Trinity TBF-1601 User manual

OWNER’S MANUAL
TRINITY ALUMINUM WORK STOOL
Model # TBF-1601
Everything in its place.®

© 2016 TRINITY - 800.985.5506
1

Your TRINITY Aluminum Work Stool should include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact
TRINITY Customer Service: 800.985.5506 or [e-mail]. Parts can also be
requested online at www.trinityii.com (Help & More, Contact Us). 
SEAT (1)
A
BASE (1)
B C
D E
PNEUMATIC (1)
CASTER (4) WRENCH (1)
PARTS LIST
© 2016 TRINITY - 800.985.5506 2

ASSEMBLY INSTRUCTIONS
Turn the BASE (B) with CASTERS (D) right-
side up, and insert the PNEUMATIC (C)
cylinder into the center ring. Push down firmly,
and make sure that the PNEUMATIC (C)
cylinder is straight.
Lay the BASE (B) upside down. Screw in
the CASTERS (D). Make sure to use the
provided WRENCH (E) to tighten the
CASTERS (D) in all the way.
Use the provided caster wrench to
tighten completely. Failure to do as
instructed could result in the caster
stem breaking.
STEP 1
STEP 2
D (4) E (1)
B (1)
C (1)
© 2016 TRINITY - 800.985.5506
3
B
E
D
C

ASSEMBLY INSTRUCTIONS
Slide the SEAT (A) on top of the
PNEUMATIC (C) cylinder. Ensure that
the SEAT (A) is centered properly, and
push down to affix the SEAT (A) to the
PNEUMATIC (C) cylinder. To secure the
entire Stool, sit down carefully on the
SEAT (A), and slowly use your weight to
affix all parts into place.
STEP 3
A (1)
© 2016 TRINITY - 800.985.5506 4
If you prefer to use this as a Stationary Work
Stool, please contact us at 800.985.5506 or
[e-mail], and we will
provide you with Feet Levelers (XBK-98-003-
2538).
Remove Casters and screw on Feet Levelers.
STATIONARY OPTION
(4)
A

SERVICE PARTS LIST –TBF-1601
Part Number Description Part Number Description
1) PSV-25-001-0001 Seat 4) ZSV-99-007-2008 Caster
2) CSV-09-005-0001 Pneumatic 5) XXX-97-002-0001 Wrench
3) CSV-25-002-0001 Base
TRINITY Customer Service provides the following replacement parts:
4
2
1
3
5
© 2016 TRINITY - 800.985.5506
5

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result
in injury and/or damage.
2. Use the provided caster wrench to tighten casters completely. Failure to do as
instructed could result in the caster stem breaking thereby causing the shelving rack
to collapse.
3. The warnings, cautions, and instructions discussed in this manual cannot
cover all possible conditions or situations that may occur. The user must
always be aware of their environment and ensure that they use the product in a safe
and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
5. Check for damaged parts. Before using this product, carefully check that all parts
are in good condition, and that the product will operate properly and perform its
intended function. Check for damaged parts and any other conditions that may affect
the operation of this product. Replace damaged or worn parts, and never use this
product with a damaged part.
6. Do NOT overload the product.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Wipe dry after use.
Total weight capacity 300 lb
© 2016 TRINITY - 800.985.5506 6

© 2016 TRINITY - 800.985.5506
7

Thank you for purchasing a TRINITY Aluminum Work Stool. In order to register your product
