TRENDnet TEW-670APB User manual

i

Regulatory notes and statements
Wireless LAN, Health and Authorization for use
The use of Wireless LAN devices may be restricted in some situations or
environments for example:
·On board of airplanes, or
·In an explosive environment, or
·In case the interference risk to other devices or services is perceived or identified
as harmful
In case the policy regarding the use of Wireless LAN devices in specific
organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial
plants, private buildings etc.) is not clear, please ask for authorization to use these
devices prior to operating the equipment.
Regulatory Information/disclaimers
Installation and use of this Wireless LAN device must be in strict accordance with
the instructions included in the user documentation provided with the product. Any
changes or modifications made to this device that are not expressly approved by the
manufacturer may void the user’s authority to operate the equipment. The
Manufacturer is not responsible for any radio or television interference caused by
unauthorized modification of this device, of the substitution or attachment.
Manufacturer and its authorized resellers or distributors will assume no liability for
any damage or violation of government regulations arising from failing to comply
with these guidelines.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:

- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are
country dependent and are firmware programmed at the factory to match the
intended destination. The firmware setting is not accessible by the end user.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive
1999/5/EC. The following test methods have been applied in order to prove
presumption of conformity with the essential requirements of the R&TTE Directive
1999/5/EC:
EN60950-1: 2006
Safety of Information Technology Equipment
EN 50385: 2002
Product standard to demonstrate the compliance of radio base stations and fixed
terminal stations for wireless telecommunication systems with the basic restrictions

or the reference levels related to human exposure to radio frequency
electromagnetic fields (110MHz - 40 GHz) - General public
EN 300 328 V1.7.1 (2006-10)
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband
transmission systems; Data transmission equipment operating in the 2,4 GHz ISM
band and using wide band modulation techniques; Harmonized EN covering
essential requirements under article 3.2 of the R&TTE Directive
EN 301 489-1 V1.6.1: (2005-09)
Electromagnetic compatibility and Radio Spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment and services;
Part 1: Common technical requirements
EN 301 489-17 V1.2.1 (2002-08)
Electromagnetic compatibility and Radio spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment and services;
Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz
high performance RLAN equipment
This device is a 2.4 GHz wideband transmission system (transceiver), intended for
use in all EU member states and EFTA countries, except in France and Italy where
restrictive use applies.
In Italy the end-user should apply for a license at the national spectrum authorities
in order to obtain authorization to use the device for setting up outdoor radio links
and/or for supplying public access to telecommunications and/or network services.
This device may not be used for setting up outdoor radio links in France and in
some areas the RF output power may be limited to 10 mW EIRP in the frequency
range of 2454 – 2483.5 MHz. For detailed information the end-user should contact
the national spectrum authority in France.

0560
Česky
[Czech] TRENDnet tímto prohlašuje, že tento TEW-670APB je ve shoděse základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW-670APB overholder de
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt TRENDnet, dass sich das Gerät TEW-670APB in Übereinstimmung mit den
grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab TRENDnet seadme TEW-670APB vastavust direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
English Hereby, TRENDnet, declares that this TEW-670APB is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente TRENDnet declara que el TEW-670APB cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ TRENDnet ΔΗΛΩΝΕΙ ΟΤΙ TEW-670APB ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ
ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ
1999/5/ΕΚ.
Français
[French]
Par la présente TRENDnet déclare que l'appareil TEW-670APB est conforme aux exigences
essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Italiano
[Italian]
Con la presente TRENDnet dichiara che questo TEW-670APB è conforme ai requisiti essenziali
ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo TRENDnet deklarē, ka TEW-670APB atbilst Direktīvas 1999/5/EK būtiskajām prasībām
un citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo TRENDnet deklaruoja, kad šis TEW-670APB atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart TRENDnet dat het toestel TEW-670APB in overeenstemming is met de
essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, TRENDnet, jiddikjara li dan TEW-670APB jikkonforma mal-ħtiġijiet essenzjali u ma
provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, TRENDnet nyilatkozom, hogy a TEW-670APB megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym TRENDnet oświadcza, że TEW-670APB jest zgodny z zasadniczymi wymogami
oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.
Português
[Portuguese] TRENDnet declara que este TEW-670APB está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian] TRENDnet izjavlja, da je ta TEW-670APB v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.

