Ultraflex ZTF Tiller System User manual

Installationmanual
(Dr./Dis./Des. n°35010/a-19/04/2019)
ITALIANO ENGLISH
I
UK
page2 pag.29
ZTF
TILLERSYSTEM
R
PARTNER

DearCustomer,
TheZTFTiller Systems are produced by ULTRAFLEX Companybelongingto ULTRAFLEXGROUP.
ULTRAFLEXGROUP is a leader insteering systems for pleasure and professionalboats for more than
85 years.
ULTRAFLEXproductionis sinceever synonimousofreliabilityandsafety. All ULTRAFLEX productsare
designedandmanufacturedtoensurethebestperformance, inaccordancetotheaimthey were
manufacturtedfor.
Thequalitymanagement systeminvolves all thecompanyresources andprocesses startingfrom
the design,inorder to:
- ensure productqualityto the customer;
-maintainandimprovethequalitystandards constantly;
-pursueacontinuousprocessimprovement tomeetthemarketneeds andtoincrease the
customer satisfaction;
-constantlytestthe products to verifytheir conformitywith EC directives, ISO normsand ABYC
(AmericanBoatandYacht Council) requirements.
To ensure yoursafetyandtomaintainahighqualitylevel, ULTRAFLEX productsare guaranteed only
iftheyare used with originalspare parts.
ULTRAFLEX
ULTRAFLEX S.p.A.
16015Casella(Genova) Italia-ViaCrose,2

ZTF SYSTEM -page3of55
Installationmanual
ENGLISH
ULTRAFLEX TABLEOFCONTENTS
SECTION1-PRODUCTDESCRIPTION
1.1 ZTFSYSTEMDESCRIPTION....................................................................................................................................7
1.2 OPERATING PRINCIPLE..........................................................................................................................................8
SECTION2-TRANSPORT
2.1 GENERAL WARNINGS..............................................................................................................................................9
2.2 PACKAGINGCONTENTS..........................................................................................................................................9
SECTION3-INSTALLATION
3.1 SAFETY WARNINGS........................................................................................................................11
3.2 INSTALLATIONTYPES.....................................................................................................................11
3.3 INSTALLATION WITH150-175-200 HP YAMAHA®ENGINES...........................................................................12
3.4 INSTALLATION WITH90-115-130 HP YAMAHA®ENGINESFROM2015 TO DATE.......................................16
3.5 YAMAHA®TILLER HANDLE ASSEMBLY.............................................................................................................18
3.6 TILLER HANDLE DISASSEMBLYFROMOUTBOARD ENGINE("REFITTING"INSTALLATION)..................20
3.7 WIRING.....................................................................................................................................................................20
DOCUMENT REVISIONS....................................................................................................................................4
MANUAL USEAND SYMBOLSUSED.............................................................................................................................5
INTRODUCTION LETTER...................................................................................................................................................6
WARRANTY........................................................................................................................................................................6
SECTION5-DISMANTLING
5.1 DISMANTLING.........................................................................................................................................................26
SECTION4-MAINTENANCE
4.1 ORDINARY MAINTENANCE...................................................................................................................................21
4.2 ZTFSYSTEMFILLING AND PURGING.................................................................................................................21

Installationmanual
page4of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
DOCUMENTREVISIONS
Rev.
Dat
e
Rev
ision description
0
25
/01/2019
First edition

ZTF SYSTEM -page5of55
Installationmanual
ENGLISH
ULTRAFLEX
MANUALUSE AND SYMBOLSUSED
STERN
BOW
STARBOARD PORT Thepictureasideexplainsthemeaningofsome
nauticalwordscontainedinthismanual.
Inthismanualthefollowingsymbolsareusedtoensuretheusersafetyandtoguarantee thecorrect
operationoftheproduct:
DANGER ImmediatehazardswhichCAUSEseverepersonalinjuryordeath.
WARNING Hazardsorunsafepractices whichCOULD CAUSEseverepersonalinjury
ordeath.
CAUTION Hazardsorunsafepractices whichCOULD CAUSEminorinjuryordamage
tothecraftorcomponentsortotheenvironment.
Thesymbolasideindicates all theoperationswhichmustbecarriedout
byqualifiedorskilledstaff,inordertoavoidhazards.
Werecommendtrainingthestaffinchargeoftheproductinstallation
andcheckingtheirknowledge.
NOTICE Importantinformationforthecorrectinstallationandformaintenance,that
doesnotcauseanydamage.
THEINSTALLATION AND MAINTENANCE MANUAL should bekeptforregularreference bytheownerofthe
boatandtransferedtoanynewownerwiththeboat.
It is necessarytoreadcarefully themanual,beforeANY ACTIVITYinvolvingtheproduct,handlingand
unloadingincluded.

