TRENDnet TEW-690AP User manual

Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
zConsult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
The availability of some specific channels and/or operational frequency bands are country
dependent and are firmware programmed at the factory to match the intended destination.
The firmware setting is not accessible by the end user.

European Union Notice:
Radio products with the CE marking comply with the R&TTE Directive (1999/5/EC), the EMC
Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission
of the European Community.
Compliance with these directives implies conformity to the following European Norms:
zEN 60950 Product Safety
zEN 300 328 Technical requirement for radio equipment
zEN 301 489-1/-17 General EMC requirements for radio equipment
Trademark recognition
All product names used in this manual are the properties of their respective owners and are
acknowledged.

Česky
[Czech] TRENDnet tímto prohlašuje, že tento TEW-690AP je ve shoděse základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW-690AP
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt TRENDnet , dass sich das Gerät TEW-690AP in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab TRENDnet seadme TEW-690AP vastavust direktiivi
1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele
asjakohastele sätetele.
English Hereby, TRENDnet, declares that this TEW-690AP is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente TRENDnet declara que el TEW-690AP cumple con
los requisitos esenciales y cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ TRENDnet ∆ΗΛΩΝΕΙ ΟΤΙ TEW-690AP ΣΥΜΜΟΡΦΩΝΕΤΑΙ
ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ
ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente TRENDnet déclare que l'appareil TEW-690AP est conforme aux
exigences essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE.
Italiano
[Italian]
Con la presente TRENDnet dichiara che questo TEW-690AP è conforme ai
requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Latviski
[Latvian]
Ar šo TRENDnet deklarē, ka TEW-690AP atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo TRENDnet deklaruoja, kad šis TEW-690AP atitinka esminius reikalavimus
ir kitas 1999/5/EB Direktyvos nuostatas.

Nederlands
[Dutch]
Hierbij verklaart TRENDnet dat het toestel TEW-690AP in overeenstemming is
met de essentiële eisen en de andere relevante bepalingen van richtlijn
1999/5/EG.
Malti
[Maltese]
Hawnhekk, TRENDnet jiddikjara li dan TEW-690AP jikkonforma mal-ħtiġijiet
essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, TRENDnet nyilatkozom, hogy a TEW-690AP megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym TRENDnet oświadcza, że TEW-690AP jest zgodny z zasadniczymi
wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy
1999/5/EC.
Português
[Portuguese
]
TRENDnet declara que este TEW-690AP está conforme com os requisitos
essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
TRENDnet izjavlja, da je ta TEW-690AP v skladu z bistvenimi zahtevami in
ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
TRENDnet týmto vyhlasuje, že TEW-690AP spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish] TRENDnet] vakuuttaa täten että TEW-690AP tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen
mukainen.
Svenska
[Swedish]
Härmed intygar TRENDnet att denna TEW-690AP står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som
framgår av direktiv 1999/5/EG.
European Union Notice:
Radio products with the CE marking comply with the R&TTE Directive (1999/5/EC), the EMC Directive
(89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the following European Norms:
zEN 60950 Product Safety
zEN 300 328 Technical requirement for radio equipment
zEN 301 489-1/-17 General EMC requirements for radio equipment
Trademark recognition
All product names used in this manual are the properties of their respective owners and are
acknowledged.

Contents
Getting Started..........................................................................................................................7
Package Contents.................................................................................................................7
Minimum System Requirements............................................................................................7
Introduction...............................................................................................................................8
Features................................................................................................................................8
Hardware Overview...............................................................................................................9
Installation Considerations......................................................................................................11
Getting Started........................................................................................................................12
Using the Configuration Menu ................................................................................................18
Network...................................................................................................................................19
LAN Setting .........................................................................................................................19
LAN Connection Type......................................................................................................19
Wireless..................................................................................................................................20
Access Point .......................................................................................................................20
Advanced ............................................................................................................................25
MAC Filter ...........................................................................................................................26
Security ...............................................................................................................................27
WPS....................................................................................................................................28
Wireless Station List ........................................................................................................29
Administrator...........................................................................................................................29
System Management ..........................................................................................................29
Upload Firmware.................................................................................................................30
Settings Management .........................................................................................................30
Status ..................................................................................................................................31
Glossary..................................................................................................................................32
Specifications..........................................................................................................................42
Limited Warranty.....................................................................................................................43

Getting Started
Congratulations on purchasing the TEW-690AP! This manual provides information for setting
up and configuring the TEW-690AP. This manual is intended for both home users and
professionals.
PACKAGE CONTENTS
•TEW-690AP
•CD_ROM (Utility and User’s Guide)
•Multi-Language Quick Installation Guide
•1 x network cable (0.6m / 2ft)
•Power adapter (12V DC, 1A)
Using a power supply with a different voltage than the one included with your product
will cause damage and void the warranty for this product.
MINIMUM SYSTEM REQUIREMENTS
Installation Requirements
•Web Browser: Internet Explorer (6 or higher)
•A computer with a network adapter or wireless adapter properly installed.
•A router with an available network LAN port.
•An available DHCP Server –routers usually have a built-in DHCP server.

