Uniden G14xx Series User manual

Accessory Camera for G14xx Series
Surveillance Systems
What’s in the Box?
1 x Camera
1 x Antenna
1 x Stand
1 x AC Adaptor
Screws and Anchors
1
5
6
7
2
3
4
8
FRONT BACK
9
10
Outdoor Camera

2
No Keys/Indicators Function
1Camera Antenna Sends signals to the monitor.
2Light sensor Measures light intensity to activate
IR LEDs for night vision.
3Microphone Receives sounds from the area
near the camera
4PIR sensor Detects motion within camera’s
line of sight.
5Camera Lens Mechanism through which the
camera views surroundings and
records images.
6Infrared LED Infrared LEDs provide viewing in
no/low light conditions.
7Pair Press this button to pair the cam-
era to the monitor.
8Camera stand Connects to the camera to allow
multiple mounting positions.
9Speaker Transmits sound from the monitor
(intercom).
10 Power Input (9V
DC)
Connect to power adaptor.

3
Installing the Camera
You can mount the camera with the stand on the bottom (for a flat
surface such as a tabletop), on the side (for a wall), or on the top (for the
ceiling).
The following tools are required:
• Electric Drill
• 5mm Drill Bit
• No. 2 Phillips Screwdriver
Mount the Camera Base
1. Hold the base of the camera stand where you want to mount
it and mark the location of the screw holes.
2. Drill holes using the 5mm drill bit.
3. Insert anchors.
4. Use the included screws to attach the base to the wall or
ceiling. You can also screw the base into a flat surface such as
a tabletop if needed.
Before attaching the camera, tug gently on the stand to make
sure it is securely in place.
When you are positioning the camera, you might want to bring the
monitor along; it’s much easier to get the camera into the right position
when you have the monitor handy.

4
Attach the Camera
1. For each camera, attach the camera bracket to the mounting
screw. You can attach the stand to the top or the bottom of
the camera as needed. Tighten it a few turns, then turn the
camera to face the direction you want.
2. Tighten the camera brace up against the camera to secure it
into place.
3. Unlock the mounting post by turning the wingnut a few turns
to the left.
4. Set the mounting post to the correct angle, then tighten the
wingnut until the post is locked into place.
5. Attach the antenna to the rear of the camera.
1
2
4
3
Loosen the
wingnut to
unlock the
mounting
post.
Attach the camera
to the mounting
screw and turn it
to the desired
direction.
Adjust the post to
the correct angle,
then tighten the
wingnut to lock the
post into place.
Tighten the brace against
the camera to
secure it
in place.

5
Power Up the Camera
Connect one end of a DC 9V AC adaptor to the camera’s power
pigtail and plug the other end into a 240 volt AC (standard
indoor) power outlet.
Adjust the camera viewing position, if needed.
If... Try...
there is no camera
Verify that the power supply adaptor for
the camera(s) is plugged in.
the picture quality
is poor
Clean the camera lens.
a white image ap-
pears at night
The camera’s infra-red LED shines due to
the invisible light that reects o surfaces
such as glass, causing white light. Place
the camera on the other side of windows
with the lens side ush against the sur-
face to improve the night vision, or place
the camera in a well-lit area.
Night Vision
This camera has built-in IR LEDs, which provides the camera
with the ability to view images in no/low light conditions. It is
important to use the provided power adaptor (and not the bat-
teries) when using the camera for prolonged periods in low light
conditions.

6
Pairing Accessory Cameras
If you add cameras, install them and then pair the camera to the
monitor.
1. Press MENU/OK on the Monitor, to bring up the System Menu
screen.
2. Select the Camera option.
3. Select Pair and then press MENU/OK. The Pair screen displays.
The pairing function assigns each camera to a different
channel on the wireless monitor (up to 4 cameras), and is
necessary for configuring additional cameras.
4. Select the channel you want to pair the camera to and press
MENU/OK. The Press Pair Key message screen displays.
5. Within 30 seconds, press the Pair button located on the
camera. Once the camera pairs to the monitor, you can view
the camera transmissions on the monitor.
When you add a new camera to your system, you have to pair
it to the monitor (that is, you have“introduce” the camera and
monitor so they can communicate).
For more details on the G14xx Surveillance System,
please refer to the G14xx Series Owner’s Manual.

