Tronair 02-7833C0110 Installation and operating instructions

OPERATION & SERVICE MANUAL
Tronair, Inc. Phone: [phone] | 800-426-6301
1 Air Cargo Pkwy East Web: www.tronair.com
Swanton, OH 43558 Email: [email protected]
12 Ton (10.8 Metric Ton)
Axle Jack
Models:
02-7833C0110, 02-7846C0110,02-7852C0100,
02-7861C0100, 02-7861-9100, 02-7863C0100,
02-7902C0100, 02-7918C0100, 02-7918C9100
05/2021 Rev. 03

REVISION DATE TEXT AFFECTED
01 07/2008 Original release
02 11/2017 Major revision
03 05/2021 Major revision

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03
TABLE OF CONTENTS PAGE
1.0 PRODUCT INFORMATION ..............................................................................................................................................1
1.1 DESCRIPTION....................................................................................................................................................1
1.2 MODEL & SERIAL NUMBER..............................................................................................................................1
1.3 MANUFACTURER..............................................................................................................................................1
1.4 USAGE ...............................................................................................................................................................1
1.5 SPECIFICATIONS..............................................................................................................................................1
2.0 SAFETY INFORMATION..................................................................................................................................................2
2.1 USAGE AND SAFETY INFORMATION..............................................................................................................2
3.0ASSEMBLY INSTRUCTIONS...........................................................................................................................................2
3.1 GENERAL INFORMATION.................................................................................................................................2
3.2 PRE-USE CHECKS............................................................................................................................................2
4.0 TRAINING.........................................................................................................................................................................2
4.1 TRAINING REQUIREMENTS.............................................................................................................................2
4.2 TRAINING PROGRAM .......................................................................................................................................2
4.3 OPERATOR TRAINING......................................................................................................................................2
5.0 OPERATING INSTRUCTIONS .........................................................................................................................................3
5.1 TO RAISE GEAR................................................................................................................................................3
5.2 TO RAISE NOSE GEAR –02-7833C0110 ONLY...............................................................................................3
5.3 TO RAISE MAIN GEAR –02-7833C0110 ONLY................................................................................................4
5.4 TO LOWER GEAR..............................................................................................................................................4
6.0 TROUBLE SHOOTING.....................................................................................................................................................5
7.0 MAINTENANCE................................................................................................................................................................6
7.1 GENERAL...........................................................................................................................................................6
7.2 SERVICING JACK..............................................................................................................................................6
7.3 JACK FUNCTION LOAD TEST...........................................................................................................................6
8.0 PROVISION OF SPARES.................................................................................................................................................6
8.1 SPARE PARTS...................................................................................................................................................6
8.2 PARTS LISTS & ILLUSTRATIONS.....................................................................................................................6
9.0 IN-SERVICE SUPPORT....................................................................................................................................................6
10.0 GUARANTEES/LIMITATION OF LIABILITY....................................................................................................................7
11.0 APPENDICES...................................................................................................................................................................7

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 1
This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc.,
it suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur. Only Tronair OEM replacement parts shall be used.
1.0 PRODUCT INFORMATION
1.1 DESCRIPTION
These Tronair Hydraulic Axle Jacks incorporate the following quality features:
Steel construction
Four-stage ram
Hi/Low, manually operated pump
Uses standard MIL-PRF-5606 hydraulic fluid
1.2 MODEL & SERIAL NUMBER
Reference nameplate on unit
1.3 MANUFACTURER
TRONAIR, Inc. Telephone: [phone] or 800-426-6301
1 Air Cargo Pkwy East Fax: [phone]
Swanton, Ohio 43558 USA E-mail: [email protected]
Website: www.tronair.com
1.4 USAGE
The purpose of this jack is to lift aircraft at the landing gear for maintenance. It has a
maximum capacity of 12 tons (10.8 metric tons).
1.5 SPECIFICATIONS
Vertical capacity.......................24,000 lbs (10.8 Metric Tons)
BUNA ‘N’ Seals
Model
Closed
in (cm)
Hydraulic
in (cm)
Mechanical
in (cm)
Extended
in (cm)
Spacer Blocks
in (cm)
Weight
lb (kg)
02-7833C0110
3 (7.6)
--
--
8-5/16 (21.1)
½ (1.3)
¾ (1.9)
1-1/2 (3.8)
60.5 (27.4)
02-7846C0100
3-3/4 (9.5)
--
--
11-5/8 (29.5)
--
--
--
31.9 (14.5)
02-7852C0100
3 (7.6)
5-5/16 (13.5)
--
8-5/16 (21.1)
--
--
1-1/2 (3.8)
55.8 (25.3)
02-7861C0100
3-3/4 (9.5)
7-13/16 (19.8)
1-1/16 (2.7)
12-5/8 (32.1)
--
--
--
44.9 (20.4)
02-7861-9100
3-3/4 (9.5)
7-13/16 (19.8)
1-1/16 (2.7)
12-5/8 (32.1)
--
--
--
44.9 (20.4)
02-7863C0100
3-3/16 (8.1)
3-3/8 (8.6)
1-7/16 (3.7)
2-3/4 (7)
15-3/8 (39.1)
½ (1.3)
¾ (1.9)
--
47.6 (21.6)
02-7902C0100
3-3/16 (8.1)
6-3/8 (16.2)
--
--
½ (1.3)
¾ (1.9)
--
47.6 (21.6)
02-7918C0100
3-3/4 (9.5)
7-13/16 (19.8)
1-1/16 (2.7)
12-5/8 (32.1)
--
¾ (1.9)
--
44.93(20.4)
02-7918C9100
3-3/4 (9.5)
7-13/16 (19.8)
1-1/16 (2.7)
12-5/8 (32.1)
--
¾ (1.9)
--
44.9 (20.4)