Introduction
TRENDnet’s 450Mbps Wireless N Access Point, model TEW-690AP, supports Access Point, Wireless
Distribution System (WDS), and Repeater mode functionality.
Advanced Multiple Input Multiple Output (MIMO) antenna technology with three spatial streams per
antenna, generates a maximum theoretical wireless throughput of 450Mbps and exceptional wireless
coverage.
A Gigabit Ethernet port maintains high performance wired connections. Wi-Fi Protected Setup (WPS)
integrates other WPS supported devices at the touch of a button. Advanced features include 4 SSIDs
per wireless band, different encryption for each SSID, WMM Quality of Service data prioritization,
WPA2-RADIUS encryption, and a convenient on/off power switch.
FEATURES
•High performance 450Mbps wireless n access point
•1 x 10/100/1000Mbps Auto-MDIX Gigabit LAN port
•1 x WPS button
•1 x Reset button
•On/off power switch (EU Version)
•Diagnostic LEDs
•Wi-Fi compliant with IEEE 802.11n standard
•Backwards compatible with IEEE 802.11g/b devices
•Features Wireless Distribution System (WDS) and Repeater modes for wireless network
expansion
•Supports 64/128-bit WEP, WPA/WPA2-PSK, and WPA/WPA2-RADIUS wireless security
•Mac filter feature for added security
•Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization
•Multiple Input Multiple Output (MIMO) antenna technology
•Define up to 3 additional SSIDs
•One touch wireless connection using the WPS button
•Maximum reliability, throughput, and connectivity with automatic data rate switching
•Easy user setup wizard and intuitive Web browser configuration
•Coverage of up to 100 meters indoor (328ft.) and 300 meters outdoor (948ft.) *
•3-year limited warranty

HARDWARE OVERVIEW
Front View
WLAN LED
A solid light indicates that the wireless segment
is ready. This LED blinks green during wireless
data transmission.
WPS LED
This LED blinks green during WPS function is
enabled.
LAN LED
A solid light indicates a connection to a Router
on the LAN port. This LED blinks green during
data transmission
POWER LED
A solid green light indicates a proper connection
to the power supply
WPS Button
Press the button to enable WPS function.

Page 10
Rear View
Auto MDI/MDIX 10/100Mbps LAN Port
This port automatically senses the cable type when
connecting to Router.
DC-IN
The DC power input connector is a single jack
socket to supply power to the TEW-690AP. Please
use the Power Adapter provided on the TEW-690AP
package.
Power Switch (EU version)
On/off Switch
Side View Reset button
Restores device to factory default settings

Page 11
Installation Considerations
The TEW-690AP allows you to access your network by using a wireless connection from
virtually anywhere within its operating range. Keep in mind that the number, thickness and
location of walls, ceilings, or other objects that the wireless signals must pass through, may
limit the range. Typical ranges vary depending on the types of materials and background RF
(radio frequency) noise in your home or business. The key to maximizing wireless range is to
follow these basic guidelines:
1. Adjust your wireless devices so that the signal is traveling in a straight path, rather than at an
angle. The more material the signal has to pass through the more signal you will lose.
2. Keep the number of obstructions to a minimum. Each obstruction can reduce the range of a
wireless device. Position the wireless devices in a manner that will minimize the amount of
obstructions between them.
3. Building materials can have a large impact on your wireless signal. In an indoor environment, try to
position the wireless devices so that the signal passes through less dense material such as dry
wall. Dense materials like metal, solid wood, glass or even furniture may block or degrade the
signal.
4. Antenna orientation can also have a large impact on your wireless signal. Use the wireless
adapter’s site survey tool to determine the best antenna orientation for your wireless devices.
5. Interference from devices that produce RF (radio frequency) noise can also impact your signal.
Position your wireless devices away from anything that generates RF noise, such as microwaves,
radios and baby monitors.
6. Any device operating on the 2.4GHz frequency will cause interference. Devices such as 2.4GHz
cordless phones or other wireless remotes operating on the 2.4GHz frequency can potentially drop
the wireless signal. Although the phone may not be in use, the base can still transmit wireless
signal. Move the phone’s base station as far away as possible from your wireless devices.
If you are still experiencing low or no signal consider repositioning the wireless devices or installing
additional access points. The use of higher gain antennas may also provide the necessary coverage
depending on the environment.

