Trane BAYHTRV108 Assembly instructions

SSAAFFEETTYY WWAARRNNIINNGG
Only qualified personnel should install and service the equipment The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment
October 2022 1188--HHBB2200DD44--11FF--EENN
Supplemental Electric Heaters
BAYHTRV105
BAYHTRV108
BAYHTRV110
BAYHTRV115
BAYHTRV120
BAYHTRV125
BAYHTRV305
BAYHTRV308
BAYHTRV310
BAYHTRV315
BAYHTRV320
BAYHTRV325
BAYHTRV405
BAYHTRV408
BAYHTRV410
BAYHTRV415
BAYHTRV420
BAYHTRV425
Installer’s Guide

©2022 18-HB20D4-1F-EN
SAFETY SECTION
IImmppoorrttaanntt — This document contains a wiring
diagram, a parts list, and service information This is
customer property and is to remain with this unit
Please return to service information pack upon
completion of work
WWAARRNNIINNGG
HHAAZZAARRDDOOUUSS VVOOLLTTAAGGEE!!
FFaaiilluurree ttoo ffoollllooww tthhiiss WWaarrnniinngg ccoouulldd rreessuulltt iinn
pprrooppeerrttyy ddaammaaggee,, sseevveerree ppeerrssoonnaall iinnjjuurryy,, oorr
ddeeaatthh
DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee
ddiissccoonnnneeccttss bbeeffoorree sseerrvviicciinngg FFoollllooww pprrooppeerr
lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr
ccaannnnoott bbee iinnaaddvveerrtteennttllyy eenneerrggiizzeedd
WWAARRNNIINNGG
SSAAFFEETTYY AANNDD EELLEECCTTRRIICCAALL HHAAZZAARRDD!!
FFaaiilluurree ttoo ffoollllooww tthhiiss WWaarrnniinngg ccoouulldd rreessuulltt iinn
pprrooppeerrttyy ddaammaaggee,, sseevveerree ppeerrssoonnaall iinnjjuurryy,, oorr
ddeeaatthh
TThheessee sseerrvviicciinngg iinnssttrruuccttiioonnss aarree ffoorr uussee bbyy
qquuaalliiffiieedd ppeerrssoonnnneell oonnllyy TToo rreedduuccee tthhee rriisskk ooff
eelleeccttrriiccaall sshhoocckk,, ddoo nnoott ppeerrffoorrmm aannyy sseerrvviicciinngg
ootthheerr tthhaann tthhaatt ccoonnttaaiinneedd iinn tthheessee ooppeerraattiinngg
iinnssttrruuccttiioonnss uunnlleessss yyoouu aarree qquuaalliiffiieedd ttoo ddoo ssoo
CCAAUUTTIIOONN
GGRROOUUNNDDIINNGG RREEQQUUIIRREEDD!!
FFaaiilluurree ttoo iinnssppeecctt oorr uussee pprrooppeerr sseerrvviiccee ttoooollss mmaayy
rreessuulltt iinn eeqquuiippmmeenntt ddaammaaggee oorr ppeerrssoonnaall iinnjjuurryy
RReeccoonnnneecctt aallll ggrroouunnddiinngg ddeevviicceess AAllll ppaarrttss ooff tthhiiss
pprroodduucctt tthhaatt aarree ccaappaabbllee ooff ccoonndduuccttiinngg eelleeccttrriiccaall
ccuurrrreenntt aarree ggrroouunnddeedd IIff ggrroouunnddiinngg wwiirreess,, ssccrreewwss,,
ssttrraappss,, cclliippss,, nnuuttss,, oorr wwaasshheerrss uusseedd ttoo ccoommpplleettee aa
ppaatthh ttoo ggrroouunndd aarree rreemmoovveedd ffoorr sseerrvviiccee,, tthheeyy mmuusstt
bbee rreettuurrnneedd ttoo tthheeiirr oorriiggiinnaall ppoossiittiioonn aanndd pprrooppeerrllyy
ffaasstteenneedd
WWAARRNNIINNGG
SSAAFFEETTYY HHAAZZAARRDD!!
OOppeerraattiinngg tthhee uunniitt wwiitthhoouutt tthhee aacccceessss ppaanneellss
pprrooppeerrllyy iinnssttaalllleedd mmaayy rreessuulltt iinn sseevveerree ppeerrssoonnaall
iinnjjuurryy oorr ddeeaatthh
DDoo nnoott ooppeerraattee tthhee uunniitt wwiitthhoouutt tthhee eevvaappoorraattoorr ffaann
aacccceessss ppaanneell oorr eevvaappoorraattoorr ccooiill aacccceessss ppaanneell iinn
ppllaaccee
WWAARRNNIINNGG
TThhiiss pprroodduucctt ccaann eexxppoossee yyoouu ttoo
cchheemmiiccaallss iinncclluuddiinngg lleeaadd,, wwhhiicchh aarree
kknnoowwnn ttoo tthhee SSttaattee ooff CCaalliiffoorrnniiaa ttoo
ccaauussee ccaanncceerr aanndd bbiirrtthh ddeeffeeccttss oorr
ootthheerr rreepprroodduuccttiivvee hhaarrmm FFoorr mmoorree
iinnffoorrmmaattiioonn ggoo ttoo wwwwww PP6655WWaarrnniinnggss
ccaa ggoovv !!
IImmppoorrttaanntt:: Wear appropriate gloves, arm sleeve
protectors and eye protection when
servicing or maintaining this equipment.