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 2
2.0 SAFETY INFORMATION
2.1 USAGE AND SAFETY INFORMATION
To insure safe operations please read the following statements and understand their meaning. Also refer to your equipment
manufacturer’s manual for other important safety information. This manual contains safety precautions which are explained
below. Please read carefully.
WARNING! —Warning is used to indicate the presence of a hazard that can cause severe personal injury,
death, or substantial property damage if the warning notice is ignored.
CAUTION! —Caution is used to indicate the presence of a hazard that will or can cause minor personal injury
or property damage if the caution notice is ignored.
3.0 ASSEMBLY INSTRUCTIONS
3.1 GENERAL INFORMATION
This product should be assembled and/or repaired using good workmanship practices and proper tools.
All replacement parts must be the same as or equal to the original parts supplied.
3.2 PRE-USE CHECKS
Refer to the Illustrated Parts List to identify and ensure that all parts are present.
Generally check over unit to assure the tightness of all nuts, bolts and screws.
With rams completely collapsed, check to see if the hydraulic pump reservoir is filled with hydraulic fluid. Replenish with
MIL-PRF-5606 fluid as required.
4.0 TRAINING
4.1 TRAINING REQUIREMENTS
The employer of the operator is responsible for providing a training program sufficient for the safe operation of the unit.
4.2 TRAINING PROGRAM
The employer provided operator training program should cover safety procedures concerning use of the unit in and around the
intended aircraft at the intended aircraft servicing location.
4.3 OPERATOR TRAINING
The operator training should provide the required training for safe operation of the unit.
NOTE: Maintenance and Trouble Shooting are to be performed by a skilled and trained technician.

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 3
5.0 OPERATING INSTRUCTIONS
The user should be familiar with the following statements prior to using the jack(s).
CAUTION!
Never put hands between aircraft and jack pad.
Always open reservoir vent screw before operating.
5.1 TO RAISE GEAR
1. Place hydraulic jack on a hard level surface.
2. Use the mechanical extension(s) and spacer blocks (if applicable) to get the ram as close as possible to the jack pad.
3. Chock aircraft tires on gear not being raised.
4. Connect pump hose.
5. Open reservoir vent screw.
6. Close pump release valve and operate pump.
5.2 TO RAISE NOSE GEAR –02-7833C0110 ONLY
1. Attach the nose gear adapter to the strut. Place the strap around the strut and lock in place with the ball lok-T pin. Insert
both sliding pins into the towing bowls on the strut. Lock sliding pins in place with the ball lok-T pins.
2. Place hydraulic jack on a hard level surface.
3. Use the spacer blocks (Z-3826, Z-3827 and Z-3869) in order to get the ram as close as possible to the jack pad.
NOTE: The one-half inch (1/2") spacer block (Z-3869) must only be used alone or located at the floor level.
WARNING!
NEVER use above the bottom spacer block.
4. After the nose gear adapter is secured onto the strut, line up jack pad with the spherical recess in the center of the
cylinder assembly.
5. Chock aircraft tires on gear not being raised.
6. Connect pump hose.
7. Open reservoir vent screw.
8. Close pump release valve and operate pump.