Page 12
Getting Started
For a typical wireless setup at home or office, please do the following:
1. Insert Setup Wizard CD into your CD-ROM drive.
2. The Welcome screen appears on your monitor. Click Setup Wizard button.
3. Read the License Agreement and click Next to continue the installation.
4. Connect an Ethernet cable from the LAN port on your Router to the LAN port on the TEW-690AP,
click Next button to continue.

Page 13
1. Plug in the power adapter of the TEW-690AP and plug in the device that you will be
connecting together. Verify the Power & Ethernet LEDs are light. EU Version please make sure
the power switch is on the On position
5. Your computer will detect TEW-690AP and the Device List screen appears on your monitor. Click
Configure button to continue (default TEW-690AP IP Address is 192.168.10.100).
6. Enter password for the Access Point. The default password is “admin”. Click Login button to
continue.

Page 14
7. To attain an IP address automatically, you can select “Dynamic IP address configuration”; to
change IP address, you can select “Static IP address configuration” and click Next button to
continue.
8. The default IP address is 192.168.10.100, you can choose to obtain network setting automatically,
or set the IP address manually. After setting, click Configure to continue.
9. Use Push Button Method, click Connect button to continue. You also need to enable WPS
function of the wireless client device to make connection.

Page 15
10. Use Push Button Method, click Connect button to continue. You also need to enable WPS
function of the wireless client device to make connection. Use PIN Method and enter your wireless
client PIN number on Wireless Device PIN, and then click Connect button to make wireless
connection.
11. To set TEW-690AP security, select Manual setup and click Next button
12. Enter SSID of TEW-690AP, click Next button.

Page 16
13. Choice Wireless Mode.
14. To disable Security Mode, select None and click Next button.
15. To use WEP security, select WEP and click Next button. Select 64-bit or 128-bit WEP key length,
and enter your WEP key. For 64-bit encryption, enter 10 hexadecimal characters, For 128-bit
encryption, enter 26 hexadecimal characters. Click Next to continue the setting.
16. To use WPA or WPA2 security, select WPA or WPA2 and click Next button. Select WPA Mode:
WPA Only, WPA2 Only, WPA or WPA2, and set Pre-Shared Key by entering 8 ~ 63 characters.
Click Next to continue the setting.

Page 17
17. Confirm your new settings. It is recommended that you save or print your wireless settings with the
Save or Print buttons. Once finished, click Configure to continue.
18. Congratulations you have configured you TEW-690AP.

Page 18
Using the Configuration Menu
Whenever you want to configure your TEW-690AP, you can access the Configuration Menu by opening
the Web-browser and typing in the IP Address of the TEW-690AP.
¾Open the Web browser.
¾Type in the current IP Address of the AP (i.e. http://192.168.10.100).
If you have changed the default IP Address assigned to the TEW-690AP (192.168.10.100),
make sure to enter the correct IP Address.
¾Type admin in the User Name field.
¾The Password is admin.
¾Click Login In.
When you log into the unit the initial screen you will see is the status page that provides
system information and network configurations .

Page 19
Network
LAN SETTING
These are the settings of the LAN (Local Area Network) interface for the Access Point. The Access
Point's local network (LAN) settings are configured based on the IP Address and Subnet Mask assigned
in this section. The IP address is also used to access this Web-based management interface.
LAN Connection Type
Choose "Static IP (fixed IP)" if your router does not support DHCP or if for any other reason you need to
assign a fixed address to the AP. In this case, you must also configure the following fields.
IP Address
The IP address of the AP on the local area network. Assign any unused IP address in the range of
IP addresses available for the LAN. For example, 192.168.10.100.
Subnet Mask
The subnet mask of the local area network.
Default Gateway
The IP address of the router on the local area network.
Choose “DHCP (Auto Config)” if your router supports DHCP and you want the router to assign an IP
address to the AP.

Page 20
Wireless
The wireless section is used to configure the wireless settings for your Access Point. Note that changes
made in this section may also need to be duplicated on wireless clients that you want to connect to your
wireless network.
To protect your privacy, use the wireless security mode to configure the wireless security features.
The Wireless tab provides the following configuration options: Basic, Advanced, MAC Filter, Security,
WPS and Station List.
ACCESS POINT
