TR-Electronic SSI-BOX User manual

SSI-BOX
Converter for SSI into PROFIBUS-DP
according to PNO-Profile Class 2
SSI-BOX Art.-No.: 489-00004 and variations
Variations
489-00003 (with Incremental-Interface, TTL-Level)
489-XXXXX (with Incremental-Interface, UP-Level 5...24 V)
will be defined!
Please keep for further use !
Edition-/Rev.-Date:
25.04.2012
Document-/Rev.-No.:
TR - E - BA - GB - 0013 - 03
Soft edition:
File name:
TR-E-BA-GB-0013-03.DOC
Author:
MÜJ
TR - Electronic GmbH
Eglishalde 6
D-78647 Trossingen
Telephone ++49 (0)7425 / 228-0
Telefax ++49 (0)7425 / 228-33
Enclosed Disk
Art.-No.: 490-00406

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 2 of 45
Imprint
TR-Electronic GmbH
D-78647 Trossingen
Eglishalde 6
Tel.: [phone]
Fax: [phone]
Copyright 1997 TR-Electronic
Guarantee
In our ongoing efforts to improve our products, TR-Electronic reserve the right to alter
the information contained in this document without prior notice.
Printing
This manual was produced on a personal computer using MS-Word for Windows. The
text was printed in Arial type.
Fonts
Italics and bold type are used for the title of a document or to emphasize text
passages.
Passages written in Courier show text which is visible on the screen / display as well
as software menu selections.
"< >" refers to keys on your computer keyboard (e.g. <RETURN>).
Copyright Information ©
MS-WORD, MS-Windows and MS-Windows-95 are registered trademarks of
Microsoft Corporation.
SIMATIC S5, STEP-5 and COM-ET-200 are registered trademarks of SIEMENS
Corporation.
PROFIBUS-DP and the PROFIBUS-Logo are registered trademarks of Profibus User
Organisation e.V. (PNO)

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 3 of 45
Revision History
Note:
The cover of this document shows the current revision status and the corresponding
date. Since each individual page has its own revision status and date in the footer,
there may be different revision statuses within the document.
Drawings that are in the appendix have their own revision history.
Document created:
13.08.1997
Revision
Date
Commissioning notes for the use of the nominal
configuration "Box+rotary encoder TR Gear"
General customizations
24.04.2002
Completed with chapter 4, page 33
Additional notes for the software state 011
10.09.2003
Manufacturer’s declaration replaced with EC Declaration
of Conformity
25.04.2012
i

