Know Your System
Meter
①“ ◀ ” Button
Decrease numbers in Meter Set Up; remove ALT Sym-
bol; move backward by date/time when viewing results
and Averages in Memory; scroll through Event Tags to
mark results (if feature on).
②“ • ” Button
Turn meter on to view Average values, to view results
in Memory, to access Meter Set Up, to turn on Event
Tags in Meter Set Up.
③“ ▶ ” Button
Increase numbers in Meter Set Up; add ALT
Symbol; move forward by date/time when viewing
results and view Averages in Memory; scroll through
Event Tags to mark results (if feature on).
7
Top of Meter
1 32

①Display Screen
Shows results, messages, user prompts, information.
②Test Port
Insert TRUE METRIX Test Strip here, contact blocks
facing up.
③Strip Release Button
Releases test strip aer testing for disposal.
④Battery Door
Use one non-rechargeable 3V lithium battery
(#CR2032), positive (“+”) side up
(see Changing Battery).
⑤Meter Label
Contains serial number of meter.
⑥Data Contacts
Connects meter with computer for data upload.
8
2
1
Front of Meter
3
4
5
Back of Meter
6

9
Full Display Screen
1. Result is from Memory
2. Time, Date
3. Time is AM/PM
4. Event Tag Symbols
5. Result is from 7, 14, or 30 day Average
6. Test Result
7. Control Symbol
8. Battery Symbol
9. Alternate Site (ALT) Symbol
10. Drop Symbol - Apply blood or control solution
11. Temperature Symbol
12. Test Reminder Symbol
13. Ketone Test Alert Symbol
14. Unit of Measure (Note: Factory set to mg/dL,
cannot be changed by user.)
3
4
2
1
7
6
5
8
910 11 12
13
14

10
①Contact End - Insert into Test Port with contact
blocks facing up .
②Sample Tip - Bring Tip of test strip to top of sam-
ple drop (blood or control solution) aer Drop
Symbol appears in the Display.
Note: Insert test strip into meter before touching Sample
Tip to blood or control solution drop.
Sample Placement
Correct Incorrect
• Allow sample drop to be drawn into Sample Tip until test-
ing begins (meter beeps and dashes move across Display).
• Do not smear or scrape drop with test strip.
• Do not apply more sample to test strip aer testing begins.
• Do not apply blood or control solution to top of test strip.
Do not insert Sample Tip with sample into Test Port.
May damage meter.
Test Strip
12
Top of Test Strip

①Lot Number (LOT) - Used for identification
when calling for assistance.
②Expiration Dates (EXP) - Write date first opened
on vial label. Discard vial and unused test strips
if either the open vial expiration date or the date
printed next to EXP on vial label has passed,
whichever comes first. See the test strip
Instructions for Use for open vial expiration date.
Caution! Use of test strips or control solution past the
Expiration Dates may give incorrect test
results. Discard out-of-date products and test
with new products.
③Control Test Range - Range of numbers in
which Control Test result must fall to assure the
system is working properly.
Note: Examples only. Do not represent actual Control
Test ranges.
11
Test Strip Vial Label
1
2
3
May 30, 2023
2

12
Control Solution Bottle Label
①Lot Number (LOT) - Used for identification
when calling for assistance.
②Expiration Dates (EXP) - Write date first opened
on bottle label. Discard bottle if either 3 months
aer rst opening or date printed next to EXP on
bottle label has passed, whichever comes rst.
③Control Solution Level (1, 2, or 3) - We
recommend testing at least 2 levels of control
solution. Contact 1-800-803-6025, Monday
- Friday, 8AM-8PM EST, for assistance with
obtaining dierent levels of control solution.
Control Solution (Control)
12
3
May 30, 2023

Getting Started
Meter comes with pre-set time and date. e
Event Tag feature, Ketone Test Alert, and all Test
Reminders are o. Before using the meter for the
first time or aer a battery change, check the time,
date, Event Tags, Alert and Reminders, and update
as needed (see Meter Set Up).
e meter turns on when a test strip is inserted into
the Test Port or when “ • ” Button is pressed (see
Memory and Meter Set Up).
Meter turns o when the test strip is released or
removed from the meter, “ • ” Button is pressed, or
aer 2 minutes of non-use.
Turning the Ketone Test Alert on sets a reminder to
check your ketones per your treatment plan when a
blood glucose result is over 240 mg/dL.
Test Reminders are set like an alarm clock to sound
a tone for 10 seconds to remind you to test. Up to
four Test Reminders per day may be set.
13

