Toyota TM4875A User manual

Type TM4875A､TM5317A
TM4875B､TM5317B
Wireless VIM for Software Writing
Operation Manual
Rev 1.0.2
Toyota Technical Development Corporation
FA Technology Dept.
Customer Business Div.

Instruction
Form：DP5-005 Revised：05
Revision history
Revised page Revised details Date Created
Newly created. Aug 25,
2020 Mizuno
Additional notes on FCC
A
dditional notes on North American
specifications
1

Instruction
Form：DP5-005 Revised：05 1
Introduction
Thank you for purchasing wireless VIM stations and wireless VIM terminals.
This manual is describing on the operation of this product and safety precautions.
Read this manual to end surely to understand the function of this product and use effectively.
- This product is for 12V vehicle only.
- Save this manual for the user to see at any time.
- Do not use this products at purpose except for the original intended use.
Cautions on radio wave
●These products use 2.4GHz. In this frequency, electronic appliance such as microwave oven,
equipment for science institution or medical, other radio wave station (Bluetooth、Wireless LAN),
licensed internal radio wave station to recognize moving device at plant manufacturing line,
special small power radio wave station without license or ham operation (They are defined as
[Other radio stations].) are operated by this frequency.
●Before use these products, confirm that [Other radio stations] is not operated near these products.
●If these products interfere [Other radio stations], change the location to use, or stop to the other
equipment operation immediately.(Stop the wave transmission)
●Communication with other products of 2.4GHz cannot be performed.
●Do not use the 5GHz band outdoors.
●TM4875A(TM4611-01) is inspected by construction design certification as specific radio equipment
001-P00519
●TM4875A(TM4611-01) corresponds to China [信部无[2005]423 号 微功率(短距离)无线电设].
●TM5317A(TM5317-21) is inspected by construction design certification as specific radio equipment.
008-200362

Instruction
Form：DP5-005 Revised：05 2
FCC CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guidelines. This equipment has very low levels of RF
energy that is deemed to comply without maximum permissive exposure evaluation (MPE).
1

Instruction
Form：DP5-005 Revised：05 3
IC CAUTION
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following
two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation
of the device.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence.
L’exploitation est autorisee aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est
susceptible d’en compromettre le fonctionnement.
This radio transmitter (21131-TM4969) has been approved by Industry Canada to operate with the antenna
types listed below with the maximum permissible gain indicated. Antenna types not included in this list,
having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this
device.
Antenna type: chip antenna Gain:0.5dBi
Antenna type: patch antenna1 Gain:8.1dBi
Antenna type: patch antenna2 Gain:8.1dBi
Le présent émetteur radio (21131-TM4969) a été approuvé par Industrie Canada pour fonctionner avec
les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne non
inclus dans cette liste,et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits
pour l'exploitation de l'émetteur.
Type d’antenne: antenne à puce Gain: 0.5dBi
Type d’antenne: antenne patch1 Gain: 8.1dBi
Type d’antenne: antenne patch2 Gain: 8.1dBi
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and
meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and
operated keeping the radiator at least 20cm or more away from person’s body.
Cet equipement est conforme aux limites d’exposition aux rayonnements enoncees pour un
environnement non controle et respecte les regles d’exposition aux frequences radioelectriques (RF)
CNR-102 de l’IC. Cet equipement doit etre installe et utilise en gardant une distance de 20 cm ou plus
entre le radiateur et le corps humain.
1

Instruction
Form：DP5-005 Revised：05 4
Safety Precautions
This section contains important information that is necessary for using the products safely.
Please be sure to read this safety precaution before using the product.
<Level of risk and injury>
<Explanation of picture indicators>
Indicators Explanation
WARNING This symbol indicates that could result in serious injury or detath.
CAUTION This symbol indicates that could result in injury or property damage.
General caution
Risk of electric shock
●This indicates the possibility of an electric shock under specific conditions.
General prohibition
●This indicates actions that are prohibited when operating this product.
Wet hands prohibited
●This indicates the possibility of an electric shock if the product is operated while
the user’s hands are wet.
Disassembly prohibited
●This indicates the possibility of an electric shock or other injury occurring due to
disassembly of the product.
Exposure to water prohibited
●This indicates the possibility of a short circuit, electric shock, a fire, or other
problem occurring due to exposure to water.
General instruction
Remove the power plug from the power outlet.