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 4 of 45
Table of contents
1 Safety...........................................................................................................................................................6
1.1 General Potential for Danger.............................................................................................................6
1.2 Safety Information..............................................................................................................................6
1.2.1 Installation information.......................................................................................................7
1.2.1.1 Wiring the converter housing........................................................................................................................8
1.2.1.2 Connecting the Cable Screening to the Converter Housing.........................................................................9
1.3 Appropriate Use.................................................................................................................................10
1.4 Danger Due to Accessories...............................................................................................................11
1.5 Authorized Operators.........................................................................................................................12
1.6 Safety Measures at the Place of Assembly.......................................................................................12
2 Transportation / Commissioning..............................................................................................................13
2.1 Transportation / Storage....................................................................................................................13
2.2 System requirements.........................................................................................................................14
2.2.1 Requirements for start-up on IM-308-C.............................................................................14
2.2.2 Requirements for start-up on SIMATIC-S7........................................................................14
2.2.3 Requirements for start-up on other PROFIBUS master devices.......................................14
3 Characteristics of the SSI-BOX / Commissioning...................................................................................15
3.1 SSI-BOX PNO identification number.................................................................................................15
3.2 Type file / device master file..............................................................................................................15
3.3 Start-up on PROFIBUS......................................................................................................................15
3.4 Which configuration is to be used?....................................................................................................16
3.5 Which SSI-format do the configurations need ?................................................................................17
3.6 Configuration and parameterization ..................................................................................................19
3.6.1 Configuration......................................................................................................................19
3.6.1.1 Box+rotary encoder class-1/16, identifier 0xD0 (208 dec.)...........................................................................20
3.6.1.2 Box+rotary encoder class-1/32, identifier 0xD1 (209 dec.)...........................................................................20
3.6.1.3 Box+rotary encoder class-2/16, identifier 0xF0 (240 dec.) / 1AX (Simatic-Manager)...................................21
3.6.1.4 Box+rotary encoder class-2/32, identifier 0xF1 (241 dec.) / 2AX (Simatic-Manager)...................................21
3.6.1.5 Box+rotary encoder TR Gear, identifier 0xF1 (241 dec.) / 2AX (Simatic-Manager) .....................................22
3.6.2 Parameterization................................................................................................................25
3.6.2.1 Code sequence ............................................................................................................................................25
3.6.2.2 Class 2 functionality......................................................................................................................................25
3.6.2.3 Commissioning diagnostic control................................................................................................................25
3.6.2.4 Scaling function control ................................................................................................................................25
3.6.2.5 Measuring units per revolution .....................................................................................................................26
3.6.2.6 Total measuring range [units] hi and total measuring range [units] lo..........................................................26
3.6.2.7 Revolutions numerator hi and Revolutions numerator lo..............................................................................26
3.6.2.8 Revolutions denominator..............................................................................................................................27
3.6.2.9 Code SSI-Interfacebox .................................................................................................................................27
3.6.2.10 Code PROFIBUS interface:........................................................................................................................27
3.6.2.11 Preset 1 value [units] hi and preset 1 value [units] lo.................................................................................27
3.6.2.12 Preset 2 value [units] hi and preset 2 value [units] lo.................................................................................28
3.6.3 Notes for the scaling function ............................................................................................30
3.6.3.1 Nominal configurations "Box+rotary encoder class-1 / class-2"...................................................................30
3.6.3.2 Nominal configuration "Box+rotary encoder TR Gear".................................................................................30

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 5 of 45
3.7 Preset adjustment..............................................................................................................................31
3.8 SSI interface ......................................................................................................................................31
3.9 Optional Incremental-Interface ..........................................................................................................32
4 Characteristics of the SSI-BOX (connection of linear encoders)..........................................................33
4.1 SSI-BOX PNO identification number.................................................................................................33
4.2 Type file / device master file..............................................................................................................33
4.3 Start-up on PROFIBUS......................................................................................................................33
4.4 Configuration and parameterization ..................................................................................................34
4.4.1 Configuration......................................................................................................................34
4.4.2 Use notes...........................................................................................................................37
4.4.3 Parameterization................................................................................................................38
4.4.3.1 Code sequence: ...........................................................................................................................................38
4.4.3.2 Class 2 functionality:.....................................................................................................................................38
4.4.3.3 Commissioning diagnostic control:...............................................................................................................38
4.4.3.4 Scaling function control: ...............................................................................................................................38
4.4.3.5 Measuring units per meter hi and measuring units per meter lo ..................................................................39
4.4.3.6 Preset 1 value [units] hi and preset 1 value [units] lo...................................................................................39
4.4.3.7 Preset 2 value [units] hi and preset 2 value [units] lo...................................................................................40
4.5 Preset adjustment..............................................................................................................................41
5 Trouble-shooting and diagnostic facilities..............................................................................................42
5.1 Visual indicators.................................................................................................................................42
5.2 How to use the PROFIBUS diagnostics............................................................................................43
6 Appendix .....................................................................................................................................................44
6.1 Technical Data...................................................................................................................................44
6.2 General instructions for cabling.........................................................................................................45
Pin assignment .............................................................................. www.tr-electronic.de/f/ZN 00-000-1170
Dimension drawing........................................................................ www.tr-electronic.de/f/ZN 00-000-1164
EC Declaration of Conformity..................................................www.tr-electronic.de/f/TR-E-KE-DGB-0018