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 4
5.3 TO RAISE MAIN GEAR –02-7833C0110 ONLY
1. Attach main gear adapter to trailing link. Secure in place with both retaining pins.
2. Place hydraulic jack on a hard level surface between tires.
3. Use the spacer blocks (Z-3826, Z-3827 and Z-3869) in order to get the ram as close as possible to the jack pad.
NOTE: The one-half inch (1/2") spacer block (Z-3869) must only be used alone or located at the floor level.
WARNING!
NEVER use above the bottom spacer block.
4. After the main gear adapter is secured on trailing link, line up jack pad with the spherical recess in the center of the
cylinder assembly.
5. Chock aircraft tires on gear not being raised.
6. Connect pump hose.
7. Open reservoir vent screw.
8. Close pump release valve and operate pump.
5.4 TO LOWER GEAR
Slightly open pump release valve to slowly lower jack.

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 5
6.0 TROUBLE SHOOTING
TROUBLE
PROBABLE CAUSE
ACTION
Fluid leakage at pump
piston or pump body
Damaged backup ring, o-ring, piston or
pump body
Remove piston and pump body. Inspect for
damage. Replace defective part(s). Replace
removed o-ring and backup ring
External fluid leakage at
ram(s)
Damaged o-ring, backup ring or inner
cylinder wall
Remove ram(s) as a unit from cylinder.
Inspect parts. Replace o-ring and defective
part(s)
Jack fails to lift rated load
Release valve not closed properly
Fully tighten release valve
Low fluid level
Fill to correct fluid level
Pressure relief valve improperly adjusted
Adjust or replace release valve
Leakage at inlet or outlet check ball
Inspect valve body for wear or replace valve
body and check balls
Vent screw closed
Open vent screw
Ram(s) will not support
load after manual or
pneumatic pump up
Leaking ram o-ring seals
Check for external leakage, if present replace
defective seal and back up ring
Leaking pressure check valve
Inspect valve body for wear or replace valve
body and check balls
Leaking pressure relief valve
Remove release valve, inspect ball and ball
seat in pump block. Replace effective part(s)
Ram(s) raise and fall with
each manual pump stroke
Release valve open
Fully tighten release valve
Inlet check valve not seated or sticking
Pump rapidly to dislodge or replace valve
body
Pressure check valve not seated or sticking
Pump rapidly to dislodge or replace valve
body
Jack fails to lower
Ram locknut not loosened
Raise jack ¼ inch and release locknut
Vent screw closed
Open vent screw
O-Ring (pinched or rolled)
Replace o-ring and back-up ring, clean up
cylinder wall of debris

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 6
7.0 MAINTENANCE
7.1 GENERAL
All maintenance and/or repair work should be done using good workmanship practices and proper tools.
The work area should be clean and free of dirt.
When O-rings and backup rings are removed, every effort should be made to avoid the contact of tools with the critical
surfaces of parts. Surface deformities could cause degradation of seals and failure.
It is good practice to replace all O-rings and backup rings once removed. Cut and damaged rings normally result in fluid
leakage.
At this time flush old hydraulic fluid and dirt from overall system and replenish with new, clean hydraulic fluid
No modifications shall be carried out which adversely affect the compliance of the jack with draft standard 2006/42/EC.
7.2 SERVICING JACK
To Disassemble Jack:
1. Collapse jack rams.
2. Remove cap screws (pg 10, Item 22) surrounding jack cylinder and retaining ring (pg 10, Item 21).
3. Lift cylinder from axle jack base weldment (pg 10, Items 15 thru 20). Operate jack hand pump to help remove cylinder.
a. Separate rams by removing internal rings (pg 11, Items 4, 5, & 6).
b. Replace all seals including internal rings.
To Reassemble Jack:
1. Re-assemble in reverse order of above.
2. Torque each cap screw (pg 10, Item 22) to 50 ft-lb, using standard cross torque procedure.
To Bleed Jack of Air:
1. Open reservoir vent screw on hand pump.
2. Pump unit to fully extended position.
3. Turn jack upside down.
4. Push jack back to fully collapsed position.
7.3 JACK FUNCTION LOAD TEST
1. Take all necessary precautions to prevent injury.
2. Always jack against a load and never against the jack itself.
3. Apply a test load equal to the jack rated capacity plus 10%. Note: Do not exceed this load.
4. Capacity test annually
8.0 PROVISION OF SPARES
8.1 SPARE PARTS
Spare parts may be obtained from the manufacturer:
TRONAIR, Inc. Telephone: [phone] or 800-426-6301
1 Air Cargo Pkwy East Fax: [phone]
Swanton, Ohio 43558 USA E-mail: [email protected]
Website: www.tronair.com
8.2 PARTS LISTS & ILLUSTRATIONS
Reference the following page for Replacement Parts and Kits available.
9.0 IN-SERVICE SUPPORT
Contact Tronair for technical services and information.

