tousek PULL T8 User manual

Mounting and istallation manual
PULL T8, -T10, -T15 Master / Slave
sliding gate openers for opposite sliding gates
Safety Sensor
b
y
T
Ü
V
-
S
ü
d
I
N
I
T
I
A
L
T
E
S
T
UNDER
EN 13241-1*)

- 2 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
This manual is the sole property of the TOUSEK Ges.m.b.H. and may not be made available to competitors. All rights reserved. No part of it may be reproduced without our prior
written permission. We will not accept liability for any claims resulting from misprints or errors. This edition of the manual replaces all earlier publications of the same.
Index
General warning and safety details.................................................................................................................. 3
1. Notes, general characteristics, function, technical data ................................................................................... 4
2. Mounting ........................................................................................................................................................ 5
3. Control unit, overview ..................................................................................................................................... 8
Connection Master- Slave control unit ................................................................................................. 9, 10
Programming, Stucture of the menu................................................................................................... 12, 13
Connections and adjustments ................................................................................................................. 14
Switches / Buttons .............................................................................................................................. 14
Safety.................................................................................................................................................. 16
Motor................................................................................................................................................... 20
Operating mode .................................................................................................................................. 21
Lamps / Lights .................................................................................................................................... 22
Diagnosis ............................................................................................................................................ 24
4. Emergency release in case of power failure (note for the user) .................................................................... 25
5. Change of euro standard cylinder ................................................................................................................. 25
6. Connection of radio receiver ......................................................................................................................... 26
7. Optional DIN rail for mounting of additional equipmen .................................................................................. 27
8. Initial operation ........................................................................................................................................ 28–30
9. Error diagnosis ............................................................................................................................................... 32
10. Cable plan ...................................................................................................................................................... 33
11. Dimensioned drawing..................................................................................................................................... 34
Declaration of incorporation .......................................................................................................................... 35

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 3 -
GENERAL WARNING AND SAFETY NOTES
• These installation and operating instructions form an integral part of the product “sliding gate operator”. They have been
specically written for professional installers trained and skilled in the trade and should be carefully read in their full length
before carrying out the installation. They describe the proper installation and operation of the sliding gate operator only,
not of the overall device “automatic gate”. After the installation this manual has to be handed over to the user.
• Installation, connection, adjustments, putting into operation, and servicing may only be carried out by trained profession-
als in full accordance with these installation- and operating instructions.
• Before carrying out works at the gate-system, the power supply has to be turned o󰀨.
• The EU Machine Directive, laws and rules concerning the prevention of accidents, and laws and standards which are in
force in the EU and in the individual countries have to be strictly followed.
• The TOUSEK Ges.m.b.H. cannot be held liable for any claims resulting from disregards of the laws and standards in
force during the installation and operation.
• The packaging materials (cardboard, plastic, EPS foam parts and lling material etc.) have to be properly disposed of
in accordance with the applying recycling- and environmental procection laws. They may be hazardous to children and
therefore have to be stored out of children´s reach.
• The product is not suitable for installation in explosion-hazardous areas.
• The product may only be used in accordance with its original purpose, for which it has been exclusively designed, and
which is described in these installation and operating instructions. The TOUSEK Ges.m.b.H. rejects any liability if the
product is used in any way not fully conforming to its original purpose as stated herein.
• Children have to be instructed, that the gate facility as well as the belonging parts may not be used improperly, e.g. for
playing. Furthermore handheld transmitters have to be kept in safe places and other impulse emitters as buttons and
switches have to be installed out of children‘s reach.
• Before beginning with the installation the installer has to make sure that all mechanical components of the gate facil-
ity, like carrier prole/rail, gate frame and panels, guiding elements etc. are su󰀩ciently supportive and resistant for the
purpose of gate automation.
• All electrical installations have to be made in full conformity with the applying rules and laws (e.g. using a fault current
circuit breaker, proper grounding etc.).
• An all-pole disconnecting main switch with a contact opening-gap of minimum 3 mm has to be foreseen.
• The electric motor heats up during operation. Therefore the device should only be touched after it has cooled o󰀨.
• After installation the proper function of the gate facility and the safety devices has to be checked!
• The TOUSEK Ges.m.b.H. rejects any liability for claims resulting from usage of the product in combination with compo-
nents or devices which do not fully conform to the applying safety laws and rules.
• Only original spare- and replacement parts may be used for repair of the product.
• The installer has to inform the user about all aspects of the automatic operation of the complete gate facility, as well as
about emergency operation. The installer further has to supply to the user all instructions relating to the safe operation
of the gate facility. The installation and operating instructions also have to be handed over to the user.
• Please notice that the warranty will not be applicable if the label with the engine number has been removed or
damaged.
Maintenance
• Maintenance works may only be carried out by qualied personnel.
• Check the proper sensitivity setting of the ARS safety reverse system once a month.
• Check the proper function of the emergency release mechanism periodically.
• Check if all mounting screws are securely fastened periodically.
• Remove dirt deposits from the operator and gear rack periodically.
• Maintenance and servicing of the complete gate facility has to be carried out according to the gate builder´s/
installer´s instructions.

