TRINITY Pro TLSF-7211 User manual

OWNER’S MANUAL
Important / Important / Importante
DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE| DESCARGUE LAAPLICACIÓN GRATUITA
Directives intelligentes
Instrucciones Inteligentes
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
TRINITY PRO 72” STAINLESS STEEL ROLLING
WORKBENCH W/ ADJUSTABLE TOP
Model # TLSF-7211

Your TRINITY PRO 72in Stainless Steel Rolling Workbench w/ Adjustable Top should include the following
parts. Please inspect box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via our “Contact Us” section at www.trinityii.com.
You will need 14mm wrench for caster assembly which is NOT included.
ABC
CASTER
BOLT (16)
M10
D
LINER (11)
E G H
LOCKING
CASTER (2)
F
NON-LOCKING
CASTER (2)
KEY (4)
WORKBENCH
w/Adjustable top (1)
PARTS LIST
SHELF (1)
CRANK (1)
© 2020 TRINITY - 800.985.5506 1
I
SHELF SUPPORT (4)

ASSEMBLY INSTRUCTIONS
STEP 1
Location of parts:
1) KEYS (H) are hooked to key leash mounted
inside TOP MIDDLE Drawer.
2) LINERS (G) are inside BOTTOM RIGHT Drawer.
3) CASTERS (B/C), CASTER BOLTS (D), SHELF
SUPPORTS (F) and CRANK (I) are boxed inside
BOTTOM LEFT Drawer.
4) SHELF (E) is inside bottom Cabinet.
12
© 2020 TRINITY - 800.985.5506
2
3
4
STEP 2
Lay WORKBENCH (A) on its backside. Lift
workbench by side handles. Do NOT lift
workbench by wood top. Two people are needed.
Do NOT attempt this alone.
Position LOCKING CASTERS (B) on side of
WORKBENCH (A) of your choice and align holes to
pre-installed nuts on underside of WORKBENCH
(A). Use a 14mm socket wrench to fully tighten
CASTER BOLT (D) to WORKBENCH (A).
Repeat above steps to install NON-LOCKING
CASTERS (C).
Notes:
* Make sure to install both LOCKING CASTERS (B)
on same side of workbench.
** For ease of use, place LOCKING CASTERS (B) on
side you will regularly push or pull.
*** If you plan to push workbench against a wall,
place LOCKING CASTERS (B) on front long side for
ease of access.
B
D
C
A
B (2) C (2) D (16) 14mm

ASSEMBLY INSTRUCTIONS
STEP 3
E (1)
Place LINERS (G) inside each drawer and Cabinet.
STEP 4
EF
G (11)
G
© 2020 TRINITY - 800.985.5506 3
F (4)
Carefully lift Workbench upright. Two people
are needed. Do NOT attempt this alone.
SHELF (E) is shipped inside the bottom cabinet.
Tilt SHELF (E) diagonally and remove it from
cabinet.
Attach SHELF SUPPORT (F) by hooking it over
position tab at desired height. Make sure all
four SHELF SUPPORTS (F) are at same level. Tilt
SHELF (E) diagonally to move it inside cabinet.
Place SHELF (E) on top of all four SHELF
SUPPORTS (F).
You can adjust shelf height position by
removing shelf, re-locating shelf supports and
replacing shelf.
Position Tab

USAGE INSTRUCTIONS
I (1)
I
4
RAISE WOOD TOP
LOWER WOOD TOP
© 2020 TRINITY - 800.985.5506
Insert CRANK (I) into receiver on Workbench. Turn
CRANK (I) clockwise to raise wood top. Remove
CRANK (I) and store inside drawer after wood top is
raised to desired position.
Turn CRANK (I) counterclockwise to lower wood top.
Remove CRANK (I) and store inside drawer after
wood top is lowered to desired position.

USAGE INSTRUCTIONS
DRAWER REMOVAL
DRAWER REPLACEMENT
Pull drawer out so that it is almost fully extended. On RIGHT-hand side, push black release lever DOWN.
On LEFT-hand side, pull black release lever UP. While holding levers as instructed, pull drawer forward
until released from slides attached to Workbench (“Workbench Slides”).
Note: Slides attached to drawer (“Drawer Slides”) are an integral part of drawer and must be removed
along with drawer itself.
To replace drawer, pull slides out completely. Insert brackets on each side of Drawer Slides into
corresponding slots on Workbench Slides, making sure they are properly positioned. Once brackets are
inserted into slots, completely close drawer to set all slides in their proper positions.
© 2020 TRINITY - 800.985.5506 5

