TouchTunes Virtuo Floor Stand User manual

Floor Stand Guide

Disclaimer
Document Part Number: 900579-001 Rev 04 April 2012
TouchTunes and the TouchTunes logo are trademarks of TouchTunes Interactive Networks.
All other brand and product names are trademarks or registered trademarks of their respective
corporations.
The mention of any product does not constitute an endorsement by TouchTunes Interactive Networks.
This manual is furnished under a lease agreement and may only be copied or used within accordance
with the termsof such lease agreement. The content ofthis manual is furnished for informational useonly,
is subject to change without notice, and should not be construed as a commitment by TouchTunes
InteractiveNetworks.TouchTunesInteractiveNetworksassumes noresponsibilityorliabilityforanyerrors
or inaccuracies that may appear in this document.
Except as permitted by such lease agreement, no part of this publication may be reproduced, stored in
any retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or
otherwise, without prior written consent of TouchTunes Interactive Networks.
Changes are periodically made to the information herein; these changes will be incorporated into new
editions of this publication. TouchTunes may make improvements and/or changes in the products and/or
software programs described in this publication at any time.
If you have comments on this manual or the products it describes, address them to:
TouchTunes Interactive Networks
Attention: Publications
400 Sainte Croix Avenue, Suite 200 E
Montreal, Quebec, Canada H4N 3L4
Service Hotline: [phone]
Fax: [phone]
TouchTunes may use or distribute whatever information you supply in any way it believes appropriate
without incurring any obligations to you.
Copyright © 2012 TouchTunes Interactive Networks. All rights reserved, including those to reproduce this
publication or parts thereof in any form without permission in writing from TouchTunes Interactive
Networks.

Contents
1Welcome 5
Introducing the Virtuo Floor Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Disclaimer and important safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Contacting TouchTunes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 Installing the Virtuo Floor Stand 11
Bringing the Virtuo Floor Stand to a location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
List of Floor Stand components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Preparing tools for installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Removing the Floor Stand from the Pallet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Removing the Wheels..........................................................................................................................16
Removing the Subwoofer (temporarily). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Removing the Floor Stand from the Pallet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Re-Inserting the and fastening the subwoofer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Attaching the wheels to the main frame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Assembling the baseplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Rolling the Floor Stand into the Baseplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Levelling the Floor Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Installing and Connecting the Floor Stand Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Removing the Floor Stand Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Attaching the Array Speakers..............................................................................................................25
Mounting the Virtuo to the Floor Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Installing the crossover box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Understanding Floor Stand wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting the audio cables to the Virtuo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting the subwoofer and array speaker wires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Wiring the DA-415 amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Speaker wiring examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Securing the wires...................................................................................................................... 37
Reattaching the back panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Powering up the Virtuo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4

Virtuo Floor Stand Guide 900579-001 Rev 03
Welcome
This section introduces the Virtuo Floor Stand, provides important safety information, and describes how to get
customer support.
Introducing the Virtuo Floor Stand
About this guide
Disclaimer and important safety information
Contacting TouchTunes

Virtuo Floor Stand Guide
Welcome
Introducing the Virtuo Floor Stand
6
Introducing the Virtuo Floor Stand
About this guide
This guide is intended for Operators of TouchTunes digital jukeboxes and their technicians, and TouchTunes
technical support and field service personnel. It provides important information about the installation, setup, and
operation of your new Virtuo.
Congratulations on your purchase of a
Virtuo Floor Stand.
As well as supporting your Virtuo
SmartJuke, the Virtuo Floor Stand
provides you with a platform for
equipping your Virtuo with TouchTunes
acoustic packages, resulting in a
powerful combination of sound output
configurations on all 3 zones.

