TurboWheel Swift User manual

User Manual

P01: Backlight. Range 1-3, 3 = Brightest
P02: Units. 1 = KPH, 2= MPH
P03: Battery Voltage. 24, 36, 48, 52, 60.
Default = 48V
P04: Dash Timeout. Range 1-60 minutes
Default = 10 minutes
P06: Tire Diameter. Default = 8
P07: Motor Poles. Default = 28
P08: Power Output. Default = 100
P09: Kick-off Start.Default = 0
1 = Push-to-Start
P11: Regenerative Braking. Range 0-5
0 = Off, 5 = Strongest
P15: Low voltage cut. Default = 39
P17: Cruise-control. Default = 0, Off
1 = Enabled
Turbowheel Swift: Dashboard
Enable the Settings Mode: Pressing the Power + Mode
simultaneously will enter the Dashboard setting mode.
Short pressing the power button will toggle through the 10
available settings for the scooter
Toggling through
the Settings
Changing the
P Value
Once you have the P setting you wish to change, press the mode
button will increase value, the power button to decrease it
Setting the
Change
Holding the mode button will set the value & return you to the P
menu. Also, after 5 seconds the Dash will return to the main screen.
2
P12: Acceleration Power. Range 1-5
Default = 3

Turbowheel Swift
LG 12.8Ah 48V, 614Wh
Front/rear drum + regenerative
220lb
500W rear-hub motor
Front & deck headlights with braking mode
Front spring & dual-rear shock absorbers
39.5 lb
~23 MPH
~25 Miles
8.5” pneumatic front, 8” solid rear
Turbowheel Swift: Technical Specifications
3
20A Controller

Turbowheel Swift: Unfolding
4

Turbowheel Swift: Folding
5

39
6
Plug the charger into the electrical outlet