- 4 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Characteristics PULL T8, -T10, -T15
• Programmable control panel accessible from exterior with
illuminated display in english
•
Direct connection of 8,2 kOhm contact barriers (safety sensing edges (2-channels)
• Three operating modes (impulse, automatic and dead man)
• Adjustable partial opening
• Built in control board in separate housing
• Safety system ARS (automatic reversal system)
• Self locking worm gear
• Emergency release, lockable with prole half cylinder (3 keys included) -
changeable, thus incorporation into an existing house key system is possible.
• Self learning end positions (limits)
• Drive unit (gearbox unit) made of steel and runs in an oil bath
• Permanently selearning force
• Adjustable soft stop (no loss of force even with reduced revolution speed)
• worm gear and worm wheel made of tempered steel
•
1. General Sliding gate operator PULL T8, -T10, -T15 / Master-Slave
Technical data
Sliding gate opener
PULL- T8 T10 T15 T8 T10 T15
control board integrated max. drive 30m
Power supply 230V a.c., 50Hz duty cycle in S3 mode 40% 40–60%
max. current consumption
(excl. equipment) 1,6A 1,9A 2,2A Ambient temperature -20°C bis +40°C
Gear wheel Z20M4 Z16M4 Protection class IP44
max. gate weight 800kg 1000kg 1500kg Torque sensor
Spees 11m/min 9m/min Art.no.. Master 11110430 11110640 11110680
Torque 25Nm 30Nm Slave 11110440 11110650 11110690
optional equipment pluggable receiver • additional module für courtyard/control lamp • additional module for gate status •
bracket incl. top hat rail • radio transmission systemTX 310 • iinductive system TX 400i
Motor selection by using a spring scale T8 T10 T15
Attach the spring scale to the gate at approx. the height of the rack. Then pull
horizontally and without rocking at motor speed. Compare the max. detected
tractive force with the guide values listed on the right.
up to
30kg
up to
40kg
up to
60kg
General
During the development of the new operator generation Tousek PULL T8, -T10, -T15 special attention has been paid to a quick and simple in-
stallation and a troublefree operation, together with the proven quality and reliability. Accordingly, many clever details have been built into the
operator - from the automatic learning of gate end positions, to the control board with removable clamps an integrated safety sensing edge
analysis, to an easy programmable text display - which make it particularly user-friendly. The drive unit itself consists of an electric motor and
a worm gearing, accommodated in a robust aluminium housing, and - together with the integrated microprocessor control unit and the safety
reverse system ARS - forms a compact device with small overall dimensions. The safety reverse system ARS senses obstacles during open-
ing and closing of the gate and permits a continuous adjustment of the drive force. Following the Tousek tradition, all operator components have
been built in a particularly robust and resistant way to guarantee the safe and reliable operation even in the most adverse weather conditions.
Additional improvements are for example: control board with display is accesible from outside, the separate control board housing, which double
protects this sensible part, or an oil bath which ensures that the motor/gearing components can move in an optimal way in all temperatures with
perfect lubrication and cooling e󰀨ect. The installation of the PULLT8 is possible for new or already exsting sliding gates in a simple and fast way.
Functions
The integrated control board has three operation modes : impulse mode (with button/switch function open and close), automatic mode
(automatic closing) and dead-man mode (the gate moves as long as the button/switch is pressed)
Not only the possibility of connecting a button/switch OPEN / CLOSE / STOP, photocells and a safety device, but also a pedestrian entry
button/switch which enables the partial opening of the gate. The system has 230V output terminals, for connecting a signal lamp. Further it´s
equipped with slots for a pluggable radio receiver and an additional module (for courtyard lamp or for evaluating the gate state).