Welcome
Disclaimer and important safety information
Virtuo Floor Stand Guide
7
Disclaimer and important safety information
TouchTunes Interactive Networks is not responsible for any damage resulting from the improper installation or
connection of test kit components or any other external equipment to your kit. Nor is TouchTunes responsible
for any damage caused during shipment (except the shipment to the original purchaser) or any damage caused
by:
• impacts, fluids, fire, flood, wind, earthquake, lightning or similar disaster
• unauthorizedmodifications,attachments orperipherals,improperuse,environment,installationor electrical
supply
• improper maintenance
• any other misuse, abuse, or mishandling
Familiarize yourself with this important safety information before proceeding with product installation.
WARNING: Do not operate the Virtuo Floor Stand without the integrated
subwoofer and the base plate attached.
The subwoofer and the base plate are integral components to maintaining
the Virtuo Floor Stand’s stability, and both must remain attached to the
Virtuo Floor Stand at all times when in operation.
WARNING: The handles and wheels on the Virtuo Floor Stand are intended
to facilitate tilting the Floor Stand backwards and rolling the Floor Stand into
its base WITHOUT a Virtuo mounted.
Reclining the Floor Stand and/or rolling it on its wheels with a Virtuo
mounted presents a serious risk of human injury. The Floor Stand
handles are not lift points with or without a Virtuo mounted to the
Floor Stand.
WARNING: Do not operate the Virtuo Floor Stand without the integrated
subwoofer and the base plate attached.
The subwoofer and the base plate are integral components to maintaining
the Virtuo Floor Stand’s stability, and both must remain attached to the
Virtuo Floor Stand at all times when in operation.
WARNING: This symbol alerts you to the presence of dangerous voltage within the product
enclosure that can be of sufficient magnitude to constitute a risk of electrical shock. Do not
remove the cover or back. There are no user-serviceable parts inside. Servicing must be
performed by qualified personnel only.

Virtuo Floor Stand Guide
Welcome
Disclaimer and important safety information
8
CAUTION: This appliance must not be tipped (except to roll stand with no Virtuo mounted),
shaken, rocked, or climbed upon. Doing so can cause injury or death. This appliance is only
intended for use with the Virtuo SmartJuke.
CAUTION: Do not install this equipment near any heat sources, such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
CAUTION: Do not defeat the safety purposes of the polarized or grounding-type plug. A
polarized plug has two blades with one blade wider than the other. A grounding-type plug
has two blades and a third grounding prong. The wider blade or the third grounding prong
are provided for your safety. If the provided plug does not fit in your outlet, consult an
electrician for replacement of the obsolete outlet.
To prevent risk of fire or electric shock, avoid overloading wall outlets, and do not use
extension cords.
Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
CAUTION: See product enclosure for safety related markings and refer to the product’s
Virtuo manual on the TouchTunes website for additional safety information.
Do not use this apparatus near water of moisture—Do not use this product near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, near a swimming pool, or
anywhere else that water or moisture are present.
Clean only with a dry cloth—and as directed in this document. Unplug this product from
the wall outlet before cleaning.
Do not block any ventilation opening. Install in accordance with the manufacturer’s
instructions—To ensure reliable operation of the product and to protectit from overheating,
put the product in a position and location that will not interfere with its proper ventilation.
Do not let objects or liquids enter the product—as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric shock.
Use only attachments and accessories specified by the manufacturer.

Welcome
Disclaimer and important safety information
Virtuo Floor Stand Guide
9
Refer all service to qualified service personnel. Service is required when the apparatus has
been damaged in any way: such as power-supply cord or plug is damaged; liquid has been
spilled or objects have fallen into the apparatus; the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
The Floor Stand is supplied with a preinstalled DA-415 amplifier in the base. The amplifier in
the Virtuo must be used only to power theFloor Stand’s array speakers andsubwoofer. The
DA-415 amplifier can be used only to power other speakers not included on the Floor Stand,
such as a house system.
Do not add a second amplifier to the Virtuo Floor Stand.

Virtuo Floor Stand Guide
Welcome
Contacting TouchTunes
10
Contacting TouchTunes
If you need help with or have questions about this document, contact TouchTunes by:
• using the email links on the Contacts page on the TouchTunes Dashboard at
https://operator.touchtunes.com.
• calling the TouchTunes 24/7 Service Hotline at 847-353-1954.
To help us assist you more effectively with problem reports, the following information can be required when
contacting TouchTunes Support:
• Virtuo ID.
• The serial number of any component you believe to be defective.
• The date/time of the problem.
• Actions performed immediately before the problem occurred.
• Any additional comments.
If you need assistance with this or any other TouchTunes product, call technical support at 847-353-1954.
We value your comments.