Installationmanual
page6of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
ULTRAFLEXguaranteesthatitsproductsarewell designedandfree frommanufacturingandmaterialdefects,
foraperiodoftwoyearsfromthedateofmanufacturing.
Fortheproductswhichareinstalledandusedonworkingorcommercialboatsthewarrantyis limitedto
oneyearfromthedateofmanufacturing.
Ifduringthisperiodtheproductprovestobedefective duetoimpropermaterialsand/ormanufacture, the
manufacturerwill repairorreplace thedefective partsfree ofcharge.
Otherdirectorindirectdamageis notcoveredbythiswarranty.Inparticularthecompanyisnotresponsible
andthis warrantywill notcoverthedamageresultingfromincorrectinstallationoruse oftheproduct
(exceptforreplacementorrepairofdefective partsaccordingtotheconditionsandtermsabove).
This warrantydoes notcovertheproductsinstalledonraceboatsorboatsusedincompetitions.
Thedescriptionsandillustrationscontainedinthis manualshould beusedas generalreference only.This
warrantyis applicableonly when ULTRAFLEX steeringsystemcomponentsareusedwith ULTRAFLEX control
units.
Foranyfurtherinformationplease contactourTechnical Assistance Service.
ULTRAFLEX steeringsystemcomponentsproducedby ULTRAFLEX aremarkedaccordingtotheDirective
2013/53/EU.
Weremindyouthatonlymarkedsteeringsystemsmustbeusedontheboatsmarked.
Weinformyouthatthe ULTRAFLEX warrantyis null ifsome ULTRAFLEX componentsarereplacedwithproducts
ofotherbrands.
WARRANTY
TECHNICALASSISTANCE SERVICE
INTRODUCTIONLETTER
North-South-CentralAmerica:
UFLEX USA
6442ParklandDrive
Sarasota,FL34243
Ph.:+1.941.351.2628
Fax: [phone]
Email: [e-mail]
www.uflexusa.com
UFLEX S.r.l.
ViaMiliteIgnoto,8A
16012 Busalla(GE)-Italy
Ph.:+39.010.962.01
Fax: [phone]
Email: [e-mail]
www.uflexgroup.it
This installationandmaintenancemanualis anintegrantpartoftheproductandshouldbeeasily availabletostaff
inchargeofuse andmaintenance.
Theusermustknowthecontentofthis manual.
ULTRAFLEX declines all responsibilityforpossiblemistakesinthis manualduetoprintingerrors.
Althoughthemainfeatures ofthetypeofproductdescribedarenotsubjecttochange, ULTRAFLEX Companyreserves
therighttomodifyanyparts, detailsandaccessories itdeemsnecessarytoimprove theproductorformanufacturing
orcommercialrequirements, atanytimeandwithoutbeingobligedtoupdatethis manualimmediately.
ALLRIGHTSARE RESERVED.Publishingrights, trademarks, partnumbersandphotographsof ULTRAFLEX products
containedinthis manualare ULTRAFLEX property.
Greatcarehasbeentakenincollectingandcheckingthedocumentationcontainedinthismanualtomakeitas
completeandcomprehensibleaspossible.Nothingcontainedinthis manualcanbeinterpretedaswarrantyeither
expressedorimplied-including,notinarestrictedway,thesuitabilitywarrantyforanyspecialpurpose.Nothing
containedinthis manualcanbeinterpretedas amodificationorconfirmationofthetermsofanypurchasecontract.
Toensurethecorrectproductandcomponentoperation,theproductmustbeinstalledbyqualifiedstaff.
Incase ofpartdamageormalfunction,please contactthequalifiedstaff orourTechnicalAssistance Service.
WARNING

