Uberhaus 11S766F User manual

PARTS LIST
PART
NO. MATERIAL CODE PART Q’TY PART NO. MATERIAL CODE PART Q’TY
1
2
3
4
1
2
4
1
6
7
6
5
8
9
10
4
8
12
12
1
TGS66ZP-CS01
TGS66ZP-CS02
TGS66ZP-CS03
62TGS66ZPY101
17C17A0403001Y4
17C01A0706002Y4
17C01A0709002Y4
17FA05040301-Y4
1800337002
17KAA0201----Y4
TABLE TOP
SUPPORT
LEG
CENTER
CONNECTOR WITH RING
BOLT M6*16
BOLT M6*25
WASHER d6.5*D13*1.0
BOLT CAP M6
HEX.KEY WRENCH 6MM
Attention:
Make sure that each bolt needed for all steps match
the corresponding figure to ensure proper assembly.
Step 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Insert the legs (#3) and the supports (#2) into the
plastic holders attached on the underside of the table
top (#1) rim. Fasten them together by using screws (#5).
See Figure 1.
Do not sit or stand on this table.
A weighted umbrella base must be used when using an umbrella with this table.
Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings.
Keep children away during assembly. This item contains small parts which can be swallowed by children.
Children should always be under direct adult supervision while using the product.
Retain the assembly instructions for future reference.
PAGE 1 OF 2
COURTYARD CREATIONS INC.
FIGURE 1
SCREW ST4.2*12
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
DINING SET - TABLE
RONA CODE: 79275015
ITEM NUMBER: 11S766F
ASSEMBLY INSTRUCTIONS
!
!
!
!
!
You will need the following tools:
- Phillips Screwdriver (Not Included)
- Hex. Key Wrench (See Part #10)
5
1
3
33
3
2
2

FIGURE 4
Step 2:
Fasten the center connector with ring (#4) to the middle
of the legs (#3) by using bolts (#6) and washers (#8).
Keep the bolts loose. See Figure 2.
Step 4:
Turn the table to its upright position. See Figure 4.
NOTE:
To use an umbrella with this table, please remove
the plastic center plug and put the umbrella pole
through the table top and center connector ring.
Cleaning and Maintenance
• Wash frame parts with mild soap and water, rinse thoroughly, and dry frame completely. Do not use bleach, acid,
or other solvents on the frame parts.
• Wash glass with mild soap and water, rinse thoroughly, and dry glass completely.
• Please inspect and tighten all bolts and fasteners on a regular basis to ensure proper performance and safety of
your table.
• When moving the table, remove the umbrella and lift the table. Do not drag.
• We recommend the use of furniture covers when not in use.
• In order to prolong the life and beauty of your table, we recommend that it be stored in a dry and secure area
during off season periods.
• Tempered glass has been used for increased strength and safety of your table. However, during windy
conditions the umbrella should be lowered and/or removed.
• A weighted umbrella base must be used when using an umbrella with this table.
