Tronair 02-7815C0110 Installation and operating instructions

OPERATION & SERVICE MANUAL
Tronair, Inc. Phone: [phone] | 800-426-6301
1 Air Cargo Pkwy East Web: www.tronair.com
Swanton, OH 43558 Email: [email protected]
Models:02-7815C0110
02A7815C0110
02A7848C0120
10 Ton (9.07 Metric)
Two Stage Jack
w
07/2021 Rev. 06

REVISION DATE TEXT AFFECTED
03 09/2011 Modified 3.0 Specifications, 5.1 Jack Instructions, 6.1 General,
6.4 Jack Function Load Test, and Parts List
04 12/2017 Major revision
05 07/2018 Major revision
06 07/2021 Modified Parts Lists

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06
TABLE OF CONTENTS PAGE
1.0 PRODUCT INFORMATION ..............................................................................................................................................1
1.1 DESCRIPTION....................................................................................................................................................1
1.2 MODEL & SERIAL NUMBER..............................................................................................................................1
1.3 MANUFACTURER..............................................................................................................................................1
1.4 USAGE ...............................................................................................................................................................1
1.5 SPECIFICATIONS..............................................................................................................................................1
2.0 SAFETY INFORMATION..................................................................................................................................................1
2.1 USAGE AND SAFETY INFORMATION..............................................................................................................1
2.2 WARNING AND DANGER SIGNS......................................................................................................................1
2.3 SAFETY GUIDELINES .......................................................................................................................................2
2.4 CONDITIONS FOR SAFE USE ..........................................................................................................................2
3.0 ASSEMBLY INSTRUCTIONS...........................................................................................................................................2
3.1 GENERAL INFORMATION.................................................................................................................................2
3.2 PRE-USE CHECKS............................................................................................................................................2
4.0 TRAINING.........................................................................................................................................................................2
4.1 TRAINING REQUIREMENTS.............................................................................................................................2
4.2 TRAINING PROGRAM .......................................................................................................................................2
4.3 OPERATOR TRAINING......................................................................................................................................2
5.0 OPERATION.....................................................................................................................................................................3
5.1 JACK INSTRUCTIONS.......................................................................................................................................3
6.0 TROUBLE SHOOTING.....................................................................................................................................................6
7.0 MAINTENANCE................................................................................................................................................................7
7.1 GENERAL...........................................................................................................................................................7
7.2 SERVICING JACK..............................................................................................................................................7
7.3 JACK FUNCTION LOAD TEST...........................................................................................................................7
7.4 PNEUMATIC PUMP............................................................................................................................................7
8.0 PROVISION OF SPARES.................................................................................................................................................8
8.1 SOURCE OF SPARE PARTS.............................................................................................................................8
8.2 RECOMMENDED SPARE PARTS LISTS ..........................................................................................................8
9.0 IN SERVICE SUPPORT....................................................................................................................................................8
10.0 GUARANTEES/LIMITATION OF LIABILITY....................................................................................................................8
11.0 APPENDICES...................................................................................................................................................................8