14
Getting Started (cont.)
Event Tags allow you to tag your blood glucose
results to link to the following events:
Before meal – test was taken just before a meal,
Aer meal – test was taken 2 hours aer the
start of a meal,
Exercise – test was taken during or aer exercise,
Medications – medication taken may have
aected test result,
Sick – test was taken when sick,
Other – any other reason that the test is unique
or dierent in some way (example: stress,
drinking alcohol). In your logbook, note the
reason that the test result was tagged. Seeing a
result with an Event Tag in the meter Memory
reminds you that there is more about this test
result in your log book.
Tagging results helps track the eect specic events
may have on your blood glucose test results. Event
Tagging may assist you and your Doctor or Health-
care Professional with managing diabetes.

15
Quality Control Testing
To assure you are getting accurate
and reliable results, TRUE METRIX
oers two kinds of quality Control
Tests. ese tests let you know that
your System is working properly
and your testing technique is good.
Automatic Self-Test
An Automatic Self-Test is performed
by the meter each time a test strip is
inserted correctly into the Test Port.
Insert a test strip into the Test Port.
e meter is working properly if:
~ the full Display appears, then
~ the time appears in the upper
part of the Display, and then,
~ the Drop Symbol begins to blink.
If an error message appears in the Display,
the meter will not perform a test.
See Troubleshooting or call 1-800-803-6025,
Monday - Friday, 8AM-8PM EST.
Caution! If any segments are missing in the Display
when meter is first turned on, do not use the
meter for testing. Call 1-800-803-6025, Mon-
day - Friday, 8AM-8PM EST.
Contact
Blocks
Face Up
Full Display
Drop Symbol
Error Message

16
Control Test
We recommend performing Control Tests for practice
before using your meter for the first time to test your
blood.
Control Tests should be performed:
• For practice to ensure your testing technique is good,
• Occasionally as you use a vial of test strips,
• When opening a new vial of test strips,
• If results seem unusually high or low,
• If a vial has been le opened or exposed to extreme
heat or cold, or humidity,
• Whenever a check on performance of the system is
needed,
• If meter damage is suspected (meter was dropped,
crushed, wet, etc.)
Note: It is important to perform Control Tests with more
than one level of control solution. ree levels of
TRUE METRIX Control Solution are available
for Control Tests. Call 1-800-803-6025, Monday -
Friday, 8AM-8PM EST, for assistance in obtaining
dierent levels of control solution.
Caution! Ranges printed on test strip vial label are for
Control Test results only and are not suggested
levels for your blood glucose. Do not drink
control solution.

How to Test Control Solution
Use ONLY TRUE METRIX Control Solution with
the TRUE METRIX Self Monitoring Meter and Test
Strips.
1. Check dates on control solution
label and test strip vial label. Do not
use control solution or test strips
if expiration dates have passed.
(Control solution - 3 months aer
rst opening or date next to EXP on
bottle label; test strips - aer open
vial expiration date (see test strip
Instructions for Use) or date next to
EXP on vial label.) Discard expired
products and use new products.
2. Allow control solution, vial of test strips and
meter to adjust to room temperature. Write date
first opened on both control solution bottle label
and test strip vial label when using for the rst
time.
3. Gently swirl or invert control solution bottle to
mix.
DO NOT SHAKE!
4. Remove one test strip from vial. Close test strip
vial immediately. Use test strip quickly aer
removal from vial.
17
May 30, 2023

18
5. Insert test strip into Test Port.
Meter turns on.
Note: If test strip has been out of the vial
too long before testing, an error
message appears upon insertion
of the test strip into the meter.
Release and discard old test strip.
Use new test strip for testing.
6. Wait until Drop Symbol appears in
Display. Keep test strip in meter until
testing is finished.
Note: If test strip is removed before testing is finished, an
error message appears. Release and discard old test
strip. Use new test strip for testing.
7. With cap removed, turn control
solution bottle upside down.
Squeeze one drop of control
solution onto a clean tissue. Wipe
o bottle tip and discard tissue.
8. Gently squeeze a drop of control
solution onto a small piece of
unused aluminum foil or clear
plastic wrap. Dispose aer use.
LB0010
9 JUNE 2009
Drop Symbol
Contact Blocks
Face Up
Discard Control
Solution Drop on
Tissue

