TYCO Series DS-2 Dry-Type Sprinklers,
11.2K Pendent, Standard (5 mm Bulb)
and Quick Response (3 mm Bulb)
and Standard Coverage, are decora-
tive glass bulb automatic sprinklers
typically used where:
• pendent sprinklers are required on
dry pipe systems that are exposed to
freezing temperatures; for example,
sprinkler drops from unheated
portions of buildings
• sprinklers and/or a portion of the
connecting piping may be exposed to
freezing temperatures; for example,
sprinkler drops from wet systems into
freezers
NOTICE
Series DS-2 Dry-Type Sprinklers
described herein must be installed
and maintained in compliance with this
document, as well as with the appli-
cable standards of the National Fire
Protection Association, in addition to
the standards of any other Authorities
Having Jurisdiction. Failure to do so
may impair the performance of these
devices.
Owners are responsible for maintaining
their fire protection system and devices
in proper operating condition. The
installing contractor or sprinkler manu-
facturer should be contacted with any
questions.
Series DS-2 Dry-Type Sprinklers must
only be installed in fittings that meet
the requirements of the Design Criteria
section.
Model/Sprinkler
Identification
Numbers (SINs)
TY5255 - Standard Response
TY5235 - Quick Response
Technical
Data
Approvals
UL and C-UL Listed
NYC Approved under MEA 173-02-E
Refer to Table A.
Maximum Working Pressure
175 psi (12,1 bar)
Inlet Thread Connections
1-inch NPT (Standard Order)
ISO 7-R1
Discharge Coefficient
Refer to Table B.
Temperature Ratings
Refer to Table A.
Finishes
Sprinkler: Natural Brass, Chrome
Plated, White Polyester
Escutcheon: White Coated or Chrome
Plated, Brass Plated
IMPORTANT
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cautions
with respect to handling and instal-
lation of sprinkler systems and
components. Improper handling and
installation can permanently damage
a sprinkler system or its compo-
nents and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.
Physical Characteristics
Inlet.....................Copper
Plug ....................Copper
Yoke . . . . . . . . . . . . . . Stainless Steel
Casing . . . . . . . . . . . . . . . Galvanized
Carbon Steel
Insert ................... Bronze
Bulb Seat . . . . . . . . . . . . . . . . Bronze
Bulb ......................Glass
Compression Screw . . . . . . . Bronze
Deector................. Bronze
Frame................... Bronze
Guide Tube . . . . . . . . . Stainless Steel
Water Tube . . . . . . . . . Stainless Steel
Spring . . . . . . . . . . . . . Stainless Steel
Gasketed Spring
Plate Seal . . . . . . . . . Beryllium Nickel
w/Teon*
Pin . . . . . . . . . . . . . . . Stainless Steel
Button Spring . . . . . . . Stainless Steel
Escutcheon . . . . . . . . . .Carbon Steel
*DuPont Registered Trademark
*Refer to Table B for info on discharge coefcients.
Series DS-2 Dry-Type Sprinklers
11.2K* Pendent
Standard and Quick Response, Standard Coverage
Page 1 of 8 MAY 2011 TFP530
Technical Services 800-381-9312 | [phone]
www.tyco-fire.com

COMPRESSION
SCREW
FRAME
INSERT
PLUG WITH
GASKETED SPRING
PLATE SEAL
WATER TUBE
SPRING
CASING
BULB
SEAT
DEFLECTOR
3 or 5 mm
BULB
GUIDE
TUBE
PLUG
SPRING
PIN
INLET
YOKE
VENT HOLE
INLET BAND
Temperature
Rating
Bulb
Color Code
TY5255
Standard Response
TY5235
Quick Response
with Flush Escutcheon
(Figure 2)
with Extended Escutcheon
(Figure 4)
without Escutcheon
(Figure 5)
TY5255
Standard Response
TY5235
Quick Response
with Recessed Escutcheon
(Figure 3)
SPRINKLER FINISH
Natural Brass Chromed
Plate
White
Polyester Natural Brass Chromed Plate
White
Polyester
135°F (57°C) Orange
1, 2, 3
1, 2, 3
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green N/A
286°F (141°C) Blue
Notes
1. Listed by Underwriters Laboratories, Inc. (maximum order length of 48 inches)
2. Listed by Underwriters Laboratories for use in Canada (maximum order length of 48 inches)
3. Approved by the City of New York under MEA 173-02-E
TABLE A
SERIES DS-2 STANDARD RESPONSE DRY-TYPE PENDENT SPRINKLERS
— LABORATORY LISTINGS AND APPROVALS —
Operation
When TYCO Series DS-2 Dry-Type
Sprinklers are in service, water is
prevented from entering the assembly
by the Plug with Gasketed Spring
Plate Seal (Figure 1) in the Inlet of the
Sprinkler.
