Ultrawave hygea d3ntal Assembly instructions

Operator Instrucon
Manual

THIS PAGE IS INTENTIONALLY BLANK

1
hygea d3ntal Operang Manual
Important Informaon.......................................................... 2
PC Set Up.............................................................................. 6
Machine Set Up - Posioning the hygea d3ntal..................... 7
To Record the Saved Data..................................................... 9
Controls & Indicators............................................................ 11
Connecng to Services.......................................................... 12
Operaon ............................................................................. 13
Degas.................................................................................... 14
Process Locking Lid............................................................... 16
Preparing To Run A Cycle....................................................... 17
During Operaon.................................................................. 18
Successful Compleon of Cycle ............................................. 18
Basket Draining..................................................................... 19
Programming Opons............................................................ 19
Seng the Temperature ........................................................ 20
Seng the Cycle Time........................................................... 20
Seng the Power Level......................................................... 21
Seng the Frequency Leap................................................... 22
Using The Ultrawave Cycle Validaon Soware..................... 28
Periodic Tesng and Validaon.............................................. 32
Specicaons ........................................................................ 33
Dimensions........................................................................... 37
Maintenance / Troubleshoong............................................ 38
Warranty............................................................................... 42
WEEE Compliance................................................................. 42
Returning Equipment to Ultrawave....................................... 43
hygea d3ntal Accessories...................................................... 44
Contents

2
Safety Instrucons
The primary concern of Ultrawave is that this equipment is operated and maintained
with the safety of the paent and sta in mind. To assure safe and reliable operaon:
Read and understand this manual before aempng to install or operate the hygea
d3ntal.
Ensure that the relevant personnel are informed on the contents of this manual.
Equipment Alert
• Always ensure the liquid is above the level sensor when in operaon.
• Do not operate the hygea d3ntal without water and ensure that the bath
contains waterbased soluons before use
• Do not place parts or containers directly on the boom of the cleaning
tank; always use a basket to support items. Failure to comply may cause
damage to the transducers and will void your warranty
• Do not place hands or ngers in the bath. Doing so may cause discomfort
and possible skin irritaon. Avoid contact with soluons
• Do not move the hygea d3ntal when it contains water
• Do not put hot water above 40°C into the hygea d3ntal
• Never use solvents or ammable soluons. Doing so may cause a re or
explosion and will void your warranty
• Do not use mineral acids. These could damage your bath
• Do not use soluons containing chlorine bleach.
• Only a cered service technician should disassemble the hygea d3ntal
should it be needed.
hygea d3ntal Operang Manual
Important Informaon

2 3
Safety Instrucons
Cauon to avoid electrical shock:
Do unplug from power source before lling or emptying the bath.
Do keep the control panel and area around the hygea d3ntal clean and dry –
wipe up any ultrasonic soluon which spills over the tank brim.
Do not operate the ultrasonic cleaner without an earthed mains cable.
Do not immerse the ultrasonic cleaner in water.
Subjecng the hygea d3ntal to improper treatment or misuse will invalidate
the warranty.
The hygea d3ntal is designed and built to minimise electromagnec interference
with other devices. However, if interference is noced between another device and
this product:
Remove interfering device from room.
Plug the hygea d3ntal into an isolated circuit.
Increase separaon between ultrasonic and interfering device.
Contact Ultrawave if interference persists.
hygea d3ntal Operang Manual
Electromagnec Interference

4
Safety Symbols
Danger
Indicates an imminently hazardous situaon which will result in serious or
fatal injury. This symbol is used only in the most extreme condions.
Cauon
Indicates a potenally hazardous situaon which may result in minor or
moderate injury. It may also be used to alert against unsafe pracces.
Equipment Alert
Indicates a potenally hazardous situaon which could result in
equipment damage.
Shipping Symbols
hygea d3ntal Operang Manual
Proper shipping
orientaon
Keep dry
Fragile
REF
Catalogue Number
Date of
Manufacture
SN
Serial Number
Manufacturer

45
Transportaon / Storage Condions
Check your hygea d3ntal and its carton carefully for any internal or external damage. If
you nd damage, contact Ultrawave or your supplier immediately.
hygea d3ntal Operang Manual
Ambient Temperature Range -20°C to +45°C
Relave Humidity 10% to 90% (non-condensing)
Atmospheric Pressure 49.6 kPa to 106.4 kPa
Parts/Accessories Included with the hygea d3ntal QTY
Three Tier Basket Carrier 1
Instrument Cassees 2
Basket Tray 2
Basket Clip 1
Lid 1
Hose Connector 1
Drain Hose 1
Power Cable 1
Quick Guide 1
Sonozyme 3 Sachets 6
Wireless USB Dongle 1
For addional accessories please visit the ultrawave website
www.ultrawave.co.uk
Unpacking Your hygea d3ntal