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 5 -
2. Installation Sliding gate operator PULL T8, -T10, -T15 / Master-Slave
General installation notes
Before installing the Tousek PULL T8, -T10, -T15 sliding gate operator we recommend checking the following points:
• Checking the gate structure:
On a gate which travels on oor rails please check the bottom rollers and the upper guide rollers and make
sure that there is no undue friction or jamming.
On a cantilever gate please check if the gate can be moved out of its end-positions without undue e󰀨ort.
• The gate must travel in a stable manner without lateral movements of the gate panel.
• Make sure that the gate travels in a regular way without undue friction or jamming along the whole travel length.
• Make sure that there are stoppers at both ends of the track, preventing the gate from running over its travel limit.
ATTENTION !
• ATTENTION: Mechanical limits are necessary!
• ATTENTION: the sliding gate operator has been developed and designed for the automation of horizontally
travelling sliding gates. Gates on sloping tracks (i.e. gates which follow an inclined, non-horizontal, travel
path) must not be automated without additional safety devices (which make sure that the gate cannot start
moving on its own from any gate position).
2
5a
11
3
1
4a
4
5
6
6a
6b
9
10
12
8
7
or
P
(5) Control board
(Display and control buttons)
(5a) Removable display cover
(6) Control housing
(6a) Cover for optional, pluggable
radio module
(6b) Indication for opt. additional module
(7) Sensor
(8) Motor condenser
(9) Motor-/gear unit
(10) Threaded hole for attachment of
motor cover
(11) Motor cover
(12) optional DIN rail or angle with DIN rail
can be bolted at position (P) 3x:
e.g. for two devices with 11 pole plug
socket
(1) Lockable emergency release (PHZ)
(2) Gear wheel
(3) Cable ttings
(4) Ground plate
(4a) Slotted holes (4x) for mounting on
the foundation/ground
Technischer Aufbau PULL T8, -T10, -T15 Master

- 6 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
NOTE concerning cable layout
• The electric cables have to be laid in insulating sleeves which are suitable for underground usage. The insulat-
ing sleeves have to be lead into the inner of the operator housing (see picture).
• 230V cables and control lines have to be laid in separate sleeves.
• Only double-insulated cables, which are suitable for underground usage (e.g. E-YY-J) may be used.
• In case that special regulations require another type of cable, cables according to these regulations have to be
used.
2.1 Installation of the motor In Installation
(1) lockable emergency release (PHZ)
(2) gear wheel
(3) cable
(4) ground plate
(4a) slotted holes (4x) for connection on
the ground
(Z) steel gear rack
After installing the protection tubes (check cable exit of operator (3)) and having nished the concrete foundation, the
motor has to be bolted through the 4 slotted holes (4a) to the concrete foundation. It is particularly important that the
operator is mounted parallel to the gate panel, and that the measurements given in the drawing are kept.
22
121 (PULL T8) 113 (PULL T10) 117 (PULL T15)
25
2
Z
4
1
3,4
Gear wheel:
PULL T8: Z20M4, r44
PULL T10 , -T15 : Z16M4, r36
63 67 (PULL T15)
Ground plate PULL T8, -T10 Installation of the motor
• Dimensions in mm
• depth of ground plate: 8mm
43
4a
85
52
272
48,5
58,5
40 13,5
119,5
309
30,530,5
18,5 18,5

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 7 -
approx.
1mm
Attention
• Do not weld the individual gear rack elements
together!
• Disengage the motor from the output drive pinion with
the emergency release lever (see emergency release for
instructions) and open the gate completely.
• Install the spacer tubes (D) with the help of the bolts and
washers on the rst meter of gear rack
• Make sure that the bolts/screws sit in the top end of the
vertical slots (L), then tighten them.
• Place the rst gear rack element on the drive pinion and
x it in place with a screw clamp.
• Move the gate by hand until reaching the end of the rst
gear rack element, then weld the rst, second, and third
spacer tube to the gate
• Proceed with the other gear rack elements in the same
manner.
• Before xing the second meter of gear rack it is es-
sential to place another gear rack element under the
rst and second gear rack elements, thereby making
sure that the gearing module between the two gear
rack elements will be exactly kept (see illustration).
• After installation of the gear rack please loosen the
fastening bolts slightly and rise the gear rack a little
along the vertical slots, creating a distance of approx.
1 mm between the ank of the drive pinion and the
gear rack.
• The gear rack elements can also be installed without weld-
ing, i.e. by screwing them to the gate frame together with
the spacer tubes. Apart from that the gear rack elements
have to be installed in the same manner.
2.3 Dismantling
The dismantling of motor is made the other way around of mounting.
Before dismantling please plug o󰀨 power supply of motor !
2.2 Installation of the gear rack Installation
L
D
Ground plate PULL T15 Installation of the motor
• Dimensions in mm
• depth of ground plate: 12mm
4a
272
48,5
58,5
75 13,5
119,5
309
30,530,5
18,5 18,5
3
3
50
25
4