The glass bulb contains a uid that
expands when exposed to heat. When
the rated temperature is reached, the
uid expands sufciently to shatter
the glass bulb, and the Bulb Seat is
released.
The compressed Spring is then able
to expand and push the Water Tube as
well as the Guide Tube outward. This
action simultaneously pulls inward on
the Yoke, withdrawing the Plug with
Gasketed Spring Plate Seal from the
Inlet, allowing the sprinkler to activate
and ow water.
FIGURE 1
SERIES DS-2 STANDARD RESPONSE DRY-TYPE PENDENT SPRINKLER
— ASSEMBLY —
TFP530
Page 2 of 8

K-Factor
LENGTH,
Inches (mm)
K-Factor,
GPM/psi1/2
(LPM/bar1/2)
2-1/2 to 6-1/4
(63 mm to 159 mm)
11.2
(161,3)
6-1/2 to 10-1/2
(165 mm to 267 mm)
11.1
(159,8)
10-3/4 to 14-3/4
(273 mm to 375 mm)
11.0
(158,4)
15 to 18-3/4
(381 mm to 476 mm)
10.9
(157,0)
19 to 23
(483 mm to 584 mm)
10.8
(155,5)
23-1/4 to 26-3/4
(591 mm to 679 mm)
10.7
(154,1)
27-1/4 to 31-1/4
(692 mm to 794 mm)
10.6
(152,6)
31-1/2 to 35-1/4
(800 mm to 895 mm)
10.5
(151,2)
35-1/2 to 39-1/2
(902 mm to 1003 mm)
10.4
(149,8)
39-3/4 to 43-1/2
(1010 mm to 1105 mm)
10.3
(148,3)
43-3/4 to 48
(1111 mm to 1219 mm)
10.2
(146,9)
TABLE B
— DISCHARGE COEFFICIENTS —
2-1/4±1/8"
(57,2±3,2 mm)
ORDER LENGTHS:
3" to 48"
(76,2 to 1219,2 mm)
IN 1/4" (6,4 mm)
INCREMENTS
**ESCUTCHEON
WILL PERMIT
±1/4" (6,4 mm)
ADJUSTMENT
FACE OF
SPRINKLER
FITTING
FACE OF
CEILING
2-3/4" DIA.
(69,9 mm)
3-5/8" DIA.
(92,1 mm)
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
FIGURE 2
SERIES DS-2 DRY-TYPE PENDENT WITH FLUSH ESCUTCHEON
STANDARD RESPONSE (TY5255) OR QUICK RESPONSE (TY5235)
1-5/8±1/8"
(41,3±3,2 mm)
ESCUTCHEON
WILL PERMIT
±3/8" (9,5 mm)
ADJUSTMENT
ORDER LENGTHS:
3-1/2" to 48"
(88,9 to 1219,2 mm)
IN 1/4" (6,4 mm)
INCREMENTS
**
FACE OF
SPRINKLER
FITTING
FACE OF
CEILING
2-3/4" DIA.