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 7
10.0 GUARANTEES/LIMITATION OF LIABILITY
Tronair products are warranted to be free of manufacturing or material defects for a period of one year after shipment to the
original customer. This is solely limited to the repair or replacement of defective components. This warranty does not cover the
following items:
a) Parts required for normal maintenance
b) Parts covered by a component manufacturers warranty
c) Replacement parts have a 90-day warranty from date of shipment
If you have a problem that may require service, contact Tronair immediately. Do not attempt to repair or disassemble a product
without first contacting Tronair, any action may affect warranty coverage. When you contact Tronair be prepared to provide the
following information:
a) Product Model Number
b) Product Serial Number
c) Description of the problem
If warranty coverage is approved, either replacement parts will be sent or the product will have to be returned to Tronair for
repairs. If the product is to be returned, a Return Material Authorization (RMA) number will be issued for reference purposes
on any shipping documents. Failure to obtain a RMA in advance of returning an item will result in a service fee. A decision on
the extent of warranty coverage on returned products is reserved pending inspection at Tronair. Any shipments to Tronair must
be shipped freight prepaid. Freight costs on shipments to customers will be paid by Tronair on any warranty claims only. Any
unauthorized modification of the Tronair products or use of the Tronair products in violation of cautions and warnings in any
manual (including updates) or safety bulletins published or delivered by Tronair will immediately void any warranty, express or
implied.
The obligations of Tronair expressly stated herein are in lieu of all other warranties or conditions expressed or implied. Any
unauthorized modification of the Tronair products or use of the Tronair products in violations of cautions and
warnings in any manual (including updates) or safety bulletins published or delivered by Tronair will immediately
void any warranty, express or implied and Tronair disclaims any and all liability for injury (WITHOUT LIMITATION and
including DEATH), loss or damage arising from or relating to such misuse.
11.0 APPENDICES
APPENDIX I Safety Data Sheet –MIL-PRF-5606 Hydraulic Fluid
APPENDIX II Declaration of Conformity
APPENDIX III Maintenance Schedule

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 8
Parts List
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
V-1405
LABEL, AXLE JACK
1
2
Z-5684
ASSEMBLY, HAND PUMP
1
3
V-1001
LABEL, MADE IN USA
1
4
Z-3823
WELDMENT, AXLE JACK BASE
1
5
N-2228-12-S-B
ELBOW, 90° FEMALE
1
6
A-1155-01
ANGLE, HOSE SUPPORT
1
7
Z-5680
ASSEMBLY, HOSE
1
8
G-1100-105506
BOLT, H H, GR 5, 1/4-28 X 3/4 LONG
2
9
G-1250-1050N
FLATWASHER, 1/4 NARROW
2
10
N-2205-02-S
PLUG, HOLLOW HEX
1
11
HC-1551
ELBOW, SWIVEL NUT, SAE #6
1
K-3772
Kit, Hand Pump Replacement; consists of:
N/S
N-2203-06-S
Nipple, Pipe
1
N/S
N-2713
Nipple, Hydraulic (Male)
1
N/S
HC-2762
Hand Pump with Labels
1
K-1508
Kit, Hydraulic Pump Seal Replacement
(This kit includes all soft seals, wipers, and gaskets required to reseal the pump)

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 9
Parts List
When ordering replacement parts/kits, please specify model, serial number and color of your unit.

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 10
Parts List
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Z-4936-Z1
Z-4936-Z2
Z-4936-Z3
Z-4936-Z4
Z-4936-Z5
Z-4936-Z6
Z-4936-Z7
Z-4936-Z8
1
Z-4936-81
BASE ASSEMBLY, 12 TON AXLE JACK
1
1
1
1
1
1
1
1
2
V-2839
LABEL, JACK TYPE/SERIAL
1
1
1
1
1
1
1
1
7
R-2012-01
PAD, JACK
1
-
-
-
-
-
-
-
8
R-2012-02
PAD, JACK
1
-
-
-
-
-
-
-
9
R-2012-03
PAD, JACK
1
-
-
-
-
-
-
-
10
R-1820
PAD, AXLE JACK
-
-
-
1
-
-
-
-
11
Z-7392
WELDMENT, ADAPTOR
-
-
-
-
-
-
-
1
12
Z-3363
ASSEMBLY, NOSE ADAPTER
-
-
-
-
-
1
1
-
13
Z-3299
ASSEMBLY, MAIN ADAPTER
-
-
-
-
-
-
1
-
14
Z-3275
ASSEMBLY, NOSE ADAPTER
-
-
-
1
-
-
-
-
15
Z-4935
ASSEMBLY, CYLINDER
1
-
-
-
-
-
-
1
16
Z-3825
ASSEMBLY, CYLINDER
-
1
-
-
-
-
1
-
17
Z-5737
ASSEMBLY, CYLINDER
-
-
1
-
-
-
-
-
18
Z-10908
ASSEMBLY, CYLINDER
-
-
-
1
-
-
-
-
19
Z-10909
ASSEMBLY, CYLINDER
-
-
-
-
1
-
-
-
20
Z-10910
ASSEMBLY, CYLINDER
-
-
-
-
-
1
-
-
21
J-2485
RING, CYLINDER RETAINING
1
1
1
1
1
1
1
1
22
G-1151-110716
SCREW, 5/8-18 X 1-3/4" SOCKET HD CAP
4
4
4
4
4
4
4
4