SERVICE PARTS LIST –TLSF-7211
Part Number Description Part Number Description
1) ZSV-12-015-1575 Slide (workbench side) 15) XBK-22-006-2615 27” Drawer Liner
2) ZSV-12-001-1575 Slide (drawer side) 16) XBK-22-006-1727 Shelf Liner
3) LNA-06-016-7219 Wood Top 17) XBS-08-017-1421 Right Door
4) XSV-05-029-0001 Crank 18) ZSV-99-028-5020 Non-locking Caster
5) XSV-05-001-0900 Side Handle 19) AMA-05-007-3000 Door Handle
6) ZSV-01-001-0612 Handle Bolt 20) XBS-07-009-1509 15” 2nd Medium Drawer
7) XBS-07-009-1506 15” 1st Medium Drawer 21) XBK-23-010-3012 End cap
8) XBS-07-009-1512 15” Large Drawer 22) XBS-07-009-1503 15” Small Drawer
9) ZSV-99-027-5020 Locking Caster 23) AMA-05-007-1400 15” Drawer Handle
10) ZSV-01-001-1020 Caster Bolt 24) XBS-07-009-2703 27” Drawer
11) XBS-08-016-1421 Right Door 25) AMA-05-007-2600 27” Drawer Handle
12) XSV-02-017-0001 Shelf Support 26) CSV-11-005-0XXX Lock
13) PBK-03-084-2615 Shelf 27) XBK-02-047-0001 Key leash
14) XBK-22-006-1415 15” Drawer Liner 28) XBK-10-003-0XXX Key
TRINITY Customer Service provides the following replacement parts:
© 2020 TRINITY - 800.985.5506
6

2
3
5
15
18
8
20 7
4
1
6
9
12
19
10
11
14
21
23
22
SERVICE PARTS LIST –TLSF-7211
13
24
25
26
7
28
27
TRINITY Customer Service provides the following replacement parts:
NOTE: Replacement keys may be ordered using the code shown on the face of the lock.
© 2020 TRINITY - 800.985.5506
16
17

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in
injury and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a
damaged part.
5. Do NOT overload the product. Below capacity is based on evenly distributed weight.
6. Lock the casters when leaving workbench in stationary position.
7. Lock the drawers and cabinet before moving the workbench.
8. Remove all items from wood top and lower the wood top before moving the workbench.
9. Always move workbench with two people. Roll slowly and constantly check surroundings
to ensure enough clearance. Heavy weight workbench can be hard to stop if moving too
fast, causing serious injury or damage.
10. Do NOT open more than one drawer at a time. Tipping can occur.
11. Do NOT step or lean on open drawers. Tipping can occur.
12. Do NOT lift workbench by wood top. Wood top may separate causing injury.
13. Do NOT hang on the wood top. Tipping can occur
14. Be careful of areas under the wood top when it is being lowered. Lower slowly and stop
immediately if sensing resistance. Crushing of items or body parts can occur.
Weight capacity per drawer w/ 1 pair of slides 45.4 kg / 100 lb
Weight capacity per drawer w/ 2 pairs of slides 90.7 kg / 200 lb
Weight capacity of wood top when raised 136.1 kg / 300 lb
Total weight capacity of workbench when wood top lowered 997.9 kg / 2200 lb
8© 2020 TRINITY - 800.985.5506

WARNINGS
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Keep dry and avoid damp environments.
•Use a quality stainless steel cleaner and follow instructions that come with the cleaner.
Wipe ALONG the grain (NOT against).
•Wood top can be cleaned with damp cloth and wiped dry immediately with dry cloth. If
needed, solvent-based wood furniture cleaner can be used.
•Clean up any spills immediately to prevent stains from forming on the wood top.
CARE AND MAINTENANCE
15. Do NOT store items underneath the wood top. Crushing of items can occur.
16. Do NOT let children play near the workbench.
17. Load the workbench starting with the bottom drawers to prevent workbench from tipping.
18. Make sure all drawers and cabinet are closed tightly before locking or unlocking.
9
© 2020 TRINITY - 800.985.5506

© 2020 TRINITY - 800.985.5506
10

© 2020 TRINITY - 800.985.5506 11
Thank you for purchasing a TRINITY PRO 72in Stainless Steel Rolling Workbench w/Adjustable Top. In
order to register your product and receive streamlined customer service, please fill out the following
Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration
Form online at www.trinityii.com or (3) scan and email the form to [e-mail].
Include a copy of your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TLSF-7211 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
PRODUCT REGISTRATION

© 2020 TRINITY - 800.985.5506
12

1 YEAR LIMITED WARRANTY
TRINITY PRO 72” Stainless Steel Rolling Workbench w/Adjustable Top
Model # TLSF-7211
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
TRINITY PRO 72in Stainless Steel Rolling Workbench w/Adjustable Top (“Product”) that each Product shall be
free from defects in workmanship and materials for a period of 1 year from the date of original purchase.
Trinity’s obligation under this warranty shall be limited to repair or replacement of, or adequate
compensation for the Product which shall not be greater than the amount of the purchase price of the
Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the
property of Trinity and must be returned to Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at [phone], between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates and assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
© 2020 TRINITY - 800.985.5506 13

TRINITY Customer Service
TEL: [phone]
FAX: [phone]
EMAIL: [e-mail]
Monday through Friday
5:00 AM –5:00 PM (PST)
www.trinityii.com
QUESTIONS? NEED PARTS?
WE ARE HERE TO HELP!
Please feel free to contact us. There are no questions too small, or
any problems too big. We’re committed to providing our customers
with the highest level of service.
CONTACT US
