TRINITY 48” STAINLESS STEEL TABLE
Model # TLS-0201 / TLS-0201C (W/ CASTERS)

© 2020 TRINITY - 800.985.5506
1

Your TRINITY 48” Stainless Steel Table should include the following parts. Please inspect box contents to
ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via “Contact Us” section at www.trinityii.com.
PARTS LIST
TABLE TOP (1)
A
SHELF (1)
B C
HEX KEY (1)
D
NON-LOCKING
CASTER (2)
E
GH
LEG (4)
Feet Leveler comes pre-installed
HEX SCREW (8)
F
SCREW CAP (8)
LOCKING
CASTER (2) ADAPTER (4) WRENCH (1)
IJ
(TLS-0201C only)
© 2020 TRINITY - 800.985.5506 2

ASSEMBLY INSTRUCTIONS
Slide SHELF (B) over each LEG (C) to desired height.
Using provided HEX KEY (F), tighten HEX SCREW (D)
into SHELF (B).
Turn HEX KEY (F) as far clockwise as possible, take out
HEX KEY (F), reposition, reinsert, and turn as far
clockwise as possible again until HEX SCREW (D) is
securely in place. Place SCREW CAP (E) over each
HEX SCREW (D).
Lay TABLE TOP (A) upside-down on a smooth flat
surface. Insert LEGS (C) into round slots on bottom
of TABLE TOP (A). Make sure LEGS (C) are fully
inserted into TABLE TOP (A).
You will insert and tighten HEX SCREWS (D) in
Step 3.
STEP 1
STEP 2
A (1) C (4)
E (4) F (1)
D (4)
C
A
B (1)
B
DE
© 2020 TRINITY - 800.985.5506
3

ASSEMBLY INSTRUCTIONS
Mobile Option
Unscrew Feet Leveler from each LEG (C). Screw
ADAPTER (I) onto each CASTER (G/H). Screw
CASTER (G/H) into each LEG (C). Make sure to
place (2) LOCKING CASTERS (H) on same side of
Table. Tighten as much as possible with WRENCH
(J).
Use provided caster wrench to tighten
completely. Failure to do as instructed could
result in caster stem breaking.
Stationary Option
Unscrew ADAPTER (I) with CASTER (G/H) from
each LEG (C). Screw in Feet Leveler into each
LEG (C). Lift Table right side up, and adjust Feet
Levelers until Table is stable and level.
Use HEX KEY (F) to tighten HEX SCREW (D) for
each LEG (C) into TABLE TOP (A).
Turn HEX KEY (F) as far clockwise as possible,
take out HEX KEY (F), reposition, reinsert, and
turn as far clockwise as possible again until
HEX SCREW (D) is securely in place. Place
SCREW CAP (E) over each HEX SCREW (D).
Turn Table right-side up and adjust Feet
Levelers until Table is stable and level.
FEET
LEVELER
STEP 3
STEP 4 (TLS-0201C only)
E (4) F (1)
D (4)
DE
I (4) J (1)
H (2)
G (2)
G
I
J
© 2020 TRINITY - 800.985.5506 4

SERVICE PARTS LIST –TLS-0201 / TLS-0201C (w/Casters)
Part Number Description Part Number Description
1) XBS-06-007-4824 Table Top 7) XXX-97-001-0001 Hex Key
2) XBS-03-012-4417 Shelf 8) XBK-01-016-2535 Adapter
(TLS-0201C only)
3) XGL-04-010-3200 Leg 9) ZSV-99-007-4010 Non-locking Caster
(TLS-0201C only)
4) XSV-98-004-3283 Feet Leveler 10) XBK-23-005-0914 Screw Cap
5) ZSV-99-008-4010 Locking Caster
(TLS-0201C only)
11) ZSV-01-015-0812 Hex Screw
6) XXX-97-002-0001 Wrench
(TLS-0201C only)
TRINITY Customer Service provides the following replacement parts:
5
6
3
8
7
4
9
2
11 1
10
© 2020 TRINITY - 800.985.5506
5

1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions in this manual cannot cover all possible
conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product. Any
modifications will void warranty.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a
damaged part.
5. Table must be used with at least one shelf installed for stability. Additional shelf can be
added and is available on trinityii.com.
6. Use the provided caster wrench to tighten casters completely. Failure to do as
instructed could result in the caster stem breaking thereby causing the shelving rack to
collapse.
7. Lock the casters when being used as a work surface.
8. Do NOT overload the product.
WARNINGS
CARE AND MAINTENANCE
Weight capacity per shelf 68 kg / 150 lb (evenly distributed)
Total weight capacity on feet levelers 408 kg / 900 lb (evenly distributed)
Total weight capacity on casters 136 kg / 300 lb (evenly distributed)
•Use a quality stainless steel cleaner and follow instructions that come with the cleaner.
Wipe ALONG the grain (NOT against).
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Keep dry and avoid damp environments. Should not be left out unprotected in the
elements.
6
© 2020 TRINITY - 800.985.5506

© 2020 TRINITY - 800.985.5506
7
