Read Me First
MIL-SM8DPA Packing List:
Before you start installing MIL-SM8DPA Managed Switch, please verify that the package
contains the following items:
6-Port 100/1000 Dual Speed SFP + 2-Port RJ-45/ 100/1000SFP Managed Switch
AC Power Cord
User’s Guide CD-ROM
RJ-45 Transform RS-232 Cable
Please notify your sales representative immediately if any of the aforementioned items is
missing or damaged.
Power Requirements: AC Line
Voltage : 100240 VAC
Frequency : 5060 Hz
Consumption : 40W
Quick Installation:
1. Install the switch in the rack with mounting accessory.
2. Connect the MIL-SM8DPA switch to an AC power source.
3. The port 1–8 connector is LC SFP on the switch. Use Single-mode or Multi-mode Fiber
cable to connect between MIL-SM8DPA and end station.
4. The port 7, 8 includes two types of media --- TP and (100/1000M) SFP fiber module; they
support TP or fiber with auto-detected function.
5. Use RJ-45 interface to pre-configure MIL-SM8DPAfor network management.
For example: IP address, VLAN, Port Trucking, STP, etc.
MIL-SM8DPA switch’s serial port default settings are listed as follows:
Baud rate 115,200
Stop bits 1
Data bits 8
Parity N
Flow control none
The default values of MIL-SM8DPA switch are as follows:
IPAddress : 192.168.1.77
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.1.254
Username : admin
Password : root
User also can use telnet or web to pre-configure MIL-SM8DPA with the default IP
address and username/password in the first configuration. Please refer to User’s Guide
contained in CD-ROM for details on the setting of parameters. MIL-SM8DPA user’s
manual is filed under the path: \manual of the CD-ROM.

MIL-SM8DPA ReadMe First
Date: March 20 11
Revision A
0
2
Warning:
Self-demolition on Product is strictly prohibited. Damage caused by self-demolition will
be charged for repairing fees.
Do not place product at outdoor or sandstorm.
Before installation, please make sure input power supply and product specifications are
compatible to each other.
The SSL only provide the CLI for switch management and SSH default
enable without UI for management.
The TACACS+ feature for management authentication purpose.
Before importing / exporting configuration please make sure the firmware
version is always the same.
After firmware upgrade, the switch will remove the configuration
automatically to latest firmware version.
10900 Red Circle Drive
Minnetonka, MN 55344