ZTF SYSTEM -page7of55
Installationmanual
ENGLISH
ULTRAFLEX
1PRODUCTDESCRIPTION
1.1ZTFTillerSystemdescription
TheZTFTillerSystemis ahydraulic device thatneutralizes thepropellertorqueofoutboard engines onthe
tillerhandlewhiletheoperatorisnotactivelymakingasteeringcoursechange.It enables theoperatorto
maintaintherightcoursewithoutexcessive physicaleffort.
Thehydraulicvalve opensthemomenttheoperatormakesasteeringcourse changeatwhichpointthe
propellertorquewill bepresentonthetillerhandle. It is importantthattheoperatormaintainsafirmgrip
onthetillerhandleatall times whileoperatingtheboat;especiallywhenmakingsteeringcourse changes.
TheZTFTillerSystemconsistsoffourmaincomponents:
Tillerhandle(supplieddirectlybyYamaha®oroneofitsresellers)
Maindevice
UC130ZTFhydrauliccylinder
Hydraulichoses
1
2
3
1
4
423
NOTICE
TheZTFTillerSystemis alwayssuppliedoil-filled,purged,functioningandwithproperlyconnectedhoses.
Avoidtwisting,damaging,bendinganddisconnectingthehoses.
CAUTION
TheZTFTillerSystemmustbeusedcombinedwith Yamaha®outboard engines of90-115-130 HP produced
from2015 todate, andengines of150-175-200 HP -models2.7L F150 Mechanical,VF150 VMAXSHO, F175,
VF175 VMAXSHO, andF200 Mechanical- andmustbeassembledonly onboatsspecificallydesignedand
suitablyequippedforbeingsteeredwiththetillerhandle. Theinstallerandtheoperatorareresponsiblefor
ensuringtheproperfunctioningoftheZTFTillerSystemontheboat,bearinginmindfactorslikespeed,
motorloadsandworkingconditions.
CAUTION
Forinstallations otherthanthe ones requiredforabove-mentionedYamaha® engines, please contact ULTRAFLEX
TechnicalAssistanceService.
CAUTION
Do notuse this device forpurposes otherthanthose itwas madefor,as specifiedintheinstallationmanual.
CAUTION

Installationmanual
page8of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
1.2Operatingprinciple
Thepatentedhydraulic valve andcorrespondingcylinderoftheZTFTillerSystemopensandcloses incase
theoperatorpushes orpullsthetillerhandle. Whentheoperatorneitherpushes norpullsthetillerhandle
(changingsteeringcourse),thehydraulicvalve closes eliminatingthesteeringloadfrompropellertorque
onthetillerhandle.
TheoperatorMUSTmaintainafirmgriponthetillerhandleunderALL operatingconditions; whileactively
changingcourseorwhilemaintainingafixedcourse(withvalve closed) asseaconditions,floatingdebris,
orotherconditionscould changethesteeringcoursewithoutinputdirectly fromtheoperator.
TheZTFTillerhas aBy-Pass Knobunderneaththeprimary
assemblythatcanbeusedtoengageordisengagethe
hydraulicvalve. Turningtheknobclockwise completely will
activatetheZTFvalve -lockingoutthepropellertorquewhile
notactively changingsteeringcourse. Turningtheknob
counter-clockwise willdisengagetheZTFTillervalve which
will allowthepropellertorquetoreachthetillerhandle-
evenwhennotactively makingasteeringcoursechange.
It is essentialthattheoperatorconfirmsthefunctionalityand
statusoftheZTFTillerSystembeforeeachuse.
To determinewhetherthesystemis active andfunctional,
firstcheck toensurethattheBy-PassKnobisfirmlyclosed
byturningtheBy-pass Knobclockwise.Thenfirmlypushon
thebackoftheenginetosimulateasteeringchange(withoutpushingonthetillerhandlesimultaneously).
If theenginedoes notturnineitherdirection,theZTFis engaged.
If theenginemoves,tightentheBy-PassKnobintheclockwise directionandcheckagaintoseeifthe
enginemoves. If itcontinues tomove, donotuse theboatandcontactyourdealerof ULTRAFLEX fortechnical
support.
Internalvalve
open Internalvalve
open Internalvalve closed
Propellertorque
Noeffort
=
Zerotorque
feedback
Propellertorque Propellertorque
WARNING
ZERO
TORQUE
FEEDBACK
OFF
ZERO
TORQUE
FEEDBACK
ON

