Trinity EcoStorage THA-3328 User manual

OWNER’S MANUAL
TRINITY EcoStorage® 24" Stainless Steel Wall Shelf
Model# THA-3328 / THA-33282 (2-pack)
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
Intelligent Instructions
Directives intelligentes
Instrucciones Inteligentes
DOWNLOAD THE FREEAPP | TÉLÉCHARGERL’APPLICATION GRATUITE| DESCARGUE LA APLICACIÓN GRATUITA

blank

PARTS LIST
Your TRINITY EcoStorage® 24” Stainless Steel Wall Shelf include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [email protected]. Parts can also be requested online
via our “Contact Us” section at www.trinityii.com.
You will need a pencil, a Philips screwdriver, and a drill for assembly.
A
SHELF (1)
B
LEFT BRACKET (1)
C
RIGHT BRACKET (1)
D
NUT (4)
E
WRENCH (1)
F
SCREW (4)
G
ANCHOR (4)
H
WALL MOUNTING
TEMPLATE (1)
© 2023 TRINITY - 800.985.5506 1

ASSEMBLY INSTRUCTIONS
STEP 1
Two people are recommended for
ease of assembly.
Place SHELF (A) upside down on a
soft surface. Attach LEFT & RIGHT
BRACKETS (B & C) to SHELF (A) as
shown, making sure threaded
studs on two inner sides of shelf fit
into notches on LEFT & RIGHT
BRACKETS (B & C). Fasten NUT (D)
onto each threaded stud with
provided WRENCH (E).
Note: LEFT BRACKET (B) has
TRINITY logo embossed.
C
B
D
E
A
STEP 2
Place WALL MOUNTING TEMPLATE
(H) against wall at your desired
location. With a pencil, mark
locations to install screws.
Notes:
* Please consult a local contractor If
you are unsure if your wall is able to
bear the load of the wall shelf.
** Depending on wall mount
requirement with or without
anchors. Pre-drill appropriate size
hole at each marked location.
H
Screw
holes
© 2023 TRINITY - 800.985.5506
2
A (1) B (1) C (1) D (4) E (1)
H (1)

ASSEMBLY INSTRUCTIONS
STEP 3
If ANCHORS (G) are required, insert
ANCHORS (G) completely into each
drilled hole. Place assembly from step
1 to wall as shown. Align four holes
on LEFT & RIGHT BRACKETS (B & C) to
marked locations. Fasten SCREWS (F)
through these holes into wall tightly
with a Philips screwdriver.
FG
© 2023 TRINITY - 800.985.5506 3
F (4) G (4)

SERVICE PARTS LIST –THA-3328 / THA-33282 (2-pack)
TRINITY Customer Service provides the following replacement parts:
# Part Number Description # Part Number Description
1)
XBS
-03-103-2412
Shelf
5)
XWH
-96-002-0003
Wall Mounting
Template
2)
XBS
-19-018-1025
Right Bracket
6)
XXX
-97-002-0006
Wrench
3)
XGR
-01-032-0837
Anchor
7)
ZNC
-01-008-0608
Nut
4)
XSV
-01-045-0538
Screw
8)
XBS
-19-017-1025
Left Bracket
1
2
3
4
5
6
7
8
4© 2023 TRINITY - 800.985.5506

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product. Any
modifications will void product warranty.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
5. Do NOT overload the product. Each shelf holds up to 250lb with evenly distributed weight.
6. Do NOT allow children to climb or hang on the shelf.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals. Do not leave salt on the shelf
or near saltwater environment.
•Rinse surface thoroughly with hot water after using soaps and detergents containing
chlorides to prevent corrosion.
•Do not use scouring pad, carbon steel brushes, or steel wool for cleaning. Iron particles left
behind can lead to rust.
•Avoid the use of oily rags or greasy cloths when wiping the surface. Wipe dry after use so
that water does not leave water spots.
•Use a quality stainless steel cleaner and follow instructions that come with the cleaner.
Wipe ALONG the grain (NOT against).
•This product is designed for indoor use.
© 2023 TRINITY - 800.985.5506 5

blank
6© 2023 TRINITY - 800.985.5506

PRODUCT REGISTRATION
Thank you for purchasing a TRINITY EcoStorage® 24” Stainless Steel Wall Shelf. In order to register
your product and receive streamlined customer service, please fill out the following Product
Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form
online at www.trinityii.com or (3) scan and email the form to [email protected]. Include a
copy of your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
© 2023 TRINITY - 800.985.5506 7

1 YEAR LIMITED WARRANTY
NITY EcoStorage® 24" Stainless Steel Wall Shelf
Model# THA-3328 / THA-33282 (2-pack)
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
TRINITY EcoStorage® 24” Stainless Steel Wall Shelf (“Product”) that each Product shall be free from defects in
workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation
under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product
which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity,
during the warranty period. All replaced parts and Products become the property of Trinity and must be
returned to Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at [phone], between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates and assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
8© 2023 TRINITY - 800.985.5506

blank
© 2023 TRINITY - 800.985.5506 9

CONTACT US
QUESTIONS? NEED PARTS?
WE ARE HERE TO HELP!
Please feel free to contact us. There are no questions too small, or
any problems too big. We’re committed to providing our customers
with the highest level of service.
TRINITY Customer Service
TEL: [phone]
FAX: [phone]
EMAIL: [e-mail]
Monday through Friday
5:00 AM –5:00 PM (PST)
www.trinityii.com
