Tunstall VitalBase VBC3 User manual

USER GUIDE
Step N°1 : Sleep mode Exit
Step N°2 : Verification of normal operation
If this step does not take place correctly start again with step N°1
VitalBase watch - VBC3
123
Push the button for 3 seconds The red led lights up Immediately release the button
123
Push and release the button
The red led turns on then turns off VitalBase is ready
LED
Alarm Button
After removing VitalBase from its package, fully read the documentation
before performing the following steps.
MATP0412
For optimal results, VitalBase has to be permanently worn on the wrist .
Other uses may generate false alarms.

Step N°3 : Enter sleep mode
Specifications
Description of VitalBase FALL Watch
VitalBaseFALL is as simple to wear as a watch.
LED
ALARM BUTTON
For optimal results, VitalBase has to
be permanently worn on the wrist.
Other uses may generate false
alarms.
Weight : 50 grams
Water resistant
Cleaning : water and soap only
Plastic : made of hypoallergenic plastic
Radio frequency : 869.2125 MHz
Radio range : up to 50 metres (in building)
Operating Temperature : +5° C to +40° C
Types of alarms
Manual Alarm :
Manual Alarm: Activated by pushing the button
Automatic Alarm :
If VitalBase detects a fall, the system will automatically activate the alarm
Low battery on the alarm (silent alarm sent in case of failure battery)
Vibrator :
Before sending an alarm signal to the Home unit, the VitalBase product starts to
vibrate intermittently for approx. 8 seconds; during this period if you move your arm ,
the alarm will be cancelled. If you still require assistance, press the alarm button.
IP 67
Examples of fall types :
- Unconsciousness condition and motionlessness due to a heavy fall or sudden loss of balance, it can happen in everyday life in your bathroom, when you
wake up, or each time you walk around in your house (to go to bed, to sit, to eat, to walk, to read, go up/down stairs…)
- NB : In spite of all the intelligence on the VitalBaseFALL solution, it is possible that some falls (as soft fall, controlled fall against a wall or on a chair…)
cannot be detected by VitalBase
FALL
. Fall detection technologies cannot analyse all the situations.
- NB : If Vitalbase FALL does not detect a fall, the user can at anytime generate an alarm by pushing the alarm button.
MATP0412
Battery life : up to 2 years
While led is on, press and release the button 5 times quickly
Holding the last 5th press until the led turns off. Once the led turns off, release the button.
After 5 seconds, you can check that the VitalBase is back into sleep mode by pressing 2 times quickly on the button.
The watch vibrates and the led flashes
If it is not working please restart the process from the begining.
VitalBase watch needs to lay down on the table during this step as shown on this picture
Press and release the button just like for sending an alarm
Release3- BDNCAUGUST13