ZTF SYSTEM -page9of55
Installationmanual
ENGLISH
ULTRAFLEX
1.Bracket
2.Hardwarefasteningthedevicetothebracket
(2screwsM12,2nuts, 4washers)
3.Hardwarefasteningthecylinderlinkarmtothe
enginearm(2specialboltsULTRABOLT, 2high
nuts, 4washers)
4.Hardwarefasteningthecylinderlinkarmtothe
enginearm(1SVS boltULTRABOLT, 1SVS
washer, 1thinnut)
5.Hardwarefasteningthebracket totheengine
arm(2pivots,2washers,2nuts)
CAUTION: thishardwareisalwaysincludedin
Yamaha®tillerhandles
KITQU1
(150-175-200 HPENGINES)
KITND1
(90-115-130HPENGINESFROM
2015)
2.1Generalwarnings
2TRANSPORT
Theproductweightwithitspackagingis 20kg (44lbs.).Therefore, itcanbehandledmanually.
2.2Packagingcontents
Beforeusingtheequipmentcheckthattheproducthasnotbeendamagedduringtransport.Also
makesurethatall thestandardcomponentsareinthepackaging.Incaseofdamage,donotuse the
ZTFTillerSystemandnotifythefreightcarrierandyourdealer/distributorimmediately.
TheZTFTillerSystemis providedwiththefollowingitems:
WARNING
Thestaffinchargeofhandlingmustoperatewithprotectivegloves andsafetyshoes.
12
3
Yamaha® tillerhandle
Maindevice
Accessory kitbasedoninstallationtype,providedseparately (see thefollowingtablewithrelated
drawingsandparagraph3.2)



IfYamaha®tillerhandle is new,itwill
alwaysbe supplied with original bracket
and the required fastening screws.Itwill
be necessarytoremovethe original
bracket in ordertoinstall the ZTFsystem.
NOTICE
ORIGINAL
BRACKET

Installationmanual
page10of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
KITQU1 KITND1
1
2
34
5
1
2
Thepackaging mustbe disposed ofaccordingtothe existinglaws.
CAUTION

ZTF SYSTEM -page11of55
Installationmanual
ENGLISH
ULTRAFLEX
3INSTALLATION
3.2Installationtypes
TheZTFsystemhastwodifferentinstallationtypes:
1)NEWINSTALLATION: TheCustomerpurchasesanewYamaha®tillerhandleor,moregenerally,the
possessedtillerhandlehasneverbeeninstalledontheoutboardengine.
2)REFITTING: TheCustomer'sYamaha®tillerhandlehasbeenalreadyinstalledontheoutboardengine.
Moreover,theinstallationprocedurevariesaccordingtothetypeofYamaha®outboardengineonwhich
theZTFsystemisinstalled,asdescribedinthefollowingscheme:
3.1Safetywarnings
Strictlyfollowtheprecautionsandthesafetywarningsthroughoutthis entiremanual.Failuretodoso could
resultinlossofsteeringwithpossibledamage, injuriesanddeath.
ULTRAFLEX declines all responsibilityforerrorsduringinstallation,mis-application,mis-use, neglect,or
lackofmaintenance orroutineinspection.
-DONOTPUTHANDSBETWEENTHEMOVINGPARTS.
-Donotdisableinanyway thesafetydevices.
-Do notmodifyoradddevices to the system, without ULTRAFLEXwrittenauthorizationortechnical intervention
whichwill prove themodification.
-Installationshould only beperformedby wellexperienced andtrainedmarinetechnicians.
PERICOLO
DANGER
NEWINSTALLATION
(theCustomerpurchasesa
newtillerhandleorthe
possessedtillerhandlehas
neverbeeninstalledon
theoutboardengine)
REFITTING(theCustomer's
tillerhandlehasbeen
alreadyinstalledonthe
outboardengine)
TYPEOFOUTBOARD
ENGINE
ENGINETYPE
90-115-130 HPFROM2015
ENGINETYPE
150-175-200 HP
USEOFKITQU1 USEOFKITND1
FOLLOWTHE
INSTALLATION
INSTRUCTIONSFOR200
HPENGINES(seepar.3.3)
FOLLOWTHE
INSTALLATION
INSTRUCTIONSFOR130
HPENGINES(seepar.3.4)
TILLERHANDLEASSEMBLY
(seepar.3.5)
CONNECTINGSHIFTAND
THROTTLECABLES
(seepar.3.7)
INSTALLATION
TYPE
Dismantlingthetiller
handlefromtheoutboard
engine(seepar.3.6)

