Uberhaus 38115076 User manual

10’x10’ Gazebo
Operators’ Manual
Abri-soleil 10 x 10 pi
Guide de l'utilisateur
Model/Modèle : 38115076

GAZEBO ASSEMBLY INSTRUCTIONS
Our easy-to-follow, step-by-step instructions will guide you through the project from start to
finish. The final product will be a quality piece that will give you years of enjoyment.
All you will need is a screwdriver, a hammer and two ladders of at least 8 feet (2.5 m) high
(not included).
DO NOT assemble this item alone for your safety. Two people are necessary for smooth &
safe installation.
Item identification: For ease of identification, all parts are labeled to correspond to the Step
number in which the part is used.

Post
A 4
Stake plate
B 4
Stake cover
C 4
Valance 1
D 4
Valance 2
E 4
Supporting bar
F 8
Slanted beam
G 4
Straight beam
H 4
Lower slanted beam
connector
I 4
Top connector
J 1
Hook
K 1
Mosquito net
L 1
Canopy
M 1
Wall (curtain)
N 1
Parts List
Hardware Pack 1
AA M6 x15 bolt 40 PCS
BB M6 flat washer 88 PCS
CC M6x50 bolt 8 PCS
DD M6x15 bolt 32 PCS
GG M6 nut 8 PCS
HH
plastic cover
40 PCS
Z
M6 hex wrench
2 PCS

Fig.1: Attach stake cover (C) to post (A), then fix stake plate (B) to post (A) with bolt (AA) and flat washer
(BB). Repeat for all posts.
Fig.2: Attach lower slanting beam connector (I) by inserting it into Post (A) with bolt (AA) and flat washer
(BB). Repeat for all slanted beams.
Fig.3: Insert Valance 2(E) into Valance 1 (D); attach with bolt (CC), flat washer (BB) and nut (GG), then
cover bolt (CC) with plastic cover (HH). Repeat for each assembly.
Fig.4: Attach assembled valance to post (A) with bolt (DD) and flat washer (BB), then cover bolt (DD) with
plastic cover (HH). Repeat on all sides.

Fig.5: Attach assembled valance inside with bolt (DD) and flat washer (BB). Repeat for each corner. Then,
cover all bolts (DD) with plastic covers (HH).
Fig.6:
Hardware Pack 2
Fig.7: Attach hook (O) to top connector.
Fig.8: Insert slanted beam (G) and straight beam (H) into top connector (J). Repeat for all beams.
Fig.9: Insert lower part of slanted beam (G) into lower slanted beam connector (I)
Fig.10: Attach lower part of straight beam (H) into valance with bolt (AA) and flat washer (BB). Tighten
fully.
AA M6 x15 bolt 4 PCS
BB M6 flat washer 4 PCS

EE
Φ 8x180 stake 16 PCS
FF
plastic loop 104
PCS
Hardware Pack 3
Fig.11: Attach wall (N) onto lower tube of valance with plastic loop (FF). Repeat for all walls.
Fig.12: Attach mosquito nets (L) onto lower valance tubes, with plastic loops (FF).
Fig.13: Spread canopy (M), attach hook to post (A), then attach the velcro straps of the canopy to
valance.
Fig.14: Lift stake cover(C), anchor the gazebo on the lawn with stakes (EE) through stake plate (B).

IMPORTANT:
1. Keep all children and pets away from assembly area. Children and pets should be supervised while
gazebo is being assembled.
2. The assembled gazebo should be located at least 6 feet (2 m) from any obstruction such as fence,
garage, house, overhanging branches, laundry lines or electrical wires.
3. This unit is heavy. Do not assemble this item alone. Six people are recommended for safe assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment. Please read all instructions before
assembly and use.
6. For outdoor use only. Install on level ground. 16 stakes are provided to secure the gazebo in the
ground. If you wish to secure the pavilion to a wood deck or concrete surface, 16 anchors are provided
for these surfaces.
7. Check all bolts for tightness before and during usage.
8. Please check your state and local regulations prior to purchasing. Some jurisdictions may require
permits for installation and use. Some special procedures may be valid in your area.
9. While this gazebo is manufactured to withstand strong force winds through only the supplied ground
stakes, in areas subject to frequent severe weather, securing the gazebo to a deck, concrete patio or
footings should be considered.
NOTE: The gazebo’s roof and structure are not guaranteed against extreme weather conditions (storms,
high winds, etc.). If the gazebo is not dismantled for the winter, snow must be cleaned off regularly. Any
damage caused by snow accumulation is not covered by the warranty.
Care & Maintenance:
Our steel components for garden accessories and furniture are treated with rust inhibiting paint that
protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once
these protective coatings are scratched. This is not a defect and thus not covered by the warranty.
To minimize this condition, we recommend care when assembling & handling the product to prevent
scratching the paint. Should any scratching or damage occur, we recommend immediate touch-up with
rust inhibiting paint.
Surface rust can also be easily removed with a very light application of common cooking oil. If surface
oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping on
to deck or patio and caused damaging stains, which may be difficult to remove. This can be prevented if
the above-mentioned measures are taken to keep the product from oxidizing.

Warranty
Thank you for purchasing this UBERHAUS product. These products have been made to demanding,
high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of
12 months from the date of purchase.
This warranty does not affect your statutory rights. In case of any malfunction of your UBERHAUS
product (failure, missing part, etc.), please contact one of our service technician at our toll free service
line at 1-866-206-0888 from 8 AM to 6 PM, Monday to Friday, Eastern time. RONA reserves the right to
repair or replace the defective product, at its discretion.
The product is guaranteed for 12 months if used for normal trade purposes. Any warranty is invalid if the
product has been overloaded or subject to neglect, improper use or an attempted repair other than by an
authorized agent. Heavy-duty or daily professional/commercial usage are not guaranteed. Due to
continuous product improvement, we reserve the right to change the product specifications without prior
notice.

DIRECTIVES D’ASSEMBLAGE DE L’ABRI-SOLEIL
Nos instructions claires et faciles à suivre vous aideront à assembler votre abri facilement, du début
à la fin. Le résultat sera un abri de haute qualité qui vous offrira des années de plaisir.
Tout ce qu’il vous faudra sera un tournevis, un marteau et deux échelles d'au moins 8 pi (2,5 m) de
hauteur (non fournis).
Attention : CETTE UNITÉ EST TRÈS LOURDE!
Pour votre sécurité, N’ASSEMBLEZ PAS cet article tout seul. Deux personnes seront
requises pour une installation facile et en toute sécurité.
Identification des articles: pour faciliter leur identification, toutes les pièces sont étiquetées pour
correspondre au numéro de l’étape dans laquelle la pièce sera employée.

Poteau
A 4
Plaque d’ancrage
B 4
Couvercle d’ancrage
C 4
Traverse 1
D 4
Traverse 2
E 4
Barre de support
F 8
Poutre inclinée
G 4
Poutre droite
H 4
Raccord inférieur de
poutre inclinée
I 4
Raccord du toit
J 1
Crochet
K 1
Filet moustiquaire
L 1
Toit
M 1
Mur (rideau)
N 1
Liste des pièces
Sachet de quincaillerie 1
AA Boulon M6 x15 40 mcx
BB Rondelle plate M6 88 mcx
CC Boulon M6x50 8 mcx
DD Boulon M6x15 32 mcx
GG Écrou M6 8 mcx
HH
Couvre-boulon en plastique
40 mcx
Z
Clé hexagonale M6
2 mcx
