U-Line H-1799 User manual

PAGE 1 OF 4 1115 IH-1799
πH-1799, H-5527
SHOP DESK
1-800-295-5510
uline.com
PARTS
TOOLS NEEDED
Phillips Screwdriver
10 mm Wrench
7 mm Wrench
Small Bolt x 4
Large Bolt x 44
Adjustable Foot x 4
Desk Top x 1
Drawer x 1
Small Nut x 4
Large Nut x 44
Leg x 4
Top Shelf x 1
Bottom Shelf x 1
Small Washer x 4
Drawer Lock x 1
Drawer Track x 2
Small Lock Washer x 4
Plastic Cable Ring and Cover x1

PAGE 2 OF 4 1115 IH-1799
LEG ASSEMBLY
1. Place desk top on a smooth, non-marring surface
with top side facing down.
2. Attach legs using 4 large bolts and 4 large nuts on
each leg. (See Figure 1)
NOTE: Make sure all 4 leg holes are lined up
with desk top holes before assembling.
3. Attach adjustable feet to inside of legs at desired
height. Only bolt the top 2 holes on each leg using
2 large bolts and 2 large nuts. (See Figure 2)
4. Attach bottom shelf to legs. Bolt shelf to legs using
6 large bolts and 6 large nuts. (See Figure 3)
NOTE: Insert bolts through legs, adjustable feet,
and shelf. (See Figure 3, Inset A)
ASSEMBLY
Figure 1
Figure 2
Figure 3
Inset A

PAGE 3 OF 4 1115 IH-1799
ASSEMBLY CONTINUED
DRAWER ASSEMBLY
1. Remove drawer slides from the outsides of the
drawer. Press the drawer slide release lever to
remove slides completely. (See Figure 4)
NOTE: Depending on the side, press release
lever either down or up to remove slides.
2. Attach drawer slides to drawer tracks using 2 small
bolts, washers, lock washers and nuts. Extend drawer
slide completely to attach to track. Insert center bolt
first to align front bolt hole. (See Figure 5)
3. Insert drawer tracks into inside of desk top, aligning
front and back bolt holes. Drawer slides must
face inward. Use 4 large bolts and 4 large nuts to
assemble each drawer track to the desk top.
(See Figure 6)
NOTE: Lip should face the bottom of desk.
Figure 5
RELEASE LEVER
DRAWER TRACK
Figure 4
Figure 6

PAGE 4 OF 4 1115 IH-1799
TOP SHELF ASSEMBLY
1. Set desk top assembly upright and recheck all bolts
and nuts for tightness.
2. Place top shelf on desk top and assemble with 6
large bolts and 6 large nuts. (See Figure 7)
3. Insert plastic cable ring and cover into the top shelf
from the front of the desk.
4. Insert drawer into desk top.
LOCK ASSEMBLY
1. Disassemble drawer lock and reassemble lock on
drawer. (See Figure 8)
ASSEMBLY CONTINUED
Figure 7
Figure 8
