Trinity TBFLWH-1424 User manual

OWNER’S MANUAL
TRINITY 30” x 18” x 35” STAINLESS STEEL TOP KITCHEN CART
Model # TBFLWH-1424
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
Intelligent Instructions
Directives intelligentes
Instrucciones Inteligentes
DOWNLOAD THE FREEAPP | TÉLÉCHARGERL’APPLICATION GRATUITE| DESCARGUE LA APLICACIÓN GRATUITA

PARTS LIST
Your TRINITY Stainless Steel Top Kitchen Cart should include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via our “Contact Us” section at www.trinityii.com.
A
STAINLESS STEEL TOP (1)
B
SHELF (2)
C
LEFT HANDLE LEG (1)
D
RIGHT HANDLE LEG (1)
E
CASTER LEG (2)
F
HANDLE (1)
G
CASTER (2)
H
LEG SCREW (12)
Black
I
HANDLE SCREW (2)
Silver
J
SCREWDRIVER (1)
K
WRENCH (1)
1© 2023 TRINITY - 800.985.5506

ASSEMBLY INSTRUCTIONS
STEP 1
Lay STAINLESS STEEL TOP (A) on a clean surface
to prevent scratching the top surface. Take
LEFT HANDLE LEG (C) and orient it in proper
position by aligning hole for mounting handle
along long edge of STAINLESS STEEL TOP (A).
Place LEG SCREW (H) through hole in STAINLESS
STEEL TOP (A) and tighten it with SCREWDRIVER
(J) to top nut in LEFT HANDLE LEG (C).
Repeat for RIGHT HANDLE LEG (D).
Note: LEFT & RIGHT HANDLE LEG (C & D) have FOOT PAD
on bottom.
STEP 2
Place HANDLE SCREW (I) through hole in LEFT
HANDLE LEG (C) and tighten it with
SCREWDRIVER (J) to nut in HANDLE (F).
Repeat for RIGHT HANDLE LEG (D).
© 2023 TRINITY - 800.985.5506 2

ASSEMBLY INSTRUCTIONS
STEP 3
Lay kitchen cart on its side so it is leaning on side of
STAINLESS STEEL TOP (A) and RIGHT HANDLE LEG
(D). Orient SHELF (B) so flat surface faces STAINLESS
STEEL TOP (A). Place LEG SCREW (H) through hole in
SHELF (B) and tighten it with SCREWDRIVER (J) to nut
in RIGHT HANDLE LEG (D).
Repeat for LEFT HANDLE LEG (C) and for
2nd shelf.
STEP 4
Place LEG SCREW (H) through hole in STAINLESS
STEEL TOP (A) or SHELF (B) and tighten it with
SCREWDRIVER (J) to nut in CASTER LEG (E).
Repeat until all 6 LEG SCREWS (H) have been
installed.
3© 2023 TRINITY - 800.985.5506

ASSEMBLY INSTRUCTIONS
STEP 5
Flip cart over and lay STAINLESS STEEL
TOP (A) on a clean surface again. Screw
CASTER (G) into nut of CASTER LEG (E).
Tighten CASTER (G) with WRENCH (K).
Use provided caster wrench to tighten
completely. Failure to do as instructed
could result in caster stem breaking.
STEP 6
Carefully flip completed cart right side up.
© 2023 TRINITY - 800.985.5506 4

SERVICE PARTS LIST –TBFLWH-1424 (White)
TRINITY Customer Service provides the following replacement parts:
# Part Number Description # Part Number Description
1) XBS-06-021-3018 Stain Steel Top Frame 7) XXX-97-001-0002 Screwdriver
2) LWH-04-003-3400 Right Handle Leg 8) LWH-03-004-2816 Shelf
3) XBS-05-004-1600 Handle 9) XXX-97-002-0001 Wrench
4) ZSV-01-004-0643 Handle Screw 10) XBK-98-002-2525 Foot pad
5) LWH-04-004-3400 Left Handle Leg 11) ZSV-99-007-3010 Caster
6) ZBK-01-004-0635 Leg Screw 12) LWH-04-005-3025 Caster Leg
5© 2023 TRINITY - 800.985.5506

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and / or damage.
2. Tighten all casters completely by using the wrench. Failure to do as instructed could
result in the caster stem breaking, thereby causing the product to collapse.
3. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of the
environment and ensure to use the product in a safe and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and / or safety of the product, and may affect the life of the product. Any
modifications will void product warranty.
5. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a
damaged part.
6. Do NOT overload the product. Below capacity is based on evenly distributed weight.
7. Do NOT roll the product on an uneven surface. Only move the product on a smooth
surface. Rolling over rough or uneven surfaces may cause casters to break or items on the
product to fall, resulting in injury and / or damage. Wood and laminate flooring can be
scratched or dented. Ensure your flooring can bear the weight of loaded product before
rolling loaded product across your flooring.
8. Do NOT allow children to climb or play around the product. Tipping may occur causing
injury.
9. Do NOT stand or lean on the product or use any part of this product as a step ladder.
Tipping may occur causing injury.
10. Do NOT move a loaded cart. Tilting of cart is needed to move it and items may fall causing
damage or injury.
Weight capacity per Shelf on Casters 50 lb
Total weight capacity of Kitchen Cart 150 lb
© 2023 TRINITY - 800.985.5506 6

CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do NOT use scouring pad for cleaning.
•Use a quality stainless steel cleaner and follow instructions that come with the cleaner.
Wipe ALONG the grain (NOT against).
•This product is designed for indoor use.
7© 2023 TRINITY - 800.985.5506

PRODUCT REGISTRATION
Thank you for purchasing a TRINITY Stainless Steel Top Kitchen Cart. In order to register your product
and receive streamlined customer service, please fill out the following Product Registration Form and
(1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
www.trinityii.com or (3) scan and email the form to customerservi[email protected]m. Include a copy of
your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
© 2023 TRINITY - 800.985.5506 8