- 8 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Ringkabelschuh für
Erdungsanschluss
Grounding
The grounding connection is made
on the operator housing with the
designated grounding screw!
Elements of control board
(K) Terminal blocks
(KM) Motor clamps
(C) Condenser plug
(S) Sensor plug
(D) Display plug
(B) System connector (for connection
Master/Slave)
(N) Connection emergency release cable
(FE) Slot for optional radio receiver
(see page 26 for connection)
(ZM) Connection slot for optional modulel
(see page 23 for connection)
(F) Safety fuse T 3,15A
3. Control board Sliding gate operator PULL T8, -T10, -T15 / Master-Slave
Attention
During connection, adjustment and
maintenance works please take care,
that the electronic circuit board won´t
be damaged by moisture (rain).
Important
The optional „tousek-connect“ or the
„tousek service interface“ must
be connected with socket (D)!
Overview of the control board
K
KM F
FE ZM
S
D
C
N
88 89
B

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 9 -
3.1 Terminal assignment Sliding gate operator PULL T8, -T10, -T15 / Master-Slave
Grounding
The grounding connection is made on the operator
housing with the designated grounding screw!
see gure page 8
Signal lamp 230V, 100W
Power supply 230V a.c.
Contact for photocells
Common photocell contact
Power supply photocell receiver
Power supply photocell transmitter
Power supply common photocell
Main safety edge
Side safety edge
Common contact safety edge
Pedestrian - switch
CLOSE - switch
common
impulse - switch
STOP - contact
Power supply
max. 24Va.c., 5W
40
41
43
45
46
31
37
32
30
33
34
52
51
50
1
2
10
11
85
84
86
24V
~
L
N
8.k2
8.k2
L
N
black
Motor connection
red 230V a.c. blue
pre-wired
Motor condenser
24V
~
Master control unit Terminal assignment
The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide
the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation!
Safety sensing edges
Function main safety sensing edge (MCE):
Safety during closing
Function side safety sensing edges (SE):
Safety during opening
MCE
SE
CLOSE OPEN
If no stop switch is connected, termi-
nals 31/37 have to be wire-bridged.
Connection Master /Slave control unit
• For the connection of the master and slave control unit connect the
terminals 88 and 89 in the system connector to each other.
• Max. cable length between the operators: 25m.
• Cable type e.g.: PVC control cable YSLY 2 x1mm2or equivalent.
88 89
B
SLAVE control unit
88 89
B
High Low
Bus system

- 10 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Slave control unit Terminal assignment
40
41
43
45
46
31
37
32
30
33
34
52
51
50
1
2
10
11
85
84
86
L
N
8.k2
8.k2
L
N
black
Motor connection
ret 230Va.c. blue
pre-wired
Motor condenser
Signal lamp 230V, 100W
Power supply 230V a.c.
Main safety sensing edge
Side safety sensing edge
common contact safety edge
Jumper (must not be removed!)
Power supply
max. 24Va.c., 5W
Grounding
The grounding connection is made on the operator
housing with the designated grounding screw!
see gure page 8
• During connection, adjustment and maintenance works please take care, that the electronic circuit
board won´t be damaged by moisture (rain).
Connection Master /Slave control unit
• For the connection of the master and slave control unit connect the
terminals 88 and 89 in the system connector to each other.
• Max. cable length between the operators: 25m.
• Cable type e.g.: PVC control cable YSLY 2 x1mm2or equivalent.
Safety sensing edges
Function main safety sensing edge (MCE):
Safety during closing
Function side safety sensing edges (SE):
Safety during opening
MCE
SE
CLOSE OPEN
88 89
B
MASTER control unit
88 89
B
High Low
Bussystem

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 11 -
Warning
• Before taking o󰀨 the control cover, the
mains switch must be turned o󰀨!
• If the control is power supplied, its inner part is under tension.
• In order to avoid electrical strokes, the safety regulations have to be kept.
• The device may only be connected by trained professionals.
• The product is not suitable for installation in explosion-hazardous areas.
• An all-pole disconnecting mains switch with a contact opening gap of min. 3 mm has to be foreseen. The gate
facility has to be secured according to the valid safety regulations!
• IMPORTANT: The control lines (buttons, radio, photocells, etc.) have to be laid separately from the 230V lines
(supply line, motors, signal lamp).

