0 513 I H -112 8PAGE 1 OF 2
LEGS AND FRAME ASSEMBLY
1. Insert adjustable feet (1) into legs (2) and slide into
place at desired height.
NOTE: If desired, insert locking tabs through
legs and adjustable feet to lock feet into place.
2. Place legs (2) in upright position. Legs should be
placed approximately 41" apart for 48" units, 53"
apart for 60" units and 65" apart for 72" units.
3. Attach stringer (3) to table legs using center 4 holes
in back legs. Fasten with 8 bolts, washers and nuts.
4. Place lower shelf (4) across braces of legs. Attach
lower shelf using 4 nuts and bolts.
5. To attach tabletop (5) to frame assembly, place
tabletop on a smooth, non-marring surface with top
side facing down.
6. Rotate the assembled frame upside down and line
up with the pre-drilled holes on the bottom side of
the top.
ASSEMBLY
#DESCRIPTION QTY
1 Adjustable Feet 4
2Legs 2
3Stringer 1
4Lower Shelf 1
5Tabletop 1
¼" - 20 x ⁄" Bolts 12
¼" - 20 Nuts 12
Lock Washers 12
#14 - ¾" Wood Screws 16
Locking Tabs 4
3
1
2
4
5
PACKING TABLES
1-800-295-5510
uline.com
πH -112 8, H -113 5
H -113 6, H -1137
H-1138, H-3657
0 513 I H -112 8PAGE 2 OF 2
NON-STEEL TOP ASSEMBLY
(Composite Wood, Laminate, Maple, Stainless Steel, ESD)
1. Using 16 wood screws, attach legs to the under side
of the top (5) through pre-drilled holes. (See Figure 1)
2. Set bench assembly upright and recheck all nuts,
bolts and screws for tightness.
STEEL TOP ASSEMBLY
1. Insert top end channel in each end of tabletop.
(See Figure 2)
2. Align tabletop, leg and channel holes. Secure with
4 bolts. 4 weld nuts are provided on each channel.
(See Figure 3)
NOTE: There are 2 extra top end channels
provided, for a total of 4, for installing an
optional pedestal or drawer.
3. Secure leg to top using bolts and nuts inserted in
second hole from each corner.
NOTE: Holes run along front-facing 2 holes and
back-facing 2 holes.
4. Set bench assembly upright and recheck all nuts,
bolts and screws for tightness.
ASSEMBLY CONTINUED
Figure 1
OPEN
END
OF
BRACKET
FACES
INTO
THE
TOP
.
Figure 2
Figure 3
π CHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
Hardware Pack Includes:
DESCRIPTION QTY
¼" x #20 x 5⁄8"Bolts 30
¼" x #20 Nuts 22
Lock Washers 22