Virtuo Floor Stand Guide 900579-001 Rev 04
Installing the Virtuo Floor Stand
This chapter explains how to install the Virtuo Floor Stand in a location, including how to assemble the
baseplates, mount a Virtuo on the Floor Stand, and wire the speakers and integrated subwoofer.
Topics
Bringing the Virtuo Floor Stand to a location
List of Floor Stand components
Preparing tools for installation
Removing the Floor Stand from the Pallet
Attaching the wheels to the main frame
Assembling the baseplate
Installing and Connecting the Floor Stand Acoustics
Mounting the Virtuo to the Floor Stand
Installing the crossover box
Understanding Floor Stand wiring
Connecting the audio cables to the Virtuo
Connecting the subwoofer and array speaker wires
Wiring the DA-415 amplifier
Securing the wires
Reattaching the back panel
Powering up the Virtuo

Virtuo Floor Stand Guide
Installing the Virtuo Floor Stand
Bringing the Virtuo Floor Stand to a location
12
Bringing the Virtuo Floor Stand to a location
Before you begin, bring the Floor Stand to the area of the location where you intend to install it. This avoids
possibly damaging the unit by moving it afterwards.
IMPORTANT: TouchTunes recommends that you unpack the Floor Stand as closely as possible
to its intended installation location.
CAUTION: The Virtuo is heavy and represents a serious safety hazard if its mounting system
should fail. Installation of the mounting system for the Virtuo should be performed only by an
experienced installer or licensed contractor familiar with standard rigging, mounting and hanging
practices as recognized by a licensed engineer or government agency in your area.

Installing the Virtuo Floor Stand
List of Floor Stand components
Virtuo Floor Stand Guide
13
List of Floor Stand components
A TouchTunes Virtuo Floor Stand is delivered on a pallet, including hardware components and a parts kit.
These tables show the weight and dimensions of the Virtuo Floor Stand.
Before you install the Floor Stand, check that you have received all of the hardware components and that the
hardware components and items in the parts kit are in good condition.
Floor Stand weight
Floor Stand 180 lbs. (82 kg)
Packaging 50 lbs. (23 kg)
Floor Stand dimensions
Width Depth Height
Floor
Stand 37.63 in. (96 cm) 37.63 in. (96 cm) 71.75 in. (183 cm)
Floor
Stand
Crated
34.50 in.
(88 cm) 26.00 in. (66 cm) 77.50 in. (179 cm)

Virtuo Floor Stand Guide
Installing the Virtuo Floor Stand
List of Floor Stand components
14
To check that you have all Virtuo Floor Stand components
1. Verify that you have received these hardware components for Virtuo:
2. Open the Parts kit and verify that it contains these components:
3. Check the condition of the hardware components and parts kit items to ensure they are in good condition.
Component
Quantity Component Description TouchTunes Part Number
1 Floor Stand 700275-100
1 Integrated subwoofer 500w 700280-xxx
1 DA-415 4 channel amplifier 700039-154
2 Array speakers 150w 700283-xxx
1 Crossover box 700282-001
1 right base plate 400933-001
1 left base plate 400934-001
Component
Quantity Component Description TouchTunes Part Number
8 wing screws for Floor Stand 1/4-20 x 2 1/2, zinc plated
4 are attached to the Floor Stand 200099-040
8 washers, flat, no.10, zinc plated, to be used with 200099-040
4 are attached to the Floor Stand 200134-001
2 brackets for baseplates length 2-3/8 x width 3-23/32 x thickness 0.097,
galvanized steel 400951-001
8 screws for the baseplates Phillips, truss head, 1/4-20 x 1/2, zinc plated 200125-008
2 speaker wire, HAR, 18AWG speaker wire, 48" for array speakers 300703-048
1 18AWG speaker wire, 72” for subwoofer 300704-072
6 HWR, dome plug, 3/8", black nylon to plug holes if array speakers
not installed 400953-006
6 FAS, SCR, X-PAN,10-24x1/2,ZN for wall bracket installation 200128-008
2 36’ CAT-5 harness 300142-036
1 power cable for amplifier, HAR, A/C Power Cord 72" 300180-072
2 Euroblock connectors, ECP, EURO TERM BLOCK CONN, 4-PIN 100000-001
1 Virtuo Floor Stand Guide (this manual) 900579-001
Rev 04
CAUTION: Do not attempt installation if any hardware component or item in the parts kit is
damaged. Contact your distributor or TouchTunes to report the damage immediately and
request replacement parts.