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 1
This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval
voids all warranties and releases Tronair, Inc., it suppliers, distributors, employees, or financial institutions from any liability
from consequences that may occur. Only Tronair OEM replacement parts shall be used.
1.0 PRODUCT INFORMATION
1.1 DESCRIPTION
10 Ton Two Stage Tripod Jack
1.2 MODEL & SERIAL NUMBER
Reference nameplate on unit
1.3 MANUFACTURER
TRONAIR, Inc. Telephone: [phone] or 800-426-6301
1 Air Cargo Pkwy East Fax: [phone]
Swanton, Ohio 43558 USA E-mail: [email protected]
Website: www.tronair.com
1.4 USAGE
The device is intended to lift an aircraft by its fuselage and/or main wing with other hydraulic jacks arranged by position and
quantity to provide proper balance, and in conjunction with the correct jack pad, whose maximum load on any one jack does
not exceed the rated capacity of the jack.
The jacks are not intended for metal forming, metal working, or any purpose other than that stated above.
1.5 SPECIFICATIONS
Capacity........................................................ 20,000 lbs (9.07 metric ton)
Closed Height................................................ 27.6 in (70 cm)
Mechanical Extension ................................... 12 in (30.5 cm)
Hydraulic Extension....................................... 33 in (83.8 cm)
Fully Extended .............................................. 72.5 in (184.2 cm)
Weight
02-7815C0110 ....................................... 271 lbs (123 kg)
02A7815C0110, 02A7847C0120 ........... 286 lbs (130 kg)
2.0 SAFETY INFORMATION
2.1 USAGE AND SAFETY INFORMATION
To insure safe operations please read the following statements and understand their meaning. Also refer to your equipment
manufacturer’s manual for other important safety information. This manual contains safety precautions which are explained
below. Please read carefully.
WARNING! —Warning is used to indicate the presence of a hazard that can cause severe personal injury,
death, or substantial property damage if the warning notice is ignored.
CAUTION! —Caution is used to indicate the presence of a hazard that will or can cause minor personal injury
or property damage if the caution notice is ignored.
2.2 WARNING AND DANGER SIGNS
See labels on unit. WARNING!
The ram locknuts are user operated safety devices. Failure to utilize these locknuts may result in personal
injury or death.

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 2
2.3 SAFETY GUIDELINES CAUTION!
Do not place hands on top of jack near ram locknuts while lowering jack.
Pinch points exist between top of jack and threads on ram.
Never put hands between the aircraft and the jack pad; as after aircraft has been lowered, struts may
have hung up.
Never align jack under aircraft by pounding on jack legs. Dented legs may lead to jack collapse.
Always lower ram locking nut(s) after jack is under load. Be sure ram nut(s) is seated fully after
jacking.
Always raise and lower jacks simultaneously so that aircraft remains level.
Always use a tail or nose stand, as applicable, for additional stability.
WARNING!
The ram locknuts are user operated safety devices.
Failure to utilize these locknuts may result in personal injury or death.
2.4 CONDITIONS FOR SAFE USE
Use in a clean dry environment on a level surface.
Operate between -20C and 50C/-4F and 122F.
3.0 ASSEMBLY INSTRUCTIONS
3.1 GENERAL INFORMATION
This product should be assembled and/or repaired using good workmanship practices and proper tools. Bolts and elastic
stopnuts should be tightened to a torque not to exceed industry standards for Grade '5' bolts. The 3/8-24 bolts should be
tightened to 35 ft-lbs (47.5 N-m).
All replacement parts must be the same as or equal to the original parts supplied.
3.2 PRE-USE CHECKS
Refer to the Parts Lists and Illustrations to identify and ensure that all parts are present.
Generally check over unit to assure the tightness of all nuts, bolts and fittings.
With rams completely collapsed, check hydraulic fluid level: correct level is three-quarter inch (¾"/1.9 cm) below vent, with
the hydraulic ram fully retracted. Replenish with MIL-PRF-5606 fluid as required.
4.0 TRAINING
4.1 TRAINING REQUIREMENTS
The employer of the operator is responsible for providing a training program sufficient for the safe operation of the unit.
4.2 TRAINING PROGRAM
The employer provided operator training program should cover safety procedures concerning use of the unit in and around the
intended aircraft at the intended aircraft servicing location.
4.3 OPERATOR TRAINING
The operator training should provide the required training for safe operation of the unit.
NOTE: Maintenance and Trouble Shooting are to be performed by a skilled and trained technician.