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 6 of 45
1 Safety
1.1 General Potential for Danger
The SSI-BOX cannot function as a stand-alone unit, i.e. it is a component part that is
intended to be installed in a complete system consisting of several such components
working together. This means that the SSI-BOX does not have a direct protection
device of its own.
The user must check the received data from the SSI-BOX for validity.
All the persons who are involved in the assembly, commissioning and operation of the
device
must be appropriately qualified
must follow exactly the instructions in this manual.
This is for your own safety and the safety of your equipment!
1.2 Safety Information
This operating manual contains information that you must comply with to ensure your
personal safety and to avoid damage to property. The information is emphasized by
warning triangles, which have different appearances to match the level of danger:
Warning
Means that if the appropriate safety measures are ignored, death, severe injury or
considerable damage to property can occur.
Caution
Means that if the appropriate safety measures are ignored, slight injury or damage to
property can occur.
Note
Emphasizes important information about the product, its properties or helpful hints for
using it.
i

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 7 of 45
1.2.1 Installation information
Due to the fact that the SSI-BOX is normally used as a component part of a larger
system, this information is intended to provide a guideline for safe installation of the
device in its environment.
Warning
Observe the safety and accident prevention regulations that apply to the specific
application.
In the case of equipment with a fixed connection (stationary installations/systems)
without all-pole mains switches and/or fuses, you must install a mains switch or a
fuse in the system and connect the equipment to a protective earth.
Before commissioning devices that are run with mains voltage, check whether the
set rated voltage range matches the local mains voltage.
With a 24-V supply, ensure safe electrical isolation of the extra-low voltage. Use
only mains units that comply with IEC 364-4-41 or HD 384.04.41 (VDE 0100 Part
410) standards.
Fluctuations in or deviations from the rated mains voltage may not exceed the
tolerances stated in the technical data. If they do, functional failures of the electrical
components and hazardous conditions cannot be ruled out.
You must take precautions to ensure that, following voltage dips and failures, it is
possible to restart an interrupted program in an orderly manner. In this context, no
dangerous operating status conditions may occur even for a brief period of time. If
necessary, you must force an EMERGENCY STOP.
EMERGENCY STOP devices that comply with EN 60204/IEC 204 (VDE 0113)
must remain effective in all the operating modes of the automation equipment.
Unlocking the EMERGENCY STOP devices must not result in an uncontrolled or
undefined restart.
Install the connecting and signal lines such that inductive and capacitive
interference does not adversely affect the automation functions.
Install automation technology equipment and its operator input elements such that
they are sufficiently protected against being operated by mistake.
Take appropriate hardware and software measures in the I/O link to prevent
possible cable or wire breakages on the signal side leading to undefined status
conditions in the automation equipment.

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 8 of 45
1.2.1.1 Wiring the converter housing
Note
In addition to the connection terminals, the converter housing contains all the
electronics for converting SSI signals that come from the encoder into appropriate
Profibus data. To protect the electronics from environmental influences, we chose a
housing that complies with type of protection IP 67 according to DIN 40 050.
Please be sure that during cabling you use the proper cable screw glands and their
seals (o-rings). The lid of the housing must be tightened correctly (see "Appropriate
Use" on page 10). Screw glands and lid must be sealed properly. If dirt or oil will
penetrate inside the converter housing the electronic will be damaged.
Connection You should use the Siemens-specified twisted-pair cables for the positive and
negative signals of the SSI clock, SSI data and RS485 signals.
For the Profibus, you only need to connect the DataA and DataB terminals. On the
connection board, there are two sets for the lines to the previous station and to the
next one. Terminals P5V2 and M5V2 must be kept open.
Chapters 4 and 5 of the manual entitled Distributed Peripheral System ET200 contain
supplementary information about additional line lengths and installation of the
Profibus. You can obtain this manual from Siemens quoting order number
EWA 4NEB 780 6000-01
i

