Tyco Fire Product TY-B Series User manual

Series TY-B – 2.8, 5.6, and 8.0 K-factor
Upright, Pendent, and Recessed Pendent Sprinklers
Standard Response, Standard Coverage
Page 1 of 8 NOVEMBER 2014 TFP151
IMPORTANT
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cau-
tions with respect to handling and
installation of sprinkler systems and
components. Improper handling and
installation can permanently damage
a sprinkler system or its compo-
nents and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.
Worldwide
Contacts
www.tyco-fire.com
General
Description
TYCO Series TY-B, 2.8, 5.6, and 8.0
K-factor, Upright and Pendent Sprin-
klers described in this technical data
sheet are standard response, standard
coverage decorative 5 mm glass bulb
type spray sprinklers designed for use in
light, ordinary, or extra hazard, commer-
cial occupancies such as banks, hotels,
shopping malls, factories, reneries, and
chemical plants.
The recessed version of the Series TY-B
Pendent Sprinkler, where applicable, is
intended for use in areas with a nished
ceiling. It uses a two-piece Style 10 (1/2
inch NPT) or Style 40 (3/4 inch NPT)
Recessed Escutcheon. The Recessed
Escutcheon provides 1/2 inch (12,7 mm)
of recessed adjustment or up to 3/4 inch
(19,1 mm) of total adjustment from the
ush pendent position. The adjustment
provided by the Recessed Escutcheon
reduces the accuracy to which the xed
pipe drops to the sprinklers must be cut.
Corrosion resistant coatings, where
applicable, are utilized to extend the life
of copper alloy sprinklers beyond that
which would otherwise be obtained
when exposed to corrosive atmo-
spheres. Although corrosion resistant
coated sprinklers have passed the
standard corrosion tests of the appli-
cable approval agencies, the testing
is not representative of all possible
corrosive atmospheres. Consequently,
it is recommended that the end user
be consulted with respect to the suit-
ability of these coatings for any given
corrosive environment. The effects of
ambient temperature, concentration of
chemicals, and gas/chemical velocity,
should be considered, as a minimum,
along with the corrosive nature of the
chemical to which the sprinklers will be
exposed.
An intermediate level version of the
Series TY-B Pendent Sprinkler can be
obtained by utilizing the Series TY-B
Pendent Sprinkler in combination with
the Model S2 Shield.
NOTICE
The Series TY-B Sprinklers described
herein must be installed and maintained
in compliance with this document, as
well as with the applicable standards of
the National Fire Protection Association
(NFPA), in addition to the standards of
any other authorities having jurisdiction.
Failure to do so may impair the perfor-
mance of these devices.
The owner is responsible for maintaining
their fire protection system and devices
in proper operating condition. Contract
the installing contractor or product
manufacturer with any questions.
Sprinkler
Identification
Numbers (SINs)
TY1151 – Upright 2.8K, 1/2˝ NPT
TY1251 – Pendent 2.8K, 1/2˝ NPT
TY3151 – Upright 5.6K, 1/2˝ NPT
TY3251 – Pendent 5.6K, 1/2˝ NPT
TY4151 – Upright 8.0K, 3/4˝ NPT
TY4251 – Pendent 8.0K, 3/4˝ NPT
TY4851 – Upright 8.0K, 1/2˝ NPT
TY4951 – Pendent 8.0K, 1/2˝ NPT

TFP151
Page 2 of 8
*
**
**
*
*
PENDENTUPRIGHT CROSS SECTION
2-3/16"
(55,6 mm)
WRENCH
FLATS
Pipe thread connections
per ISO 7-1 can be
provided on special
request.
Temperature rating is
indicated on Deector.
CEILING PLATE
SEATING SURFACE
7/16"
(11,1 mm)
NOMINAL
MAKE-IN
2-1/4"
(57,2 mm)
1-9/16"
(39,7 mm)
2
4
5
6
7
3
1
1
2
Sealing
Assembly
Button
Frame
-
-
Bulb
Bushing
-
7
3-
4-
6-
1/2" NPT
Deector
Compression
Screw
5-
* **
**
*
*
UPRIGHT PENDENT CROSS SECTIONRECESSED PENDENT
7/16"
(11,1 mm)
NOMINAL
MAKE-IN
ESCUTCHEON
PLATE SEATING
SURFACE
STYLE 10
RECESSED
ESCUTCHEON
Pipe thread connections per
ISO 7-1 can be provided on
special request.
