Trinity ECOSTORAGE TBFZ-2221 User manual

OWNER’S MANUAL
TRINITY ECOSTORAGE® LARGE 2-TIER SLIDING DRAWER
Model # TBFZ-2221
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
Intelligent Instructions
Directives intelligentes
Instrucciones Inteligentes
DOWNLOAD THE FREEAPP | TÉLÉCHARGERL’APPLICATION GRATUITE| DESCARGUE LA APLICACIÓN GRATUITA

PARTS LIST
Your TRINITY EcoStorage® Large 2-Tier Sliding Drawer should include the following parts. Please inspect
box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [email protected]om. Parts can also be requested online
via our “Contact Us” section at www.trinityii.com.
You will need a pencil and a Philips screwdriver for assembly.
Note: There are two options for installation:
1) In cabinet –go to page 2-3
2) On wire rack –go to page 4-6
A
LARGE DRAWER (1)
B
SMALL DRAWER (1)
C
LEFT SLIDE (1)
D
RIGHT SLIDE (1)
E
F
CABINET MOUNTING
TEMPLATE (1)
G H I
Used when installing in cabinet Used when installing on wire rack
PLATE
SCREW (4)
CABINET
SCREW (4) RACK PLATE (4)
CONNECTOR (4)
1© 2022 TRINITY - 800.985.5506

ASSEMBLY INSTRUCTIONS –In Cabinet
STEP 1
Place CABINET MOUNTING TEMPLATE
(F) inside your cabinet. With a pencil,
mark locations to install screws.
Note: For easier installation you can
pre-drill a small hole at each marked
location. Screw
holes
F
STEP 2
Identify LEFT & RIGHT SLIDES (C & D).
Note: BACK end of each SLIDE (C & D) has
a clear plastic tip.
Place LEFT & RIGHT SLIDES (C & D) in their
proper orientation and desired position
inside cabinet.
Extend LEFT & RIGHT SLIDES (C & D)
slightly and align center of oval slots to
your marking in cabinet. Use self-tapping
CABINET SCREWS (G) to fasten LEFT &
RIGHT SLIDES (C & D) in your cabinet.
G
CD
FRONT
BACK
© 2022 TRINITY - 800.985.5506 2
CLIPS should be
on the OUTSIDE.

STEP 3
Extend LEFT & RIGHT
SLIDES (C & D) out of your
cabinet.
Place LARGE DRAWER (A)
on clips of LEFT & RIGHT
SLIDES (C & D), with one
hand holding one slide,
other hand pushes down
to secure bottom wire of
LARGE DRAWER (A) into
clips as image shows.
A
C
STEP 4
D
Insert 4 CONNECTORS (E) into posts of LARGE DRAWER (A). Place SMALL
DRAWER (B) on connectors. Make sure smaller ends of connectors are
completely inside drawer posts.
Push sliding drawer back into cabinet.
ASSEMBLY INSTRUCTIONS –In Cabinet
3© 2022 TRINITY - 800.985.5506
B
E

ASSEMBLY INSTRUCTIONS –On Wire Rack
STEP 1
STEP 2
Place LARGE DRAWER (A) on top of CLIPS
to ensure proper SLIDES spacing.
Position as such:
Take LARGE DRAWER (A) away once
SLIDES spacing is set.
Note: For ease of installation, do NOT
clip LARGE DRAWER (A) into LEFT &
RIGHT SLIDES (C & D) until Step 4.
Identify LEFT & RIGHT SLIDES (C & D).
Note: BACK end of each SLIDE (C & D) has
a clear plastic tip.
Place LEFT & RIGHT SLIDES (C & D) on
desired wire shelf. Line up slides along
wires on wire shelf to ensure slides are
straight and front/back ends of slides are
flush.
CLIPS should be
on the OUTSIDE. FRONT
BACK
© 2022 TRINITY - 800.985.5506 4
A
CD

ASSEMBLY INSTRUCTIONS –On Wire Rack
STEP 3
STEP 4
5© 2022 TRINITY - 800.985.5506
FRONT
BACK
Hold RACK PLATES (H) with one hand
under wire shelf where slot of slide is,
with a Phillips screwdriver, secure
LEFT & RIGHT SLIDES (C & D) to wire
shelf by putting PLATE SCREWS (I)
through slots and fasten to RACK
PLATES (H).
Attach LARGE DRAWER (A) to CLIPS of
LEFT and RIGHT SLIDES (C & D) until
DRAWER wire clicks into CLIPS.
Installation Suggestion:
With LARGE DRAWER (A) resting on top
of CLIPS, brace top of LARGE DRAWER
(A) with one hand, with a rubber
mallet, lightly tap each bottom corner
of LARGE DRAWER (A) closest to CLIPS
to secure LARGE DRAWER (A) into
CLIPS. A
I
H

ASSEMBLY INSTRUCTIONS –On Wire Rack
STEP 5
Insert 4 CONNECTORS (E) into posts
of LARGE DRAWER (A). Place SMALL
DRAWER (B) on connectors. Make
sure smaller ends of connectors are
completely inside drawer posts.
© 2022 TRINITY - 800.985.5506 6
B
E

SERVICE PARTS LIST –TBFZ-2221 (Chrome)
TRINITY Customer Service provides the following replacement parts:
7© 2022 TRINITY - 800.985.5506
# Part Number Description # Part Number Description
1)
XBK
-23-002-1210
Plastic Cap
6)
ZSV
-12-003-1575
Right
Slide
2)
ZSV
-04-060-1000
Connector
7)
ZSV
-01-005-0428
Rack Plate
3)
ZSV
-21-021-1920
Large Drawer
8)
ZSV
-01-004-0414
Plate Screw
4)
XWH
-96-001-0009
Cabinet Mounting
Template
9)
ZSV
-12-004-1575
Left Slide
5)
ZSV
-01-003-0414
Cabinet
Screw 10)
ZSV
-21-021-1818
Small Drawer

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product. Any
modifications will void product warranty.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
5. Do NOT overload the product. Each pair of slides holds up to 50lb with evenly distributed
weight.
6. Do NOT allow children to climb or play in the drawer.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals
•Keep dry and avoid damp environments
© 2022 TRINITY - 800.985.5506 8

PRODUCT REGISTRATION
Thank you for purchasing a TRINITY Ecostorage® Large 2-Tier Sliding Drawer. In order to register your
product and receive streamlined customer service, please fill out the following Product Registration
Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
www.trinityii.com or (3) scan and email the form to [email protected]om. Include a copy of
your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TBFZ-2221 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
9© 2022 TRINITY - 800.985.5506

1 YEAR LIMITED WARRANTY
TRINITY Ecostorage® Large 2-Tier Sliding Drawer
Model # TBFZ-2221
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
TRINITY Ecostorage® Large 2-Tier Sliding Drawer (“Product”) that each Product shall be free from defects in
workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation
under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product
which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity,
during the warranty period. All replaced parts and Products become the property of Trinity and must be
returned to Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at [phone], between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates and assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
© 2022 TRINITY - 800.985.5506 10