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 9 of 45
1.2.1.2 Connecting the Cable Screening to the Converter Housing
To prevent disturbance signals entering the converter housing, we used cable screw
glands with which it is possible to connect the screen on the inside. For this reason, no
connection point for the screen is provided inside the converter housing.
Procedure:
1. Screw the cable screw gland into the housing.
2. Dismount the compression nut (1) and the terminal holder (2).
3. Push the compression nut (1) and the terminal holder (2) over the cable.
4. Strip the cable; push back the braiding around the terminal holder (2) such that the
braiding goes over the inner O-ring (3) and does not lie over the cylindrical section
or the torsional bars.
5. Insert the terminal holder (2) into the intermediate gland (4) such that the torsional
bars fit into the intended lengthwise grooves in the intermediate gland (4).
6. Screw the compression nut (1) to the intermediate gland (4).
Converter Housing
Measuring system
cable
Repeat orders
Article
Article number
Reducer: PG21 to PG11 (with O-ring)
48-010-065
Filler plug: PG11 (with O-ring)
49-010-006
Cable screw gland: PG11 (with O-ring)
49-010-003
O-ring: Converter housing lid
MTO-134X3,5
Part 1
Compression nut
Part 2
Terminal holder
Part 3
Inner O-ring
Part 4
Intermediate gland

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 10 of 45
1.3 Appropriate Use
The SSI-BOX exclusively is used for connection with SSI-encoders.
Usable encoder types:
Rotary encoders without checksum, 4096/4096, binary, tree-format,
exclusively usable for the nominal configuration "Box+rotary encoder TR Gear"
Rotary encoders with checksum, 28 data bit, binary, 15 bit CRC,
usable for all nominal configurations
Linear encoders without checksum, 24 data bit, binary,
exclusively usable for the nominal configuration "Box+rotary encoder TR Gear"
The SSI-BOX can be parameterized via the PROFIBUS according to the PNO profile
and is designed to be run on PROFIBUS-DP networks according to DIN 19245 Part 1-
3 up to a maximum of 12 Mbauds. The parameterization and equipment diagnostics
are performed by the PROFIBUS master according to Version 1.0 of the PNO encoder
profile.
In addition to the Profibus data the angular data can also output at the same time
synchronous-serial.
Note
1
2
3
4
To avoid damaging the lid seal on
the converter housing and to
guarantee sealing, you must evenly
tighten the screws crosswise.
(See the example on the left.)
Warning
Deenergize the system before carrying out wiring or opening and closing
electrical connections!
Short-circuits, voltage peaks etc. can lead to malfunctions and uncontrolled conditions
in the system or to serious personal injury or damage to property.
Before switching on the system, check all the electrical connections!
Connections that are made incorrectly can lead to system malfunctions; wrong
connections may result in serious personal injury or damage to property.
For safety reasons, mechanical or electrical changes to the measuring systems
are prohibited!
i

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 11 of 45
Caution
Always keep to the operating temperature range of -20° to +70° C!
Keep to the sealing of the converter housing (see note on page 10), principal
when industrial liquids to run over the housing!
Note
Always keep to the commissioning, operating and programming instructions specified
in this manual.
1.4 Danger Due to Accessories
Caution
Clamps that are not connected correctly in the converter housing can lead to an
encoder malfunction!
Tightly screw the mating connector to its intended connector.
i

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 12 of 45
1.5 Authorized Operators
This device may only be commissioned by qualified personnel. In the context of the
safety-specific information in this document, qualified personnel are considered to be
persons who are authorized to commission, ground and mark circuits, equipment and
systems in accordance with recognized safety standards.
1.6 Safety Measures at the Place of Assembly
Warning
Do not carry out welding if the device has already been wired-up or is switched-
on!
Potential fluctuations can destroy the device or adversely affect its function.
Do not touch connector contacts with your hands!
Static charges could destroy the electronic components in the device.
Inputs that are not being used may not be connected (refer to the pin
assignments)!
Keep to the supply voltage range: 11-27 V DC (±5% residual ripple)
Note
Ensure that the area around the place of assembly is protected from aggressive
media (acid, etc.).
i

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 13 of 45
2 Transportation / Commissioning
2.1 Transportation / Storage
Transportation Information
Do not drop the device or subject them to excessive jolting!
Use only the original packaging material!
Incorrect packaging material can cause damage to the device in transit.
Storage
Storage temperature: -30 to +80° C
Store in a dry place.

