True TR1HPT-1S-1S User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TR1HPT-1S-1S
TR1HPT-1S-1S
Model Doors
Capacity
(Cu. Ft.)
(liters)
Cabinet Dimensions
(inches)
(mm)
LD
†H*Watts Voltage
NEMA
Config.
Cord Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TR1HPT-1S-1S 2 31
878
29
737
371/4
947
781/4
1988
2000 115/208-240/60/1 14-20P 9
2.74
400
182
†Depth does not include 11/8 " (29 mm) for system mechnical components
*Height does not include 61/8
" (156 mm) for legs, 5 " (127 mm) for optional castors and 1 " (26 mm) for system mechanical components.
Requires 115/208 -240/60 Hz, single phase, 3 pole, 4 wire circuit.
6/07
Provides cabinet holding
temperature of 80°F to 180°F
(26.6°C to 82.2°C).
Equipped with low-velocity fans
to assure even temperature
distribution throughout the
cabinet. Fans are controlled by
exterior on/off switch.
Two (2) stainless steel (for
corrosion resistance), finned tube
heating elements (1000 watts
each) for uniform generation of
electric heat. Cabinet comes with
a total of 2000 watts.
300 series stainless steel exterior
and interior. The very finest
stainless with higher tensile
strength for fewer dents and
scratches.
Equipped with one (1) interior
kit option per full section, factory
installed. Four (4) different
interior kits available.
Positive seal self-closing door
with 120° stay open feature.
Lifetime guaranteed door hinges
and torsion type closure system.
Entire cabinet structure and
solid doors are foamed-in-place
using high density, CFC free,
polyurethane insulation.
R
TR Specification Series:
Pass-Thru Solid Door Heated Cabinet
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor (U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
DESIGN
• True’s solid door pass-thru heated cabinets
are designed with enduring quality that
protects your long term investment.
HEATER SYSTEM
• Cabinet is designed to provide holding
temperatures of 80°F to 180°F (26.6°C to
82.2°C). Heating system controlled by
exterior on/off switch and temperature
control dial.
• Two (2) stainless steel (for corrosion
resistance), finned tube heating elements
(1000 watts each) for uniform generation of
electric heat. Cabinet comes with a total of
2000 watts.
• Equipped with low-velocity fans to assure
even temperature distribution throughout
the cabinet. Fans are controlled by exterior
on/off switch.
• Manually controlled vent located on top of
the cabinet for positive humidity control.
• 12" x 20" (305 mm x 508 mm) pan for water
included, if additional humidity required.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors,
front, sides, back and bottom.
• Interior - 300 series stainless steel liner
and floor.
• Insulation - entire cabinet structure and
solid doors are foamed-in-place using high
density, CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 6" (153 mm) stainless
steel legs.
DOORS
• Front and rear doors are 300 series stainless
steel exterior and liner. Doors open within
cabinet dimension.
• Door locks standard.
• Lifetime guaranteed recessed door handles.
Each door fitted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to ensure permanent
attachment.
• Positive seal self-closing door with 120° stay
open feature. Lifetime guaranteed door
hinges and torsion type closure system.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• One (1) factory installed, interior kit option.
Four (4) different interior kits available (see
kit options). Pilasters and tray slides are
factory installed at no charge.
LIGHTING
• Incandescent interior lighting. Lights
activated by exterior on/off switch; safety
shielded
MODEL FEATURES
• Exterior, color coded, temperature display;
accurate direct reading of internal cabinet
temperture.
• Designed to hold warm baked or cooked
food. Cabinet is not designed to heat
ambient or cold product.
• NSF-4 compliant for open food product.
ELECTRICAL
• True requires a sole use circuit be dedicated
for the unit.
• Unit completely pre-wired at factory and
ready for final connection to a 115/208-
240/60 Hz. single phase, 20 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 6" (153 mm) Seismic/flanged legs.
❒4" (102 mm) diameter swivel castors.
❒ Stainless steel rail skirt for use with legs (field
installed).
❒ Metal door handles (factory installed).
❒ Electronic temperature control (factory
installed).
❒ Correctional facilities options.
❒ Curb mountable units.
KIT OPTIONS
❒ Kit #1: Nine (9) sets of #1 type tray slides and
pilasters (factory installed), bottom support
of one (1) 18"L x 26"D (458 mm x 661 mm)
pan or two (2) 14"L x 18"D (356 mm x
458 mm) pans.
❒ Kit #2: One (1) set half-section #2 steel rod
tray slides and pilasters (factory installed),
rim support of one (1) 18"L x 26"D (458 mm
x 661 mm) pan.
❒ Kit #3: Six (6) sets of universal type tray slides
and pilasters (factory installed), bottom
support of one (1) 18"L x 26"D (458 mm x
661 mm) pan, two (2) 14"L x 18"D
(356 mm x 458 mm) pans or two (2) 12"L x
20"D (305 mm x 508 mm) pans.
❒ Kit #4: Three (3) chrome shelves 25"L x
2813/16"D (635 mm x 732 mm). Four (4)
shelf clips included per shelf and wall
mounted pilasters (factory installed). Shelves
adjustable on 6" (153 mm) increments.
❒ Additional kit option components available
individually.
❒ Stainless steel (electro polished) shelves to be
used with Kit Option #4.
TR1HPT-1S-1S TFQY179E TFQY181S TFQY181P TFQY1813
TR1HPT-1S-1S
115/208-240/1
NEMA-14-20R
ELEVATION PLAN VIEW
783/16"
(1986 mm)
851/4"
(2166 mm)
29"
(737 mm)
371/4"
(947 mm)
2623/32"
(679 mm)
9011/16"
(2304 mm)
61/16"
(154 mm)
2623/32"
(679 mm)
TR Specification Series:
Pass-Thru Solid Door Heated Cabinet
1"
(26 mm)
77"
(1956 mm)
13/16"
(31 mm)
11/32"
(27 mm)
389/32"
(973 mm)