- 12 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
• Before starting the programming, please choose the language. Use the buttons +or -to choose menu
language and conrm with .
• The language must be set in the master and in the Slave control board.
Note: Language selection can also be chosen by pressing the ESC button ( ) for 5s, from any posi-
tion in menu.
• The program menu of the MASTER control is divided into “BASIC SETTINGS” and “MENU CONTROL”
• The program menu of the SLAVE control includes only the “MAIN MENU”.
The di󰀨erent menu points are indicated as follows:
= selectable settings = factory settings = status display
Gshows the menu points which are in the “ BASIC SETTINGS”
BASIC SETTINGS
• When entering the programming of the control unit for the rst time you will see the BASIC SETTINGS
(see initial operation page 27).
• Here the necessary adjustments which are necessary for the use of the operator/gate can be set quickly.
• For advanced settings/programming please choose the menu point “menu (control)”.
MAIN MENU
• For futher programming you will reach immediatly the MENU (CONTROL) (Basis settings are skipped)
• The menu control includes all kinds of settings, whereas in the slave control board only a part of the menu options
described in the menu structure ( see page 13) can be selected (marked with “M / S”).
All other functions are taken over by the master!!
Programming buttons
Programming menu Adjustments/overwiev
3.2 Adjustments - overview Sliding gate operator PULL T8, -T10, -T15 / Master-Slave
A
T
• For programming please remove cover (A) of control
device (loosen 2 bolts).
• The text display (T) informs you ou about operating status,
chosen menus and the adjustment of various parameters..
• The programming of the control is carried out with the help
of four buttons (+, -, (=Enter) and (=Escape).
• Scrolling through the available menu points (up/
down) or the adjustment of a parameter (value in-
crease/decrease) is carried out with buttons + and –..
AUTO-COUNT: when holding one of the buttons the value
changes automatically.
• When pressing the -button a conrmation for entering
the shown menu point, resp. for accepting the shown value
of a parameter is given.
• When pressing the -button you return to the superior
menu point. Possibly changed adjustments of a parameter
are rejected with this button (the former values will remain).
• AUTO-EXIT: if no button is pressed during 1 min. then the
menu switches automatically to the “ready” menu (wihtout
saving changed parameters).

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 13 -
Main layer Sub layer Settings/adjustments
Button/Switch
see page14 M
impulste switch 
OPEN/STOP/CLOSE
 OPEN/CLOSE/ OPEN
 OPEN
 DEAD MAN
*) if impulse button is
set to DEADMAN, then
the pedestrian and
close button are also
set automatically to
DEADMAN mode.
(not selectable under
„pedest.- button“)
M
pedestrian button 
OPEN/STOP/CLOSE
 OPEN/CLOSE/ OPEN
 OPEN
 DEAD MAN*)
Safety
see page 16
MGphotocell  activ
 not activ
M/S
G
Main safety sensing edge
 activ
 not activ
 radio edge TX
 TX 400
M/S
G
Side safety sensing edge
 activ
 not activ
 radio edge TX
 TX 400
M
photocell funtion  reverse when closing
 stop, after release open
 during closing stop, then close
M
photocell pause time  no inuence
 abort pause ttime
 re-start pause time
 after opening close immediately
Mphotocell test  activ
 not activ
Motor
see page 20
M/S max. force  25...100% [ increment 5] = 70%
M/S ARS-response time  0,15...0,95s [ increment 0,05] = 0,50s
M/S speed  65...100% [ increment 5 ] = 100%
M/S soft stop distance  0...2m [ increment 0,1] = 0,5m
M/S soft stop spped  30...60% [ increment 5 ] = 50%
M/S end position OPEN  0...-30 [ increment 1] = -5
M/S end position CLOSED  0...-30 [ increment 1] = -5
Operating mode
siee page 21
M
impulse logic  Stop, Start of pause
 impulse elimination during opening
 pause time extension
M/S Gopening direction  <<<–left
 –>>> right
MGoperating mode  impulse mode
 automatic 1...255s [ increment 1]
Mpartial opening  10...100% [ increment 1] = 30%
M
automatic mode  complete/partial opening
 only complete opening
 only partial opening
Mpause time logic  no inuence
 constant open in automatic mode
M
motor partial opening  Master
 Slave
 Master and Slave
Lights/Lamps
siee page 22
Mprewarning OPEN  OFF, 1...30s = OFF
Mprewarning CLOSE  OFF, 1...30s = OFF
M
additional module  courtyard lamp/control lamp
 gate status1
 gate status 2
Mcourtyard lamp 1)  OFF 5...950s = OFF
M
control lamp 1)  on at opening and closing
 ashes slowly/illuminates/ashes faster
 illuminaTES IN OPENNG POSITION
Diagnosis
see page 24
M/S status disply  status display of all inputs
Mdelete positions  NO
 YES
Mfactory settings  NO
 YES
M/S software version  show software version
M/S serial number  show serial number
M/S protocol  show protocol notes
M/S status sensor  show sensor
1) The menu points courtyard lamp and control lamp will only appear on display if in menu
„Additional module“ courtyard lamp/control lamp is selected.
Menu structure Adjustments/overwiev
+
–
control board PULL T8, -T10, -T15 / Master-Slave
ESC ENTER
Note: some adjustments regarding function or operating logic can only be executed if gate is closed and if the display shows „ready“.
M selectable in Master control unit
M/S selectable in Master- und Slave control unit