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 3
5.0 OPERATION
The user should be familiar with the following statements prior to using the jack.
CAUTION!
1. NEVER put hands between aircraft and jack pad. Aircraft struts may hang up and allow aircraft to
suddenly drop.
2. NEVER align jack under aircraft by pounding on jack legs. Dented legs may lead to jack collapse.
3. ALWAYS lower ram locking nut(s) as aircraft is raised. Be sure ram nut(s) is seated fully after jacking.
4. ALWAYS raise and lower jacks simultaneously so that aircraft remains level.
5. ALWAYS use a tail or nose stand for additional stability.
WARNING!
When collapsing rams by hand miss-staging may occur and cause pinch points. To collapse ram, add a
minimum 50 lb load to the mechanical extension. Keep hands and fingers clear of locking nuts. Failure to
adhere to this safety instruction can cause injury.
5.1 JACK INSTRUCTIONS
To Raise Aircraft:
1. Place jack on a hard, level surface.
2. Raise mechanical extension as close to aircraft jack pad as possible.
3. Close pump release valve and operate pump.
WARNING!
The locking pin MUST be placed in the ram protection ring groove and fully through the mechanical
extension.
The locking pin washer and ball lock MUST be placed outside the ram protection ring.
Visually inspect the jack prior to every use.
Do not place extra locking pins in any other hole on
the mechanical extension.
Insure mating surfaces to jack point are free of
debris and damage.
Under no conditions should the locking pin washer
or washer groove be inside the ram protection ring
groove.
Under no conditions should the locking pin’s ball
lock be inside the ram protection ring groove.
Never use the jack if the ram protection ring is not
installed.
Never use the locking pin without a locking pin
washer.
Never use a locking pin that has been damaged.
Never use a ram protection ring that has been
damaged or deformed.
Replace ram protection ring if it does not have a
radius groove for the locking pin.
Load test jacks annually.
Only order replacement parts from Tronair.
Failure to comply could result in premature failure
below certified weight and could cause serious injury including death.

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 4
5.1 JACK INSTRUCTIONS (continued) Correct Pin Placement
Incorrect Pin Placements
Results Of Locking Pin In Incorrect Location
Washer In
Ram Protection Ring
Ball Lock In
Ram Protection Ring
Washer On Top Of
Ram Protection Ring
Locking Pin Not In
Ram Protection Ring
and top Locking Pin
in Mechanical Extension
(use only one pin)

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 5
5.1 JACK INSTRUCTIONS (continued) Ram Protection Ring
NOTE: Turning the pump relief valve counter-clockwise lowers the jack. Turning the pump release valve clockwise
stops the jack's descent and allows it to be raised.
4. If air pump is to be used, be sure shop air needle valve is closed and attach shop air (125 psi/8.6 bars Maximum) to
needle valve. Slowly open needle valve. Close needle valve when ram reaches required height.
5. Hydraulic rams must be completely retracted before operating the jack.
6. Close pump release valve and operate pump.
7. Hydraulic rams must extend in order from largest to smallest diameter.
8.
9. Largest diameter hydraulic ram must fully extend before the next stage ram begin to raise.
10. Lower mechanical lock nut(s) while extending rams. Keep within 1” of bottom of extending ram.
11. Do not continue to operate air pump after all rams have fully extended.
WARNING!
The ram locknuts are user operated safety devices. Failure to utilize these locknuts may result in personal
injury or death.
To Lower Aircraft:
1. Lower all jacks simultaneously.
2. If ram locking nut(s) is tight, raise jack slightly to release nut(s)
3. Ensure proper staging as aircraft is being lowered: loosen locknut beginning with smallest ram (1” max) until stage is
completely lowered. Repeat for next smallest stage.
4. Loosen pump release valve slightly to slowly lower aircraft.
NOTE: When using the jack during a washing or cleaning operation, the jack should be completely covered to
protect it from cleaning solution, dirt and/or foreign material which might get on or between the ram and cylinder
causing damage to the seals and O-rings.
CAUTION!
Do not place hands on top of jack near ram locknuts while lowering jack. Pinch points exist between
top of jack and threads on ram.
Always wear safety glasses while operating this equipment.
Unacceptable Condition
Acceptable Condition
Damage
and
Deformation
No
Deformation