Instruction
Form：DP5-005 Revised：05 5
WARNING
Do not insert items inside of the housing.
●There is a risk of electric shock or fire and this may also cause malfunctions.
Do not use with a power source other than the specified power
source.
●There is a risk of electric shock or fire and this may also cause malfunctions.
Do not operate with wet hands.
●This may cause an electric shock.
Do not disassemble or modify the product.
●There is a risk of electric shock or fire and this may also cause malfunctions.
Securely insert the power plug into the power outlet completely
up to its base.
●This may cause a fire due to electric shock and generation of heat.
Regularly wipe dust off of the power plug.
●Dust may cause a fire.
Please remove the power plug from the outlet and wipe it with a dry cloth.

Instruction
Form：DP5-005 Revised：05 6
CAUTION
Use of non-specified parts is prohibited.
●There is a risk of fire and this may also cause malfunctions.
Connection to non-specified devices and cables is prohibited.
●There is a risk of fire and this may also cause malfunctions.
Do not use the product when the cable is in a pinched or bundled
condition.
●There is a risk of fire and electric shock as well as malfunctions due to cable
damage or heat generation.
Do not place other items on top of the product.
●This may cause a fire due to warping or damage to the case.
Do not get the product wet or allow water or solvents to get on it.
●There is a risk of electric shock or fire and this may also cause malfunctions.
Do not use the product in a tightly enclosed place or place a cover on
it.
●This may cause the generation of heat or a fire.
Do not use the product in a place where it may get wet.
●There is a risk of electric shock or fire and this may also cause malfunctions.
Remove the power plug from the outlet before conducting
maintenance or leaving the product unused for a long period.
●There is a risk of electric shock or fire and this may also cause malfunctions.
Turn the power off when attaching and removing the power plug.
●There is a risk of electric shock or fire and this may also cause malfunctions.
Immediately turn the power off when abnormal noise,
abnormal smell, or smoke is produced.
●If the product continues to be used in this state, it may cause an electric shock or
fire due to a short circuit.
A request
Please do not peel off or stain the safety-related indicators.
●This may cause improper use.
This product complies with the WEEE Directive (2002/96/EC) marking
requirement.
Do not dispose in domestic household waste.

Instruction
Form：DP5-005 Revised：05 7
Table of contents
INTRODUCTION ...................................................................................................................................................... 1
CAUTIONS ON RADIO WAVE ................................................................................................................................. 1
SAFETY PRECAUTIONS......................................................................................................................................... 4
TABLE OF CONTENTS ........................................................................................................................................... 7
1. PRODUCT OUTLINE ........................................................................................................................................... 8
1.1 USES ....................................................................................................................................................................8
1.2 FUNCTIONS..........................................................................................................................................................8
1.3 OPERATION ENVIRONMENT ....................................................................................................................................9
1.4 DIAG COMMUNICATION SPECIFICATION ...................................................................................................................9
2.PRODUCT COMPOSITION................................................................................................................................. 12
2.1 COMPONENT PARTS .............................................................................................................................................12
2.2 PART NAMES .......................................................................................................................................................13
3.HOW TO OPERATE ............................................................................................................................................ 17
3.1 MODE SHIFT ........................................................................................................................................................17
3.2 MODE SHIFT FLOW OUTLINE (BY WIRELESS)..........................................................................................................18
3.4 SOFTWARE WRITING SPECIFIATION ....................................................................................................................19
3.4.5 WiFi access point connection .....................................................................................................................21
3.5 PREPARATION......................................................................................................................................................22
3.6 OPERATION .........................................................................................................................................................24
3.7 REWRITING PROGRAM .......................................................................................................................................26
4.MAINTENANCE .................................................................................................................................................. 27
4.1 INSPECTION.........................................................................................................................................................27
5.SPECIFICATION ................................................................................................................................................. 30
5.1 WIRELESS VIM STATION.......................................................................................................................................30
5.2 WIRELESS VIM TERMINAL ....................................................................................................................................33
6.1 PARAMETER FOR WIRELESS ST...........................................................................................................................37
6.2 PARAMETER FOR WIRELESS TERMINAL .................................................................................................................39
7. WARRANTY ....................................................................................................................................................... 40
8. AFTER-SALES SERVICE ................................................................................................................................. 42