- 14 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
• Before taking o󰀨 the control cover, the
mains switch must be turned o󰀨!
• If the control is power supplied, its inner part is under
tension.
• In order to avoid electrical strokes, the safety regula-
tions have to be kept.
• The device may only be connected by trained profes-
sionals.
• The product is not suitable for installation in explosion-
hazardous areas.
• An all-pole disconnecting mains switch with a contact
opening gap of min. 3 mm has to be foreseen. The
gate facility has to be secured according to the valid
safety regulations!
• IMPORTANT: The control lines (buttons, radio, pho-
tocells, etc.) have to be laid separately from the 230V
lines (supply line, motors, signal lamp).
Warning notes
• A general status display of all inputs can be found in the menu DIAGNOSIS / STATUS DISPLAY
3.3 Connections and adjustments PULL T8, -T10, -T15 / Master-Slave
The di󰀨erent menu points, that can be selected in the Master control board (= M) or in the Master and in the
Slave control board (= M/S ) are indicated as follows:
= selectable setting (or possible value assignment) = factory settings = status display
Gshows the menu points which are in the “ BASIC SETTINGS” of the Master control board
Furthermore connection notes and other instructions are indicated as follows
M= regards the Master control board M/S = regards the Master ans Slave control board
As impulse emitters pushbuttons or key switches as well as external radio receivers with potential free make
contacts can be used.
Impulse switch (terminals M30/32) MButtons/switches
OPEN/ STOP / CLOSE impulse repetition (factory settings): After a command of the impulse switch the motor starts
an open or close movement. If the impulse switch is pressed again during this movement, the motor stops. With the
next command, the motor drives in the opposite direction of the last gate movement.
OPEN / CLOSE / OPEN impulse repetition: After a command of the impulse switch the motor starts an open or close
movement. If the impulse switch is pressed again during this movement, the motor reverses.
•In this operation mode it is not possible to stop the motor with the impulse switch – it always
travels until reaching an end position. (Opened or closed position).
• for the function OPEN/CLOSE/OPEN we strongly suggest the installation of a photocell!
OPEN: Only open commands are accepted of the impulse switch. Closing the gate with the impulse switch is not
possible.
DEAD-MAN: The motor opens as long as the impulse switch is pressed – closing the gate with the impulse switch
is not possible. As soon as the switch is released, the gate stops. If hold to run operating mode is selected, the radio
receiver slot (FE) is set out of order for reasons of safety.
IMPORTANT: Do not put into operation in dead man mode.
Select only after putting into operation (see page 27), if desired.
Buttons/switches Connections and adjustments

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 15 -
As impulse emitters pushbuttons or key switches as well as external radio receivers with potential free make
contactscan be used.
Pedestrian opening button (terminals M30/34) MButtons / switches
OPEN/ STOP / CLOSE impulse repetition: An impulse through the pedestrian button-while the gate is in motion-
causes gate stopping. If the gate is within the pedestrian area, then an impulse through the pedestrian button causes
inversion of the direction.
If the gate is in complete open position an impulse through the pedestrian button causes a movement in CLOSE di-
rection and the gate stopps at pedestrian OPEN position.
OPEN / CLOSE / OPEN impulse repetition:
If the gate is within the pedestrian area, then an impulse through the
pedestrian button causes inversion of the direction.
If the gate is in complete open position an impulse through the pedestrian button causes a movement in CLOSE direction
and the gate stopps at pedestrian OPEN position.
•In this operation mode it is not possible to stop the motor with the pedestrian button – it always
travels until reaching an end position. (Opened or closed position).
• for the function OPEN/CLOSE/OPEN we strongly suggest the installation of a photocell!
OPEN: Only open commands are accepted of the pedestrian opening button. Closing the pedestrian entry with the
button is not possible.
DEADMAN (not selectable): As soon as the Impulse button is set to DEADMEN, automatically the pedestrian- and the
CLOSE button are set to DEADMEN.
The motor opens as long as the pedestrian button is pressed – closing the gate with the pedestrian button is not
possible. As soon as the switch is released, the gate stops.
As CLOSE-buttons you may use pushbuttons or key switches as well as external radio receivers with potential
free make contacts can be used.
CLOSE-button (terminals M30/33) Buttons / switches
•A command with the CLOSE-switch engages closing of gate. In deadman mode the gate closes as long as the
CLOSE-switch is pressed/switched. As soon as switch is released the gate movement stops.
STOP-switch (terminals M/S 31/37) Buttons / switches
• when pressing the stop switch the gate stops in any desired position.
As stop switch a break contact has to be used.
If no stop switch is connected, terminals 31/37 have to be wire-bridged.
37
31
The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide
the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation!