(69,9 mm)
3-5/8" DIA.
(92,1 mm)
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
FIGURE 3
SERIES DS-2 DRY-TYPE PENDENT WITH RECESSED ESCUTCHEON
STANDARD RESPONSE (TY5255) OR QUICK RESPONSE (TY5235)
Notes
K-Factor Length is determined as follows:
• Flush: Order Length from Figure 2 plus 1/2
inch (12,7 mm)
• Recessed: Order Length from Figure 3 plus
1/4 inch (6,3 mm).
• Extended: Order Length from Figure 4 plus
3-1/4 inch (82,6 mm)
• Without Escutcheon: Order Length from
Figure 5 minus 2-1/4 inches (57,2 mm)
TFP530
Page 3 of 8

DO NOT
WRENCH
RECESS
PUSH WRENCH
IN TO ENSURE
ENGAGEMENT
WITH SPRINKLER
WRENCHING AREA
SPRINKLER
WRENCHING
AREA
FIGURE 6
W-TYPE 17
SPRINKLER WRENCH
FIGURE 7
DO NOT GRASP DEFLECTOR
ESCUTCHEON
WILL PERMIT
±1-3/8" (34,9 mm)
ADJUSTMENT
ESCUTCHEON
WILL PERMIT
±5/8" (15,9 mm)
ADJUSTMENT
FACE OF
SPRINKLER
FITTING
FACE OF
CEILING
FOR ORDER LENGTHS
< 3-1/4" (82,6 mm):
4-7/8±1/8" (123,8±3,2 mm)
-or-
FOR ORDER LENGTHS
> 3-1/4" (82,6 mm):
5-5/8±1/8" (142,9±3,2 mm)
2-3/4" DIA.
(69,9 mm)
*
**
3-5/8" DIA.
(92,1 mm)
*
**
ORDER LENGTHS:
1" to 45-1/4"
(25,4 to 1149,4 mm)
IN 1/4" (6,4 mm)
INCREMENTS
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
FIGURE 4
SERIES DS-2 DRY-TYPE PENDENT WITH EXTENDED ESCUTCHEON
STANDARD RESPONSE (TY5255) OR QUICK RESPONSE (TY5235)
ORDER LENGTHS:
5" to 48"
(127,0 to 1219,2 mm)
IN 1/4" (6,4 mm)
INCREMENTS
MINIMUM
2-1/4" (57,2 mm)
DEFLECTOR
TO CEILING
FACE OF
SPRINKLER
FITTING
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
FIGURE 5
SERIES DS-2 DRY-TYPE PENDENT WITHOUT ESCUTCHEON
STANDARD RESPONSE (TY5255) OR QUICK RESPONSE (TY5235)
TFP530
Page 4 of 8

Ambient Temperature
Exposed to Discharge End
of Sprinkler
Temperatures for Heated Area1
40°F (4°C) 50°F (10°C) 60°F (16°C)
Minimum Exposed Barrel Length, Inches (mm)2
40°F (4°C) 0 0 0
30°F (-1°C) 0 0 0
20°F (-7°C) 4 (100) 0 0
10°F (-12°C) 8 (200) 1 (25) 0
0°F (-18°C) 12 (305) 3 (75) 0
-10°F (-23°C) 14 (355) 4 (100) 1 (25)
-20°F (-29°C) 14 (355) 6 (150) 3 (75)
-30°F (-34°C) 16 (405) 8 (200) 4 (100)
-40°F (-40°C) 18 (455) 8 (200) 4 (100)
-50°F (-46°C) 20 (510) 10 (255) 6 (150)
-60°F (-51°C) 20 (510) 10 (255) 6 (150)
Notes
1. For protected area temperatures that occur between values listed above, use the next cooler temperature.
2. These lengths are inclusive of wind velocities up to 30 mph (18,6 kph).
TABLE C
EXPOSED SPRINKLER BARRELS IN WET PIPE SYSTEMS
— MINIMUM RECOMMENDED LENGTHS —
The conguration shown in Figure 8 is
only applicable for wet pipe systems
where the sprinkler tting and water-
lled pipe above the sprinkler tting are
not subject to freezing and where the
length of the Dry-Type Sprinkler has the
minimum exposure length depicted in
Figure 10. Refer to the Exposure Length
section.