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 6
6.0 TROUBLE SHOOTING
TROUBLE
PROBABLE CAUSE
ACTION
Fluid leakage at pump piston or
pump body
Damaged backup ring, o-ring, piston or
pump body
Replace pump
External fluid leakage at rams
Damaged o-ring, backup ring or inner
cylinder wall
Remove rams as a unit from cylinder.
Inspect parts. Replace o-ring and
defective part(s)
Jack fails to lift rated load
Release valve not closed properly
Fully tighten release valve
Low fluid level
Fill to correct fluid level
Pressure relief valve improperly adjusted
Adjust or replace release valve
Leakage at inlet or outlet check ball
Inspect valve body for wear or replace
valve body and check balls
Vent screw closed
Open vent screw
Rams will not support load after
manual or pneumatic pump up
Leaking ram o-ring seals
Check for external leakage, if present
replace defective seal and back up ring
Leaking pressure check valve
Inspect valve body for wear or replace
valve body and check balls
Leaking pressure relief valve
Remove release valve, inspect ball and
ball seat in pump block. Replace
effective part(s)
Rams raise and fall with each
manual pump stroke
Release valve open
Fully tighten release valve
Inlet check valve not seated or sticking
Pump rapidly to dislodge or replace valve
body
Pressure check valve not seated or sticking
Pump rapidly to dislodge or replace valve
body
Jack fails to lower
Ram locknut not loosened
Raise jack ¼ inch and release locknut
Vent screw closed
Open vent screw
O-Ring (pinched or rolled)
Replace o-ring and back-up ring, clean
up cylinder wall of debris

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 7
7.0 MAINTENANCE
7.1 GENERAL
The jack should be stored with some type of cover to protect the jack from liquids (such as Skydrol or cleaning solutions)
and other foreign matter that might get on or between ram and cylinder which will damage seals and O-rings.
All maintenance and/or repair work should be done using good workmanship practices and proper tools. The work area
should be clean and free of dirt.
When O-rings and backup rings are removed, every effort should be made to avoid the contact of tools with the critical
surfaces of parts. Surface deformities could cause degradation of seals and failure.
It is good practice to replace both O-rings and backup rings once removed. Cut and damaged rings normally result in fluid
leakage.
If any cylinder bore is found to be rusty, they may be honed as follows:
First stage cylinder to a maximum diameter of 4.505 in (11.443 cm)
Second stage ram to a maximum diameter of 3.379 in (8.583 cm)
Surface finish of all bores to be 16 micro inches. If the pitting in the bores cannot be removed by this process, the jack
cylinder or ram in question must be replaced before the jack can be returned to service.
If cylinder is honed replace cylinder bore with .0002-.0003 chrome plating.
At this time, flush old hydraulic fluid and dirt from overall system and replenish with new, clean hydraulic fluid.
No modifications shall be carried out which adversely affect the compliance of the jack with draft standard 2006/42/EC.
7.2 SERVICING JACK
90-Day Routine Maintenance
If jack is not being used on a regular basis, every 90 days the jack should be fully extended and retracted to exercise the seals
and to prevent rust build up on the cylinder I.D. While ram is extended, clean the threads and spray with DoALL RPM, LPS, or
equivalent that is water repellent and will not harm BUNA “N” O-rings.
To Disassemble Jack for Seal Replacement:
1. Raise first stage ram high enough to allow removal of the retaining snap ring.
2. Raise both first and second stage rams together to the point where this assembly can be lifted from the jack cylinder.
NOTE: If the second stage ram is allowed to precede the first stage ram, it will fill with oil causing an oil spill when
the assembly is removed from the cylinder.
To Reassemble Jack:
1. Re-assemble in reverse order of above.
2. Spray I.D. of cylinder and O.D. of rams with DoALL RPM, LPS or equivalent water repellent that will not harm the Buna
“N” O-rings to protect surfaces from rusting whnot in use.
NOTE: To minimize air entrapment under the rams, raise the oil level in the cylinder to chamfer of the cylinder prior
to ram insertion.
3. Lightly peen first thread on second stage ram to prevent nut removal after seal kit installation.
7.3 JACK FUNCTION LOAD TEST
If function load testing of this jack is required:
1. Take all necessary precautions to prevent injury.
2. Always jack against a load and never against the jack itself.
3. Do not exceed a test load equal to the jack rated capacity plus 5% - 10%.
4. Test annually.
7.4 PNEUMATIC PUMP
Reference Appendix II Haskel information for complete parts list and repair information.