Instruction
Form：DP5-005 Revised：05 8
1. Product outline
1.1 Uses
This product is the interface (Shown as I/F) to perform diag communication between TVECSIII and
the vehicle by radio wave.
It is composed by wireless VIM station (Shown as wireless ST) connected to TVECSIII and
wireless VIM terminal (Shown as wireless terminal) connected to the vehicle .
1.2 Functions
Diag communication function
・Vehicle communication (High speed CAN communication) supported by diag CAN prococol
(ISO15765).
・Vehicle communication (ISO9141 K line) supported by KWP2000 diag protocol (ISO14230).
・Vehicle communication supported by diag ehter protocol.
・Vehicle communication compliant with the Diag Ether protocol.
・Setting to radio wave frequency, ID and power of transmittion.
・Prevent the miss reading of the vehicle by BodyNo during radio wave connection.
・CAN-FD (*CAN FD is equipped with only hardware functions.)
ECU reprogramming
・The ECU is reprogrammed using the ECU reprogramming data (.cuw) stored
in the main microcomputer.
Supported communication: CAN, CAN FD (scheduled to be released)

Instruction
Form：DP5-005 Revised：05 9
Figure 1 System configuration
1.3 Operation Environment
This product is connected with TVECSIII.
For operation environment, confirm the condition of TVECSIII operation.
1.4 Diag Communication Specification
Diag communication specification for this product is based on following specification by TMC.
・Phase3 Diag communication specification Ver.P1.13 （Issued 22th Feb, 2002）
・Phase4 Diag communication specification Ver.2.15-c (Issued 13th Jan, 2012)
・Phase5 Diag communication specification
・Phase5 Diag ether communication specification
TVECSⅢ
Power IC
Ethernet
Wireless VIM Station
Main
microcomputer
(OS：Linux)
LED
x8
AC
adapter
Radio control
microcomputer
(OS：None)
shared
memory
Wireless
module
No.1
Wireless
module
No.2
KﾗｲﾝI/F
分圧
SPI
内蔵
ﾌﾗｯｼｭ
(eMMC)
内蔵
Wifi
電源
DART
CAN H
CAN L
K‐Line
Ethernet
Tx,Rx
Activation
+B
SPI
SPI
UART
LANC EtherPHY
&ﾄﾗﾝｽ
A/D
SPI
DLC
ｺﾈｸﾀ
CAN
PHY
制御信号
制御通信
RX63N
ｵﾘｼﾞﾅﾙ
無線
CAN‐FD
ｺﾝﾄﾛｰﾗ
ｱﾝﾃﾅ
DC/DC
GP I O
クレードル
電源
USB
GPI O GP I O
GPI O
電源
GP I O
CableDetect
外部
接続
ｺﾈｸﾀ
Wireless terminal
Terminal
control
device
Cradle
USB
WiFi AP
Ethernet
Original
Ration
Partial
pressure
Antenna
Cradle
Power
Built-in
Wifi
External
connector
DLC
connector
EtherPHY
Trance
K-Line I/F
CAN-FD
Controller
Power
Supply
Built-in
flash
(eMMC)
Power
Supply
Control
signal
Control
signal

Instruction
Form：DP5-005 Revised：05 10
Word explanation
●Operation mode of wireless ST
Status Contents
Search Mode Initial status after start.
Search wireless terminal (Initial mode, Parameter writing wait
mode) by wireless.
Inspection Mode Perform diag communication with the vehicle through wireless
terminal (Inspection mode).
Parameters Write Mode Write parameter for wireless terminal (Parameter write mode).
Write BodyNo mainly.
Maintenance Mode Change wireless ST parameter (Through wired LAN)。
No wireless communication at this mode.
●Operation mode of wireless terminal
Status Contents
Initial Mode Initials status after start in BodyNo wireless registered
terminals.
Wait for test mode transition instruction from wireless ST.
Inspection Mode Diag communication is performed. According to wireless ST
instruction,
Diagnostic program communication with vehicle is
performed, and send communication results to wireless ST.
Mode to confirm write completion result.
Software Write Mode Mode that downloads software write data and performs write.
Parameter Write Wait Mode Status of start at BodyNo delete.
Wait receiving shift instruction to parameter write mode.
Parameter Write Mode Register (write) BodyNo that was instructed by wireless ST
register.
Sleep Mode Modes that is running on power savings.
Shift to sleep mode if set time by initial or parameter write
mode is passed.
●[Radio frequency]
Communication is performed out in setting frequency. it is necessary to match the radio frequency of
wireless ST and wireless terminals for communication.