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 11
Cylinder Assemblies Parts List
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
K-2779
Kit, Cylinder Seal Replacement; consists of:
4
G-1398-300
First Cylinder Internal Ring
1
5
G-1398-250
Second Cylinder Internal Ring
1
6
G-1398-200
Third Cylinder Internal Ring
1
7
HC-2008-240
Main Cylinder O-ring
1
8
HC-2000-236
First Cylinder O-ring
1
9
HC-2023-236
First Cylinder Backup Ring
1
10
HC-1697-32
Main Cylinder Wiper
1
11
HC-2000-232
Second Cylinder O-ring
1
12
HC-2023-232
Second Cylinder Backup Ring
1
13
HC-1697-28
First Cylinder Wiper
1
14
HC-2000-228
Third Cylinder O-ring
1
15
HC-2023-228
Third Cylinder Backup Ring
1
16
HC-1697-24
Second Cylinder Wiper
1
17
HC-2000-224
Fourth Cylinder O-ring
1
18
HC-2023-224
Fourth Cylinder Backup Ring
1
19
HC-1697-20
Third Cylinder Wiper
1

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 12
Parts List –02-7833C0110
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-4936-Z7
ASSEMBLY, 12 TON AXLE JACK
1
2
V-2840
LABEL, JACK MODEL
1
4
Z-3869
ASSEMBLY, 1/2" BASE BLOCK
1
5
Z-3826
ASSEMBLY, 3/4" BASE BLOCK
1
6
Z-3827
ASSEMBLY, 1-1/2" BASE BLOCK
1

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 13
Parts List –02-7846C0110
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-4936-Z7
ASSEMBLY, 12 TON AXLE JACK
1
2
V-2840
LABEL, JACK MODEL
1

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 14
Parts List –02-7852C0100
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-4936-Z2
ASSEMBLY, 12 TON AXLE JACK
1
2
V-2840
LABEL, JACK MODEL
1
4
H-4156
CASE, JACK TRANSPORT
1
5
Z-3827
ASSEMBLY, 1-1/2" BASE BLOCK
1

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 15
Parts List –02-7861C0100, 02-7861-9100
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-4936-Z3
ASSEMBLY, 12 TON AXLE JACK
1
2
V-2840
LABEL, JACK MODEL
1
4
H-4156
CASE, JACK TRANSPORT
1
NOTE: 02-7861-9100 is painted Yellow

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 16
Parts List –02-7863C0100
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-4936-Z1
ASSEMBLY, 12 TON AXLE JACK
1
2
V-2840
LABEL, JACK MODEL
1
4
H-4156
CASE, JACK TRANSPORT
1
5
Z-3869
ASSEMBLY, 1/2" BASE BLOCK
1
6
Z-3826
ASSEMBLY, 3/4" BASE BLOCK
1

Models: 02-7833C0110, 02-7846C0110, 02-7852C0100,02-7861C0100, 02-7861-9100,
02-7863C0100, 02-7902C0100, 02-7918C0100, 02-7918C9100
12 Ton (10.8 Metric Ton) Axle Jack
05/2021 | Rev. 03 Page | 17
Parts List –02-7902C0100
When ordering replacement parts/kits, please specify model, serial number and color of your unit.
Item
Part Number
Description
Qty
1
Z-4936-Z8
ASSEMBLY, 12 TON AXLE JACK
1
2
V-2840
LABEL, JACK MODEL
1
4
H-4156
CASE, JACK TRANSPORT
1
5
Z-3869
ASSEMBLY, 1/2" BASE BLOCK
1
6
Z-3826
ASSEMBLY, 3/4" BASE BLOCK
1