18-HB20D4-1F-EN 3
Supplementary Electric Heaters 4
Installer’s Guide 5
Field Wiring – Air Conditioners 7
Field Wiring – Heat Pumps 8
Table of Contents

418-HB20D4-1F-EN
Supplementary Electric Heaters
UNIT MODEL
ELECTRIC
HEATER
MODEL
RATED
VOLT-
AGE
PHASE AMPS
HEATER
CAPACITY NO.
OF
STAGES
KW/STAGE
MCA
MAX. FUSE
OR HACR
CKT BKR
SIZE (a)
CANADA
ONLY MAX.
CKT BKR
SIZE (b)
KW BTUH 1 2
&TCC&018-060‡1
&WCC&018-060‡1
&TCY&024-060‡1
&WCY&024-060‡1
&WCZ&024-060‡1
BAYHTRV105 208/
240 118/
21
3.76/
5.0
12800/
17100 13.76/ 5.0 —23/ 26 25/30 25/30
&TCC&018-060‡1
&WCC&018-060‡1
&TCY&024-060‡1
&WCY&024-060‡1
&WCZ&024-060‡1
BAYHTRV108 208/
240 129/ 33
6.0/
8.0
20500/
27300 16.0/ 8.0 —36/
41 40/45 40/45
&TCC&024-060‡1
&WCC&024-060‡1
&TCY&024-060‡1
&WCY&024-060‡1
&WCZ&024-060‡1
BAYHTRV110 208/
240 136/
42
7.5/
10.0
25600/
34100 17.5/ 10.0 —45/ 52 45/60 45/60
&TCC&030-060‡1
&WCC&030-060‡1
&TCY&030-060‡1
&WCY&030-060‡1
&WCZ&036-060‡1
BAYHTRV115 208/
240 154/ 63
11.27/
15.0
38500/
51200 27.5/ 10.0
3.76/
5.0
68/
78 70/80 70/80
&TCC&042-060‡1
&WCC&042-060‡1
&TCY&042-060‡1
&WCY&042-060‡1
&WCZ&048-060‡1
BAYHTRV120# 208/
240 172/ 83
15.0/
20.0
51200/
68300 27.5/ 10.0
7.5/
10.0
90/
104 90/110 90/110
&TCC&060‡1
&WCC&060‡1
&TCY&042-060‡1
&WCY&042-060‡1
&WCZ&048-060‡1
BAYHTRV125# 208/
240 190/ 104
18.78/
25.0
64100/
85300 211.26/ 15.0
7.5/
10.0
113/
130 125/150 125/150
W/TC*3036-060‡3
W/TCY4036-060‡3
&WCZ&036-060‡3
*CC4036-060‡3
BAYHTRV305 208/
240 310/
12
3.76/
5.0
12800/
17100 13.76/ 5.0 —13/ 15 15/15 15/15
W/TC*3036-060‡3
W/TCY4036-060‡3
&WCZ&036-060‡3
*CC4036-060‡3
BAYHTRV308 208/
240 317/ 19
6.0/
8.0
20500/
27300 16.0/
8.0 —21/
24 25/25 25/25
W/TC*3036-060‡3
W/TCY4036-060‡3
&WCZ&036-060‡3
*CC4036-060‡3
BAYHTRV310 208/
240 321/
24
7.5/
10.0
25600/
34100 17.5/ 10.0 —26/ 30 30/30 30/30
W/TC*3036-060‡3
W/TCY4036-060‡3
&WCZ&036-060‡3
*CC4036-060‡3
BAYHTRV315 208/
240 331/ 36
11.27/
15.0
38500/
51200 27.5/ 10.0
3.76/
5.0
39/
45 40/45 40/45
W/TC*3048-060‡3
W/TCY4048-060‡3
&WCZ&048-060‡3
*CC4048-060‡3
BAYHTRV320 208/
240 342/ 48
15.0/
20.0
51200/
68300 27.5/ 10.0
7.5/
10.0
52/
60 60/60 60/60
W/TC*3060‡3
W/TCY4048-060‡3
&WCZ&048-060‡3
*CC4060‡3
BAYHTRV325# 208/
240 352/ 60
18.78/
25.0
64100/
85300 211.26/ 15.0
7.5/
10.0
65/
75 70/80 70/80
W/TC*3036-060‡4
&WCZ&036-060‡4
*CC4036-60‡4
BAYHTRV405 480 3 6 5.0 17100 1 5.0 — 8 15 15
W/TC*3036-060‡4
&WCZ&036-060‡4
*CC4036-60‡4
BAYHTRV408 480 3 10 8.0 27300 1 8.0 — 13 15 15
W/TC*3036-060‡4
&WCZ&036-060‡4
*CC4036-60‡4
BAYHTRV410 480 3 12 10.0 34100 1 10.0 — 15 15 15