Instruction
Form：DP5-005 Revised：05 11
●[Wireless ID]
Only if wireless ID is matched, it is functioned as receive filter.
Transmitted data from wireless VIM station are identified by wireless terminals in the same radio
frequency or adjacent frequencies.
However, if it was sent in same frequency, it is impossible to communicate normally because of
interference.
(Specials function for being identified by wireless terminals near line)
Keep wireless ID for inspection mode as ID for parameter write wait mode when BodyNO delete so
that next line is not identified incorrectly when Diag when disconnection confirmation after Diag
inspection.
(Example)
Mode Inspection mode (BodyNo delete) Parameter write wait mode
Wireless ID 01 → 01

Instruction
Form：DP5-005 Revised：05 12
2.Product composition
2.1 Component parts
<Main body>
N0. Item name Type Remarks
1 Wireless VIM Station TM4875A/TM4875B TM4875B：For USA / Canada
2 Wireless VIM Terminal TM5317A/TM5317B TM5317B：For USA / Canada
<Option>
N0. Item name Type Remarks
3 Wireless antenna PA2409S Manufacturer: NATEC
4 Wireless antenna
connection cable
C5SFAL-SPP-EXT10MF Manufacturer: Antenna
Technology
Wire: 5D-SFA-LITE
Connector: SMAP-SMAP
5 POE Splitter
POE Injector
POS-1002
POI-2002-V3
Manufacturer: LevelOne
Input: 100-240V AC
Output: DC12V
6 Wireless VIM station setting
tool
TM3523-07 Use to install wireless VIM station
* For No.3 wireless antenna, not use except for "PA2409S".
PC
Monitor
1. Wireless VIM Station
HUB
LAN Cable
5. POE
TVECSⅢ
2. Wireless VIM
Terminal
3. Wireless
Antenna
4. Wireless antenna connection
cable
RUN
COLLISION
RECEIVE/LINK
COM PORT
PRG
RF LINK
MODE
ANTENNA
WirelessVIM
6. Wireless VIM Station setting tool

Instruction
Form：DP5-005 Revised：05 13
2.2 Part names
《No.1 Wireless ST》
RUN COLLISION RECEIVE/LINK COM PORT PRG RF LINK MODE ANTENNA
DC IN ETHERNET
RESET
RUN PRG
ANTENNA① ANTENNA②
◇Function name
No. Names Marks Purpose
① SMA jack for wireless antenna - Wireless antenna connection
② Status LED - Wireless ST status display (Referto
next content）
③ Status (7 segment) - Radio frequency display (Refer to
next content)
④ DC jack DC IN Power supply connection
⑤ Ethernet connector (RJ-45) ETHERNET PC communication
⑥ Reset switch RESET Wireless ST reset
⑦ Switch for progralm write RUN、PRG Internal program rewriting
①
②
④ ⑤ ⑥
⑦
171 [mm]
40 [mm]
85 [mm]
③

Instruction
Form：DP5-005 Revised：05 14
◇Status LEDs function
Name Color Contents
RUN Green Wireless ST start status
On: Starting （Just after power is supplied）
Blink: Running （Blink 2 sec approximately）
Off: Device power is OFF.
COLLISION Yellow Ethernet collision detection
On: Data collision
Off: Normal
* With RJ-45 connector （COLLISION）
RECEIVE/LINK Green Ethernet link
On: Connection status is good.
Blink: Data communication
Off: Connection is not performed or confirmed.
* With RJ-45 connector（RECEIVE/LINK）
MODE Green Operation status
On: Inspection mode
Blink: Parameter write mode
Off: Search mode
COM PORT Orange Wireless ST diag communication status
On: Communicating
Off: Without communication
ANTENNA Green Antenna
On: ANTENNA 1 is used
Off: ANTENNA 2 is used
RF LINK Green Communication status between wireless
terminals
On: Communicating
Off: Without communication
PRG Green Program rewriting mode
On: Program rewriting mode
Off: Normal operation mode
◇Status (7 segmentLED) function
Display frequency set for Wireless module.
[----] is displayed when wireless communication is stopped.