Slovensky
[Slovak] TRENDnet týmto vyhlasuje, že TEW-670APB spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish] TRENDnet vakuuttaa täten että TEW-670APB tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar TRENDnet att denna TEW-670APB står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

vii
TABLE OF CONTENT
About This Guide...........................................................................................................................................................................................1
Overview of this User’s Guide..................................................................................................................................................................1
Introduction....................................................................................................................................................................................................2
Unpacking and Setup.....................................................................................................................................................................................3
Unpacking ..................................................................................................................................................................................................3
Setup...........................................................................................................................................................................................................3
Hardware Instalation......................................................................................................................................................................................4
Front panel .................................................................................................................................................................................................4
Rear Panel ..................................................................................................................................................................................................5
Side Panel...................................................................................................................................................................................................6
Hardware connections ...............................................................................................................................................................................6
Connect to the Switch/Hub/Router........................................................................................................................................................7
Check the installation ............................................................................................................................................................................7
Configuring the Wireless LAN Access Point ...............................................................................................................................................7
Login to the Wireless AP through WLAN................................................................................................................................................7
Login ..........................................................................................................................................................................................................7
Main Screen of the Access Point...............................................................................................................................................................8
Wizard........................................................................................................................................................................................................8
Status........................................................................................................................................................................................................12
Basic Setting ............................................................................................................................................................................................14
IP Setting..................................................................................................................................................................................................17
Advanced Wireless Setting......................................................................................................................................................................18
Access Point Mode ..............................................................................................................................................................................18
Wireless Bridge mode..........................................................................................................................................................................19
Repeater mode .....................................................................................................................................................................................20
Security ....................................................................................................................................................................................................22
Tools.........................................................................................................................................................................................................23
Technical Specifications..............................................................................................................................................................................25

1
ABOUT THIS GUIDE
Congratulations on your purchase of this 300Mbps Dual Band Wireless N Access
Point. This manual helps to describe the innovating wireless technology that can
help you build a wireless network easily! The manual contains detailed instructions
in operation of this product. Please keep this manual for future reference.
Overview of this User’s Guide
Introduction. Describes the 802.11a/b/g/n Dual Band WLAN Access Point and its
features.
Unpacking and Setup. Helps you get started with the basic installation of the
802.11a/b/g/n Dual Band WLAN Access Point.
Hardware Installation. Describes the LED indicators of the AP.
Configuring the Wireless LAN Access Point. Provides instructions on how to
configure the AP and it’s features.
Technical Specifications. Lists the technical (general, physical and environmental)
specifications of the 802.11a/b/g/n Dual Band WLAN Access Point.

2
INTRODUCTION
The 300Mbps Dual Band Wireless N Access Point (TEW-670APB) creates a high
performance dual band wireless n network with up to 14x the speed and 4x the
coverage of wireless g.
Create a wireless network using either the more common 2.4GHz or the
uncongested low-interference 5GHz wireless radio frequency with Dual Band
wireless n technology.
Extend your wireless network by adding additional wireless access points using the
Wireless Distribution System (WDS) feature. Monitor device status with SNMP v3
reporting. Advanced wireless encryption secures your wireless network. Provide
high speed Dual Band wireless coverage to stream HD media, download files and
surf the Internet.
Features
Wi-Fi Compliant with IEEE 802.11n (Draft 2.0) , IEEE 802.11b, IEEE 802.11b
and IEEE 802.11a standards.
Non-concurrent Dual Band architecture: create either a 2.4 or 5Ghz wireless
network.
Add a wireless network with Access Point mode or expand your network with
Wireless Distribution System (WDS).
Built in DHCP server allows for IP address distribution on the local network.
1 x 10/100Mbps Auto-MDIX LAN port
Supports 64/128-bit WEP(for 11b/g), WPA/WPA2, and WPA-PSK/WPA2-
PSK
Allow or restrict wireless access with MAC filtering
Easy wireless setup via WiFi Protection Setup.

UNPACKING AND SETUP
This chapter provides unpacking and setup information for the Access Point.
Unpacking
Open the box of the Access Point and carefully unpack it. The box should contain
the following items:
TEW-670APB
Multi-Language Quick Installation Guide
Power Adapter
CD-Rom (User’s guide)
If any item is found missing or damaged, please contact your local reseller for
replacement.
Setup
The setup of the Wireless Access Point can be performed using the following steps:
Locate an optimum location for the Wireless LAN Access Point (AP). The best
place for your AP is usually the center of your wireless network, with line of
sight to all of your mobile stations.
Visually inspect the Ethernet RJ45 port connector and make sure that it is fully
plugged in to the system’s Ethernet switch/hub port.
Fix the direction of the antennas. Try to place the AP in a position that can best
cover your wireless network. Normally, the higher you place the antenna, the
better the performance will be. The antenna’s position enhances the receiving
sensitivity.
Visually inspect if the Power Adapter was fully plugged to the device power
jack.