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 14 of 45
2.2 System requirements
2.2.1 Requirements for start-up on IM-308-C
In order to start up the SSI-BOX on an IM-308-C, the following minimum requirements
must be met :
COM-ET-200 for Windows Version 2.0 or higher.
IM-308-C Edition 3 or higher.
TR-Electronic supplies a disk containing the device master file (*.GSD) and a type
file (*.200) for COM-ET-200 for Windows (art.no. 490-00406).
2.2.2 Requirements for start-up on SIMATIC-S7
In order to start up the SSI-BOX on a programmable controller of the SIMATIC S7
type, the following minimum requirements must be met:
STEP-7 for Windows Version 2.1 Edition 4 or higher. The Version 2.1 basic
package supplied by Siemens does not support the parameterization function via
input masks !
SIMATIC S7-300 or S7-400 with PROFIBUS-DP interface.
TR-Electronic supplies a disk containing the device master file (*.GSD) and a type
file (*.200) for COM-ET-200 for Windows (art.no. 490-00406).
2.2.3 Requirements for start-up on other PROFIBUS master devices
Please contact our sales department for further information.

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 15 of 45
3 Characteristics of the SSI-BOX / Commissioning
Note
An encoder exchange only do when the voltage is switched off.
3.1 SSI-BOX PNO identification number
The SSI-BOX has the PNO ID number AAAB (hex). This number is reserved and filed
with the PNO.
3.2 Type file / device master file
The type files used with the SSI-BOX have the filename "TRSS00XX.200" and the
device master file which is used has the filename " TR09_SSI.GSD".
3.3 Start-up on PROFIBUS
When started up, the SSI-BOX has the status 'Baud search'. After detecting the Baud
rate, it switches to the status WAIT_PRM and waits for the parameterization data from
the DP master. Parameterization takes place automatically during the start-up phase
of the DP master. The parameters transferred to the SSI-BOX are the code
sequence, the measuring length in increments and the number of increments per
revolution (see PNO encoder profile for more details). After a successful
transmission of formally correct parameterization data, the SSI-BOX switches to the
status WAIT_CFG. The PROFIBUS master then sends a configuration byte in order to
define the number of inputs and outputs. If the configuration byte is correct, the SSI-
BOX switches to the status DATA_EX.
i

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 16 of 45
3.4 Which configuration is to be used?
The type file or device master file contains four nominal configurations for the PNO
Class 1 and 2, each with 16 and 32-bit resolution and two nominal configurations for
TR-specific extensions.
PNO configurations
"Box+rotary encoder class-1/16" or "Box+rotary encoder class-1/32"
class-1/16: 16 bit inputs (master), class-1/32: 32 bit inputs (master)
no encoder scaling, the encoder operates with the standard resolution specified
on the rating plate.
Limitation of the diagnostic data to 16 bytes
Changing of the code sequence possible
"Box+rotary encoder class-2/16" or "Box+rotary encoder class-2/32"
class-2/16: 16 bit inputs / outputs, class-2/32: 32 bit inputs / outputs
Encoder scaling possible, however the measuring units per revolution must
be an integer and the number of revolutions must be a second power.
Preset adjustment via the bus
Changing of the code sequence possible
TR configurations
"Box+rotary encoder TR Gear"
32 bit inputs / outputs
Encoder scaling possible, the measuring units per revolution can be a comma
number and the number of revolutions a broken number (no second power)
Preset adjustment via the bus
Changing of the code sequence possible
Programming of the output code, Profibus- and SSI-interface
Programming of the preset value for the external preset inputs 1 and 2
"Box+linear encoder"
Designated for the configuration of linear encoders, starting from software version 011.
At software versions up to 010 the configuration must be made by linear encoders
exclusively via the TR configuration "box +rotary encoder TR Gear"

