFD Customer Display (with RJ45 cable)
e. Second Display with Touch
f. CF Card Adapter Board
g. SSD Module
h. Wall Mount Kit

- 3 -
2 System View
2-1 Front View
No. Description
1 Touch
2 MSR (optional)
3 Stand (with power brick and cable management)
4 I/O Ports
5 Stand hole for cables outlet
6 Second Power Button
1
2
5
4
3
6

- 4 -
2-2 Rear View with stand
2-3 Rear View without stand
No. Description
6 2nd Display (Optional)
7 Ventilation holes
8 HDD Door
9 VFD dummy cover
10 Ventilation holes
11 VESA holes (100x100mm)
12 Thumbscrew hole for stand / wall-mount bracket
13 Handle of Motherboard
6
7
8
9

- 5 -
2-4 Side View
No. Description
14 Speaker outlet
15 Stand hinge cover (at both sides)
2-5 Bottom View
No. Description
16 Rubber foot
17 Holder bracket for power brick
14
15
16
17

- 6 -
2-6 I/O View
No. Description
a Power Switch
b PS/2
c 2nd VGA
d USB (x4)
e / m Thumbscrews for fixing the motherboard
f DC-IN (19V)
g LAN
h Cash Drawer
i MIC-in
J Line-out
k COM 1, 2, 3, 4
l Parallel

- 7 -
3 System Dimensions
3-1 15” System Dimensions
3-2 17” System Dimensions

- 8 -
4 Peripheral Installation
4-1 VFD Installation
The VFD requires 12V power and must be connected to a powered COM port
(COM3 or COM4). Please refer to chapter 7-1-3 (B78 motherboard, jumper JP3),
chapter 7-2-3 (B98 motherboard, jumper JP5), Chapter 7- 3-3 (B68
motherboard, jumper JP3), and Chapter 7-4-3 (C48 motherboard, jumper JP7)
for correct jumper setting.
VFD Module View
VFD Installation Procedure
1. Slide the VFD module to the VESA bracket on the stand and tighten it with
thumb screw.
2. Connect the VFD cable to the COM port on the system.

- 9 -
4-2 Second Display Installation
4-2-1 8.4" Second Display Installation
Accessories:
8.4” 2nd Display
VGA Cable x 1
Screw x 6
2nd Display Bracket
System Stand

- 10 -
Installation Procedure:
1. Attach the 2nd display bracket to the stand system and fasten the thumb
screw (x1).
2. Loosen the thumb screw (x2) and the screw (x2) of the female VGA cable.
3. Pull the I/O panel towards you by the handle

- 11 -
4. Replace the VGA cable to male type.
5. Connect the other end of VGA cable to the jumper on the motherboard.
The locations of VGA power jumper are as following:
B78: JP1 and JP2
B98: JP9 and JP13
B68: JP4
C48: JP18
Please see chapter 7 for different motherboards.
6. Attach the stand with 2nd display bracket to the LCD touch panel. Fix the
stand with 2nd display bracket on the VESA holes (x4) until it snaps in
place.
7. Fasten the thumb screw (x1) and connect the VGA cable to the LCD touch
panel.

- 12 -
8. Attached the 2nd display and connect the other end of cable to the system
port.
4-2-2 10.4" / 12.1" Second Display Installation
Accessories:
2nd display
VGA Cable x 1 Screw x 2

- 13 -
Installation Procedure:
1. Thread two ends of the cable respectively through the upper and the lower
gap on the 2nd display on the bracket.
2. Align the boss on 2nd display to the holes on the bottom of the system
stand. Attach 2nd display to the stand.
3. Fasten the 2nd display stand with the screws (x2), and connect cable to 2nd
display.
2nd display
System stand