9. With test strip still in meter, touch
Sample Tip of test strip to top of
drop of control solution. Allow
drop to be drawn into test strip.
Remove test strip from drop when
meter beeps.
10. Dashes appear across the Display to
show meter is testing.
Note: If meter does not beep and begin testing soon
aer drawing up sample, release and discard
test strip. Repeat test with new test strip. If
problem persists, see Troubleshooting.
11. Compare meter result to
Control Test range printed on
test strip vial label for level of
control solution you are using.
If result is in range, System can
be used for testing blood. If
result does not fall within range,
repeat test using a new test strip.
Note: Control Test result shows the
Control Symbol in the Display.
19
Meter testing
(Example only.
Does not represent actual
Control Test ranges.)
Control Symbol
Test Strip
Vial Label
Control Solution
Bottle Label

Caution! If Control Test result is outside range,
test again. If result is still outside range,
system should not be used for testing
blood. Call 1-800-803-6025, Monday -
Friday, 8AM-8PM EST.
12. Aer result is shown, Strip
Release Button flashes. Hold
meter with test strip pointing
down. Press Strip Release Button
to release and discard test strip
into appropriate container. Meter
turns o.
Note: Removing test strip before result displays
cancels the test. An error message appears and
the result is not stored in Memory. Retest with
a new test strip and do not remove before result
is displayed.
20

21
Testing Blood
Obtaining a Blood Sample
WARNING!
• e TRUE METRIX Self Monitoring Blood Glucose
System is for one person use ONLY. DO NOT share
your meter or lancing device with anyone, including
family members. Do not use on multiple patients!!
• ALL parts of your blood glucose monitoring system
could carry blood-borne pathogens aer use, even
aer cleaning and disinfecting.
2
• Cleaning and disinfecting the lancing device and the
meter destroys most, but not necessarily all, blood-
borne pathogens.
• Wash your hands thoroughly with soap and warm
water before and aer handling the meter, lancing
device, lancets, or test strips as contact with blood
presents an infection risk.
• If the meter is being operated by a second person who
provides testing assistance, the meter and lancing
device should be cleaned and disinfected prior to use
by the second person.
• It is important to keep the meter and the lancing
device clean and disinfected. For instructions on how
to clean and disinfect the meter and lancing device,
see Meter Care, Cleaning and Disinfecting and Lancing
Device Cleaning and Disinfecting.

22
Obtaining a Blood Sample (cont.)
Refer to lancing device Instructions for Use for detailed
instructions.
• Never share lancets or lancing device. Lancets are for
single use only. Do not re-use.
• Do not use venous blood for testing.
• To help prevent false high results, wash hands before
using the system to test blood, especially aer fruit has
been handled.
From Fingertip
1. Prepare fingertip by washing hands with soap and
warm water. Rinse and dry thoroughly.
Disinfect the clean skin with an
antiseptic (e.g., 70% alcohol).
2. Place end of lancing device
device equipped with a lancet
against tip of finger. Lance fingertip.
3. Set lancing device aside. To help blood drop form,
lower hand to waist level, gently massaging finger
from palm to fingertip. Allow blood drop to form
before attempting to apply to the test strip. Apply
sample to test strip Sample Tip.
4. Recap and remove used lancet from lancing device.
e used lancet may be biohazardous. Please discard
it carefully according to your Doctor or Healthcare
Professional's instructions.

23
From Forearm
Important Notes Regarding Forearm Testing
4
• Check with your Doctor or Healthcare Professional
to see if forearm testing is right for you.
• Results from forearm are not always the same as
results from fingertip.
• Use fingertip instead of forearm for more
accurate results:
~ Within 2 hours of eating, exercise, or taking insulin,
~ If your blood sugar may be rising or falling rapidly or
your routine results are oen fluctuating,
~ If you are ill or under stress,
~ If your forearm test results do not match how you feel,
~ If your blood sugar may be low or high,
~ If you do not notice symptoms when blood sugar is
low or high.
1. Select area to be lanced. Wash with soap and warm
water, rinse and dry thoroughly. Disinfect the clean
skin with an antiseptic (e.g., 70% alcohol).
2. Rub area vigorously or apply a warm dry compress to
increase blood flow.
3. Place end of lancing device equipped
with a lancet firmly against forearm.
Press Trigger Button. Apply firm pressure
on lancing device for 10 seconds. Apply
sample to test strip Sample Tip.

24
4. Recap and remove lancet from lancing device.
Caution! e used lancet may be biohazardous.
Please discard it carefully according to
your Doctor or Healthcare Professional's
instructions.