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 17 of 45
3.5 Which SSI-format do the configurations need ?
PNO configurations
All PNO configurations (class 1/16, class 1/32, class 2/16, class 2/32) exclusively
need the TR-SSI-format:
TR encoder type
SSI binary with 28 data bits and 15 bit checksum
Output format
Revolutions, 12 bit
Steps / Revolution, 16 bit
TR checksum
28 data bits
15 bit
0
0
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
0
0
0
0
MSB (242)
(215)
(214)
LSB (20)
Programmings < 12 bits (revolutions) are completed MSB-sided accordingly with
"0". Programmings < 16 bit (steps/revolution) are completed LSB-sided (starting
from 215) accordingly with "0".
The bit pattern entered into the output format corresponds to the encoder
resolution 4096 steps/revolution x 1024 revolutions.
TR configuration
The TR configuration "Box+rotary encoder TR Gear" can be operated with different
SSI-formats:
Rotary encoders
1. TR encoder type
SSI binary with 28 data bits and 15 bit checksum (see PNO configurations)
2. General encoder type
SSI binary with 24 data bits, 4096 steps/rev. x 4096 rev., tree-format
Output format
Revolutions, 12 bit
Steps / Revolutions, 12 bit
24 data bits
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
MSB (223)
LSB (20)
The encoder absolutely must have the programming, which is specified above. The
SSI-BOX is reduced in the programming (see use notes of this configuration on
page 23).

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 18 of 45
Linear encoder (only up to software versions 010)
3. General linear encoder type
SSI binary with 24 data bits, full resolution (0.1 or 0.01 mm) and a max.
measuring length in increments from within 24 bits.
Output format
Measuring length in increments (max. 16 777 215)
24 data bits
0
0
0
0
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
MSB (223)
LSB (20)
Programmings of the linear measuring system < 24 bits are completed MSB-sided
accordingly with "0".
The bit pattern entered into the output format corresponds to a measuring length of 20
bits.
The encoder absolutely must have the programming, which is specified above. The
SSI-BOX is reduced in the programming (see use notes of this configuration
on page 23).
Starting from software version 011 no restriction (see chapter 4 page 33).

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 19 of 45
3.6 Configuration and parameterization
Parameterization, i.e. the transfer of parameters for the code sequence, encoder
resolution, etc., exclusive takes place within the configuration program for the relevant
PROFIBUS master (a programming via "EPROG"-program is not possible). For this
purpose, the type file of the SSI-BOX must be copied into the relevant directory for
type files. In the case of some programs, such as COM PROFIBUS or STEP7
Manager, the internal equipment list (hardware catalogue) has to be updated within
the software. For more information on the integration of field devices, please refer to
the documentation supplied with your software.
In order to integrate and parameterize the SSI-BOX in a master system, it is usually
necessary to carry out the following two steps within the configuration program.
3.6.1 Configuration
For configuration purposes, i.e. input of length and I/O type on the PROFIBUS, the
configuration program usually provides an input mask in which the identifier is
normally preset depending on the nominal configuration, so that all you have to do is
enter the I/A addresses.
Depending on the required nominal configuration, the SSI-BOX will assign a
different number of input and output words on the PROFIBUS.
The parameters described below are also dependent on the nominal configuration.
In the following, the individual nominal configurations are described, together with the
position of the communication bytes for data exchanges with the PROFIBUS-DP
master.

Operating Manual SSI-BOX PROFIBUS-DP (PNO) ELECTRONIC GmbH
TR - ELECTRONIC GmbH, Global Quality Management, Eglishalde 6, 78647 Trossingen, Tel.++49 (0)7425-228-0, Fax ++49 (0)7425-228-33
Date: 25.04.2012
TR - E - BA - GB - 0013 - 03
Page 20 of 45
3.6.1.1 Box+rotary encoder class-1/16, identifier 0xD0 (208 dec.)
The SSI-BOX uses one input word only, which is consistently transferred via the bus.
Input word IW x
Data byte 1
Data byte 0
LSB
MSB
Input byte x+0
Input byte x+1
Relevant parameter data:
Code sequence
3.6.1.2 Box+rotary encoder class-1/32, identifier 0xD1 (209 dec.)
The SSI-BOX uses two input words only, which are consistently transferred via the
bus.
Double input word ID x
Data byte 3
Data byte 2
Data byte 1
Data byte 0
LSB
MSB
Input byte x+0
Input byte x+1
Input byte x+2
Input byte x+3
Relevant parameter data:
Code sequence
Note:
In the case of configurations for CLASS 1, preset adjustment is not possible via the
PROFIBUS, and only the code sequence can be changed. The encoder operates with
the standard resolution specified on the rating plate. The diagnostic data are limited to
16 bytes.
i