7
Operating frequency range 2.400 ~ 2.4835GHz
TX power 15dBm (typical)
Spread spectrum FHSS
Modulation type GFSK
Data Rate 2 Mbps
Communication range 150ms Line of Sight
Image sensor type
(Manufacturer/Model #)
1/4” color CMOS image sensor
Eective pixel H: 640; V: 480
Image processing MJPEG
Image resolution 640x480 @ 10fps
320x240 @ 20fps
Lens 3.6mm F2.0
Exposure Auto
White balance Auto
Power requirement 9.0Vdc ± 5%
Power consumption 160mA (IR LED O)
350mA (IR LED On)
Operating temp range –10 ~ 50° C
Weatherproof IP65
RoHS Compliance Yes
Camera Housing Material Plastic
SPECIFICATION

8
G1400
IMPORTANT: Satisfactory evidence of the original purchase is
required for warranty service
Please refer to our Uniden website for any details or warranty durations
offered in addition to those contained below.
Warrantor: The warrantor is either Uniden Australia Pty Limited ABN 58 001
865 498 (“Uniden Aust”) or Uniden New Zealand Limited (“Uniden NZ”) as the
case may be.
Terms of Warranty: Uniden Aust/NZ warrants to the original retail purchaser
only that the G1400 (“the Product”), will be free from defects in materials and
craftsmanship for the duration of the warranty period, subject to the limitations
and exclusions set out below.
Warranty period: This warranty to the original retail purchaser is only valid
in the original country of purchase for a Product rst purchased either in
Australia or New Zealand and will expire one (1) year from the date of the
original retail sale.
If a warranty claim is made, this warranty will not apply if the Product is found
by Uniden to be:
A. Damaged or not maintained in a reasonable manner or as recommended in
the relevant Uniden Owner’s Manual;
B. Modified, altered or used as part of any conversion kits, subassemblies or any
configurations not sold by Uniden Aust or Uniden NZ;
C. Improperly installed contrary to instructions contained in the relevant
Owner’s Manual
D. Repaired by someone other than an authorized Uniden Repair Agent in
relation to a defect or malfunction covered by this warranty; or
E. Used in conjunction with any equipment, parts or a system not manufactured
by Uniden.
Parts Covered: This warranty covers the Product and included accessories.
User-generated Data: This warranty does not cover any claimed loss of
or damage to user-generated data (including but without limitation phone
numbers, addresses and images) that may be stored on your Product.
ONE YEAR LIMITED WARRANTY

9
Statement of Remedy: If the Product is found not to conform to this warranty
as stated above, the Warrantor, at its discretion, will either repair the defect
or replace the Product without any charge for parts or service. This warranty
does not include any reimbursement or payment of any consequential
damages claimed to arise from a Product’s failure to comply with the
warranty.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
This warranty is in addition to and sits alongside your rights under either the
COMPETITION AND CONSUMER ACT 2010 (Australia) or the CONSUMER
GUARANTEES ACT (New Zealand) as the case may be, none of which can
be excluded.
Procedure for obtaining warranty service: Depending on the country in
which the Product was rst purchased, if you believe that your Product does
not conform with this warranty, you should deliver the Product, together with
satisfactory evidence of your original purchase (such as a legible copy of the
sales docket) to Uniden at the addresses shown below. You should contact
Uniden regarding any compensation that may be payable for your expenses
incurred in making a warranty claim. Prior to delivery, we recommend that you
make a backup copy of any phone numbers, images or other data stored on
your Product, in case it is lost or damaged during warranty service.
UNIDEN NEW ZEALAND LTD
Service Division
150 Harris Road, East Tamaki
Auckland 2013
Phone: [phone]
Email: [email protected]
UNIDEN AUSTRALIA PTY LTD
Service Division
345 Princes Highway,
Rockdale, NSW 2216
Phone: [phone]
Email: [email protected]

10

11

© 2013 Uniden Australia Pty Limited. Uniden New Zealand Limited.
Printed in PRC.
