True TCGG-60-S User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TCGG-60-S
TCGG-60-S
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†HHP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TCGG-60-S 2 30
850
460
1/4
1531
351/4
896
473/4
1213
1/2115/60/1 12.7 5-15P 9
2.74
N/A
N/A
†Depth does not include 7/8
" (23 mm) for rear door handles.
12/06
True’s curved glass deli display
case combines efficient, high
volume merchandising and
exceptional refrigeration with
an elegant curved glass front
for sophisticated presentation
of deli products.
High humidity gravity coil
refrigeration system maintains
38°F to 40°F (3.3°C to 4.4°C) for
the freshest display of meats,
cheeses, and deli products.
Self-contained, environmentally
friendly (CFC free) 134A
refrigeration system.
Cabinet is NSF-7 certified to
hold open food product.
Insulated double pane curved
front glass provides maximum
insulation value for greater
efficiency and energy savings.
Both panes are tempered for
safety.
Four (4) adjustable, lighted,
cantilevered PVC coated
shelves.
Fluorescent lamps are low UV
emitting to enhance product
appearance and increase shelf
life.
All stainless steel interior and
exterior.
Display Case:
Curved Glass Deli Case
R
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D Back
PLAN VIEW
KCL
TCGG-60-S
TCGG-60-S
DESIGN
•True’s curved glass deli display case
combines efficient, high volume
merchandising and exceptional
refrigeration with an elegant
curved glass front for sophisticated
presentation of deli products.
• Gravity coil refrigeration system
guarantees the freshest display of
meats, cheeses, and deli products.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser maintains 38°F to
40°F (3.3°C to 4.4°C).
• High humidity gravity coil refrigeration
system. Ideally suited for deli meats,
cheeses and salads.
• Condensing unit located behind
panel in back of unit. Entire system
slides out for easy cleaning and
maintenance.
• Automatic defrost system; time-
initiated, time-terminated.
CABINET CONSTRUCTION
• Exterior - all stainless front, sides, back
and top. Black front and rear grills
and trim.
• Interior - NSF approved white
aluminum sides and top. 300 series
stainless steel floor with coved corners.
• Insulation - entire cabinet structure is
foamed-in-place using high density,
CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame
rail dipped in rust inhibiting enamel
paint for corrosion protection inside
and out.
• Frame rail fitted with leg levelers.
CURVED FRONT DISPLAY GLASS
• Insulated double pane glass provides
maximum insulation value for greater
efficiency and energy savings. Both
panes are tempered for safety.
DOORS
• “Low-E”, double pane thermal glass
insert with mitered plastic channel
frame.
• Each door fitted with 12" (305 mm)
long molded plastic handle.
• Self-closing doors. Sliding doors ride
on stainless steel V-Channel with
stainless steel bearings. Doors fit
within plastic channel frame.
SHELVING
• Four (4) adjustable, lighted, white
heavy duty PVC coated wire shelves
221/2" L x 277/8" D (572 mm x 709
mm). Shelving system is cantilevered
with adjustable angles to maximize
presentation.
LIGHTING
• Cabinet is equipped with five (5)
light sources for maximum product
display; four (4) shelf mounted and
one (1) cabinet mounted. Fluorescent
lamps are low UV emitting to enhance
product appearance and increase shelf
life.
MODEL FEATURES
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• Four (4) amp exterior scale receptacle.
• NSF-7 compliant for open food
product.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
115/60/1 phase - 15 amp dedicated
outlet. Cord and plug set included.
RECOMMENDED OPERATION
CONDITIONS
• TCGG models are designed to operate
in an environment where temperature
and humidity do not exceed 75°F
(23.8°C) and 55% relative humidity.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒21/2" (64 mm) diameter castors.
❒Ratchet locks.
❒Additional lighted shelves.
❒Non-lighted shelves.
❒Remote cabinets (condensing unit
supplied by others; system comes
standard with 404A expansion valve
and requires R404A refrigerant).
Consult factory technical service
department for BTU information.
115/60/1
NEMA-5-15R
Display Case:
Curved Glass Deli Case
1619/32"
(422 mm)
RIGHT VIEW
291/16"
(739 mm)
355/32"
(893 mm)
347/8"
(886 mm)
BACK VIEW
605/32"
(1528 mm)
287/16"
(723 mm)
465/8"
(1185 mm)
5/16"
(8 mm)
3/4"
(20 mm)
4711/16"
(1212 mm)
1513/32"
(392 mm)
291/4"
(743 mm)
3531/32"
(914 mm)
13/16"
(21 mm)
277/8"
(709 mm)
