TRENDnet's TE100-S16plus is a high performance, auto-
sensing 16-port NWay rack-mountable Fast Ethernet Switch.
It is designed to eliminate unnecessary traffic and relieve
congestion on critical network paths. With 10/100Mbps NWay
technology, the TE100-S16plus automatically negotiates
between 10Base-T and 100Base-TX network speeds, as well
as half and full duplex modes. The TE100-S16plus also has a
module bay for optional multimode SC type fiber module that
allows connection to another fiber device up to 2Km away (in
full-duplex mode). Supporting "Port Trunking" and Quality of
Service (QoS), TRENDnet's TE100-S16plus is the perfect
solution for network backbone and multimedia applications.
TE100-S16plus
16-port 10/100Mbps NWay Switch (Rack Mount)
16 10/100Mbps NWay half/full duplex MDI-X ports
One Uplink port (shared) with port 8
Integrate address Look-Up Engine, supports up to 16K
absolute MAC address
Support three QoS levels; checked via IP Header, 802.1Q
VLAN Tag, and/or selected per-port basis
Supports trunking function; max. of 8 trunk ports are
available with max. 1.6Gbps trunking bandwidth
512KB internal RAM for frame buffering § Wire-speed
filtering/forwarding rates
IEEE 802.3x flow control for full-duplex mode; Back
pressure flow control for half-duplex mode
Store-and-forward switching method
Extensive front-panel diagnostic LEDs
One module bay for optional one-port 100Base-FX
multimode SC type fiber connection
5 Year Warranty
FEATURES BENEFITS
Performance:
Expandability:
Flexibility:
Cost Effectiveness:
Performance:
Port Trunking function creates up to
1.6Gb fat pipe between two Switches.
QoS Support improves network
multimedia applications' performance.
Optional 100Base-FX module links to
other fiber device up to 2Km (full-
duplex).
The NWay ports automatically
negotiate between 10Base-T and
100Base-TX network speeds as well
as between half- and full-duplex
modes.
Provide 10/100Mbps of Fast Ethernet
at an affordable rate.
Top performance at an affordable
price.
TE100-S16plus (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking
To Order Please Call:
1-888-326-6061
SPECIFICATIONS
NETWORKING SOLUTIONS
TE100-S16plus
16-port 10/100Mbps NWay Switch (Rack Mount)
TE100-S16plus
16-port 10/100Mbps NWay Switch (Rack Mount)
Standards:
• IEEE 802.3 10Base-T and IEEE 802.3u
100Base-TX/100Base-FX ANSI/IEEE 802.3
NWay auto-negotiation
Connectors:
• 16 10/100Mbps shielded RJ45 ports
• 1 MDI-II Uplink port shared with port 8
Network Cables:
• Ethernet: CAT 3, 4, 5 UTP/STP
• Fast Ethernet: CAT 5 UTP/STP for 100Base-TX
• Fiber Module: 62.5/125mm multimode fiber-optic with
SC type connector (412 m in half-duplex mode,
2 Km in full-duplex mode)
Protocols:
• CSMA/CD
Data Transfer Rate:
• Ethernet: 10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
• Fast Ethernet: 100Mbps (Half-Duplex),
200Mbps (Full-Duplex)
Data RAM Buffers:
• 512Kbytes per device
Filtering Address Table:
• 16K entries per device
Internal Power Adapter:
• 100~240 VAC, Universal Power Supply
Diagnostic LEDs:
• Power, FX, Link/Act, FDX/COL
Dimensions:
• 440 x 140 x 44 mm
(17.3 x 5.51 x 1.73 inch) (W x H x D)
Temperature:
• Operating: -10° ~ 50°C (14° ~ 122°F)
• Storage: -10° ~ 70°C (14° ~ 158°F)
Humidity:
• Operating: 10% ~ 90% RH
• Storage: 5% ~ 90% RH
Emission:
• FCC Class A, CE Mark A, VCCI-A
PRODUCT INFORMATION
TE100-S16plus: 16-Port 10/100Mbps NWay
Fast Ethernet Switch
TE100-S24plus: 24-Port 10/100Mbps NWay
Fast Ethernet Switch
TE100-S32plus: 32-Port 10/100Mbps NWay
Fast Ethernet Switch
TE100-SFXM: Multimode SC-Type Fiber
Slide-in Module for TE100-S1616/S2424 and
TE100-S16/S16plus/S24plus