Installing the Virtuo Floor Stand
Preparing tools for installation
Virtuo Floor Stand Guide
15
Preparing tools for installation
You may require these tools to install the Floor Stand. Ensure that you have all the tools at hand before
beginning the installation:
• spirit level to ensure the Floor Stand and the Virtuo are level
• Phillips #2 screwdriver
• Phillips #3 screwdriver
• 3/8 inch open ended wrench
• 3/16 inch Allen Key (Hex Key)
• tie wraps for securing wires

Virtuo Floor Stand Guide
Installing the Virtuo Floor Stand
Removing the Floor Stand from the Pallet
16
Removing the Floor Stand from the Pallet
The Floor Stand arrives bolted to a pallet, with the Floor Stand’s wheels also attached to the pallet with wood
screws. In order to remove the Floor Stand from the pallet and assemble it, you will need to:
- Remove the wheels from the pallet
- Detach and remove (temporarily) the subwoofer from the floor stand
- Detach and remove the Floor Stand from the pallet
- Re-insert and fasten the subwoofer to the base of the Floor Stand
- Bolt the wheel to the rear-base of the Floor Stand
- Assemble the baseplate
- Roll the Floor Stand into the baseplate and secure it
- Use the levellers as needed to ensure the entire Floor Stand is stable
Removing the Wheels
Begin by removing the wheels from the pallet and any duct tape on the base of the Floor Stand.
CAUTION: The subwoofer weights 70 lbs. (31.8 kg), so exercise care in moving it.

Installing the Virtuo Floor Stand
Removing the Floor Stand from the Pallet
Virtuo Floor Stand Guide
17
Removing the Subwoofer (temporarily)
Unbolt the and remove the integrated subwoofer from the Floor Stand and place it aside. There are 6 bolts
securing it to the Floor Stand. You will be permanently reinserting it and re-attaching it momentarily.
WARNING: Do not operate the Virtuo Floor Stand without the integrated subwoofer and the base
plate attached.
The subwoofer and the base plate are integral components to maintaining the Virtuo Floor
Stand’s stability, and both must remain attached to the Virtuo Floor Stand at all times when in
operation.

Virtuo Floor Stand Guide
Installing the Virtuo Floor Stand
Removing the Floor Stand from the Pallet
18
Removing the Floor Stand from the Pallet
Remove the 4 bolts securing the Floor Stand to the pallet using the open ended 3/8 wrench. Carefully remove
the Floor Stand and set it on a level surface.
WARNING: The Floor Stand handles are not lift points and must not be used to remove the Floor
Stand from the pallet.

Installing the Virtuo Floor Stand
Removing the Floor Stand from the Pallet
Virtuo Floor Stand Guide
19
Re-Inserting the and fastening the subwoofer
With the Floor Stand resting on a level surface, re-insert the subwoofer and bolt it in place securely.

Virtuo Floor Stand Guide
Installing the Virtuo Floor Stand
Removing the Floor Stand from the Pallet
20
Attaching the wheels to the main frame
Assembling the baseplate
Remove the wheels from the pallet if you have
not done so already, and use the use 8 bolts
andwashers providedto attachthe two wheels
to the base of the Floor Stand.
The baseplate consist of a right and left piece that
combine to form a horseshoe. The Floor Stand is
then rolled into this plate and secured.
Connect the two baseplate pieces as shown with the
right piece on top of the left piece.
Front of the Floor Stand