Temperature rating
is indicated on
Deector.
2-7/8" (73,0 mm) DIA.
1/2" NPT
1
2 Button
Frame
-
-
Bulb4 -6-Deector
5
6
4
2
3
1
3-5-
WRENCH
FLATS
2-3/16"
(55,6 mm)
2-3/16"
(55,6 mm)
1-1/2"
(38,1 mm)
Sealing
Assembly
Compression
Screw
FIGURE 1
SERIES TY-B UPRIGHT (TY1151) AND PENDENT (TY1251) SPRINKLERS
2.8 K-FACTOR, 1/2 INCH NPT, STANDARD RESPONSE
FIGURE 2
SERIES TY-B UPRIGHT (TY3151) AND PENDENT (TY3251) SPRINKLERS
5.6 K-FACTOR, 1/2 INCH NPT, STANDARD RESPONSE

TFP151
Page 3 of 8
* **
**
*
*
UPRIGHT PENDENT CROSS SECTIONRECESSED PENDENT
ESCUTCHEON
PLATE SEATING
SURFACE
Pipe thread connections per
ISO 7-1 can be provided on
special request.
Temperature rating
is indicated on
Deector.
1
2 Button
Frame
-
-
Bulb4 -6-Deector
3-5-
Sealing
Assembly
Compression
Screw
2-7/8" (73,0 mm) DIA.
3/4" NPT
5
6
4
2
3
1
STYLE 40
RECESSED
ESCUTCHEON
WRENCH
FLATS
1/2"
(12,7 mm)
NOMINAL
MAKE-IN
2-1/4"
(57,2 mm)
2-5/16"
(58,7 mm)
1-9/16"
(39,7 mm)
*
**
**
*
*
PENDENTUPRIGHT CROSS SECTION
2-1/4"
(57,2 mm)
1-9/16"
(39,7 mm)
2-3/16"
(55,6 mm)
1
2
Sealing
Assembly
Button
Frame
-
-
Bulb
3-
4-
6-
1/2" NPT WRENCH
FLATS
Deector
Compression
Screw
5-
5
6
4
2
3
1
Pipe thread connections
per ISO 7-1 can be
provided on special
request.
Temperature rating is
indicated on Deector.
CEILING PLATE
SEATING SURFACE
7/16"
(11,1 mm)
NOMINAL
MAKE-IN
FIGURE 4
SERIES TY-B UPRIGHT (TY4851) AND PENDENT (TY4951) SPRINKLERS
8.0 K-FACTOR, 1/2 INCH NPT, STANDARD RESPONSE
FIGURE 3
SERIES TY-B UPRIGHT (TY4151) AND PENDENT (TY4251) SPRINKLERS
8.0 K-FACTOR, 3/4 INCH NPT, STANDARD RESPONSE

TFP151
Page 4 of 8
KSPRINKLER
TYPE TEMPERATURE RATING
BULB
LIQUID
COLOR
SPRINKLER FINISH (8)
NATURAL
BRASS CHROME PLATED POLYESTER*** LEAD COATED WAX COATED WAX-OVER-LEAD COATED
2.8
1/2˝
NPT
UPRIGHT
(T Y1151)
and
PENDENT
(TY1251)
Figure 1
135°F (57°C) Orange
1, 2, 3 N/A
155°F (68°C) Red
175°F ( 79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve 1, 2
5.6
1/2˝
NPT
UPRIGHT
(TY3151)
and
PENDENT
(TY3251)
Figure 2
135°F (57°C) Orange
1, 2, 3, 4, 5, 6, 7 1, 2, 3, 5
1, 2, 3, 5 1, 2, 3, 5
155°F (68°C) Red
175°F ( 79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue 1**, 2**, 3**, 5** 1**, 2**, 3**, 5**
360°F (182°C) Mauve N/A
RECESSED
PENDENT
(TY3251)*
Figure 5
135°F (57°C) Orange
1, 2, 3, 4, 5 N/A
155°F (68°C) Red
175°F ( 79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue 1, 2
8.0
3/4˝
NPT
UPRIGHT
(TY4151)
and
PENDENT
(TY4251)
Figure 3
135°F (57°C) Orange
1, 2, 3, 4, 5, 6, 7 1, 2, 5
1, 2, 3, 5 1, 2, 5
155°F (68°C) Red
175°F ( 79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue 1**, 2**, 3**, 5** 1**, 2**, 5**
360°F (182°C) Mauve N/A
RECESSED
PENDENT
(TY4251)*
Figure 6
135°F (57°C) Orange
1, 2, 3, 4, 5 N/A
155°F (68°C) Red
175°F ( 79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue 1, 2
8.0
1/2˝
NPT
UPRIGHT
(TY4851)
and
PENDENT
(TY4951)
Figure 4
135°F (57°C) Orange
1, 2, 3, 4, 5, 6 N/A
