Uberhaus 10S880A User manual

ASSEMBLY INSTRUCTION
GRILL GAZEBO
RONA CODE: 79275000
ITEM NUMBER: 10S880A
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
PAGE 1 OF 7
Do not discard any of the packaging until you have checked that you have all the parts and pack of
fittings.
Keep children away during assembly. This item contains small parts which can be swallowed by
children. Children should always be under direct adult supervision while using the product.
Retain the assembly instructions for future reference.
COURTYARD CREATIONS INC.
!
!
!
KUS3200-CS01
KUS3200-CS02
62KUS3200X103
62KUS3200X102
KUS3200-CS03
KUS3200-CS04
KUS3200-CS05
17TAN00042
17TAN00043
KUS3200-CS06
17ICA051601--Y3
17C33A0709001Y4
17C33A0706001Y4
17C17A0403001Y4
17FA05040301-Y4
1800337004
17KAA0101----Y4
KUS3200-CS07
KUS3200-CS08
LEG A
LEG B
SHORT SUPPORT
LONGER SUPPORT
SHORT CANOPY SUPPORT BRACE
LONGER CANOPY SUPPORT BRACE
CANOPY FRAME CONNECTOR
METAL CONNECTOR A
METAL CONNECTOR B
TABLE TOP
PEG
BOLT M6*25
BOLT M6*16
SCREW ST4.2*12
WASHER d6.5*D13*1.0
BOLT CAP
HEX.KEY WRENCH 4MM
SMALL CANOPY
LARGE CANOPY
1
2
3
4
5
6
7
8
9
2
2
2
2
4
4
2
2
2
11
10
12
13
14
15
16
17
18
19
4
2
16
16
4
32
32
1
1
1
PARTS LIST
PART
NO.
MATERIAL
CODE PART Q’TY
UBERHAUS

FIGURE 1
25
#12 BOLT M6*25
FIGURE 2
PAGE 2 OF 7
Attention:
Make sure that each bolt needed for
all steps match the corresponding
figure to ensure proper assembly.
Step 1:
Fasten one short support (#3) to the
legs (#1 and #2) by using bolts (#12)
and washers (#15). Tighten all the
bolts. Complete the same procedure
for the remaining short support (#3)
and legs (#1 and #2). See Figure 1.
NOTE:
1. The labels marked “1” and “2” and
the labelled arrows on the legs
(#1 and #2) should coincide with
Figure 1 to ensure proper
assembly.
2. Make sure the arcs of the short
supports (#3) are facing down.
Step 2:
Fasten the longer supports (#4) to
the legs (#1 and #2) by using bolts
(#12) and washers (#15). Tighten
all the bolts. See Figure 2.
NOTE:
Make sure the arcs of the longer
supports (#4) are facing down.
25
#12 BOLT M6*25

PAGE 3 OF 7
FIGURE 3
FIGURE 4
Step 3:
Fasten the metal connectors (#8
and #9) to the legs (#1 and #2) by
using bolts (#13) and washers
(#15). Tighten all the bolts.
See Figure 3.
NOTE:
Make sure that the labelled arrows
on the metal connectors (#8 and #9)
are facing outside.
Step 4:
Fasten the table tops (#10) to the
metal connectors (#8 and #9) by
using bolts (#13) and washers
(#15). Tighten all the bolts.
See Figure 4.
NOTE:
Make sure that the labelled arrows
on the table tops (#10) coincide with
Figure 4 – Illustration A to ensure
proper assembly.
16
#13 BOLT M6*16
16
#13 BOLT M6*16

PAGE 4 OF 7
FIGURE 5
Step 1
Step 2
Step 3
Step 5:
Insert the longer canopy support
braces (#6) into the canopy frame
connector (#7).
See Figure 5 – Step 1.
Step 6:
Place the large canopy (#19) onto
the assembled canopy frame. Then
insert the ends of the longer canopy
support braces (#6) into the pockets
of the large canopy (#19).
See Figure 5 – Step 2 and Step 3.

FIGURE 6
Step 1
Step 2
Step 3
Step 7:
Insert the short canopy support
braces (#5) into the canopy frame
connector (#7).
See Figure 6 – Step 1.
Step 8:
Place the small canopy (#18) onto
the assembled canopy frame. Then
insert the ends of the short canopy
support braces (#5) into the
pockets of the small canopy (#18).
See Figure 6 – Step 2 and Step 3.
PAGE 5 OF 7

FIGURE 7
Step 1
Step 2
FIGURE 8
Step 9:
Insert the small canopy assemlbly
onto the large canopy assembly.
Fasten them together by using
screws (#14). See Figure 7.
Step 10:
Insert the canopy assembly onto
the legs (#1 and #2). Then fasten
the canopy belts to the supports.
See Figure 8.
PAGE 6 OF 7

FIGURE 9
PAGE 7 OF 7
Step 11:
Stick the pegs (#11) into the ground
and hook the pegs (#11) through the
metal spacer’s holes correctly.
See Figure 9.
Step 12:
Re-check and re-tighten all bolts
and cover them with bolts caps
(#16).
Cleaning and Maintenance
• Wash frame and fabric parts with mild soap and water, rinse thoroughly and dry frame
completely. Do not use bleach, acid, or other solvents on the frame or fabric parts.
• We recommend the use of furniture covers when not in use.
• Please inspect and tighten all bolts or fasteners on a regular basis to ensure proper
performance and safety of your gazebo.
• In order to prolong the life and beauty of your gazebo, we recommend that it be stored in a
dry and protected area during off season periods.