- 16 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Photocells
• The control unit has a power supply connection for a 24V a.c. photocell (LS):
supply LS-transmitter: terminals 40/41 / supply LS-receiver: terminals 40/43.
Note: in „gate closed“ position the terminals 40/41 are being switched into energy saving mode - no current
(only if no radio transmission system TX 310 is used) !
• The contact has to be closed when using powered and positioned photocells (opening contact).
Connection of the photocell contact: terminals 45/46
• When using two pairs of photocells please do not
install both photocell transmitters/receivers on the
same side (to eleminate interference between both) !
Exception: photocells with SYNC function allow the
installation of both photocell transmitters/receivers on
the same side without causing interference to each
other.
• Photocell self-test function: The control unit has a monitoring function for the connected photocells. A test is triggered
by each impulse and will be checked if the receiver of the photocell responds to the signal from the photocell transmit-
ter. If there is no communication between the photocell receiver and transmitter the control unit responds with an error.
The deactivation of the self-test function is only allowed if the safety installations correspond to the category 3 !
• The exact function of the photocells depend on the programming of the control unit.
Photocell function please see menu point SAFETY / photocell function or photocell with pause time (page 19)
• More detailed information in the corresponding photocell manual.
Important
• Jumper J of transmitter and receiver has to
be adjusted in the same way.
Standard:
Trasmitter1 Receiver 1
Receiver 2 Trasmitter 2
mit SYNC-Funktion:
Trasmitter1 Receiver 1
Trasmitter2 Receiver 2
GPhotocell (contact: terminal 45/46) MSafety
activ: to be selected, if photocell should be triggered.
not activ: to be selected, if photocell should not be triggered.
Photocell - connection examples
Photocell Tousek LS 26
as safety device
46
45
43
41
40
+
~
-
~
12/24V
J
+
~
-
~
12/24V
NC C NO
J
Trasmitter Receiver
Sicherheit Connections and adjustments
M

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 17 -
Activation of SYNC-function
• To activate the SYNC-function when
you connect two photocells (see notes
on photocells) (see right gure
the plug-in bridges (J) in both photocell
transmitters have to be removed (see
manual LS 41).
SYNC
J
2 Photocells Tousek LS 41 as safety-
device with active SYNC-function
Transmitter Receiver
Transmitter Receiver
Photocell Tousek LS 41
as safety device
Transmitter Receiver
Important
• as the LS 45/2 has no SYNC-function, both photocell
transmitters and receivers must be mounted on dif-
ferent sides!
2 Photocells Tousek LS 45/2
as safety device
Photocells Tousek RLS 610
as safety device
M M
M
M
46
45
43
41
40
24Va.c.
24–230V
a.c./d.c.
COM
NO
NC
COM
N.O. COM N.C.
46
45
43
41
40
N.O. COM N.C.
N.O. COM N.C.
46
45
43
41
40
1 2
+ -
~ ~
12/24V
1 2 3 4 5
+ -
~ ~
12/24V
1 2
+ -
~ ~
12/24V
1 2 3 4 5
+ -
~ ~
12/24V
46
45
43
41
40
transmitter 1 receiver 1
receiver 2 transmitter 2
NO NC COM
NO NC COM

