Ubiquiti U-LTE User manual

U-LTE Stand Mounting Bracket
Double-Sided Adhesive Self-Tapping Screws (Qty. 2) Screw Anchors (Qty. 2)
Package Contents
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

RP-SMA Cap
System Requirements
Linux, Mac OS X, or Microsoft Windows 7/8/10
Java Runtime Environment 1.8 or above recommended
Web Browser: Google Chrome (Other browsers may have limited functionality)
UniFi Controller software v5.12.x (or newer), available at: ui.com/download/unifi
Hardware Overview
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

RP-SMA Antenna Connector
Reset Button
You can connect an optional external LTE antenna (not included). If you are not
using an external antenna, then you can cover the connector with the RP-SMA Cap.
The Reset Button serves two functions:
Restart Press and release the Reset button quickly.
Restore to Factory Default Settings Press and hold the Reset button for more than
five seconds, until the display indicates “Factory Reset”.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Secondary
Main
LCD Screen
This Gigabit Ethernet port is used for bridging and can provide passive PoE to a
device.
This Gigabit Ethernet port is used to connect the power and should be connected to
the LAN and DHCP server. 803.2at PoE+ can be provided by an 802.3at PoE+
switch, such as a UniFi PoE Switch.
Displays status information, including the LTE signal strength.
Installation Requirements
Phillips screwdriver
Wall-mounting (optional): drill with 6 mm drill bit
For WAN failover:
UniFi Dream Machine, model UDM
UniFi Security Gateway, model USG, USG-PRO-4, or USG-XG-8
UniFi cloud account
Note: The U-LTE can only be adopted via remote access at: unifi.ui.com
Activation of Ubiquiti LTE data plan
For indoor applications, use Category 5 (or above) UTP cabling approved for indoor
use.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

For outdoor applications, shielded Category 5 (or above) cabling should be used for
all wired Ethernet connections and should be grounded through the AC ground of the
power supply.
We recommend that you protect your networks from harmful outdoor environments
and destructive ESD events with industrial-grade, shielded Ethernet cable from
Ubiquiti. For more details, visit: ui.com/toughcable
WARNING: To reduce the risk of fire or electric shock, do not expose this
product to rain or moisture.
Note: Although the cabling can be located outdoors, the U-LTE itself should be
housed inside a protective enclosure.
Hardware Installation
The U-LTE can be mounted in three ways:
Screw Mount
“Adhesive Mount”
“Desktop Mount”
Screw Mount
1.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

2.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

3.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

4.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

5.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Proceed to “Connecting Ethernet”.
Adhesive Mount
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

1.
2.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

3.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Proceed to “Connecting Ethernet”.
Desktop Mount
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Connecting Ethernet
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Setup
Overview
You will do the following:
Adopt the U-LTE in the UniFi Controller software.
Set up your LTE account. You can manage your LTE subscription at:
account.ui.com/subscriptions
If the primary WAN 1 or 2 goes offline, then the configured networks fail over to the U-
LTE.
Configuration
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

1. In the UniFi Controller, click the Devices tab. The U-LTE should be automatically
detected and begin the setup wizard; proceed to step 2. Otherwise, select the U-LTE
and click Adopt.
2. Click Setup LTE.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

3. For your ui.com account, enter your email address or username and password.
Select I agree to the Terms of Service and click Next.
If you do not have a ui.com account, click Create a new ui.com account and follow
the on-screen instructions.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

4. For payment information, enter the following:
Credit card number
Expiration month and year in this format: MM/YY
CVC (Card Verification Code) on the back of your card
Click Next.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

5. The U-LTE will reboot. It can take up to 20 minutes to activate on the cellular
network. Click Done to close this screen.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Using the U-LTE
To monitor data usage, click the U-LTE on the Devices screen. Its Properties panel will
appear.