For wet pipe system installations of
1-inch NPT Series DS-2 Dry-Type
Sprinklers connected to CPVC piping,
use only the following TYCO CPVC
ttings:
• 1” x 1” NPT Female Adapter (P/N
80145)
• 1” x 1” x 1” NPT Sprinkler Head
Adapter Tee (P/N 80249).
For dry pipe system installations, use
only the side outlet of maximum 2-1/2-
inch reducing tee when locating Series
DS-2 Dry-Type Sprinklers directly
below the branch line. Otherwise, use
the conguration shown in Figure 9 to
assure complete water drainage from
above Series DS-2 Dry-Type Sprinklers
and the branch line. Failure to do so
may result in pipe freezing and water
damage.
NOTICE
Do not install Series DS-2 Dry-Type
Sprinkler into any other type fitting
without first consulting the Technical
Services Department. Failure to use the
appropriate fitting may result in one of
the following:
• Failure of the sprinkler to operate prop-
erly due to formation of ice over the
Inlet Plug or binding of the Inlet Plug.
• Insufficient engagement of the Inlet
pipe-threads with consequent leakage.
Drainage
In accordance with the minimum
requirements of the National Fire
Protection Association for dry pipe
sprinkler systems, branch, cross, and
feed-main piping connected to Dry
Sprinklers and subject to freezing
temperatures must be pitched for
proper drainage.
Exposure Length
When using Dry Sprinklers in wet pipe
sprinkler systems to protect areas
subject to freezing temperatures, use
Table C to determine a sprinkler’s
appropriate exposed barrel length
to prevent water from freezing in the
connecting pipes due to conduction.
The exposed barrel length measure-
ment must be taken from the face of
the sprinkler tting to the surface of the
structure or insulation that is exposed
to the heated area. Refer to Figure 10
for an example.
Design
Criteria
TYCO Series DS-2 Dry-Type Sprinklers
are intended for use in re sprinkler
systems designed in accordance with
the standard coverage installation rules
recognized by the applicable Listing
agency; for example, UL Listing is
based on NFPA 13 requirements.
Sprinkler Fittings
Install 1-inch NPT Series DS-2 Dry-Type
Sprinklers in the 1-inch NPT outlet or
run of the following ttings:
• malleable or ductile iron threaded
tee ttings that meet the dimen-
sional requirements of ANSI B16.3
(Class 150)
• cast iron threaded tee ttings that
meet the dimensional requirements
of ANSI B16.4 (Class 125).
Do not install Series DS-2 Dry-Type
Sprinklers into elbow ttings. The Inlet
of the sprinkler can contact the interior
of the elbow.
The unused outlet of the threaded tee is
plugged as shown in Figure 9.
You can also install Series DS-2
Dry-Type Sprinklers in the 1-inch NPT
outlet of a GRINNELL Figure 730
Mechanical Tee. However, the use of
the Figure 730 Tee for this arrangement
is limited to wet pipe systems.
TFP530
Page 5 of 8

INSULATED
FREEZER
STRUCTURE
(ENDS ON
OPPOSING
SIDES OF
STRAP TIES
BOOT)
ADHESIVE
SHOWN
WITH FLUSH
ESCUTCHEON
DS-2
2-3/4" DIA.