155°F (68°C) Red
175°F ( 79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
Notes:
1. Listed by Underwriters Laboratories, Inc. (UL)
2. Listed by Underwriters Laboratories, Inc. for use in Canada (C-UL)
3. Approved by FM Global (FM Approvals)
4. Approved by the Loss Prevention Certication Board (LPCB Ref. No. 007k/03)
5. Approved by the City of New York under MEA 354-01-E
6. VdS Approved (For details contact Tyco Fire Suppression & Building Products, Enschede, Netherlands, Tel. [phone] / Fax [phone])
7. Approved by the Loss Prevention Certication Board (LPCB Ref. No. 094a/05)
8. Where Polyester Coated, Lead Coated, Wax Coated, and Wax-over-Lead Coated Sprinklers are noted to be UL and C-UL Listed, the sprinklers are UL and C-UL Listed as Corrosion-
Resistant Sprinklers. Where Lead Coated, Wax Coated, and Wax-over-Lead Coated Sprinklers are noted to be FM Approved, the sprinklers are FM Approved as Corrosion-Resistant
Sprinklers.
* Installed with Style 10 (1/2˝ NPT) or Style 40 (3/4˝ NPT) 3/4˝ Total Adjustment Recessed Escutcheon, as applicable
** 150°F (66°C) maximum ceiling temperature
*** Frame and deector only
N/A – Not Applicable
TABLE A
SERIES TY-B UPRIGHT AND PENDENT SPRINKLERS
LABORATORY LISTINGS AND APPROVALS

TFP151
Page 5 of 8
Technical
Data
Approvals
UL and C-UL Listed
FM Approved
LPCB Approved
VdS Approved
NYC Approved
(Refer to Table A for complete ap-
proval information, including corro-
sion-resis-tant status.)
Maximum Working Pressure
Refer to Table B.
Discharge Coefficient
K=2.8 gpm/psi1/2 (40,3 lpm/bar1/2)
K=5.6 gpm/psi1/2 (80,6 lpm/bar1/2)
K=8.0 gpm/psi1/2 (115,2 lp m /bar 1/2)
Temperature Ratings
Refer to Table A.
Finishes
Sprinkler: Refer to Table C.
Recessed Escutcheon: Signal or Pure
White, Jet Black, Chrome Plated, or
Natural Brass
Physical Characteristics
Frame ....................... Bronze
Button..................Brass/Copper
Sealing Assembly. . . . . . . Beryllium Nickel
w/TEFLON
Bulb ......................... Glass
Compression Screw. . . . . . . . . . . . Bronze
Deector. . . . . . . . . . . . . . . . . . . . . Copper
Bushing (K=2.8) . . . . . . . . . . . . . . . Bronze
Operation
The glass bulb contains a uid which
expands when exposed to heat. When
the rated temperature is reached, the
uid expands sufciently to shatter the
glass bulb, allowing the sprinkler to
activate and water to ow.
Design
Criteria
TYCO Series TY-B, 2.8, 5.6, and
8.0 K-factor, Upright and Pendent
Sprinklers are intended for re protec-
tion systems designed in accordance
with the standard installation rules
recognized by the applicable Listing
or Approval agency (e.g., UL Listing is
based on the requirements of NFPA
13, and FM Approval is based on the
requirements of the FM Global Loss
Prevention Data Sheets). Only the Style
10 or 40 Recessed Escutcheon, as
applicable, is to be used for recessed
pendent installations.