Instruction
Form：DP5-005 Revised：05 15
《No.2 Wireless terminal》
◇Function name
No. Name Purpose
① DLC3 connector Vehicle connection
② Disconnection prevention lock Wireless terminals disconnection
prevention
③ Status LED Wireless terminals status display
（Refer to followings）
④ FLASH connector For cradle connection
50.0 [mm]
1
24.0 [mm]
4
2
67.4 [mm]
83.4 [mm]
3

Instruction
Form：DP5-005 Revised：05 16
◇Status LED function
Name Color Contents
LINK Orange Communication status between Wireless ST
On: Communicating
Off: Without communication
MODE Orange Operation state
On: Initial mode （BodyNo is registered）
Blink: Inspection mode （Cycle Approx. 2 sec）
Parameter write mode （Cycle Approx. 1 sec）
Off: Parameter write wait mode （BodyNo is not
registered.）
RUN White Wireless terminal starting status
On: Starting （Just after power supply）
Blink:: Operation normally （Cycle Approx. 2 sec）
Off: Device power is off or sleep
WR Green Software write result
On: Software writing success
Blink: Software writing fail
(Cycle Approx. 500 msec）
Software writing processing
(Cycle Approx. 2 sec）
Off: Software writing is not processed
◇Pin configuration
Signal names Marks DLC3
Vehicle
connector
(N.C) - 1
(N.C) - 2
RX+(Ether) RX+ 3
Chassis GND CG 4
Signal GND SG 5
CAN High CAN_H 6
ISO9141 K-Line SIL 7
Activation(Ether) ACT 8
(N.C) - 9
(N.C) - 10
RX-(Ether) RX- 11
TX+(Ether) TX+ 12
TX-(Ether) TX- 13
CAN Low CAN_L 14
(N.C) - 15
Vechicle Battery VB 16

Instruction
Form：DP5-005 Revised：05 17
3.How to operate
3.1 Mode shift
This system performs diag communication, frequency control for BodyNo delete/write process and
judgment to perform process for each stations. So mode control is performed at wireless station
and wireless VIM.
Wireless ST and wireless terminal perform mode transitions by TVECSIII command.
《Wireless ST》
《Wireless terminal》
State Transition Diagram（Wireless VIM Terminal）
Inspection Mode
Parameter Write Mode
パラメータ書込
待機モード
Parameter Write
Wait mode
初期モードInitial Mode
BodyNo
Registration status
BodyNo
unregistered state
Sleep mode
BodyNo
Registered
BodyNo
Registered
Sleep Mode
Software Writing
Mode
RUN
COLLISION
RECEIVE/LINK
COM PORT
PRG
RF LINK
MODE
ANTENNA
LAN
Wireless
TVECSⅢ
1.command 2.Mode transition 3.Mode transition
instruction
4.Mode transition
Wireless VIM Terminal
Wireless VIM Station
State Transition Diagram
（Wireless VIM Station）
Inspection Mode
Parameters Write
Mode
サーチモード
Search Mode
Maintenance Mode
Start-up

Instruction
Form：DP5-005 Revised：05 18
3.2 Mode shift flow outline (By wireless)
Example of process
RUN
COLLISION
RECEIVE/LINK
COM PORT
PRG
RF LINK
MODE
ANTENNA
①BodyNo writing
Wireless
VIM
terminal
Installed
condition
Communication
content
VinNo writing After inspection
Implementation
timing
None
Before inspection
②Diag
communication
Original Ration
Conection Remove
③Software
writing
（DL、VinNo
verification）
WiFi
④Write
completion
⑤Diag
communication
RUN
COLLISION
RECEIVE/L I NK
COM PORT
PRG
RF LINK
MODE
ANTENNA
Original Ration
⑥BodyNo
Deletion None
Wireless ST Wireless ST
Terminal
Software writing Completion
confirmation