(69,9 mm)
CLEARANCE
HOLE
DSB-2 BOOT
AREA
SUBJECT
TO
FREEZING
RUN
OUTLET
PLUGGED
TO DRY
SYSTEM
DSB-2
BOOT
FITTING
(SEE DESIGN
CRITERIA
SECTION)
SPRINKLER
HEATED
AREA (SEE DESIGN
CRITERIA
SECTION)
FACE OF
SPRINKLER
FITTING
LENGTH
EXPOSURE
DSB-2
BOOT
SIDE
OUTLET
PLUGGED
TO WET
SYSTEM
FITTING
(SEE DESIGN
CRITERIA
SECTION)
SPRINKLER
DSB-2
BOOT
HEATED
AREA
FIGURE 8
SPRINKLER FITTING
— HEATED AREA —
FIGURE 9
SPRINKLER FITTING
— UNHEATED AREA —
FIGURE 10
— EXPOSURE LENGTH —
FIGURE 11
MODEL DSB-2 DRY SPRINKLER
BOOT WITH SERIES DS-2
DRY-TYPE PENDENT SPRINKLER
For protected area temperatures
between those given above, the
minimum recommended length from
the face of the tting to the outside of
the protected area may be determined
by interpolating between the indicated
values.
Clearance Space
In accordance with Section 8.4.9.2
of the 2010 edition of NFPA 13, when
connecting an area subject to freezing
and an area containing a wet pipe
sprinkler system, the clearance space
around the sprinkler barrel of Dry-Type
Sprinklers must be sealed. Due to
temperature differences between two
areas, the potential for the formation
of condensation in the sprinkler and
subsequent ice build-up is increased. If
this condensation is not controlled, ice
build-up can occur that might damage
the dry-type sprinkler and/or prevent
proper operation in a re situation.
Use of the Model DSB-2 Dry Sprinkler
Boot, described in technical data sheet
TFP591 and shown in Figure 11, can
provide the recommended seal.
Installation
Series DS-2 Dry-Type Sprinklers must
be installed in accordance with the
following instructions.
NOTICE
Series DS-2 Dry-Type Sprinklers must
only be installed in fittings that meet
the requirements of the Design Criteria
section. Refer to the Design Criteria
section for other important require-
ments regarding piping design and
sealing of the clearance space around
the Sprinkler Casing. With reference
to Figure 7, do not grasp the sprinkler
by the deflector. Failure to follow this
instruction may impair performance of
the device.
Do not install any bulb-type sprinkler if
the bulb is cracked or there is a loss of
liquid from the bulb. With the sprinkler
held horizontally, a small air bubble
should be present. The diameter of the
air bubble is approximately 1/16 inch
(1,6 mm) for the 135°F (57°C) rating to
1/8 inch (3,2 mm) for the 360°F (182°C)
rating.
Obtain a leak-tight 1-inch NPT sprinkler
joint by applying a minimum-to-
maximum torque of 20 to 30 ft. lbs.
(26,8 to 40,2 Nm). Higher levels of
torque may distort the sprinkler Inlet
with consequent leakage or impairment
of the sprinkler.
Do not attempt to compensate
for insufcient adjustment in an
Escutcheon Plate by under or over-
tightening the Sprinkler. Re-adjust the
position of the sprinkler tting to suit.
1. Install pendent sprinklers only in the
pendent position. The deector of a
pendent sprinkler must be parallel
to the ceiling.
2. With a non-hardening pipe-thread
sealant such as Teon*applied to
the Inlet threads, hand-tighten the
sprinkler into the sprinkler tting.
Do not grasp the sprinkler by the
deflector (Figure 7).
3. Wrench-tighten the sprinkler using
either:
• a pipe wrench on the Inlet Band or
the Casing (Figure 1).
• the W-Type 17 Sprinkler Wrench
on the Wrench Flat (Figure 2).
Apply the Wrench Recess of the
W-Type 17 Sprinkler Wrench to the
Wrench Flat.
*DuPont Registered Trademark
TFP530
Page 6 of 8

Note: If sprinkler removal becomes
necessary, remove the sprinkler
using the same wrenching method
noted above. Sprinkler removal
is easier when a non-hardening
sealant was used and torque guide-
lines were followed. After removal,
inspect the sprinkler for damage.