KTYPE
SPRINKLER FINISH
NATURAL
BRASS CHROME PLATED POLYESTER* LEAD COATED WAX COATED WAX-OVER-LEAD COATED
2.8
1/2˝
NPT
UPRIGHT (TY1151)
and
PENDENT (TY1251)
175 psi (12,1 bar) N/A
5.6
1/2˝
NPT
UPRIGHT (TY3151)
and
PENDENT (TY3251) 250 psi (17,2 bar) (a)
OR
175 psi (12,1 bar)
RECESSED PENDENT
(TY3251)
8.0
3/4˝
NPT
UPRIGHT (TY4151)
and
PENDENT (TY4251)
175 psi (12,1 bar)
RECESSED PENDENT
(TY4251) 175 psi (12,1 bar) N/A
8.0
1/2˝
NPT
UPRIGHT (TY4851)
and
PENDENT (TY4951)
175 psi (12,1 bar)
Notes:
a. The maximum working pressure of 250 psi (17,2 bar) only applies to the Listing by Underwriters Laboratories, Inc. (UL), the Listing by Underwriters Laboratories, Inc. for use in
Canada (C-UL), and the Approval by the City of New York.
* Frame and deector only
N/A – Not Applicable
TABLE B
SERIES TY-B UPRIGHT AND PENDENT SPRINKLERS
MAXIMUM WORKING PRESSURE

TFP151
Page 6 of 8
Installation
TYCO Series TY-B, 2.8, 5.6, and 8.0
K-factor, Upright and Pendent Sprin-
klers must be installed in accordance
with this section.
General Instructions
Do not install any bulb type sprinkler if
the bulb is cracked or there is a loss of
liquid from the bulb. With the sprinkler
held horizontally, a small air bubble
should be present. The diameter of the
air bubble is approximately 1/16 inch
(1,6 mm) for the 135°F (57°C) to 3/32
inch (2,4 mm) for the 360°F (182°C)
temperature ratings.
A leak-tight 1/2 inch NPT sprinkler
joint should be obtained by applying
a minimum-to-maximum torque of 7
to 14 ft.-lbs. (9,5 to 19,0 Nm). Obtain
a leak-tight 3/4 inch NPT sprinkler joint
by applying a minimum to maximum
torque of 10 to 20 ft.-lbs. (13,4 to 26,8
Nm). Higher levels of torque may distort
the sprinkler inlet and cause leakage or
impairment of the sprinkler.
Do not attempt to make-up for insuf-
cient adjustment in the escutcheon
plate by under- or over-tightening the
sprinkler. Readjust the position of the
sprinkler tting to suit.
2-7/8" DIA.
(73,0 mm)
2-1/4" DIA.
(57,2 mm)
MOUNTING
SURFACE
FACE OF
SPRINKLER
FITTING
5/8±1/4"
(15,9±6,4 mm)
MOUNTING
PLATE
1/8"
(3,2 mm)
SERIES
TY-B
CLOSURE
3/4" (19,1 mm)
1-1/4" (31,8 mm)
1/4" (6,4 mm)
3/4" (19,1 mm)
2-7/8" DIA.
(73,0 mm)
2-1/4" DIA.
(57,2 mm)
MOUNTING
SURFACE
CLOSURE
FACE OF
SPRINKLER
FITTING
5/8±1/4"
(15,9±6,4 mm)
MOUNTING
PLATE
1-5/16" (33,3 mm)
13/16" (20,6 mm)
1/8"
(3,2 mm)
3/4" (19,1 mm)
1/4" (6,4 mm)
SERIES
TY-B
WRENCH
RECESS
PUSH WRENCH
IN TO ENSURE
ENGAGEMENT
WITH SPRINKLER
WRENCHING AREA
WRENCH RECESS
(END "A" USED FOR
1/2" NPT MODELS)
WRENCH RECESS
(END "B" USED FOR
3/4" NPT MODELS)
FIGURE 7
W-TYPE 6
SPRINKLER WRENCH
FIGURE 5
SERIES TY-B RECESSED PENDENT SPRINKLER ASSEMBLY
WITH TWO-PIECE 3/4 INCH TOTAL ADJUSTMENT
STYLE 10 RECESSED ESCUTCHEON 5.6 K-FACTOR, 1/2 INCH NPT
FIGURE 6
SERIES TY-B RECESSED PENDENT SPRINKLER ASSEMBLY
WITH TWO-PIECE 3/4 INCH TOTAL ADJUSTMENT
STYLE 40 RECESSED ESCUTCHEON 8.0 K-FACTOR, 3/4 INCH NPT
FIGURE 8
W-TYPE 7 RECESSED
SPRINKLER WRENCH

TFP151
Page 7 of 8
Upright and Pendent Sprinklers
The Series TY-B Upright and Pendent
Sprinklers must be installed in accor-
dance with the following instructions:
Note: Install pendent sprinklers in the
pendent position; install upright sprin-
klers in the upright position.