- 18 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Safety sensing edges (main and side edge) M/S
• OBSTACLE DETECTION: when a contact strip/safety
edge is triggered/activated then a change of direction is
e󰀨ected for 1 second. Then the gate stops.
Hence if safety edges have to react on obstacles in closing movement have to be serially connected
to the terminals of the main safety edge.
Safety edges that have to react on obstacles in opening movement have to be serially connected
to the terminals of the side safety edge.
Example: W 8,2kΩ nal resistance
1 Final edge
2+3 passage edge
S to control board
When connecting one safety edge a nal edge (1) has to be used.
Side safety sensing edge
Function:
safety during opening
Main safety sensing edge
Fuction:
Safety during closing
1
W
2 3 S
50
52
50
51
main safety sensing edge Side safety sensing edge
M/S
• Connection and detailed information of radio transmission system TX 310 see according manual.
• C onnection and detailed information of inductive system TX 400i see according manual.
GMain safety sensing edge (terminal 50/52) M/S Safety
activ: to be selected if the contact strip (8,2kOhm) of the main safety sensing edge should be evaluated.
not activ: to be selected if the contact strip of the main safety sensing edge should NOT be evaluated.
Radio transmission TX: to be selected if safety sensing edge (8,2kΩ) of main entrance edge should be evaluated
with the radio transmission system TX 310.
TX 400: to be selected if safety sensing edge (8,2kΩ) of main entrance edge should be evaluated with the system
TX 400i.
GSide safety sensing edge (terminal 50/51) M/S Safety
activ: to be selected if the contact strip (8,2kOhm) of the side safety sensing edge should be evaluated.
not active: to be selected if the contact strip of the side safety sensing edge should NOT be evaluated.
Radio transmission TX: to be selected if safety sensing edge (8,2kΩ) of side entrance edge should be evaluated
with the radio transmission system TX 310.
TX 400: to be selected if safety sensing edge (8,2kΩ) of side entrance edge should be evaluated with the system
TX 400i.
Important
• After giving the impulse to program the end positions, no other impulse must be given. Also the safety devices
mustn´t be triggered. This would lead to an interruption of the programming process.
• Therefore, the mechanical stops must be set so that the existing contact strips cannot be triggered.

tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 19 -
Photocell function MSafety
Reverse at closing: an interruption of the photocell during closing makes the gate reverse (open). In automatic mode
the gate closes as soon as the pause time has run out. In impulse operation another closing command has to be given.
Stop after release open: an interruption of the photocell beam during opening or closing makes the motor stop as long
as the photocell stays interrupted. After release of the photocell, the gate opens. In automatic mode the gate closes as
soon as the pause time has run out, in impulse operation another closing command has to be given.
Stop at closing, after release open: an interruption of the photocell during closing makes the motor stop as long as
the photocell stays interrupted. After release of the photocell, the gate opens.
Photocell with pause time MSafety
no inuence: the photocell doesn’t have any inuence on the pause time in automatic mode.
Immediate closing: in automatic mode an interruption of the photocell during pause time shortens the pause time.
After release of the photocell the gate starts closing.
Restart pause time: in automatic mode an interruption of the outer photocell during pause time, restarts the pause
time. As soon as the pause time has run out, the gate closes.
Close after opening: If the photocell is interrupted during the opening movement, the gate starts closing as soon as
it reached end position open after release of the photocell.
Photocell test MSafety
active: photocell self-test is executed with an opening impulse (switch, button) in gate position „closed“.
not active: photocell self-test is not executed.
Attention
• The photocell self-test can only be deactivated by selecting „not active“.
• The deactivation of the self-test function is only permittedif the safety installations correspond to the
category 3 !

- 20 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Attention
With force adjustment the valid safety regulations and standards have to be strictly followed !
max. force 70% (factory setting) M/S Motor
25–100% adjustable [increment 5]: determines the max. possible motor force.
ARS response time 0,50s (factory setting) M/S Motor
0,15–0,95s adjustable [increment 0,05]: determines, in which time the AR-System responds. The lower the value,
the more sensitive the sensor will react.
Speed 100% (factory setting) M/S Motor
65–100% adjustable [increment 5]: determines the speed of motor.
Soft stop distance 0,5m (factory setting) M/S Motor
0–2m adjustable [increment 0,1]: determines the distance of soft run.
Soft stop speed 50% (factory setting) M/S Motor
30–60% adjustable [increment 5]: determines the speed during soft run.
End position OPEN -5 (factory setting) M/S Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected OPEN limit position of gate (e.g. for
safety sensing edges). With adjustment 0 the motor runs to the previously learned open position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
End position CLOSED -5 (factory setting) M/S Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected CLOSE limit position of gate (e.g.
for safety sensing edges. With adjustment 0 the motor runs to the previously learned close position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
Motor Connections and adjustments