4. After installing the ceiling and
applying a ceiling nish, slide on the
outer piece of the Escutcheon until
it comes in contact with the ceiling.
Do not lift the ceiling panel out of its
normal position.
When using the Deep Escutcheon,
hold the outer piece in contact with
the mounting surface (ceiling or
wall). Then rotate the inner piece
approximately 1/4 turn with respect
to the outer piece, to hold the Deep
Escutcheon rmly together.
Care and
Maintenance
TYCO Series DS-2 Dry-Type Sprinklers
must be maintained and serviced
in accordance with the following
instructions.
NOTICE
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system
that it controls, obtain permission to
shut down the affected fire protection
systems from the proper authorities
and notify all personnel who may be
affected by this action.
Absence of the outer piece of an
escutcheon, which is used to cover a
clearance hole, may delay the time to
sprinkler operation in a re situation.
A Vent Hole is provided in the Bulb Seat
(Figure 1) to indicate if the Dry Sprinkler
is remaining dry. Evidence of leakage
from the Vent Hole indicates potential
leakage past the Inlet seal and the need
to remove the sprinkler to determine
the cause of leakage; for example, an
improper installation or an ice plug.
Close the re protection system control
valve and drain the system before
removing the sprinkler.
Exercise care to avoid damage before,
during, and after installation. Never
paint, plate, coat, or otherwise alter
automatic sprinklers after they leave
the factory.
Never repaint factory-painted Cover
Plates. When necessary, replace
cover plates with factory-painted
units. Non-factory applied paint can
adversely delay or prevent sprinkler
operation in the event of a re.
Replace sprinklers that:
•were damaged by dropping, striking,
wrench twisting, wrench slippage, or
the like.
•were modied or over-heated.
• have cracked bulbs or have lost liquid
from the bulbs. Refer to the Installation
Section in this data sheet.
•are leaking or exhibiting visible signs
of corrosion.
Responsibility lies with owners for the
inspection, testing, and maintenance of
their re protection system and devices
in compliance with this document, as
well as with the applicable standards of
the National Fire Protection Association
(for example, NFPA 25), in addition to
the standards of any other Authorities
Having Jurisdiction. The installing
contractor or sprinkler manufacturer
should be contacted relative to any
questions.
Automatic sprinkler systems are recom-
mended to be inspected, tested, and
maintained by a qualied Inspection
Service in accordance with local
requirements and/or national codes.
Limited
Warranty
Products manufactured by Tyco Fire
Suppression and Building Products
(TFSBP) are warranted solely to the
original Buyer against defects in
material and workmanship when paid
for and properly installed and main-
tained under normal use and service.
This warranty will expire twelve (12)
months from installation or eighteen
(18) months from delivery, whichever
occurs rst. No warranty is given for
products or components manufac-
tured by companies not afliated by
ownership with TFSBP or for products
and components which have been
subject to misuse, improper instal-
lation, corrosion, or which have not
been installed, maintained, modied
or repaired in accordance with appli-
cable Standards of the National Fire
Protection Association, and/or the
standards of any other Authorities
Having Jurisdiction. Materials found by
TFSBP to be defective shall be either
repaired or replaced, at TFSBP’s sole
option. TFSBP neither assumes, nor
authorizes any person to assume for
it, any other obligation in connection
with the sale of products or parts of
products. TFSBP shall not be respon-
sible for sprinkler system design errors
or inaccurate or incomplete infor-
mation supplied by Buyer or Buyer’s
representatives.
In no event shall TFSBP be liable, in
contract, tort, strict liability or under
any other legal theory, for incidental,
indirect, special or consequential
damages, including but not limited to
labor charges, regardless of whether
TFSBP was informed about the possi-
bility of such damages, and in no
event shall TFSBP’s liability exceed an
amount equal to the sales price.