6
To download the Ultrawave Cycle Validaon Soware for the hygea d3ntal please go
to the URL:
www.ultrawave.co.uk/pages/validaon-soware
Note: Please ensure that you have user rights to install the soware. If not please
contact your network or IT administrator.
1. Click on the download link
2. Once the soware has downloaded click on the .msi le to run and install
Drivers
If the soware does not run correctly please also download the drivers zip le from
the URL above and unpack and install these onto your computer.
PC Set Up
Please check your PC has these minimum system requirements available:
• Windows 7 or above
• 2GB RAM
• USB 2.0 Port
Installing the Ultrawave Cycle Validaon Soware
hygea d3ntal Operang Manual

67
• The hygea d3ntal may be posioned on a table or a counter top and should be
posioned within reach of a standard earthed electrical outlet. The label located
on the back of the hygea d3ntal will idenfy correct power requirements.
• The hygea d3ntal must be posioned no more than 15 metres away from the
wireless USB dongle with direct line of sight in order to ensure the validaon data
can be received.
hygea d3ntal Operang Manual
The hygea d3ntal relies on low power radio waves to transmit
validaon data, therefore it can be suscepble to interference.
Please ensure all radio interference is kept to a minimum within the
vicinity of the unit.
If connecon is interrupted during a cycle then it will backup the
validaon data to the hygea d3ntal’s internal memory. If this occurs
please ensure that connecon is re-established as soon as possible
to ensure records are sent to the PC and no permanent loss occurs.
Machine Set Up - Posioning the hygea d3ntal

8
Posioning the hygea d3ntal (cont)
Please see the below ps for posioning of the hygea d3ntal:
hygea d3ntal Operang Manual

89
2. The hygea d3ntal will then scan and nd the USB Dongle - Please ensure it is no
more than 15 metres away.
3. If the USB is found the following screen will be displayed.
4. If any validaon records are stored within the hygea d3ntal these will then be
transferred to the PC at the end of each cycle.
5. The hygea d3ntal is now ready to use and will store data.
SCANNING FOR
USB DONGLE
USB DONGLE
FOUND
SENDING RECORD
1 OF 1
INITIALISING
COMMUNICATIONS
1. Always ensure the USB dongle is inserted into a PC or tablet prior to turning the
hygea d3ntal power on. Once the power is on please ensure the following screen is
observed:
To Record the Saved Data
hygea d3ntal Operang Manual

10
USB DONGLE
NOT FOUND
Failed Connecon
If a connecon is not found when following steps 1-3 above, the following screen
will be displayed:
hygea d3ntal Operang Manual
If this occurs please refer back to the machine setup secon on page 7.

10 11
Controls & Indicators
The dierent keys perform the following funcons:
KEY 1: Starts and ends the ultrasonic cycle
KEY 2: Menu – Scroll through the menu
KEY 3: Up/On/Yes – Adjust the sengs in the opons menu
KEY 4: Down/O/No – Adjust the sengs in the opons menu
START MENU
KEY 1 KEY 2
KEY 4
KEY 3
hygea d3ntal Operang Manual

12
1. Screw the hose connector into the drain valve at the rear of the hygea d3ntal.
2. Locate the hygea d3ntal close to a drain or sink and within easy reach of a
standard earthed electrical outlet. Do not place on a circuit which could become
overloaded.
3. Connect one end of the drain hose to the hose connector, and locate the other
end over a drain or sink. Cut and shorten hose if required.
4. Connect the power cord into a suitable outlet.
5. Ensure that the power plug and the switch are accessible.
6. Make sure the drain valve is closed.
1. Plug the power cord into the main power connecon located on the back of your
unit
2. Ensure your hygea d3ntal ultrasonic cleaner is plugged into a 240 VAC fully
earthed outlet.
hygea d3ntal Operang Manual
Connecng the Drain Assembly
Connecng the Power Cord
Connecng to Services