Step 1. With pipe thread sealant applied
to the pipe threads, hand-tighten the
sprinkler into the sprinkler tting.
Step 2. Tighten the sprinkler into the
sprinkler tting using only the W-Type
6 Sprinkler Wrench (Figure 7). For
wax-coated sprinklers, use an 8 or 10
inch adjustable wrench. With reference
to Figures 1 through 4, the W-Type
7 Recessed Sprinkler Wrench or an
adjustable wrench, as applicable, is to
be applied to the sprinkler wrench ats.
When installing wax-coated sprinklers
with an adjustable wrench, exercise
care to prevent damage to the wax
coating on the sprinkler wrench ats
or frame arms and, consequently,
exposure of bare metal to the corrosive
environment. Open the jaws of the
wrench sufciently wide to pass over
the wrench ats without damaging the
wax coating. Before wrench tightening
the sprinkler, adjust the jaws of the
wrench to contact only the sprinkler
wrench ats. After wrench tightening the
sprinkler, loosen the wrench jaws before
removing the wrench.
After installation, inspect the sprinkler
wrench ats and frame arms and
retouch (repair) the wax coating when-
ever the coating has been damaged and
bare metal is exposed. Retouch the wax
coating on the wrench ats by gently
applying a heated 1/8 inch diameter
steel rod to the damaged areas of wax,
to smooth it back over areas where bare
metal is exposed.
NOTICE
Only retouching of the wax coating
applied to the wrench flats and frame
arms is permitted, and the retouching is
to be performed only at the time of the
initial sprinkler installation.
The steel rod should be heated only
to the point at which it can begin to
melt the wax, and appropriate precau-
tions need to be taken when handling
the heated rod in order to prevent the
installer from being burned.
Recessed Pendent Sprinklers
The Series TY-B Recessed Pendent
Sprinklers must be installed in accor-
dance with the following instructions:
Step A. After installing the Style 10
or 40 Mounting Plate, as applicable,
over the sprinkler threads and with
pipe thread sealant applied to the pipe
threads, hand-tighten the sprinkler into
the sprinkler tting.
Step B. Tighten the sprinkler into the
sprinkler tting using only the W-Type
7 Recessed Sprinkler Wrench (Figure
8). With reference to Figure 3 or 4, the
W-Type 7 Recessed Sprinkler Wrench
is to be applied to the sprinkler wrench
ats.
Step C. After the ceiling is installed or
the nish coat is applied, slide on the
Style 10 or 40 Closure over the Series
TY-B Sprinkler and push the Closure
over the Mounting Plate until its ange
contacts the ceiling.
Care and
Maintenance
TYCO Series TY-B, 2.8, 5.6, and 8.0
K-factor, Upright and Pendent Sprin-
klers must be maintained and serviced
in accordance with this section.
Before closing a re protection system
main control valve for maintenance
work on the re protection system that
it controls, obtain permission to shut
down the affected re protection system
from the proper authorities and notify all
personnel who may be affected by this
action.
The owner must assure that the
sprinklers are not used for hanging
any objects and that the sprinklers are
only cleaned by means of gently dust-
ing with a feather duster; otherwise,
non-operation in the event of a re or
inadvertent operation may result.
Absence of an escutcheon, which is
used to cover a clearance, may delay
the time to sprinkler operation in a re
situation.
Sprinklers which are found to be leaking
or exhibiting visible signs of corrosion
must be replaced.
Automatic sprinklers must never be
painted, plated, coated, or otherwise
altered after leaving the factory.
Modied sprinklers must be replaced.
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced
if they cannot be completely cleaned by
wiping the sprinkler with a cloth or by
brushing it with a soft bristle brush.
Care must be exercised to avoid dam-
age to the sprinklers before, during, and
after installation. Sprinklers damaged
by dropping, striking, wrench twist/
slippage, or the like, must be replaced.