Installationmanual
page12of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
1Fastenbracket(1)ondevice (2)usingscrews (3)andnuts (4)afterhavingproperly placedwashers
(5).Lockusing218mm wrenches withatighteningtorqueof80 Nm(59 lb.-ft.).
3.3Installationwith150-175-200HPYamaha®engines
As reportedonthepreviouspages, theZTFinstallation
with150-175-200HP enginesrequirestheuseofKIT
QU1 (see also par.2.2).
NECESSARYTOOLS
(2x)Openend
wrench
18mm
Torquewrench
MOLYKOTE® 1000
CAUTION
Applygrease tothescrewshaftsbeforetighteningthenuts.
Thebracketmustbeorientedasshown inthepicture.
KIT
QU1 1
4
5
3
6
7
10
14
11
13
8
1
2
3
4
5
Openend
wrench
9/16"
CAUTION

ZTF SYSTEM -page13of55
Installationmanual
ENGLISH
ULTRAFLEX
2Place thetwoultrabolts(6)and(7)withwashers(8)intotheenginearm(9)uptohalf oftheirlength.
Thescrewsmustprotrudefromtheenginearmbyaround15mm.
NOTICE
7
6
8
9
3Assemblethedevicewith
bracket(1)ontheenginearm(9).
Becarefulnottobend,kinkor
disconnecthydraulichoses.
4Place washer(10)onthefront
ultrabolt (6),whichistheclosest
tothedevice andtightenmanually
theself-lockingnut(11).
Apply grease tothescrewshafts
beforetighteningthenuts.
19
6
10
11
CAUTION
CAUTION

Installationmanual
page14of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
5Placethecylinderlinkarm
(12)ontherearscrew(7).
Inordertocompletethefaste-
ningprocess ofthecylindertothe
enginehose,refertothe
instructionscontainedinthe
manualofthecylinder.
NOTICE
12
7
6Screwultrabolt(7)lettingit
protrudefromthecylinderlink
armby atleast5mm,thenplace
washer(13)(seepicturebelow).
7Manuallytightentheself-
lockingnut(14)onscrew(7).
Apply grease tothescrewshaft
beforetighteningthenut.
7
14
7
13
CAUTION

ZTF SYSTEM -page15of55
Installationmanual
ENGLISH
ULTRAFLEX
This check requires careful attention.
This operationrequires careful attention.
8Bringthetwoultraboltsintocontactwith
theenginetillerarmandfastenthemusinga
9/16"wrenchwith atorqueof54 Nm(40 lb.-
ft.).
CAUTION
9Afterwards, whileholdingascrewwith
a9/16"wrench,fastenthecorrespondingnut
withatorqueof54Nm(40lb.-ft.).Repeatthis
operationontheothernutalwaysbyholding
itsscrew.
Double-checkthetighteningofscrewsand
nutsbyrepeatingthesameprocedure
describedinpoints8and9(fasteningscrews
andnutswhileholdingscrews).
CAUTION
10 CompletetheassemblyofUC130 cylinder onthe outboard enginefollowingwhatis reported on
theinstallationandmaintenancemanualofthecylinder itself,exceptfor thefasteningphase ofthe
cylinder linkarmtotheenginearm,whichis described inthepreviouspoints.
Do notdisconnectthehydraulichoses for anyreason.
11 AssembleYamaha®tiller handleontheZTFdeviceas described inparagraph3.5.
NOTICE

Installationmanual
page16of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
Thebracketmustbeorientedasshown inthepicture.
Applygrease tothescrewshaftsbeforetighteningthenuts.
3.4Installationwith90-115-130HPYamaha®enginesfrom2015todate
Asreportedonthepreviouspages,theZTFinstallation
with90-115-130 HP engines from2015 requires theuse
ofKITND1 (see also par.2.2).
1Fastenbracket(1)ondevice (2)usingscrews(3)andnuts(4)afterhavingproperlyplacedwashers
(5).Lockusing218mm wrenches withatighteningtorqueof80 Nm(59 lb.-ft.).
NECESSARYTOOLS
2Screwandlockthestuds(7)totheenginearm(6)
followingthetighteningtorqueandtheinstructions
containedinthemanualofYamaha® tillerhandle.
(2x)Openend
wrench
18mm
Torque
wrench
MOLYKOTE® 1000
CAUTION
CAUTION
1
2
3
4
5
KITND1 1
354
7
910
11
Openend
wrench9/16"
Openend
wrench
14mm
7
6