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 8
8.0 PROVISION OF SPARES
8.1 SOURCE OF SPARE PARTS
Spare parts may be obtained from the manufacturer:
TRONAIR, Inc. Telephone: [phone] or 800-426-6301
1 Air Cargo Pkwy East Fax: [phone]
Swanton, Ohio 43558 USA E-mail: [email protected]
Website: www.tronair.com
8.2 RECOMMENDED SPARE PARTS LISTS
Reference the following page(s) for Replacement Parts and Kits available.
9.0 IN SERVICE SUPPORT
Contact Tronair, Inc. for technical services and information. See Section 1.3 Manufacturer.
10.0 GUARANTEES/LIMITATION OF LIABILITY
Tronair products are warranted to be free of manufacturing or material defects for a period of one year after shipment to the
original customer. This is solely limited to the repair or replacement of defective components. This warranty does not cover the
following items:
a) Parts required for normal maintenance
b) Parts covered by a component manufacturers warranty
c) Replacement parts have a 90-day warranty from date of shipment
If you have a problem that may require service, contact Tronair immediately. Do not attempt to repair or disassemble a product
without first contacting Tronair, any action may affect warranty coverage. When you contact Tronair be prepared to provide the
following information:
a) Product Model Number
b) Product Serial Number
c) Description of the problem
If warranty coverage is approved, either replacement parts will be sent or the product will have to be returned to Tronair for
repairs. If the product is to be returned, a Return Material Authorization (RMA) number will be issued for reference purposes
on any shipping documents. Failure to obtain a RMA in advance of returning an item will result in a service fee. A decision on
the extent of warranty coverage on returned products is reserved pending inspection at Tronair. Any shipments to Tronair must
be shipped freight prepaid. Freight costs on shipments to customers will be paid by Tronair on any warranty claims only. Any
unauthorized modification of the Tronair products or use of the Tronair products in violation of cautions and warnings in any
manual (including updates) or safety bulletins published or delivered by Tronair will immediately void any warranty, express or
implied.
The obligations of Tronair expressly stated herein are in lieu of all other warranties or conditions expressed or implied. Any
unauthorized modification of the Tronair products or use of the Tronair products in violations of cautions and
warnings in any manual (including updates) or safety bulletins published or delivered by Tronair will immediately
void any warranty, express or implied and Tronair disclaims any and all liability for injury (WITHOUT LIMITATION and
including DEATH), loss or damage arising from or relating to such misuse.
11.0 APPENDICES
APPENDIX I Hydraulic Schematic
APPENDIX II Haskel Technical Specifications & Performance Data with Drawing 28550
APPENDIX III Safety Data Sheet (SDS) MIL-PRF-5606 Hydraulic Fluid
APPENDIX IV Declaration of Conformity
APPENDIX V Maintenance Schedule

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 9
Parts List
When ordering replacement parts/kits, please specify model, serial number and color of your unit.