12 13
1. Pour cold water into the bath unl the level reaches the ‘FILL TO’ line (A).
2. Add 1 sachet of Sonozyme 3 (B).
3. Place the lid on top of the hygea d3ntal.
4. Turn on the hygea d3ntal via the switch at the rear, just above the power cord.
The switch will then illuminate.
5. Run degas cycle.
Equipment Alert
If the liquid level is too low, i.e below the Fill To line. You will not
be able to run a cycle unl the tank is properly lled. The following
warning will be displayed.
hygea d3ntal Operang Manual
A B
Operaon
Before Operang the hygea d3ntal
FILL TANK 24c
MENU

14
Sonozyme 3 is the recommended detergent to be used with the hygea d3ntal. As
the detergent is an essenal part of the cleaning process a reminder screen will be
displayed each me the liquid falls below the liquid level sensor or when the hygea
d3ntal is switched on.
Note: Selecng NO will not prevent the use of the hygea d3ntal this is purely a
reminder.
hygea d3ntal Operang Manual
• A degas cycle will allow opmum ultrasonic acvity by removing gases present in
the ordinary tap water.
• The me needed to degas the liquid will vary depending on the amount of gas
present in the liquid.
• A degas cycle of 5 to 10 minutes is recommended.
SONOZYME
ADDED?
YES
NO
DEGAS YES
NO
Sonozyme 3
Degas

14 15
hygea d3ntal Operang Manual
DEGASSING
SKIP
1. If the liquid falls below the Liquid Level Sensor, or if new liquid has been added or
changed, the opon to degas your hygea d3ntal will appear.
2. Prior to starng the degas cycle, remove all instruments and make sure the unit is
lled with liquid and the required dose of Sonozyme 3.
3. Place the lid on the hygea d3ntal.
4. Select the < YES key to start the degas cycle. The screen below will display.
5. Wait 5 to 10 minutes.
6. Press the key SKIP to end the degas cycle. Your degas cycle will NOT
automacally stop when degassing has completed.
Running a Degas Cycle

16
• The hygea d3ntal is ed with a lid sensors to prevent cycle interrupon. The
cycle will abort and the operator will be noed should the cycle be interrupt-
ed.
• A cycle cannot be started without the lid in place. The following screen will be
displayed if the lid is not in place.
• Once the lid is in place, the screen will alternate with either of the following
displays giving a water temperature status.
CLOSE LID
MENU
23c
WATER TEMP
TEMP OK
25c
WATER TEMP
HEATING
10c
OR
Process Locking Lid
hygea d3ntal Operang Manual

16 17
Preparing To Run A Cycle
Note: The hygea d3ntal cleaning cycle me has been factory preset to 10 minutes.
Some instruments may take longer or shorter to clean eecvely depending on
the level of contaminaon. To adjust the cycle me refer to ‘adjusng the cycle
me’ secon.
Cauon
Always rinse and inspect your instruments to ensure all debris has been removed
prior to sterilisaon.
Equipment Alert
Heang the water in the bath will aid the cleaning process. When
cleaning surgical instruments, it is recommended to limit the
temperature to 40°C. This will avoid the coagulaon of protein and
other bio burden which could then bake onto the instruments.
hygea d3ntal Operang Manual
START MENU
WATER TEMP
HEATING
10c
WATER TEMP
TEMP OK
25c
1. Place instruments to be cleaned in the three er basket carrier and use the clip
to secure the basket trays.
2. Insert basket carrier into the hygea d3ntal.
3. Check the bath for the required level of water and Sonozyme 3.
4. Place the lid on the hygea d3ntal prior to starng the cycle.
5. The hygea d3ntal is now ready for use. Press the key START to begin the
cleaning cycle.

18
1. On successful compleon of the cycle, the below message will display unl the
operator presses OK.
2. Remove the basket from the bath, rinse and inspect aer cleaning.
3. Your hygea d3ntal remembers the set parameters from the previous cycle. If the
operator wants to run the same cycle press OK. It is not necessary to run through
the menu each me.
4. Your hygea d3ntal is factory set to run a 10 minute cycle.
hygea d3ntal Operang Manual
ABORT
25c10 MINS
• The me set by the operator will be displayed and will count down as the cycle
connues.
• The temperature displayed is the actual liquid temperature and the default is 25°C,
if ashing this indicates the liquid is heang up.
• The operator can abort the cycle at any me by pressing the key ABORT.
• If the temperature reaches 50°C the hygea d3ntal is too hot. The hygea d3ntal will
automacally abort the cycle and you will receive an ABORT - OVER TEMP message.
(refer to the troubleshoong).
OK
CYCLE COMPLETE
During Operaon
Successful Compleon of Cycle