Also, replace any sprinkler that has a
cracked bulb or that has lost liquid from
its bulb. (Refer to Installation Section.)
The owner is responsible for the inspec-
tion, testing, and maintenance of their
re protection system and devices in
compliance with this document, as
well as with the applicable standards
of the National Fire Protection Asso-
ciation (e.g., NFPA 25), in addition to
the standards of any other authorities
having jurisdiction. Contact the installing
contractor or product manufacturer with
any questions.
Automatic sprinklers are recommended
to be inspected, tested, and maintained
by a qualied Inspection Service in
accordance with local requirements
and/or national codes.

GLOBAL HEADQUARTERS | 1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone [phone]
TFP151
Page 8 of 8
Copyright © 2014 Tyco Fire Products, LP. All rights reserved.
TEFLON is trademark of the DuPont Corporation.
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-re.com.
Ordering
Procedure
Contact your local distributor for
availability. When placing an order,
indicate the full product name and Part
Number (P/N).
Sprinkler Assemblies with
NPT Thread Connections
Specify: Series TY-B (specify SIN),
(specify K-factor), (specify Upright
or Pendent) Sprinkler with (specify)
temperature rating, (specify) nish or
coating, P/N (Refer to Table C)
Recessed Escutcheon
Specify: Style (10 or 40) Recessed
Escutcheon with (specify) nish, P/N*
* Refer to Technical Data Sheet TFP770
Sprinkler Wrenches
Specify: W-Type 6 Sprinkler Wrench,
P/N 56-000-6-387
Specify: W-Type 7 Sprinkler Wrench,
P/N 56-850-4-001
Wax Sticks
(for retouching wrench-damaged
wax coating)
Specify: (specify color, below) Colored
Coded Wax Stick for retouching (specify
temperature rating) temperature-rated
Series TY-B Sprinklers, P/N (specify)
Black for 135°F (57°C) ......P/N 56-065-1-135
Red for 155°F (68°C) .......P/N 56 -065-1-155
Yellow for 175°F (79°C) .....P/N 56-065-1-175
Blue for 200°F (93°C)
and 286°F (141°C) .........P/N 56-065-1-286
Note: Each wax stick is suitable for
retouching up to 25 sprinklers.
Note: The wax used for 286°F (141°C)
sprinklers is the same as for 200°F (93°C)
sprinklers, and, therefore, the 286°F (141°C)
sprinkler is limited to the same maximum
ceiling temperature as the 200°F (93°C)
sprinkler (i.e., 150°F [66°C]).
P/N 57 – XXX – X – XXX
TEMPERATURE
RATING
135 135°F (57°C)
155 155°F (68°C)
175 175°F (79°C)
200 200°F (93°C)
286 286°F (141°C)
360 360°F (182°C)
000 OPEN***
SPRINKLER
FINISH
1NATURAL BRASS
3PURE WHITE (RAL9010) *
POLYESTER
4SIGNAL WHITE (RAL9003)
POLYESTER
5JET BLACK (RAL9005) **
POLYESTER
6WA X COATED
286°F (141°C) MAX
7LEAD COATED
8WAX-OVER-LEAD
286°F (141°C) MAX
9CHROME PLATED
SIN
530 2.8K UPRIGHT (1/2˝ NPT) TY1151
531 2.8K PENDENT (1/2˝ NPT) TY1251
570 5.6K UPRIGHT (1/2˝ NPT) TY3151
571 5.6K PENDENT (1/2˝ NPT) TY3251
590 8.0K UPRIGHT (3/4˝ NPT) TY4151
591 8.0K PENDENT (3/4˝ NPT) T Y42 51
560 8.0K UPRIGHT (1/2˝ NPT) T Y48 51
561 8.0K PENDENT (1/2˝ NPT) T Y4951
Notes:
* Eastern Hemisphere sales only
** Available in only 8.0K, 155°F (68°C) or 200°F (93°C);
requires lead time to manufacture
*** Available only for 8.0 K-factor TY4151 and
TY4251 for use in deluge systems (“OPEN”
indicates sprinkler assembly without glass bulb,
button, and sealing assembly)
TABLE C
SERIES TY-B UPRIGHT AND PENDENT SPRINKLERS
PART NUMBER SELECTION