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 10
Parts List
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
G-1100-107540
BOLT, 3/8-24 X 4.0" HEX HD GR 5
1
2
G-1203-1075
JAMNUT, 3/8-24 ELASTIC
8
3
Z-6587
ASSEMBLY, FRONT WHEEL
1
4
H-1045
BREATHER
1
5
H-557
PAD, JACK
1
6
G-1300-25200
PIN, ROLL, ¼" DIAMETER X 2" LONG
1
7
Z-2301-02
WELDMENT, HANDLE
1
8
V-1198
LABEL, TRONAIR
1
9
H-1009-01
ASSEMBLY, PUMP HANDLE
1
10
G-1100-107532
BOLT, HEX HEAD, GRADE 5, 3/8 - 24 X 3¼" LONG
3
11
TF-1043-06*18.0
ASSEMBLY, HOSE, 18" LONG
1
12
N-2001-08-S-B
ELBOW, 90MALE, SAE #6 X 3/8" O.D. JIC 37
2
13
HC-2764
HAND PUMP, HYDRAULIC
1
14
G-1100-107010
BOLT, HEX HEAD, GRADE 5, 3/8-16 X 1" LONG
2
15
G-1251-1070R
LOCKWASHER, 3/8 REGULAR
2
16
N-2789-04-S-B
CONNECTOR, MALE, BEADED HOSE
1
17
V-1015
LABEL, JACKING INSTRUCTION
1
18
G-1100-109532
BOLT, 1/2-20 X 3-1/4" HEX HD GR 5
2
19
G-1203-1095
JAMNUT, 1/2-20 ELASTIC
3
20
N-2412-10
CONNECTOR, STRAIGHT MALE
1
21
G-1154-107214
SCREW, 3/8-16 X 1-1/2" LG. SOCKET BUTT HD CAP
3
22
V-1001
LABEL, MADE IN USA
1
23
V-1102
LABEL, MIL-PRF-5606
1
24
R-1341-02
SHAFT, EXTENSION
1
25
G-1318-1033
PIN, 5/8 X 3.3 LG MODEL D
1
26
TR-1994
RING, RAM PROTECTION
1
27
Z-4249-01
WELDMENT, RESERVOIR
1
28
Z-7062-00
WELDMENT, JACK
1
29
Z-7059-02-01
WELDMENT. TUBE/BASE (P)
1
30
G-1202-1075
STOPNUT, 3/8-24 ELASTIC
3
31
G-1250-1070N
FLATWASHER, 3/8 NARROW
12
32
H-3398-07
SPRING, COMPRESSION
2
33
Z-2302
WELDMENT, PIVOT
2
34
Z-2322
ASSEMBLY, REAR WHEEL
2
35
G-1100-107510
BOLT, 3/8-24 X 1 LONG HEX HD GR 5
4
36
TR-1978
TUBE, STOP
1
37
Z-1060-02
ASSEMBLY, RAM
1
38
V-1019
LABEL, MAX CAPACITY –20K
1
39
V-1775
LABEL, PUMP FORCE
1
40
V-1776
LABEL, DOWN
1
41
V-1354
TAG, RESERVOIR FILL
1
42
V-1500
TAG, CLOSED HEIGHT
1
44
H-2210-08
SPRING, COMPRESSION
1
45
Z-6588
WELDMENT, PIVOT
1
46
G-1100-109560
BOLT, HEX HEAD, GRADE 5, ½ - 20 X 6" LONG
1
47
T378-03*001.00
TUBE, SS ½ ID
2
48
V-1805
LABEL, ISO GENERAL DANGER
1

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 11
Parts List
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Z-10952-Z1
Z-10952-A1
1
Z-10952-81
BASE ASSEMBLY, JACK 5 TON "CE"
1
1
2
V-2839
LABEL, JACK TYPE/SERIAL
1
1
4
Z-5153
ASSEMBLY, AIR PUMP
-
1
5
Z-4973
ASSEMBLY, BLOWGUN
-
1
6
H-1516-11
CLAMP, 2-EAR HOSE
2
5
7
N-2066-06-S-B
PLUG, HOLLOW HEX W/ O-RING
1
-
8
N-2453-04
TEE, NYLON UNION
-
1
9
N-2001-08-S-B
ELBOW, STRAIGHT THREAD
-
1
10
TF-1047-04-08.0
HOSE, 3/8 GREY
1
-
11
TF-1047-04-02.0
HOSE, 3/8 GREY
-
1
12
TF-1047-04-07.0
HOSE, 3/8 GREY
-
1
13
TF-1047-04-05.0
HOSE, 3/8 GREY
-
1
14
TF-1043-06-18.0
HOSE, 3/8 GREY
-
1

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 12
Parts List –02-7815C0110
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-10952-Z1
ASSEMBLY, 10 TON TRIPOD JACK
1
2
V-2840
LABEL, JACK MODEL
1

Models: 02-7815C0110, 02A7815C0110, 02A7848C0120
10 Ton (9.07 Metric) Two Stage Jack with Air Pump
07/2021 | Rev. 06 Page | 13
Parts List –02A7815C0110 & 02A7848C0120
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-10952-A1
ASSEMBLY, 10 TON TRIPOD JACK
1
2
V-2840
LABEL, JACK MODEL
1

APPENDIX I
Hydraulic Schematic

Hydraulic Schematic –02-7815C0110

Hydraulic Schematic –02A7815C0110 & 02A7848C0120