4
HARDWARE INSTALATION
Front panel
The figure below shows the LED Indicator of the Wireless LAN Access Point.
Power:
This indicator lights green when the Access Point is turned on.
Status:
This indicator blinkswhen the WLAN AP is working successfully. Otherwise, an on
or off means the function of the WLAN AP has failed.
LAN:
This indicator lights green when the LAN port has successfully connected to an
Ethernet network. Otherwise, the indicator blinks while transmitting and receiving
data on the Ethernet network.
WLAN:
This indicator blinks during Wireless LAN activity.

5
Rear Panel
The figure below shows the rear panel of the Access Point
Rear Panel
LAN
Ethernet port with 10/100Mbps Fast Ethernet connections, connect this port to a
switch/hub.
RESET
Press the “RESET” button for more than 5 seconds buttonto reset the settings back
to factory default.
Power
Connect the DC Power Adapter plug to the AP’s power jack.
Antenna
Two external 3 dBi dipole antennas.

6
Side Panel
The figure below shows the side panel of the IEEE 802.11b/g/n Wireless
Broadband Router.
Side Panel
WPS
Push this button to execute the Wi-Fi Protected Setup process.
Hardware connections

7
Connect to the Switch/Hub/Router
1. Plug in one end of the RJ45 network cable to a Switch/Hub port,
2. Plug in the other end of the RJ45 network cable to the Wireless Access Point.
Check the installation
The LEDs of the Access Point are clearly visible and the status of the network link
can be seen instantly:
1.With the power source on, once the device is connected, the Power, LAN and
WLAN port LEDs will light up indicating a normal status.
2.If the LAN Port’s Link indicator does not light up then check the RJ-45 cable if
it is firmly connected to the RJ45 port, while the LAN is linked up to the
Switch/Hub, the LAN port’s LED will light up.

7
CONFIGURING THE WIRELESS LAN ACCESS POINT
The Wireless Access Point has a Web GUI interface for easy configurations
through a Web Browser. A network manager can manage, control and monitor the
AP from the local LAN. This section indicates how to configure the AP to enable
its functions.
Login to the Wireless AP through WLAN
Before configuring the Wireless AP through WLAN, make sure that the SSID,
Channel and encryption settings are set properly.
The default setting of the Wireless AP that you will use:
SSID: TRENDnet670
Wireless Mode: Access point
Channel: 6
Channel Width: 20MHz
Security: disabled
IP address: 192.168.10.100
Login to the Wireless AP through LAN
Before you configure this device, note that when the AP is configured through an
Ethernet connection, make sure the manager PC must be set on same the IP
network. For example, when the default network address of the default IP address
on the AP is 192.168.10.100, then the manager PC should be set at 192.168.10.x
(where x is a number excluding 100), and the default subnet mask is 255.255.255.0.
Open Internet Explorer 6.0 or above Web browser.
Enter IP address http://192.168.10.100 (the factory-default IP address setting) on
the address bar.
When the below screen appears enter your User name and Password, both of the
default Username and Password is “admin”

8
Main Screen of the Access Point
The screen will show the status of the AP when you login to the AP.
There are seven main functions in the main screen: Wizard, Status, Basic Setting,
IP Setting, Advanced Setting, Security and Tools.
Wizard
The setup wizard is provided as the part of the web configuration utility. Users can
simply follow the step-by-step process to configure the Access Point in 4 easy steps.
Click on the “Wizard” button and the following screen will appear. Please click
“Next” to continue.
Step 1: Set your new password
Enter a new password and click “Next” to continue.

9
Step2: Set the SSID, Channel, Operation Band, 802.11 mode and Channel
Width
Please type the name of SSID and select the Channel, Operation Band, 802.11
mode and Channel Width. Then, click “Next” to continue.
Step 3: Secure your Wireless Network
The default security setting is set to NONE. There are four options: BEST (WPA2),
BETTER (WPA), GOOD (WEP) and NONE. Please select the type of security and
click “Next” to continue.

10
BEST (WPA2 Personal)
Passphrase: The length should be at least 8 characters long and click “Next” to
continue.

11
BETTER (WPA Personal)
Passphrase: The length should be at least 8 characters long and click “Next” to
continue.
GOOD (WEP)
Key Type: Select the key format from the drop-down list HEX or ASCII.
Key Size: Select the level of encryption from the drop-down list.
Wireless Security Password: Enter your WEP security key and click “Next” to
continue.

12
Step 4: Save and Restart
The Setup wizard is now completed. The new settings will be take effect after the
Access Point has restarted. Please click “Restart” to save the new configuration
and reboot the Access Point. Click “Exit” to quit without making any changes.
Users also can go back to modify the setting by clicking “Back”.
Status
This page shows the following information.
Firmware Version: Shows the current firmware version and released date code.
LAN: Shows the Mac address, IP address (default: 192.168.10.100), Subnet Mask
and Gateway Address. The current LAN traffic calculated in terms of number of
packets sent and received by the AP through a wired connection is also displayed.