18-HB20D4-1F-EN 5
W/TC*3036-060‡4
&WCZ&036-060‡4
*CC4036-60‡4
BAYHTRV415 480 3 18 15.0 51200 2 10.0 5.0 23 25 25
W/TC*3048-060‡4
&WCZ&048-060‡4
*CC4048-60‡4
BAYHTRV420 480 3 24 20.0 68300 2 10.0 10.0 30 30 30
W/TC*3060‡4
&WCZ&048-060‡4
*CC4048-60‡4
BAYHTRV425 480 3 30 25.0 85300 2 15.0 10.0 38 40 40
1. Any power supply and circuits must be wired and protected in accordance with local electrical codes.
2. The values listed in the above table are for the electric heater only.
3. Field wiring must be rated at least 75° C.
4. * indicates an alpha character.
5. ‡ indicates model letter.
6. # Heater uses fuses.
7. & indicates a digit.
ALL VALUES ARE FOR THE ELECTRIC HEATER ONLY
(a) The HACR circuit breaker is for U.S.A. installations only.
(b) For Canada installation reference only.
Installer’s Guide
Follow these instructions to install the supplementary
heaters in packaged units as described in the heater
tables throughout this guide
These instructions do not purport to cover all variations
in system hookups nor to provide for every possible
contingency to be met in connection with the
installation Should further information be desired, or
should particular problems arise which are not covered
sufficiently for the purchaser’s purposes, refer the
matter to the manufacturer
1 Check for any shipping damage and report any to
the carrier immediately
2 Check the heater nameplate and compare with the
heater tables to ensure the available power supply
complies with the table for the particular heater
being used
IInnssttaallll HHeeaatteerrss
1 Remove screws that secure the heater panel
(located within control box access panel)
2 Remove and discard the patch plate covering the
opening where the heater will be inserted
3 Slide the heater element section of heater assembly
into the opening and, tipping the heater slightly
forward against the unit barrier, slide the heater up
to engage the lip on the top of the barrier opening
Push forward to engage the slot on the bottom of
the heater face into the tongue on the barrier This
will hold the heater in place Replace the four
screws removed in step 1 See Figure 1, p 6
4 Connect the polarized plug from the heater control
box to the matching polarized plug on the bottom
of the air conditioner or heat pump unit control box
See Figure 1, p 6
LLooww VVoollttaaggee WWiirriinngg
All low voltage connections have been made to the
heater via the polarized plug The low voltage controls
can be connected to the room thermostat from the air
conditioner or heat pump Low Voltage leads See
wiring diagrams Low voltage is 24 Volts
1 Open the heater’s control box access cover
2 Remove the unit’s power supply knockout
3 Route the field wire through the heater
compartment and strain relief bushing into the
bottom of the heater housing
4 Connect the power supply to the heater’s wire leads
or fuse block depending on the particular heater
being used
5 Connect the power supply ground lead to the
heater’s ground lead or ground lug depending on
the particular heater being used
6 Place the included extra heater wiring diagram on
the inner surface of the control/heater access panel
next to the unit wiring diagram, as the diagram on
the heater may be only partially visible when
installed
7 Close the heater housing cover
8 Reinstall the control box/heater access panel
9 Restore power to the unit
The BAYHTRV115, 120, 125, 315, 3230 and 325 electric
heaters have an inner pivoting control box to allow
easy access to fuse links mounted on the heater back
plate Remove the 2 screws from the top front of the
heater control box and pull the top of the inner control
box toward you For easier replacement of contactors,
after pivoting the inner control box toward you,
remove the screws securing the top brace of the h eater
control box as shown in Figure 1, p 6
SSuupppplleemmeennttaarryy EElleeccttrriicc HHeeaatteerrss

