U-Line H-4292 User manual

PAGE 1 OF 2 0317 IH-4292
STEEL PEGBOARD
1-800-295-5510
uline.com
πH-4292, H-4293
SAFETY
INFORMATION
• ALWAYS wear safety glasses when using any
power tool.
• ALWAYS use hearing protection when using loud
equipment.
• DO NOT sit, climb, hang or step on hooks or holders.
• DO NOT overload hooks or holders.
• DO NOT try to install pegboard panels by yourself.
Use two or more people.
SUGGESTED TOOLS
• 24" Level
• Tape Measure
• Pencil
• Chalk Line
• Drill with #2 Phillips Screwdriver Attachment
SUPPLIES
#6 wood screws, 1½" to 2", with anchors.
GENERAL
1. Install over studs, plaster or drywall.
2. Snap chalk line at desired height on wall.
NOTE: Screws may not always anchor into a
stud.
3. Mark all holes on wall before hanging pegboard.
NOTE: If hanging multiple pegboards,
mark ALL holes first.
PAGE 2 OF 2 0317 IH-4292
INSTALLATION
πCHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
PREPARATION
1. Turn pegboard around so the front, flush side is
towards the wall. Place pegboard against wall in
desired hanging position.
2. With someone holding the pegboard in place,
mark holes on wall for hanging. (See Figure 1)
3. Pre-drill holes in wall if using anchors.
NOTE: Use a 1/4" drill bit when using the H-4294
Steel Pegboard Mounting Hardware or the
H-4292 Steel Pegboard Starter Kit.
4. Remove pegboard from wall. Insert anchors into
holes in wall.
HANGING PEGBOARD (See Figure 1)
NOTE: Follow this order for best results.
Do not fully tighten screws until all eight
are in place.
1. Turn pegboard around so the front, flush side is
facing away from the wall. Place pegboard against
wall so holes through which screws pass align with
drywall anchors.
2. Fasten top center screw (A).
• 1st row from top, 24th column from left.
3. Fasten 2 top side screws (B).
• 1st row from top, 1st column from left and
1st column from right.
4. Fasten 2 side screws (C).
• 12th row from top, 1st column from left and
1st column from right.
5. Fasten 3 bottom screws (D).
• 1st from bottom, 1st column from left and
1st column from right.
• 1st row from bottom, 24th column from left.
A
C
D
C
B
B
Figure 1
