FEATURES/BENEFITS
All dimensions rounded up to the nearest 1/8" ITrue Website: www.truemfg.com IToll Free Number • 1-800-325-6152 ISpecifications subject to change without notice.
New Cantilever Shelving
Available.
(TAC-72 standard with
cantilever shelving)
• Oversized environmentally friendly (R404A)
refrigeration - holds 33°F to 38°F, the ideal
temperature for fresh salads, sandwiches,
desserts and beverages.
• Exterior - non-peel or chip white laminated
vinyl, durable and permanent.
• Interior - attractive, NSF approved, white
aluminum with 300 series stainless steel
floor and deck pans.
Available with black aluminum interior
(upcharge applies); standard with black
shelves.
• Designed for convenient access, fast ser-
vice, and attractive display.
• Safety shielded fluorescent interior lighting
for longer, brighter, shadow-free illumination.
• Adjustable, heavy duty, PVC coated wire
shelves - 10 mil thick, pure grade vinyl coat-
ing (TAC-72 standard with two white cantile-
ver shelves per level).
• Exclusive reversing condenser fan motor.
• Foamed-in-place polyurethane high density
cell insulation (CFC free).
• Leg levelers standard.
• Self-contained system.
• Illuminated sign panel.
• Available with optional 21/2" diameter castors
(excludes remote models).
• See our website www.truemfg.com for the
latest color & sign offerings.
• Optional black interiors available. Upcharge
and lead times will apply.
• Optional stainless exteriors available.
Upcharge and lead times will apply.
TAC-48
Black vinyl exterior available at no extra charge.
Stainless steel exterior available (upcharge applies).
‡ TAC-36 & TAC-48 require 208-230/60 Hz, single phase, NEMA 6-15R.
TAC-72 requires 208-230/60 Hz, single phase, NEMA 6-20R.
Black vinyl exterior available at no extra charge.
Stainless steel exterior available (upcharge applies).
‡ Requires 208-230/60 Hz, single phase, NEMA 6-15R.
Cantilever Shelving
VERTICAL AIR CURTAIN, GLASS SIDED (SELF CONTAINED)
Model
Cu.
Ft.
# of
Shelves HP Amps
Crated
Weight
Cabinet Dimensions
L D H
TAC-14GS 16.2 3 1/210.9 280 30
1
/ 4 x 30
3
/ 8 x 56
3
/ 8
TAC-30GS 25.5 4 1/214.3 N/A 30
3
/ 8 x 29
3
/ 4 x 80
3
/ 4
TAC-48GS ‡ 34.0 4 1 12.0 475 48 x 30
1
/ 4 x 80
5
/ 8
VERTICAL AIR CURTAIN (SELF CONTAINED)
Model
Cu.
Ft.
# of
Shelves HP Amps
Crated
Weight
Cabinet Dimensions
L D H
TAC-30 25.5 4 1/212.8 355 30 x 30
1
/ 8 x 80
5
/ 8
TAC-36 ‡ 31.3 4 3/47.5 420 36 x 30
1
/ 8 x 80
5
/ 8
TAC-48 ‡ 34.0 4 1 12.0 490 48 x 30
1
/ 8 x 80
5
/ 8
TAC-72 ‡ 65.9 8 (2) 3/413.7 N/A 72 x 30
1
/ 8 x 81
3
/ 4
Recommended Operating Conditions
• Units should not be installed near HVAC vents,
fans or doorways that will disrupt the air curtain
and compromise the function of the cabinet.
• Units should not be installed in direct sunlight.
• Air curtain models will run most efficiently
when completely loaded with product.
• TAC models are designed to operate in an envi-
ronment where temperature & humidity do not
exceed 75°F and 55% respectively.
• Please be advised Air Curtain models are
substantially louder than standard refrigeration
models.
NEW
NEW
VERTICAL AIR CURTAINS
NEW
NEW
NEW
TAC-14GS
(shown with
black exterior)
TAC-30
(shown with black
exterior and optional
black aluminum interior)
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
TAC-48GS
TAC-30GS