618-HB20D4-1F-EN
Figure . Typical Heater Installation
SSuupppplleemmeennttaarryy EElleeccttrriicc HHeeaatteerrss

18-HB20D4-1F-EN 7
Field Wiring – Air Conditioners
Notes:
1. Fused disconnect size,
power wiring and grounding
of equipment must comply
with codes..
2. Be sure power supply agrees
with equipment and heater
nameplate.
3. Low voltage wiring to be 18
AWG minimum conductor.
4. See heater nameplate for
current rating of heater
used.
5. See unit and heater
diagram for electrical
connection details.
6. Jumper must be connected
between 1 and 2 for fan to
operate in heating.
7. Some thermostats provide
the ‘G’ signal in the cooling
mode only. To provide the ‘G’
signal in the heating mode
an accessory relay is
required. See fig. 3 for
proper connections.
8. For cooling only omit the
electric heater, associated
power wires and the ‘W’
signal thermostat wire.
9. Fig. 4 demonstrates
connection of the two stage
electric heat thermostat
accessory only. For further
unit connection details refer
to the other figures.
10. The 41A (BR) wire is first
stage electric heat. If the
electric heater accessory has
two heating stages the 41C
(BR) wire is second stage
electric heat.
Figure 2. Field Wiring
B
G
Y
W1
W2
R
COMMON
FAN
COMPRESSOR
HEAT FIRST STAGE
HEAT SECOND STAGE
24V
(GR)
(WH)
(WH)
B
G
Y
W1
W2
R
B
G
Y
W1
W2
R
3 PH
POWER
UNIT
NOTE 1,8
3 PH
POWER
HEATER
1 PH
POWER
1 PH
POWER
FIELD PROVIDED
JUMPER
NOTE 6
TO ECONOMIZER
FACTORY PROVIDED
FIELD INSTALLED WIRES
FIELD
INSTALLED
JUMPERS
FIELD
INSTALLED
JUMPERS
FIELD
INSTALLED
JUMPERS
756977i2
FIELD PROVIDED
FIELD CONNECTED
WIRED
UNIT HEATER AREA
UNIT CONTROL
BOX
ELECTRIC
HEATER
CONTROL
BOX
HEATER
FUSES
UNIT
FUSES
GROUND
WIRE
UNIT LOW
VOLTAGE AREA
UNIT LOW
VOLTAGE AREA
SINGLE POWER
ENTRY
UNIT LOW
VOLTAGE AREA
3 PH
POWER
1 PH
POWER
BAY24X042
TYPICAL THERMOSTAT
TYPICAL THERMOSTAT
TYPICAL 2-STAGE
THERMOSTAT
UNIT LOW
VOLTAGE AREA NOTE 10
ELECTRIC
HEATER
CONTROL
BOX
UNIT CONTROL BOX UNIT HEATER AREA
TYPICAL THERMOSTAT
TO COMPR.
CONTACTOR
SPE
ACCESSORY
KIT
GROUND
WIRE
POLARIZED
PLUG
W1
W2
(WH)
(WH)
SEE SPEK INSTALLER'S GUIDE
FOR ALL OTHER EXAMPLES