ZTF SYSTEM -page17of55
Installationmanual
ENGLISH
ULTRAFLEX
4Fastenthecylinderlinkarm(8)totheenginearm(6)byscrewinga3/8"ultrabolt(9)intheclosest
holetothestern,byinterposingwasher(10):tightentheultrabolt usinga14 mm wrenchwithatorqueof
54 Nm(40 lb.-ft.).
Screwtheself-lockingnut(11)with
a9/16"wrenchandtightenitwith
atorqueof27 Nm(20 lb.-ft.).After
havingfastenedthenut(11),
recheck thatthetighteningtorque
-54Nm(40 lb.-ft.)-ofthescrew
(11)is correct.
Applygrease tothescrewshafts
beforetighteningthenuts.
5Complete the assemblyofUC130 cylinder onthe outboard engine byfollowingwhatis reported
ontheinstallationandmaintenancemanualofthe cylinder itself,exceptfor thefasteningphase of
thecylinder linkarmtotheenginearm,whichis described inthepreviouspoints.
Do notdisconnectthehydraulichoses for anyreason.
6Assemblethetiller handleontheZTFdeviceas described inparagraph3.5.
CAUTION
3Fastenthedevicewiththebracketontheenginearmusingnuts(X)andinterposingwashers(Y),
followingthetighteningtorqueandtheinstructionscontainedinthemanualofYamaha® tillerhandle.
Applygrease tothepivotsbeforetighteningthenuts.
Duringthisoperation,becarefulnottodamage,bendanddisconnectthehydraulichoses.
CAUTION
NOTICE
X
Y
8
6
10
9
11

Installationmanual
page18of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
Ifthese componentsaredamaged,theymust
bereplaced.Inthis case, contactthetechnical
assistance.
3.5Yamaha®tillerhandleassembly
TheYamaha®tillerhandleis composedofthemainbody
(1)andtheoriginalbracket(2)forconnectingittothe
enginearm.
InordertoinstallthetillerhandleontheZTFdevice, it
is necessary toremove bracket(2)andassemblethe
mainbody(1)directlyontheZTFdevice.
To this end,refertowhatisreportedinfollowing
paragraphs.
1Inordertoinstallthetillerhandleonthe
ZTFdevice, itisnecessarytoremovethe
originalbracket,takingcarenottodamage
thescrew,thebushings, thewashersandthe
connectingnut.Becarefultothepositionof
these parts,since theywillbereusedfor
assemblingthemainbodyofthetillerhandle
tothedevice.
3.5.1 Originalbracketremoval
Duringdisassembly,ALL componentsmust
beremoved,sincetheywill bereusedforthe
followingreassembling.
NOTICE
CAUTION
1
2

ZTF SYSTEM -page19of55
Installationmanual
ENGLISH
ULTRAFLEX
3.5.2 ZTFdeviceassemblyontillerhandle
1Themainbodyofthetiller
handlemustbefastenedtothe
device inlinewiththefork.
Fastenthetillerhandle(1)todevice
(2),takingcareofpositioning
bushings, spacersandwashersas
shown inthepictureaside(following
thesameorderinwhichtheywere
disassembled).
Afterhavinglubricatedbolt(3),fasten
nut(4)withatighteningtorque
between29.4 and34.3 Nm(from
21.68to25.29lb.-ft.),avoiding
excessiveplayofthehandle
allowingitstilttoanyangle.
Checkthattheupwardand
downwardmovementsoftiller
handlearecorrectandthereisno
free play alongthehorizontalaxle,
enablingtheproperfunctioningof
thedevice.
Applygreasetothescrewshafts
beforetighteningthenuts.
1
2
3
4
CAUTION

Installationmanual
page20of55-ZTF SYSTEM
ENGLISH
ULTRAFLEX
3.6Tillerhandledisassemblyfromoutboardengine
("refitting"installation)
1Removethetillerhandle
fromtheenginearm,taking
careofkeepingtheextracted
nutsandwashers. Checktheir
conditionstogetherwiththe
ringpreventingthenutlock.
Replaceanyevenslightly
damagedcomponents(inthis
case, contactthetechnicalas-
sistance).
Proceedwithassemblingthe
devicefollowingwhatis
reportedinparagraph3.4.
3.7Wiring
Proceedwithconnectingthetillerhandletotheenginecontrols(throttle, shift,ignition,etc.)followingthe
instructionssuppliedby Yamaha®.
