U-Line BILLBOARD H-8725 User manual

PAGE 1 OF 3 0522 IH-9725
H-9725
BILLBOARD™ PLASTIC
A-FRAME SIGN
1- 800-295-5510
uline.com
INSTRUCTIONS
MAIN SIGN INSERTION
1. Slide sign down through tabs until it rests on ground.
(See Figures 1-2)
Figure 1
Tabs
Figure 2
2. Push sign up into top slot. (See Figure 3)
Figure 3
3. Slide sign down into bottom slot. (See Figure 4)
Figure 4
Slot
Slot

PAGE 2 OF 3 0522 IH-9725
TOP RIDER SIGN INSERTION
NOTE: Insert top rider sign before inserting
side signs.
1. Stand frame on ground, spreading sign faces open
halfway.
2. Place rider sign in opening at top between sign
faces. Move sign faces apart until fully extended.
(See Figure 5)
Rider Sign
Figure 5
Opening
NOTE: It is recommended to cut a hole in rider
sign to make handle accessible.
SIDE SIGN INSERTION
NOTE: If using corrugated plastic sheet for side
signs, cut so flutes run horizontal.
1. Lay frame flat on ground. Lift up top sign face.
(See Figure 6)
Figure 6
Channels
2. Slide first side sign into top and bottom channels on
one side of frame. (See Figure 7)
Side
Sign
Figure 7
3. Slide second side sign into top and bottom
channels on opposite side of frame. (See Figure 8)
Side
Sign
Figure 8
INSTRUCTIONS CONTINUED

PAGE 3 OF 3 0522 IH-9725
INSTRUCTIONS CONTINUED
STABILIZING THE SIGN
STABILIZING BAR
NOTE: Use the stabilizing bar to prevent sign
faces from spreading too far apart.
1. Insert stabilizing bar into hole on bottom of each
sign face. (See Figures 9-10)
Holes
Figure 9
Figure 10 Stabilizing Bar
2. Lift up sign frame by handle to stand upright.
(See Figure 11)
F i g u re 11
Bar in use
SAND BALLASTING
NOTE: Each sign face has a hole on the side for
filling the sign frame with sand.
1. Remove plug from hole. (See Figure 12)
Figure 12
Sand Fill
Holes
Plug
2. Fill with sand and replace plug. Repeat for second
sign face.
3. Shake the sign frame to evenly distribute sand to
bottom of frame.
NOTE: 5 lbs. of sand per hole is recommended,
for a total of 10 lbs.
NOTE: Play sand is recommended for ease
of filling.
1
-800-295-551
0
uline.com
Side View