818-HB20D4-1F-EN
Field Wiring – Heat Pumps
Figure 3. Field Wiring
COMMON
FAN
COMPRSSOR
1ST STAGE ELECTRIC HEAT
2ND STAGE ELECTRIC HEAT
SWITCHOVER VALVE
DEFROST CONTROL 'T' SIGNAL
24 VOLTS
B
G
Y
W1
W2
O
T
R
UNIT LOW VOLTAGE AREA
TYPICAL THERMOSTAT
UNIT HEATER AREA
ELECTRIC
HEATER
CONTROL
BOX
POLARIZED
PLUG
UNIT CONTROL BOX
3 PH
POWER
UNIT
NOTE 1,8
3 PH
POWER
HEATER
1 PH
POWER
1 PH
POWER
UNIT CONTROL
BOX
UNIT HEATER AREA
FACTORY PROVIDED
FIELD CONNECTED
WIRES
(BL)
(YL)
(GR)
(PR)
(OR)
(OR)
B
G
Y
W1
W2
O
T
R
(BR)
(RD)
(GR)
(BL)
(WH)
(WH)
(YL)
(OR)
1 PH
POWER
3 PH
POWER
GROUND
WIRE
SINGLE POWR ENTRY
W1
W2
(WH)
(WH)
W1
W2
(WH)
(WH)
HEATER SECOND STAGE AMBIENT
TEMPERATURE LOCKOUT
NOTE 7,8
UNIT LOW
VOLTAGE
AREA
OUTDOOR
THERMOSTAT
ACCESSORY
BAYSTAT033A
NOTE 10
HEATER AMBIENT
TEMPERATURE LOCKOUT
NOTE 7,8
UNIT LOW
VOLTAGE
AREA
OUTDOOR
THERMOSTAT
ACCESSORY
BAYSTAT033A
NOTE 10
TYPICAL THERMOSTAT
TYPICAL THERMOSTAT
TYPICAL 2-STAGE
THERMOSTAT
UNIT LOW
VOLTAGE AREA
UNIT LOW
VOLTAGE AREA
TO COMPR.
CONTACTOR
ELECTRIC
HEATER
CONTROL
BOX
HEATER
FUSES
UNIT
FUSES
SPE
ACCESSORY
KIT
TO ECONOMIZER
FACTORY PROVIDED
FIELD INSTALLED WIRES
NOTE 9
(NOT APPLICABLE TO THE
WCM---F MODELS)
FIG. 3 OUTDOOR THERMOSTAT ACCESSORY CONNECTIONS
FIG. 1 SINGLE POWER ENTRY ACCESSORY CONNECTIONS FIG. 2 ECONOMIZER ACCESSORY
CONNECTIONS
GROUND
WIRE
SEE SPEK INSTALLER'S GUIDE
FOR ALL OTHER EXAMPLES
PACKAGED HEAT PUMP UNIT
Notes:
1. Fused disconnect size, power wiring
and grounding of equipment must
comply with codes..
2. Be sure power supply agrees with
equipment and heater nameplate.
3. Low voltage wiring to be 18 AWG
minimum conductor.
4. See heater nameplate for current
rating of heater used.
5. See unit and heater diagram for
electrical connection details.
6. If electric heater accessory is not
installed, omit the electric heater,
associated power wires and the “W”
and “X2” thermostat wires.
7. Fig 3 demonstrates connection of the
outdoor thermostat accessory only. For
further unit connection details refer to
the other figures.
8. The W1 wire is first stage electric heat.
If the electric heater accessory has two
heating stages, the W2 wire is second
stage electric heat..
9. When the BAYECON101A/102A or
BAYECON200A/201A economizer is
installed, the BAYRLAY004A relay
accessory kit is required to interface
the economizer to the heat pump for
proper system operation.
10. The BAYSTAT033A outdoor thermostat
accessory kit contains a thermostat
and a relay. The relay is not required to
be used in this application.

18-HB20D4-1F-EN 9
NNootteess

10 18-HB20D4-1F-EN
NNootteess

18-HB20D4-1F-EN 11
NNootteess

About Trane and American Standard Heating and Air Conditioning
Trane and American Standard create comfortable, energy efficient indoor environments for residential applications For
more information, please visit www trane com or www americanstandardair com
The manufacturer has a policy of continuous data improvement and it reserves the right to change design and specifications without notice We are committed to
using environmentally conscious print practices
18-HB20D4-1F-EN 14 Oct 2022
Supersedes 18-HB20D4-1E-EN (May 2022) ©2022
