True GDM-72FC User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
GDM-72FC
GDM-72FC
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD†H
HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
GDM-72FC 3 72
2039
678
1/8
1985
297/8
759
793/8
2017
1/2
1/2
115/60/1
230-240/50/1
12.0
6.9
5-15P
▲
9
2.74
625
284
†Depth does not include 11/8" (29 mm) for door handles. ▲Plug type varies by country.
4/06
The world’s #1 manufacturer of glass
door merchandisers.
Oversized and balanced refrigeration
system, factory sealed and pre-lubricated
for long life. Designed to accommodate
a broad range of floral temperature
settings, holds 35°F (1.6°C).
Exterior - non-peel or chip black
laminated vinyl; durable and permanent.
Interior - attractive, NSF approved, black
aluminum interior liner with 300 series
stainless steel floor.
Self closing doors. Positive seal, torsion
type closure system.
“Low-E”, double pane thermal glass
door assemblies with extruded aluminum
frames. The latest in energy efficient
technology.
Adjustable, heavy duty black PVC coated
shelves.
Patented integrated door light (IDL)
system for brighter, shadow free
illumination. Special interior agro
lighting designed for flowers to prevent
premature discoloration.
Illuminated sign panel.
Entire cabinet structure is foamed-
in-place using high density, CFC free,
polyurethane insulation.
Bottom mounted units feature
”No stoop” lower shelf to maximize
product visibility.
Storage on top of cabinet.
Easily accessible condenser coil for
cleaning.
Glass Door Merchandiser:
Floral Case
®
Shown with optional True Stripe sign.

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
GDM-72FC TFBY01E TFBY01S TFBY01P TFBY013
GDM-72FC
DESIGN
• True’s commitment to using the highest
quality materials and refrigeration systems
provides the user with better product
temperatures, and lower utility costs in an
attractive merchandiser that brilliantly displays
high profit floral arrangements.
• True’s floral merchandisers offer interior agro
lighting combined with a baffled airflow
design which creates the ideal environment to
prolong fresh flower shelf life.
• Brilliant black exterior and interior with
product accentuating black shelves further
entice customers to purchase high profit floral
arrangements.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly
(CFC free) 134A refrigerant.
• Oversized and balanced refrigeration system,
factory sealed and pre-lubricated for long life.
Designed to accommodate a broad range of
floral temperature settings, holds 35°F (1.6°C).
• Sealed, cast iron, self-lubricating evaporator
fan motor(s) and larger fan blades give True
merchandisers a more efficient low velocity,
high volume airflow design.
• Baffled airflow provides even air distribution
for longer shelf life of fresh flowers.
• Bottom mounted condensing unit positioned
for easy maintenance; “No stoop” lower shelf
maximizes visibility by raising merchandised
product to higher level.
CABINET CONSTRUCTION
• Exterior - non-peel or chip black laminated
vinyl; durable and permanent.
• Interior - attractive, NSF approved, black
aluminum interior liner with 300 series
stainless steel floor.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC free,
polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with leg levelers.
• Illuminated exterior sign panel. Variety of
sign options available.
DOORS
• “Low-E”, double pane thermal glass door
assemblies with extruded aluminum frames.
The latest in energy efficient technology.
• Self closing doors. Positive seal, torsion type
closure system.
• Each door fitted with 15" (381 mm) long
extruded black PVC handle.
• Magnetic door gaskets of one piece
construction, removable without tools for ease
of cleaning.
SHELVING
• Six (6) adjustable, heavy duty black PVC coated
wire shelves 249/16"L x 221/8"D
(624 mm x 562 mm). Four (4) chrome plated
shelf clips included per shelf.
• Shelf support pilasters made of same material
as cabinet interior; shelves are adjustable on
1/2" (13 mm) increments.
LIGHTING
• Fluorescent interior lighting. Each door
utilizes full-length, patented, integrated door
light (IDL) system. Safety shielded.
• Special interior agro lighting designed for
flowers to prevent premature discoloration.
• Cabinet lighting utilizes electronic ballast and
T-8 bulbs for brighter illumination, longer
bulb life and increased energy efficiency.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1 phase
- 15 amp dedicated outlet. Cord and plug set
included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230-240V / 50 Hz.
❒ White exterior.
❒ Rosewood exterior.
❒ Mirrored back.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/flanged legs.
❒ 2
1/2" (64 mm) diameter castors.
❒ White wire shelves.
❒Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant). Consult factory technical
service department for BTU information.
115/60/1
NEMA-5-15R
PLAN VIEW
Glass Door Merchandiser:
Floral Case
793/8"
(2017 mm)
7615/16"
(1955 mm)
2913/16"
(758 mm)
3029/32"
(786 mm)
781/8"
(1985 mm)
ELEVATION
535/8"
(1363 mm)
21/8"
(54 mm)
5/16"
(8 mm)
13/32"
(28 mm)