The foregoing warranty is made in lieu
of any and all other warranties, express
or implied, including warranties of
merchantability and tness for a partic-
ular purpose.
This limited warranty sets forth the
exclusive remedy for claims based
on failure of or defect in products,
materials or components, whether the
claim is made in contract, tort, strict
liability or any other legal theory.
This warranty will apply to the full
extent permitted by law. The invalidity,
in whole or part, of any portion of this
warranty will not affect the remainder.
TFP530
Page 7 of 8

P/N*61 – XXX – X – XXX
Notes
* Use Prex “I” for ISO 7-R1 Connection; for example, I-61-101-1-180.
1. Escutcheon Finish applies to sprinklers with escutcheons.
2. Dry-Type Sprinklers are furnished based upon “Order Length” as measured
per Figures 2 through 5, as applicable, and for each individual sprinkler
where it is to be installed. After the measurement is taken, round it to the
nearest 1/4 inch increment.
3. 286°F (141°C) temperature rating applies to non-recessed sprinkler
assemblies.
MODEL/SIN
10 Standard Response Pendent
with Flush Escutcheon
TY5255
(Figure 2)
11 Standard Response Pendent
with Recessed Escutcheon
TY5255
(Figure 3)
12 Standard Response Pendent
with Extended Escutcheon
TY5255
(Figure 4)
13 Standard Response Pendent
without Flush Escutcheon
TY5255
(Figure 5)
30 Quick Response Pendent
with Flush Escutcheon
TY5235
(Figure 2)
31 Quick Response Pendent
with Recessed Escutcheon
TY5235
(Figure 3)
32 Quick Response Pendent
with Extended Escutcheon
TY5235
(Figure 4)
35 Quick Response Pendent
without Flush Escutcheon
TY5235
(Figure 5)
SPRINKLER
FINISH
ESCUTCHEON
FINISH (1)
1 NATURAL BRASS WHITE
4 WHITE POLYESTER WHITE
9 CHROME PLATED CHROME
0 CHROME PLATED WHITE
5 NATURAL BRASS BRASS PLATED
TABLE D
SERIES DS-2 STANDARD AND QUICK RESPONSE, STANDARD COVERAGE, DRY-TYPE SPRINKLERS
— PART NUMBER SELECTION —
ORDER
LENGTH (2)
055 5.50”
082 8.25”
180 18.00”
187 18.75”
372 37.25”
480 48.00”
TEMPERATURE
RATING (3)
0 135°F (57°C)
1 155°F (68°C)
2 175°F (79°C)
3 200°F (93°C)
4 286°F (141°C)
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name, including
description and Part Number (P/N).
Dry Sprinklers
When ordering 11.2 K-Factor Series
DS-2 Dry-Type Sprinklers, specify the
following information:
• Model/SIN
Standard Response (TY5255) or
Quick Response (TY5235), Standard
Coverage, Dry-Type Pendent
Sprinkler
• Order Length
Dry-Type Sprinklers are furnished
based upon Order Length as
measured from the face of the wall to
the face of the sprinkler tting (Figure
2 through 5). After the measurement
is taken, round it to the nearest 1/4
inch increment.
• Inlet Connectionss
1-inch NPT or ISO 7-R1
• Temperature Rating
• Sprinkler Finish
• Escutcheon Type
• Part Number from Table D
Sprinkler Wrench
Specify W-Type 17 Sprinkler Wrench,
P/N 56-010-4-118.
Sprinkler Boot
Specify Model DSB-2 Dry Sprinkler
Boot, P/N 63-000-0-002. This Part
Number includes one Boot, two Strap
Ties, and 1/3 oz. of Adhesive (quantity
of adhesive is sufcient for installing
one Boot).
Copyright © 2007, 2011 Tyco Fire Suppression & Building Products. All rights reserved.
TFP530
Page 8 of 8
